•While holding the recirculation button, turn the igni-
tion switch to the “RUN” position.
•Continue holding the recirculation button for 4 sec-
onds, then release.
The recirculation control is now programmed so that the
recirculation mode willnotreset to the outside air mode
when the engine is restarted. The recirculation program-
ming can be changed back by repeating this procedure.
Rear Blower Operation
To operate the rear fan, press theREARbutton. The first
time this button is pressed theREAR AUTOdisplay
will illuminate indicating that the rear fan speed is
automatically controlled. To manually control the rear
fan speed, press theREARbutton again and only
REARwill illuminate in the display. This allows the rear
seat occupants to control the rear fan speed using theswitch located in the center console between the second
row seats. By pressing theREARbutton a third time,
the rear fan will shut off.
When the ATC display readsREAR AUTOor when the
rear fan is off, the switch located in the center console
between the second row seats is not functional. When the
ATC display readsREAR, only the rear seat occupants
can control the rear fan speed from the rear switch. When
in the “REAR” mode, the rear occupants can set the rear
switch to any fan speed includingOFF,orAUTO.
While in theAUTOposition, the rear fan speed will be
automatically controlled.
Summer Operation
The engine cooling system in air conditioned vehicles
must be protected with a high-quality antifreeze coolant
to provide proper corrosion protection and to protect
against engine overheating. A 50% solution of ethylene
UNDERSTANDING YOUR INSTRUMENT PANEL 257
4

glycol antifreeze coolant in water is recommended. Refer
to section 7, Maintenance Procedures, of this manual for
proper coolant selection.
Winter Operation
To insure the best possible heater and defroster perfor-
mance, make sure the engine cooling system is function-
ing properly and the proper amount, type, and concen-
tration of coolant is used. Refer to section 7, Maintenance
Procedures, of this manual for proper coolant selection.
Use of the air Recirculation mode during winter months
is not recommended because it may cause window
fogging.
Vacation Storage
Anytime you store your vehicle, or keep it out of service
(i.e. vacation) for two weeks or more, run the air condi-
tioning system at idle for about five minutes in the fresh
air and high blower setting. This will insure adequatesystem lubrication to minimize the possibility of com-
pressor damage when the system is started again.
Window Fogging
Vehicle windows tend to fog on the inside in mild rainy
or humid weather. To clear the windows, use the A/C
button to reduce the humidity inside the vehicle.
Fogging on the inside of the windshield can be quickly
removed by pressing the defrost button and increasing
the blower speed.
Do not use the Recirculation mode without the A/C
button for long periods as fogging may occur.
Outside Air Intake
Before driving, always make sure the air intake located
directly in front of the windshield is free of obstructions
such as leaves, ice, or snow, which could reduce airflow
and/or plug the water drain tube inside the plenum.
258 UNDERSTANDING YOUR INSTRUMENT PANEL

A/C Air Filter — If Equipped
On vehicles equipped with Automatic Temperature Con-
trol (ATC), the climate control system filters out dust and
pollen from the air. Refer to section 7 “Air Conditioning”
for filter replacement instructions.
Outside Temperature Display
The outside temperature can be shown in the ATC
display by pressing theOUTSIDE TEMPbutton. After
pressing this button, the front seat passenger’s tempera-
ture setting display will be replaced with the current
outside temperature. Press theOUTSIDE TEMPbutton
again or press the passenger’sTEMPbutton to return
the display to the passenger’s temperature setting.
Electric Rear Window Defroster
Press this button to turn on the rear window
defroster and the heated side mirrors. A light inthe button will illuminate to indicate the rear window
defroster is ON. The defroster automatically turns off
after about 10 minutes of operation.
CAUTION!
To avoid damaging the electrical conductors of the
rear window defroster, do not use scrapers, sharp
instruments, or abrasive window cleaners on the
interior surface of the window.
Labels can be peeled off after soaking with warm
water.
UNDERSTANDING YOUR INSTRUMENT PANEL 259
4

