317 Controls in detail
Starter switch positions
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the automatic transmission
is set toP.

Do not depress the brake pedal.
KEYLESS-GO start/stop button1USA only
2Canada only
Position 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have status 0 (as with
SmartKey removed).Position 1

Press the KEYLESS-GO start/stop but-
ton once.
This supplies power for some electrical
consumers, such as seat adjustment.
Ignition (or position 2)

Press the KEYLESS-GO start/stop but-
ton twice.
This supplies power for all electrical
consumers.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 544).
For information on starting the engine us-
ing the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 360).
i
If you now press the KEYLESS-GO
start/stop button


once again, the ignition (position2) is
switched on


twice, the power supply is again switched off
i
If you now press the KEYLESS-GO
start/stop button once, the power supply is
again switched off.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.

329 Controls in detailSeats
With the easy-entry/exit feature activated,
the steering wheel and driver’s seat will re-
turn to their last set memory position or a
factory-set maximum forward position
when you:

close the driver’s door with the ignition
switched on


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 317) once
with the driver’s door closed. With the easy-entry/exit feature activated
the steering wheel tilts upwards and the
driver’s seat moves a few inches to the
rear when you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 317) in position 1.
!
Do not activate the easy-entry/exit feature
if the seat backrest is in an excessively reclined
position. Doing so could cause damage to front
or rear seats.
First move the seat backrest to an upright posi-
tion.
i
For safety reasons, the driver’s seat will not
return to its last set position with the easy-en-
try/exit feature activated if the system recogniz-
es the last set position as an extreme forward
position. Instead, the driver’s seat will remain at
or move to a factory-set maximum forward posi-
tion. To again fully return the driver’s seat toyour last set position or to memory position, ad-
just the seat to the desired position or press and
hold the respective memory position button
(
page 337).
i
The last set driver’s seat and steering wheel
positions are stored when


the ignition is switched off


the position is stored in memory
(page 336)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
If the current seat position falls into a factory-set
position range and the system recognizes the
current seat position to be rearward enough for
easy entry and exit, the driver’s seat will not
move to the rear when the easy-entry/ exit fea-
ture is activated.
The adjustment procedure is briefly interrupted
when the engine is started.Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All driver’s seat and steering wheel ad-
justments must be completed before setting
the vehicle in motion. Driving off with the
driver’s seat/steering wheel still adjusting
could cause the driver to lose control of the
vehicle.

344 Controls in detailLighting
Turn the exterior lamp switch to *.
With the SmartKey in starter switch po-
sition 1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps will switch on and off
automatically.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off automatically.Daytime running lamp mode

Turn exterior lamp switch to
positionM or*.
When the engine is running, the low
beam headlamps are switched on. In
low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

tail and parking lamps


license plate lamps


side marker lamps
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam head-
lamps.
Canada only
The daytime running lamp mode is manda-
tory and therefore in a constant mode.
When the engine is running, and you shift
from a driving position to positionN orP,
the low beam headlamps will switch off
with a 3-minute delay.When the engine is running, and you


turn the exterior lamp switch to
positionC, the parking lamps
switch on additionally.


turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The corresponding exterior lamps
switch on (
page 622).
USA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Daytime driving lamps mode on/off
(USA only)” (
page 255).
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 622).
i
The front fog lamps and rear fog lamp can-
not be switched on manually with exterior lamp
switch in position*. To activate the fog
lamps, turn exterior lamp switch to
positionB and pull the exterior lamp switch
to first or second stop (
page 345).

348 Controls in detailLightingHazard warning flasher
The hazard warning flasher can be
switched on at all times, even with the
SmartKey removed from the starter switch
or with the SmartKey with KEYLESS-GO*
removed from the vehicle.
The hazard warning flasher is automatical-
ly switched on if

an air bag has been triggered


S 600 and USA only: you brake the ve-
hicle strongly at a speed of more than
50 mph (70 km/h) and bring it to a
complete stop.
1Hazard warning flasher switch

Switching on: Press hazard warning
flasher switch.
All turn signals will flash.

Switching off: Press hazard warning
flasher switch again.
Interior lighting
i
With the hazard warning flasher activated
and the combination switch set for either left or
right turn, only the respective left or right turn
signals will operate when the SmartKey in the
starter switch is in position1 or2 or the
KEYLESS-GO* start/stop button (
page 317) is
pressed once or twice.
i
If the hazard warning flasher was activated
automatically, also press hazard warning flasher
switch 1 to switch off the hazard warning flash-
er.
i
When you lock the vehicle from the outside,
the interior lighting is switched off. As soon as
one of the interior lighting buttons inside the ve-
hicle is pressed, however, the selected lamp
comes on and all of the lamps inside the vehicle
that are not switched on via a button are activat-
ed.
If you do not lock the vehicle, all lamps will be
switched off after 30 minutes. When you open
the door, you can still use the lighting for the
storage compartment, glove box and vanity mir-
ror without in the starter switch in position1 or2
or the KEYLESS-GO* start/stop button
(
page 317) pressed once or twice.

