COMBINATION METERS
Revision: 2006 November2007 350Z
COMBINATION METERSPFP:24814
System DescriptionNKS0005S
UNIFIED METER CONTROL UNIT

Speedometer, odo/trip meter, tachometer, fuel gauge and water temperature gauge are controlled by the
unified meter control unit, which is built into the combination meter. Unified meter control unit receives a
signals from unified meter and A/C amp.

Warning lamp and indicator lamp of combination meter are controlled by signals drawn from the unified
meter and A/C amp.

Odo/trip meter and A/T indicator segments can be checked in self-diagnosis mode.

Meters/gauges can be checked in self-diagnosis mode.
UNIFIED METER AND A/C AMP.
Refer to DI-44, "COMBINATION METER CONTROL FUNCTION" in “UNIFIED METER AND A/C AMP”.
POWER SUPPLY AND GROUND CIRCUIT
Power is supplied at all times

through 10A fuse [No. 19, located in the fuse block (J/B)]

to combination meter terminal 24.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 14, located in the fuse block (J/B)]

to combination meter terminal 23.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 6, located in the fuse block (J/B)]

to combination meter terminal 14.
Ground is supplied

to combination meter terminals 10, 11 and 12

through body grounds M30 and M66.
SPEEDOMETER

VDC/TCS/ABS control unit [with VDC] or ABS actuator and electric unit (control unit) [without VDC] pro-
vides a vehicle speed signal to the unified meter and A/C amp. with CAN communication line.

Unified meter and A/C amp. converts the vehicle speed signal to the 8-pulse signal, and outputs the vehi-
cle speed signal (8-pulse) to combination meter.

Combination meter indicates the vehicle speed according to vehicle speed signal (8-pulse).
PKIC4371E

COMBINATION METERS
DI-17
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
Power Supply and Ground Circuit InspectionNKS00064
1. CHECK FUSE
Check for blown combination meter fuses.
OK or NG
OK >> GO TO 2.
NG >> Be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-4, "
POWER
SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between combination meter harness connector M19
terminals 24, 23, 14 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness between combination meter and fuse.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between combination meter harness connector
M19 terminals 10, 11, 12 and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
Power source Fuse No.
Battery 19
Ignition switch ACC or ON 6
Ignition switch ON or START 14
Terminals Ignition switch position
(+)
(–) OFF ACC ON
ConnectorTerminal
(Wire color)
M1924
GroundBattery
voltageBattery
voltageBattery
voltage
23 0 V 0 VBattery
voltage
14 0 VBattery
voltageBattery
voltage
SKIB1153E
10 – Ground
: Continuity should exist. 11 – Ground
12 – Ground
SKIA8715E

DI-26
TRIPLE METERS
Revision: 2006 November2007 350Z
TRIPLE METERSPFP:24845
System DescriptionNKS0006F
TRIPLE METER

Oil pressure gauge and voltmeter are controlled by the triple
meter.

Trip computer is controlled by the signals from the unified meter
and A/C amp.

Triple meter operation can be checked with self-diagnosis mode
of combination meter.
UNIFIED METER AND A/C AMP.
Refer to DI-45, "TRIPLE METER CONTROL FUNCTION" in “UNIFIED METER AND A/C AMP”.
POWER SUPPLY AND GROUND CIRCUIT
Power is supplied at all times

through 10A fuse [No. 19, located in the fuse block (J/B)]

to triple meter terminal 2.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 14, located in the fuse block (J/B)]

to triple meter terminal 3.
Ground is supplied

to triple meter terminal 1

through grounds M30 and M66.
VOLTMETER
When ignition switch is turned to the ON position, the voltmeter indicates the battery voltage.
OIL PRESSURE GAUGE
With the ignition switch in the ON or START position, power is supplied

through triple meter terminal 9

to oil pressure sensor terminal 1.
Ground is supplied

to triple meter terminal 7

through oil pressure sensor terminal 3.
And triple meter reads oil pressure signal from oil pressure sensor

from oil pressure sensor terminal 2

to triple meter terminal 8.
NOTE:

Triple meter judges an oil pressure condition by oil pressure signal, and transmits oil pressure warning
lamp signal to combination meter through unified meter and A/C amp. with communication line.