STARTING AND OPERATING
CONTENTS

Starting Procedures.....................266
▫Automatic Transmission................267
▫Normal Starting (Above 32°F / 0°C)........267
▫Extremely Cold Weather Starting
(Below
20°F / –29°C).................267
▫High Altitude Starting
(Above 4,000 Ft. / 1 219 m)..............267
▫If Engine Fails To Start.................268
▫After Starting........................269

Engine Block Heater — If Equipped.........270
Automatic Transmission..................270
▫Brake/Transmission Interlock System.......271
▫Automatic Transmission Ignition Interlock
System.............................271
▫Four Speed Automatic Transmission........271

AutoStick............................274
▫AutoStick Operation...................274
▫AutoStick General Information............275

All Wheel Drive — If Equipped............276
5

Parking Brake.........................276

Brake System..........................278
▫Anti-Lock Brake System................279

Electronic Stability Program (ESP)...........281
▫ESP Has The Following Operating Modes....283
▫ESP/BAS Warning Lamp And
ESP/TCS Indicator Light................283
▫Brake Assist System (BAS)...............284

Traction Control........................285

Power Steering........................286

Driving On Slippery Surfaces..............287
▫Acceleration.........................287
▫Traction............................288
Tire Safety Information...................288
▫Tire Markings........................288
▫Tire Identification Number (TIN)..........292
▫Tire Loading And Tire Pressure...........293

Tires — General Information...............297
▫Tire Pressure.........................297
▫Tire Inflation Pressures.................298
▫Radial-Ply Tires......................300
▫Compact Spare Tire — If Equipped.........301
▫Limited Use Spare — If Equipped.........302
▫Tire Spinning........................302
▫Tread Wear Indicators..................303
▫Life Of Tire.........................304
262 STARTING AND OPERATING

▫Replacement Tires.....................304
▫Alignment And Balance.................305

Tire Chains...........................306

Snow Tires...........................307

Tire Rotation..........................307

Tire Pressure Monitor System — If Equipped . . . 308
▫Tire Pressure Monitoring Base System Without
Electronic Vehicle Information Center (EVIC) —
If Equipped.........................309
▫Tire Pressure Monitoring Low Pressure
Warnings...........................310
▫Base Tire Pressure Monitoring System With
Electronic Vehicle Information Center (EVIC) —
If Equipped.........................310
▫Service Tire System Soon................312▫Using Your Compact Spare —
Basic Tire Pressure Monitoring System Only . . 313
▫Tire Pressure Monitoring Premium System –
If Equipped.........................314
▫Tire Pressure Monitoring Low Pressure
Warnings...........................314
▫Service Tire System Soon................315
▫General Information...................317

Fuel Requirements......................318
▫Reformulated Gasoline.................318
▫Gasoline/Oxygenate Blends..............319
▫MMT In Gasoline.....................319
▫Materials Added To Fuel................320
▫Fuel System Cautions..................320
STARTING AND OPERATING 263
5

▫Carbon Monoxide Warnings..............321

Adding Fuel..........................321
▫Fuel Filler Cap (Gas Cap)...............321
▫Loose Fuel Filler Cap Message............323

Flexible Fuel— (Fleet Vehicles Only).........324
▫E-85 General Information................324
▫Ethanol Fuel (E-85)....................324
▫Fuel Requirements....................324
▫Selection Of Engine Oil For Flexible Fuel
Vehicles (E-85) And Gasoline Vehicles.......325
▫Starting............................325
▫Cruising Range.......................326
▫Replacement Parts.....................326▫Maintenance.........................326

Vehicle Loading........................326
▫Vehicle Certification Label...............327
▫Gross Vehicle Weight Rating (GVWR).......327
▫Gross Axle Weight Rating (GAWR).........327
▫Overloading.........................328
▫Loading............................328

Trailer Towing.........................329
▫Common Towing Definitions.............330
▫Trailer Hitch Classification...............333
▫Trailer Towing Weights
(Maximum Trailer Weight Ratings).........334
▫Trailer And Tongue Weight..............335
264 STARTING AND OPERATING
