27 At a glance
Cockpit
Item
Page
1
Combination switch

Turn signals


Windshield wipers


High beam


Cornering lamps
362
351
346
347
2
Lever for

Cruise control


DISTRONIC Plus*
380
385
3
Horn
4
Multifunction steering wheel
242
5
Instrument cluster
28
6
Steering wheel gearshift con-
trol
375
7
Gear selector lever for
automatic transmission
359
Item
Page
8
Control panel with

Front passenger front
air bag indicator lamp


Vehicle level control
switch


Electronic Stability Pro-
gram (ESP
®) switch


Parktronic*/Park Assist*
deactivation switch


Swivel COMAND display


COMAND/instrument
cluster illumination
53
401,
403
73
408,
408
81
378
9
COMAND display
79
a
Overhead control panel
37
b
Automatic climate control
Center console, upper part
424
32
Item
Page
c
Glove box lock
448
d
Cover of compartment with

CD changer


PCMCIA card slot
107
108
e
Center console, lower part
33
f
Starter switch
KEYLESS-GO* start/stop but-
ton
315
316
g
Steering wheel adjustment
Heated steering wheel*
330
331
h
Headlamp washer button
346
j
Parking brake
364
k
Hood lock release
492
l
Door control panel
39
m
Night View Assist*
420
n
Exterior lamp switch
342

54 Safety and SecurityOccupant safety
Self-test Occupant Classification Sys-
tem
After turning the SmartKey in the starter
switch to position1 or2 or pressing the
KEYLESS-GO* start/stop button once or
twice (
page 317), the 59
indicator lamp1 located in the center
console illuminates. If an adult occupant is
properly sitting on the front passenger
seat and the system senses the occupant
as being an adult, the 59 indi-
cator lamp will illuminate and go out after
approximately 6 seconds.
If the seat is not occupied and the system
senses the front passenger seat as being
empty, the 59indicator lamp
will illuminate and not go out.
Warning!
G
If the =indicator lamp and the
59 indicator lamp are lit at the
same time, there is a malfunction in the
Occupant Classification System. The front
passenger front air bag will be deactivated
in this case.
In order to ensure proper operation of the
air bag system and OCS:

Have the system checked as soon as
possible by qualified technicians.
Contact an authorized Mercedes-Benz
Center.


Do not place more than 4.4 lbs (2 kg)
into the ruffled storage bag on the back
of the front passenger seat. Otherwise,
the OCS may not be able to properly
approximate the occupant weight
category.


Do not place objects under and/or
around the front passenger seat.


Do not hang anything from or attach any
items to the seats.


Do not stuff objects such as books be-
tween the middle console and the front
passenger seat.


Do not move the front passenger seat
backwards against stiff objects.


Sit properly belted in a nearly upright
position with your back against the seat
backrest.


Do not lean on the armrests or lift your-
self from the seat by using the handle
over the door as this may cause the OCS
to be unable to correctly approximate
the occupant weight category.


Only have the seat repaired or replaced
by an authorized Mercedes-Benz Cen-
ter.


Read and observe all warnings in this
chapter.
Warning!
G
If the 59indicator lamp should
not illuminate, the system is not functioning.
You must see an authorized Mercedes-Benz
Center before seating any child on the front
passenger seat.

55 Safety and Security
Occupant safety
For more information, see the “Practical
hints” section (
page 555).
Seat belts
When the engine is started, the seat belt
telltale< illuminates for a maximum of
6 seconds and a warning chime sounds to
remind you and your passengers to fasten
your seat belts.
If after these 6 seconds, the driver’s or the
front passenger’s seat belt (with the front
passenger seat occupied) are not fastened
with all doors closed,

and the vehicle speed does not exceed
15 mph (25 km/h), the seat belt
telltale< remains illuminated for as
long as either the driver’s or front
passenger’s seat belt is not fastened.


and the vehicle speed exceeds
15 mph (25 km/h), the seat belt
telltale< starts flashing and a
warning chime sounds with increasing
intensity until both the driver’s and
front passenger’s seat belt are fas-
tened, or for a maximum of 60 seconds
from the time the vehicle speed exceeded 15 mph (25 km/h) if either
the driver’s or front passenger’s seat
belt remains unfastened.
If the driver’s or front passenger’s seat
belt remains unfastened after
60 seconds, the seat belt telltale<
stops flashing and the warning chime
stops sounding. The seat belt
telltale< then continues to be illu-
minated for as long as either the driv-
er’s or front passenger’s seat belt are
not fastened.
The seat belt telltale< will only go out
if both the driver’s and the front passen-
ger’s seat belt (with the front passenger
seat occupied) are fastened, or the vehicle
is standing still and a front door is opened.
For more information, see “Practical hints”
(
page 550).
Always wear your seat belt. All vehicle
occupants always need to have their seat
belts fastened and wear them properly.
Warning!
G
Never place anything between seat cushion
(e.g. pillow), since it reduces the effective-
ness of the Occupant Classification System.
The bottom of the child seat must make full
contact with the passenger seat cushion. An
incorrectly mounted child seat could cause
injuries to the child in case of an accident,
instead of increasing protection for the
child.
Follow the manufacturer’s instructions for
installation of child seats.

68 Safety and SecurityPanic alarm1Â button
Activating
Press and hold  button for at least
1 second.
An audible alarm and flashing exterior
lamps will operate briefly.
Deactivating
Press  button again.
or

Insert the SmartKey or the SmartKey
with KEYLESS-GO* in starter switch.
or

Press the KEYLESS-GO* start/stop
button (
page 317).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.

