2007 GMC CANYON Owner's Manual

Instrument Panel Overview........................ 156
Hazard Warning Flashers.......................... 158
Other Warning Devices............................. 158
Horn.......................................................... 158
Tilt Wheel.................................................. 158
Turn Signal/Multifunction Lever.................. 159
Turn and Lane-Change Signals................. 160
Headlamp High/Low-Beam Changer.......... 161
Flash-to-Pass............................................ 161
Windshield Wipers..................................... 161
Windshield Washer.................................... 162
Cruise Control........................................... 163
Exterior Lamps.......................................... 166
Headlamps on Reminder........................... 167
Daytime Running Lamps (DRL)................. 167
Automatic Headlamp System..................... 168
Fog Lamps................................................ 169
Exterior Cargo Lamps................................ 169
Interior Lamps........................................... 170
Instrument Panel Brightness...................... 170
Dome Lamp.............................................. 170
Dome Lamp Override................................ 170
Exit Lighting.............................................. 171
Electric Power Management...................... 171
Battery Run-Down Protection..................... 171Accessory Power Outlet(s)........................ 172
Ashtray(s) and Cigarette Lighter................ 173
Climate Controls......................................... 173
Climate Control System............................. 173
Outlet Adjustment...................................... 176
Warning Lights, Gages, and Indicators..... 177
Instrument Panel Cluster........................... 178
Speedometer and Odometer...................... 179
Trip Odometer........................................... 179
Tachometer............................................... 179
Safety Belt Reminder Light........................ 180
Passenger Safety Belt Reminder Light....... 180
Airbag Readiness Light............................. 181
Passenger Airbag Status Indicator............. 182
Battery Warning Light................................ 184
Up-Shift Light (Manual Transmission)........ 185
Brake System Warning Light..................... 185
Anti-Lock Brake System Warning Light...... 186
Engine Coolant Temperature Gage............ 187
Tire Pressure Light.................................... 187
Malfunction Indicator Lamp........................ 188
Oil Pressure Light..................................... 191
Security Light............................................ 192
Cruise Control Light.................................. 192
Section 3 Instrument Panel
153

Highbeam On Light................................... 192
Daytime Running Lamps (DRL)
Indicator Light........................................ 193
Fuel Gage................................................. 193
Driver Information Center (DIC).................. 194
DIC Controls and Displays........................ 194
DIC Warnings and Messages.................... 198
Audio System(s)......................................... 203
Setting the Time for Radios without
Radio Data Systems (RDS).................... 204
Setting the Time for Radios with
Radio Data Systems (RDS).................... 205
AM-FM Radio............................................ 205Radio with CD (MP3)................................ 208
Radio with Six-Disc CD............................. 217
Using an MP3........................................... 230
XM Radio Messages................................. 236
Theft-Deterrent Feature
(Non-RDS Radios)................................. 237
Theft-Deterrent Feature (RDS Radios)....... 238
Radio Reception........................................ 238
Care of Your CDs..................................... 239
Care of the CD Player.............................. 239
Fixed Mast Antenna.................................. 239
XM™ Satellite Radio Antenna System....... 240
Chime Level Adjustment............................ 240
Section 3 Instrument Panel
154

✍NOTES
155

Instrument Panel Overview
Manual Transmission shown, Automatic Transmission similar
156

The main components of your vehicle’s instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on
page 176.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 159.
C. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 178.
D. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 158.
E. Passenger Side Airbag. SeeAirbag System on
page 76.
F. Exterior Lamp Controls. SeeExterior Lamps on
page 166. Fog Lamps (If Equipped). SeeFog
Lamps on page 169. Exterior Cargo Lamps.
SeeExterior Cargo Lamps on page 169.
G. Parking Brake Release. SeeParking Brake
on page 130.H. Horn. SeeHorn on page 158.
I. Traction Control Button or Four-Wheel Drive
Buttons. SeeTraction Control System (TCS) on
page 249andFour-Wheel Drive on page 126.
J. Audio System. SeeAudio System(s) on
page 203.
K. Cigarette Lighter (If Equipped). SeeAshtray(s)
and Cigarette Lighter on page 173.
L. Climate Control System. SeeClimate Control
System on page 173.
M. Accessory Power Outlet. SeeAccessory Power
Outlet(s) on page 172.
N. Passenger Air Bag Status Indicator. See
Passenger Airbag Status Indicator on page 182.
O. Glove Box. SeeGlove Box on page 150.
157

Hazard Warning Flashers
The hazard warning ashers let you warn the
police and others that you have a problem.
The front and rear turn signal lamps will ash
on and off.
The hazard warning
asher button is located
on the instrument
panel, between the
two air vents in
the center.
The hazard warning ashers work no matter what
position the key is in, and even if the key is not
in the ignition.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, the turn
signals will not work.
Other Warning Devices
If you carry reective triangles, you can set one up
at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
To sound the horn, press the horn symbol on the
steering wheel pad.
Tilt Wheel
A tilt wheel allows you to adjust the steering wheel
before you drive. The tilt steering wheel can be
raised to the highest level to allow more room for
the driver to enter and exit the vehicle.
158

The tilt lever is located on the left side of the
steering column, under the turn signal lever.
To tilt, hold the steering wheel and pull the tilt lever
toward you. Move the wheel to a comfortable level,
then release the tilt lever to lock the wheel in place.
Do not adjust the steering wheel while driving.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane Change Signals. See
Turn Signal/Multifunction Lever on page 159.
53Headlamp High/Low-Beam Changer.
SeeHeadlamp High/Low-Beam Changer on
page 161.
Flash-to-Pass. SeeFlash-to-Pass on page 161.
159

NWindshield Wipers. SeeWindshield Wipers
on page 161.
LWindshield Washer. SeeWindshield
Washer on page 162.
JCruise Control. SeeCruise Control on
page 163.
Turn and Lane-Change Signals
The turn signal has two upward (for right) and
two downward (for left) positions. These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is nished, the lever will
automatically return to the off position.
To signal a lane change, raise or lower the lever
until the arrow starts to ash. Hold it there until the
change is completed. The lever will return by
itself when released.An arrow on the
instrument panel cluster
will ash in the
direction of the turn or
lane change.
As you signal a turn or a lane change, if the
arrows ash more quickly than normal, a signal
bulb may be burned out and other drivers will not
see your vehicle’s turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when
signaling a turn, check for a burned-out bulb or a
blown fuse. For bulb replacement, seeTaillamps,
Turn Signal, Stoplamps and Back-up Lamps
on page 364. For a blown fuse or circuit breaker,
seeFuses and Circuit Breakers on page 426.
160