Oil pressure gauge is not designed to indicate the low oil level. Use the oil level gauge to check the oil
level.
SKIA7097E

UNIFIED METER AND A/C AMP
DI-49
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
Power Supply and Ground Circuit InspectionNKS001M5
1. CHECK FUSE
Check for blown fuses.
OK or NG
OK >> GO TO 2.
NG >> Be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-4, "
POWER
SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between unified meter and A/C amp. harness con-
nector terminals and ground.
OK or NG
OK >> GO TO 3.
NG >> Check harness between unified meter and A/C amp. and fuse.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between unified meter and A/C amp. harness
connector and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
Power source Fuse No.
Battery 19
Ignition switch ACC or ON 10,11
Ignition switch ON or START 12
Terminals Ignition switch position
(+)
(–) OFF ACC ON
Connector Terminal
M49 21
GroundBattery
voltageBattery
voltageBattery
voltage
M50 46 0 VBattery
voltageBattery
voltage
M49 22 0 V 0 VBattery
voltage
SKIB1154E
Connector Terminal
GroundContinuity
M4929
Ye s
30
SKIA5202E

WARNING CHIME
DI-81
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
Terminals and Reference Value for Unified Meter and A/C Amp. NKS0007L
Terminals and Reference Value for Combination MeterNKS0007M
37 B/RKey switch
signalOFFKey is removed. 0 V
Key is inserted. 12 V
38 W/LIgnition
power supplyON — Battery voltage
39 L CAN-H — — —
40 P CAN-L — — —
42 GYBattery
power sup-
ply (FUSE)OFF — Battery voltage
52 B Ground ON — 0 V
55 RBattery
power sup-
ply (F/L)OFF — Battery voltage
62 LDriver side
door switch
signalOFFDoor switch is released. (Door switch ON) 0 V
Door switch is pressed. (Door switch OFF) 5 V Terminal
No.Wire
colorSignal nameMeasuring condition
Reference value
(Approx.) Igni-
tion
switchOperation or condition
Terminal
No.Wire
colorItemMeasuring condition
Reference value
(Approx.) Ignition
switchOperation or condition
1 L CAN-H OFF — —
9L/ORTX communication line
(To combination meter)ON —
11 P C A N - L O F F — —
19 R/GRX communication line
(From combination meter)ON —
21 R/W Battery power supply OFF — Battery voltage
22 Y/G Ignition power supply ON — Battery voltage
29 B Ground (POWER) ON — 0 V
30 B Ground ON — 0 V
SKIA3362E
SKIA3361E
Te r m i -
nal No.Wire
colorItem Measuring condition
Reference value
(Approx.) Ignition
switchOperation or condition
1 BR/Y Seat belt buckle switch (Driver side) ONSeat belt is unfastened. 0 V
Seat belt is fastened. 5 V

