Installation
CAUTION:
After completing installation, check A/T fluid leakage and A/T fluid level. Refer to AT- 1 2 , "
Checking A/T
Fluid" .
1. Install A/T fluid temperature sensor 2 to bracket.
2. Install A/T fluid temperature sensor 2 (with bracket) in control
valve with TCM, and then tighten A/T fluid temperature sensor 2
bolt to the specified torque. Refer to AT- 2 1 5 , "
COMPONENTS" .
3. Connect A/T fluid temperature sensor 2 connector (1).
4. Securely fasten A/T fluid temperature sensor 2 harness with ter-
minal clip ( ).
5. Install oil pan to transmission case.
a. Install oil pan gasket to oil pan.
CAUTION:
Do not reuse oil pan gasket.
Install it in the direction to align hole positions.
Complete remove all moisture, oil and old gasket, etc. from oil pan gasket mounting surface.
b. Install oil pan (2) (with oil pan gasket) and clips (1) to transmis-
sion case.
: Vehicle front
: Oil pan mounting bolt
CAUTION:
Install it so that drain plug (3) comes to the position as
shown in the figure.
Be careful not to pinch harness.
SCIA5264E
SCIA5302E
SCIA8076E
SCIA8117E
Page 226 of 312

AT-226
ON-VEHICLE SERVICE
Revision: 2006 November2007 350Z
Complete remove all moisture, oil and old gasket, etc. from oil pan mounting surface.
c. Tighten oil pan mounting bolts to the specified torque in numeri-
cal order shown in the figure after temporarily tightening them.
Refer to AT- 2 1 5 , "
COMPONENTS" .
CAUTION:
Do not reuse oil pan mounting bolts.
6. Install drain plug gasket and drain plug to oil pan, and then
tighten drain plug to the specified torque. Refer to AT- 2 1 5 ,
"COMPONENTS" .
CAUTION:
Do not reuse drain plug gasket.
7. Install bracket (2) from transmission assembly. Refer to AT- 2 1 5 ,
"COMPONENTS" .
: Vehicle front
: Bolt
8. Install heated oxygen sensor 2 harness (B) from clips (1).
9. Connect heated oxygen sensor 2 harness connectors (A).
10. Install exhaust mounting bracket. Refer to EX-3, "
Removal and
Installation" .
11. Pour ATF into A/T assembly. Refer to AT- 1 2 , "
Changing A/T
Fluid" .
12. Connect the battery cable to the negative terminal.
SCIA4113E
SCIA8269E
Page 227 of 312

ON-VEHICLE SERVICE
AT-227
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
Parking ComponentsNCS00093
COMPONENTS
REMOVAL
1. Drain ATF through drain hole.
2. Remove exhaust front tube and center muffler with power tool. Refer to EX-3, "
Removal and Installation" .
3. Remove rear propeller shaft. Refer to PR-6, "
Removal and Installation" .
CAUTION:
Do not impact or damage propeller shaft tube.
4. Remove control rod. Refer to AT- 2 0 5 , "
Control Rod Removal and Installation" .
5. Support A/T assembly with a transmission jack.
CAUTION:
When setting transmission jack, be careful not to allow it to collide against drain plug.
6. Remove rear engine mounting member with power tool. Refer to AT- 2 4 2 , "
Removal and Installation" .
1. Rear oil seal 2. Rear extension 3. Parking actuator support
4. Return spring 5. Parking pawl 6. Pawl shaft
7. Self-sealing bolt 8. Seal ring 9. Parking gear
10. Output shaft 11. Bearing race 12. Needle bearing
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-11, "
Components" .
However, refer to the following for others.
*: Apply Genuine Anaerobic Liquid Gasket or equivalent. Refer to GI-45, "Recommended Chemical Products and Sealants" .
SCIA7030E
Page 228 of 312
AT-228
ON-VEHICLE SERVICE
Revision: 2006 November2007 350Z
7. Remove tightening bolts for rear extension assembly and trans-
mission case.
8. Tap rear extension assembly with soft hammer.
9. Remove rear extension assembly from transmission case. (With
needle bearing.)
10. Remove bearing race from output shaft.
11. Remove output shaft from transmission case by rotating left/
right.
SCIA6941E
SCIA3432E
SCIA3431E
SCIA5245E
SCIA5246E
Page 229 of 312
ON-VEHICLE SERVICE
AT-229
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
12. Remove parking gear from output shaft.
13. Remove seal rings from output shaft.
14. Remove needle bearing (1) from rear extension.
15. Remove parking actuator support from rear extension.
16. Remove parking pawl (with return spring) and pawl shaft from
rear extension.
SCIA5247E
SCIA5209E
SCIA6179J
SCIA3423E
SCIA3424E
Page 230 of 312
AT-230
ON-VEHICLE SERVICE
Revision: 2006 November2007 350Z
17. Remove return spring (1) from parking pawl (2).
18. Remove rear oil seal from rear extension.
CAUTION:
Be careful not to scratch rear extension.
INSPECTION
If the contact surface on parking actuator support, parking pawl,
etc. has excessive wear, abrasion, bend, or any other damage,
replace the components.
SCIA6180J
SCIA3524E
SCIA5143E
SCIA5144E
Page 231 of 312
ON-VEHICLE SERVICE
AT-231
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
INSTALLATION
CAUTION:
After completing installation, check A/T position, A/T fluid leakage and A/T fluid level. Refer to AT- 2 0 6 ,
"Checking of A/T Position" , AT- 1 2 , "Checking A/T Fluid" .
1. As shown in the figure, use a drift to drive rear oil seal into the
rear extension until it is flush.
CAUTION:
Do not reuse rear oil seal.
Apply ATF to rear oil seal.
2. Install return spring (1) to parking pawl (2).
3. Install parking pawl (with return spring) and pawl shaft to rear
extension.
4. Install parking actuator support to rear extension.
SCIA5311E
SCIA6180J
SCIA3424E
SCIA3423E
Page 232 of 312
AT-232
ON-VEHICLE SERVICE
Revision: 2006 November2007 350Z
5. Install needle bearing (1) to rear extension.