73 Safety and Security
Driving safety systems
For more information, see “Practical hints”
section (
page 549) and (
page 582).
ETS
The Electronic Traction System is a compo-
nent of ESP
®.
The Electronic Traction System (ETS) im-
proves the vehicle’s ability to utilize avail-
able traction, especially under slippery road conditions. The brakes are applied to
the spinning wheel and power is trans-
ferred to the wheel(s) with traction.
The ESP
® warning lampvin the instru-
ment cluster starts to flash at any vehicle
speed, as soon as a tire loses traction and
the wheel begins to spin.
When you switch off the ESP
®, the ETS is
still enabled.Switching off the ESP
®
To improve the vehicle’s traction, turn off
the ESP
® in driving situations where it
would be advantageous to have the drive
wheels spin and thus cut into surfaces for
better grip such as:


when driving with snow chains


in deep snow


in sand or gravel
i
The ESP
® will only function properly if you
use wheels of the recommended tire size
(
page 655).
!
Because of the ESP’s
® automatic operation,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO start/stop button* in position0
or1) when


the parking brake is being tested on a brake
test dynamometer


the vehicle is being towed with the
front/rear axle raised
Active braking action through the ESP
® may oth-
erwise seriously damage the brake system.
Warning!
G
If you are driving too fast, the Electronic
Traction System cannot reduce the risk of
an accident.
The ETS cannot prevent the natural laws of
physics from acting on the vehicle.i
If the yellow ESP
® warning lampv
comes on while driving, the ETS is being
switched off temporarily to prevent overheating
of the drive wheel brakes. In addition, the mes-
sage “ESP Currently unavailable See Oper. Man-
ual” appears in the multifunction display.
Warning!
G
The ESP
® should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
!
Turn the ESP
® on immediately if the afore-
mentioned circumstances do not apply anymore.
i
DISTRONIC Plus* cannot be activated when
the ESP
® has been switched off.

76 Safety and SecurityAnti-theft systems
Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
The turn signal lamps flash once to in-
dicate that the alarm system is dis-
armed.
Tow-away alarm
Once the tow-away alarm is armed, a visual
and audible alarm will be triggered when
someone attempts to raise the vehicle.
To cancel the alarm after it has been trig-
gered, see “Canceling the alarm”
(page 76).

Arming: Lock your vehicle with the
SmartKey or KEYLESS-GO*.
The tow-away alarm is automatically
armed after about 30 seconds.

Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
To prevent triggering the tow-away alarm
feature, switch off the tow-away alarm be-
fore towing the vehicle, or when parking on
a surface subject to movement, such as a
ferry or auto train. To switch off the tow-away alarm, see
“Switching on/of the tow-away alarm”
(
page 228).
Canceling the alarm
To cancel the alarm, do one of the follow-
ing:
Insert the SmartKey in the starter
switch.

Press the Œ or ‹ button on the
SmartKey.
In vehicles with KEYLESS-GO*:

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft. (1 m) of the vehicle.

Press the KEYLESS-GO start/stop but-
ton (
page 317).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
i
If the turn signal lamps does not flash three
times one of the following elements may not be
properly closed:


a door


the trunk
Close the respective element and lock the vehi-
cle again.
i
The alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.
i
If the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 462) provided Tele Aid service was sub-
scribed to and properly activated and that neces-
sary mobile phone, power supply and GPS
coverage are available.
i
When you unlock your vehicle, the tow-away
protection disarms automatically.
The tow-away alarm remains disarmed until you
lock your vehicle again.


110 Control systemsCOMAND audio CD/audio DVD/MP3Submenu overviewi
The components and operating principles of
COMAND can be found on (
page 79).
CD or DVD-A or MP3
Pause/Stop/Play
(audio DVD mode only)
Tracks/Track
List/Tracks A-Z
Folders
(MP3 mode only)
Changer
Sound
Normal Track Sequence
Pause playback
Show track list
(audio CD mode and
audio DVD mode)
Select folder
Select medium
Treble
Random Tracks
Stop playback
Display alphabetical
track listing
(MP3 mode only)
Bass
Random folder
(MP3 mode only)
Restart playback
Balance/Fader
Repeat folder
(MP3 mode only)
3D Sound

112 Control systemsCOMAND audio CD/audio DVD/MP3Example display in MP3 mode
1Current playback option
2Medium type
3Disc number (not on PCMCIA card)
4Track name
5Current folder path
6Current folder
7Track time
8Graphic time and track display
9Sound settings
aMedium selection
bFolder listing
cTrack listing
dPlayback options
Stop function
Stopping playback: Select “Audio”

“Audio”
“DVD-Audio”
“Stop”.

Restarting playback: Select “Audio”

“Audio”
“DVD-Audio”
“Play”.
Playback starts at the beginning of the
DVD.
Pause function
In audio CD, audio DVD and MP3 mode
Pausing playback:
Press F briefly.

Continuing playback: PressF
again briefly.
Only in audio DVD mode

Pausing playback:
Select “Audio”
“Audio”
“DVD-Au-
dio”
“Pause”.The “Pause” screen changes to “Play”.

Continuing playback: Select “Audio”

“Audio”
“DVD-Audio”
“Play”.
The “Play” screen changes to “Pause”.
Selecting CD/DVD/MP3 media
Select “Audio”
“Audio”.

Select “CD”, “DVD-Audio” or “MP3”.
COMAND begins playback.

In audio CD, audio DVD and MP3
mode: Select “Changer”.
or

In audio CD and audio DVD mode
only: Press n when the main area is
selected.
The media list appears. The dot R in-
dicates the current medium.

Select a medium or folder.
COMAND changes the medium.
i
This function is only available in audio DVD
mode.