351 Controls in detail
Windshield wipers
Windshield wipers
Combination switch1Switching on windshield wipers
2Single wipe
Wiping with windshield washer fluid

Switch on the ignition (
page 315).
Switching on/off windshield wipers
Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
(rain sensor operation low sen-
sitivity)
VFast intermittent wiping
(rain sensor operation low sen-
sitivity)
uSlow continuous wiping
tFast continuous wiping
!
If the windshield wipers leave smears on the
windshield after the car has been driven through
an automatic car wash, then wax or other resi-
due is on the windshield. Shortly after washing
the car in an automatic car wash, clean the wind-
shield with windshield washer fluid
(
page 352).
!
Do not operate the wipers when the wind-
shield is dry. Dust that accumulates on a wind-
shield might scratch the glass and/or damage
the wiper blades when wiping occurs on a dry
windshield. If it is necessary to operate the wip-
ers in dry weather conditions, always operate
the wipers with windshield washer fluid
(
page 352).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location,

turn off the engine by turning the
SmartKey to position0 and withdraw
SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button
(page 317) and open the driver’s door
(with the driver’s door open, starter
switch is in position0, same as with
SmartKey removed from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.If the windshield wipers fail to function at all in
combination switch position u,


set the combination switch to the next high-
er wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center

353 Controls in detail
Power windows
Power windows
Opening and closing power windows
The door windows are opened and closed
electrically. The switches

for all side windows are on the driver’s
door


for the front passenger side window
are on the front passenger door


for each rear side window are on the
rear doors
1Left front door window
2Right front door window
3Left rear door window
4Right rear door window
Warning!
G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
Activate the override switch (
page 67)
when children are riding in the back seats of
the vehicle. The children may otherwise in-
jure themselves, e.g. by becoming trapped
in the window opening.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if the switch was pressed past the resis-
tance point and released, by pressing the
lower part of the respective switch again.
The door windows are equipped with the ex-
press-close and automatic reversal func-
tion. If the window encounters an
obstruction that blocks its path in a circum-
stance where you pressed the switch past
the resistance point and released it to close
the window, the automatic reversal function
will stop the window and open it slightly.
If the window encounters an obstruction
that blocks its path in a circumstance where
you are closing the window by pressing and
holding the switch, by pressing and holding
button ‹ on the SmartKey or SmartKey
with KEYLESS-GO*, by pressing and holding
the sensor surface (vehicles with
KEYLESS-GO*) on an outside door handle,
or by pressing and holding button, on
the climate control panel, the automatic re-
versal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

360 Controls in detailDriving and parkingStarting with KEYLESS-GO*
You can start your vehicle without the
SmartKey in the starter switch using the
KEYLESS-GO start/stop button on the
starter switch.
The SmartKey with KEYLESS-GO must be
located in the vehicle.
KEYLESS-GO* start / stop button1USA only
2Canada only
Make sure KEYLESS-GO start/stop
button is inserted in the starter switch
(page 316).

Make sure the automatic transmission
is set toP.
The gear position indicator in the ta-
chometer display should be on P.

Depress the brake pedal during the
starting procedure.

Do not depress accelerator.

Press KEYLESS-GO start/stop button
once.
The engine starts if the SmartKey with
KEYLESS-GO is in the vehicle.
For information on turning off the engine
with KEYLESS-GO, see “Turning off the en-
gine” (
page 365).
Starting difficulties
If the engine does not start as described,
carry out the following steps:

If you are starting the engine with the
SmartKey: Turn SmartKey in starter
switch to position0 and repeat starting
procedure.
Warning!
G
As long as the SmartKey with KEYLESS-GO
is in your vehicle, the vehicle can be started.
Therefore, never leave children unattended
in the vehicle, as they could otherwise acci-
dentally start the engine.
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle.
i
You can also start the engine with the auto-
matic transmission set to N.
i
If you wish to start the vehicle with the
SmartKey instead of the KEYLESS-GO feature,
remove the KEYLESS-GO start/stop button from
the starter switch and proceed as described in
“Starting with the SmartKey” (
page 359).

361 Controls in detail
Driving and parking

If you are starting the engine with
KEYLESS-GO: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO.
or

Remove the KEYLESS-GO* start/stop
button from starter switch.

Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO.

Repeat the starting procedure
(page 359). Remember that extend-
ed starting attempts can drain the bat-
tery.

Get a jump start (
page 639).
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.

Call Roadside Assistance.

Notify an authorized Mercedes-Benz
Center.
Driving off
Depress the brake pedal.
The gear selector lever can now be
used.

Shift automatic transmission toD orR.

Release the brake pedal.

Carefully depress the accelerator
pedal.
The electric parking brake is automati-
cally released (
page 364).
The red brake warning 0 (USA only)
or ! (Canada only) in the instru-
ment cluster goes out.
Once the vehicle is in motion, the auto-
matic central locking system engages
and the locking knobs in the doors
move down.
After a cold start, the automatic transmis-
sion shifts at a higher engine revolution.
This allows the catalytic converter to reach
its operating temperature earlier.
i
Wait for the gear selection process to com-
plete before setting the vehicle in motion.
i
Shifting from gear position P to position R,
N, or D is only possible with the brake pedal de-
pressed. Without the brake pedal depressed, the
gear selector lever can be moved, but the park-
ing pawl remains engaged, not allowing shifting
to occur.
i
After driving off the doors and the trunk lock
automatically.
You can open a locked door from the inside.
Open door only when conditions are safe to do
so.
You can deactivate the automatic locking using
the COMAND system (
page 223).