DI-84
WARNING CHIME
Revision: 2006 November2007 350Z
PRELIMINARY INSPECTION
1. CHECK BCM (CONSULT-III)
Perform self-diagnosis of BCM. Refer to BCS-15, "
CONSULT-III Function (BCM)" .
Self
-diagnostic results
No malfunction detected>> GO TO 2.
Malfunction detected>> Check applicable parts, and repair or replace corresponding parts.
2. CHECK UNIFIED METER AND A/C AMP. (CONSULT-III)
Perform self-diagnosis of unified meter and A/C amp. Refer to DI-47, "
CONSULT-III Function (METER A/C
AMP)" .
Self
-diagnostic results
No malfunction detected>> INSPECTION END
Malfunction detected>> Check applicable parts, and repair or replace corresponding parts.
Symptom ChartNKS00268
Power Supply and Ground Circuit InspectionNKS00269
1. CHECK FUSE AND FUSIBLE LINK
Check for blown BCM fuse and fusible link.
OK or NG
OK >> GO TO 2.
NG >> Be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-4, "
POWER
SUPPLY ROUTING CIRCUIT" .
Symptom Diagnoses/Service procedure
All warning chimes do not activate.Perform the following inspections.
1.DI-84, "
Power Supply and Ground Circuit Inspection".
2.DI-85, "
Meter Buzzer Circuit Inspection".
Replace BCM, found normal function in the above inspections.
Ignition key warning chime does not activate.Perform the following inspections.
1.DI-87, "
Key Switch Signal Inspection".
2.DI-86, "
Driver Side Door Switch Signal Inspection".
Replace BCM, found normal function in the above inspection.
Light warning chime does not activate.Perform the following inspections.
1.DI-88, "
Lighting Switch Signal Inspection".
2.DI-86, "
Driver Side Door Switch Signal Inspection".
Replace BCM, found normal function in the above inspection.
Seat belt warning chime does not activate.Perform DI-88, "
Seat Belt Buckle Switch (Driver Side) Signal
Inspection" .
Replace BCM, found normal function in the above inspection.
Unit Power source Fuse and fusible link No.
BCMBatteryF
18
Ignition switch ON or START 1

WARNING CHIME
DI-85
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between BCM harness connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness between BCM and fuse.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector M91 terminal
52 and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
Meter Buzzer Circuit InspectionNKS0026F
1. CHECK OPERATION OF METER BUZZER
1. Select “BUZZER” of “BCM” on CONSULT-III.
2. Perform “LIGHT WARN ALM”, “IGN KEY WARN ALM” or “SEAT BELT WARN ALM” of “ACTIVE TEST”.
Does meter buzzer beep?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “METER A/C AMP” on CONSULT-III.
2. With “DATA MONITOR”, confirm “BUZZER” under the condition of buzzer input. (Seat belt warning chime,
turn signal lamp operate, etc.)
OK or NG
OK >> Replace combination meter.
NG >> Replace BCM. Refer to BCS-17, "
Removal and Installation of BCM" .
Terminals Ignition switch position
(+)
(–) OFF ON
ConnectorTerminal
(Wire color)
M9142
GroundBattery voltage Battery voltage
55
M90 38 0 V Battery voltage
SKIB2802E
52 – Ground : Continuity should exist.
SKIA9667E
“BUZZER”
Under the condition of buzzer input : ON
Except above : OFF

WARNING CHIME
DI-87
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2006 November2007 350Z
3. CHECK DRIVER SIDE DOOR SWITCH
Check driver side door switch. Refer to DI-90, "
DRIVER SIDE DOOR SWITCH" .
OK or NG
OK >> Replace BCM. Refer to BCS-17, "Removal and Installation of BCM" .
NG >> Replace driver side door switch.
Key Switch Signal InspectionNKS0026B
1. CHECK FUSE
Check if the key switch 10A fuse [No. 21, located in the fuse block (J/B)] is blown.
OK or NG
OK >> GO TO 2.
NG >> Be sure to repair the cause of malfunction before installing new fuse. Refer to PG-4, "
POWER
SUPPLY ROUTING CIRCUIT" .
2. CHECK BCM INPUT SIGNAL
With CONSULT-llI
1. Select “BCM”.
2. With “DATA MONITOR” of “BUZZER”, confirm “KEY ON SW” when the key switch is operated.
Without CONSULT-llI
Check voltage between BCM harness connector M90 terminal 37
and ground.
OK or NG
OK >> INSPECTION END
NG >> GO TO 3.
3. CHECK KEY SWITCH
Check continuity between key switch. Refer to DI-90, "
Component Inspection" .
OK or NG
OK >> GO TO 4.
NG >> Replace key switch.“KEY ON SW”
When key is inserted to ignition key cylinder : ON
When key is removed from ignition key cylinder : OFF
37 – Ground
When key is inserted to
ignition key cylinder: Approx. 12 V
When key is removed from
ignition key cylinder: Approx. 0 V
SKIA5048E
