v. Tighten output shaft & companion flange complement bolts (1)
to the specified torque. Refer to AT- 2 8 1 , "
Components" .
: Bolt (10)
CAUTION:
Do not reuse self-sealing bolts (2).
Refer to GI section to make sure icons (symbol marks) in the fig-
ure. Refer to GI-11, "
Components" .
c.AW D m o d e l s
i. Install seal rings to output shaft.
CAUTION:

Do not reuse seal rings.

Apply petroleum jelly to seal rings.
ii. Install parking gear to output shaft.
iii. Install output shaft in transmission case.
CAUTION:
Be careful not to mistake front for rear because both sides
looks similar. (Thinner end is front side.)
SCIA6943E
SCIA5209E
SCIA5247E
SCIA5030E

ASSEMBLY
AT-355
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
iv. Install bearing race to output shaft.
v. Install gasket onto transmission case.
CAUTION:

Completely remove all moisture, oil and old gasket, etc.
from the transmission case and adapter case assembly
mounting surfaces.

Do not reuse gasket.
vi. Install adapter case assembly to transmission case.
CAUTION:
Insert the tip of parking rod between the parking pawl and
the parking actuator support when assembling the adapter
case assembly.
vii. Tighten adapter case assembly bolts (1) to the specified torque.
[With bracket (2).] Refer to AT- 2 8 1 , "
Components" .
: Bolt (10)
CAUTION:
Do not reuse self-sealing bolts (3).
Refer to GI section to make sure icons (symbol marks) in the fig-
ure. Refer to GI-11, "
Components" .
SCIA5245E
SCIA5231E
SCIA5186E
SCIA6910E

AT-360
ASSEMBLY
Revision: 2007 April2007 M35/M45
45. Adjust brake band.
a. Loosen lock nut.
b. Tighten band servo anchor end pin to specified torque.
c. Back of band servo anchor end pin three turns.
d. Holding band servo anchor end pin, tighten lock nut to the spec-
ified torque. Refer to AT- 2 8 1 , "
Components" .
AdjustmentNCS001RB
TOTAL END PLAY

Measure clearance between front sun gear and bearing race for
oil pump cover.

Select proper thickness of bearing race so that end play is within
specifications.
1. Measure dimensions “K” and “L” and then calculate dimension
“J”.
a. Measure dimension “K”.: 5.0 N·m (0.51 kg-m, 44 in-lb)
SCIA5498E
SCIA2810E
SCIA7073E
SCIA7074E

ASSEMBLY
AT-363
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
3. Install oil pump assembly in transmission case.
CAUTION:
Apply ATF to oil pump baring.
4. Apply recommended sealant (Genuine RTV Silicone Sealant or
equivalent. Refer to GI-47, "
Recommended Chemical Products
and Sealants" .) to oil pump assembly as shown in the figure.
CAUTION:
Completely remove all moisture, oil and old sealant, etc.
from the oil pump mounting bolts and oil pump mounting
bolt mounting surfaces.
5. Tighten oil pump bolts to the specified torque. Refer to AT- 2 8 1 ,
"Components" .
CAUTION:
Apply ATF to oil pump bushing.
6. Install O-ring to input clutch assembly.
CAUTION:

Do not reuse O-ring.

Apply ATF to O-ring.
7. Install converter housing to transmission case. Tighten con-
verter housing bolts (1) to the specified torque. Refer to AT- 2 8 1 ,
"Components" .
: Bolt (8)
CAUTION:
Do not reuse self-sealing bolt (2).
SCIA2811E
SCIA5321E
SCIA2300E
SCIA5011E
SCIA7985E

ASSEMBLY
AT-365
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
d. Install O-ring to A/T assembly harness connector.
CAUTION:

Do not reuse O-ring.

Apply ATF to O-ring.
e. Install A/T fluid temperature sensor 2 to bracket.
f. Install A/T fluid temperature sensor 2 (with bracket) in control
valve with TCM. Tighten A/T fluid temperature sensor 2 bolt to
the specified torque. Refer to AT- 2 8 1 , "
Components" .
CAUTION:
Adjust bolt hole of bracket to bolt hole of control valve.
g. Install control valve with TCM in transmission case.
CAUTION:

Make sure that turbine revolution sensor securely installs
turbine revolution sensor hole.

Hang down revolution sensor harness toward outside so
as not to disturb installation of control valve with TCM.

Adjust A/T assembly harness connector of control valve
with TCM to terminal hole of transmission case.

Assemble it so that manual valve cutout is engaged with
manual plate projection.
SCIA5155E
SCIA5264E
SCIA5301E
SCIA5034E
SCIA5035E

AT-366
ASSEMBLY
Revision: 2007 April2007 M35/M45
h. Install bolts A, B and C to control valve with TCM.
i. Tighten bolt 1, 2 and 3 temporarily to prevent dislocation. After
that tighten them in order (1 → 2 → 3), and then tighten other
bolts. Tighten control valve bolts to the TCM with specified
torque. Refer to AT- 2 8 1 , "
Components" .
10. Connect A/T fluid temperature sensor 2 connector.
11. Securely fasten terminal cord assembly and A/T fluid tempera-
ture sensor 2 harness with terminal clips.
12. Connect revolution sensor connector.
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5025E
SCIA5037E
SCIA5023E
SCIA5446E
SCIA7524E

AT-368
ASSEMBLY
Revision: 2007 April2007 M35/M45
ii. Install oil pan (2) (with oil pan gasket) and clips (1) to transmis-
sion case.
: Front
: Bolt (22)
CAUTION:

Install it so that drain plug comes to the position as
shown in the figure.

Be careful not to pinch harnesses.

Completely remove all moisture, oil and old gasket, etc.
from oil pan mounting surface.
iii. Tighten oil pan mounting bolts to the specified torque in numeri-
cal order shown in the figure after temporarily tightening them.
Tighten oil pan mounting bolts to the specified torque. Refer to
AT- 2 8 1 , "
Components" .
CAUTION:
Do not reuse oil pan mounting bolts.
b. VK45DE models
i. Install oil pan gasket to oil pan.
CAUTION:

Do not reuse oil pan gasket.

Install it in the direction to align hole positions.

Complete remove all moisture, oil and old gasket, etc. from oil pan gasket mounting surface.
ii. Install oil pan (3) (with oil pan gasket), clips (1) and brackets (2)
to transmission case.
: Front
: Bolt (22)
CAUTION:

Install it so that drain plug comes to the position as
shown in the figure.

Be careful not to pinch harnesses.

Completely remove all moisture, oil and old gasket, etc.
from oil pan mounting surface.

Be careful with installation direction of brackets (2).
iii. Tighten oil pan mounting bolts to the specified torque in numeri-
cal order shown in the figure after temporarily tightening them.
Tighten oil pan mounting bolts to the specified torque. Refer to
AT- 2 8 1 , "
Components"
CAUTION:
Do not reuse oil pan mounting bolts.
18. Install drain plug to oil pan. Tighten drain plug to the specified
torque. Refer to AT- 2 8 1 , "
Components" .
CAUTION:
Do not reuse drain plug gasket.
19. Install torque converter.
SCIA8039E
SCIA4113E
SCIA8035E
SCIA4113E
