Page 4 of 54
BR-4
PRECAUTIONS
Revision: 2006 November2007 350Z
Use flare nut crowfoot and torque wrench when removing and
installing brake tube.
When installing brake piping, be sure to check torque.
Before working, turn the ignition switch OFF and disconnect the
connectors of ABS actuator and control unit or the battery nega-
tive terminal.
Burnish the brake contact surfaces after refinishing or replacing
drums or rotors, after replacing pads or linings, or if a soft pedal
occurs at very low mileage.
Refer to BR-38, "
Brake Burnishing Procedure" .
WARNING:
Clean brake pads and shoes with a waste cloth, then wipe with a dust collector.SBR686C
Page 10 of 54

BR-10
BRAKE FLUID
Revision: 2006 November2007 350Z
BRAKE FLUIDPFP:KN100
On-Vehicle InspectionNFS00008
LEVEL CHECK
Check that the fluid level in the reservoir tank is within the stan-
dard (between MAX and MIN lines).
Visually check around the reservoir tank for fluid leaks.
If fluid level is excessively low, check brake system for leaks.
If warning lamp remains illuminated after parking lever is
released, check brake system for fluid leakage.
Drain and RefillNFS00009
CAUTION:
Refill with new brake fluid “DOT3”.
Do not reuse drained brake fluid.
Do not let brake fluid come in contact with painted surfaces on the body. This might damage the
paint, so if it does come in contact, immediately wipe area and wash off with water.
1. Connect a vinyl tube to bleed valve.
2. Depress the brake pedal, loosen the bleed valve, and gradually
remove the brake fluid.
3. Before working, turn the ignition switch OFF and disconnect the
connectors of ABS actuator and control unit or battery negative
terminal.
4. Make sure there is no foreign material in the reservoir tank, and
refill with new brake fluid.
5. Rest foot on brake pedal. Loosen bleed valve. Slowly depress
pedal until it stops. Tighten bleed valve. Release brake pedal.
Repeat this process a few times, then pause to add new brake
fluid to master cylinder. Continue until new brake fluid flows out.
Bleed Air. Refer to BR-11, "
Bleeding Brake System" .
SBR451D
BRA0007D
BRA0006D
Page 11 of 54
BRAKE FLUID
BR-11
C
D
E
G
H
I
J
K
L
MA
B
BR
Revision: 2006 November2007 350Z
Bleeding Brake SystemNFS0000A
CAUTION:
While bleeding, pay attention to master cylinder fluid level.
1. Before working, turn the ignition switch OFF and disconnect the connectors of ABS actuator and control
unit or battery negative terminal.
2. Connect a vinyl tube to the rear right bleed valve.
3. Fully depress brake pedal 4 to 5 times.
4. With the brake pedal depressed, loosen the bleed valve to let the air out, and then tighten it immediately.
5. Repeat steps 3, 4 until no more air comes out.
6. Tighten the bleed valve to the specified torque. Refer to BR-27, "
Components" (Front) and BR-40, "Com-
ponents" (Rear).
7. In steps 2 to 6 below, with the master cylinder reservoir tank filled at least half way, bleed air from the front
left, rear left, and front right tires, in that order.
