EI–12ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEM
EI
(3) Insert a previously registered key into the
ignition key cylinder, turn the ignition switch ON
(do not start the engine), and leave it as is for
30 minutes.
(4) Turn the ignition switch OFF and disconnect
terminals TC and CG.
(5) Start the engine.
(6) Check that the engine starts and stays on for
more then 3 seconds. The registration is
complete.
(b) After replacing the ECM.
(1) Register the ECU - ECM communication ID
(c) After replacing the transponder key ECU and ECM
(1) Register the key code(s) by following the new
key code registration procedure (procedure
"B").
(2) Register the ECU - ECM communication ID
B130075E01
Procedure Security Indicator Light Condition
1. Insert previously registered key into ignition key cylinder
OFF 2. Start engine
3. Check that engine starts and stays on for more than 3 seconds.
Registration is complete.
Procedure Security Indicator Light Condition
1. Insert previously registered key into ignition key cylinder
OFF 2. Start engine
3. Check that engine starts and stays on for more than 3 seconds.
Registration is complete.

EI–14ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEM
EI
TERMINALS OF ECU
1. CHECK TRANSPONDER KEY AMPLIFIER
(a) Disconnect the E5 amplifier connector.
(b) Measure the resistance of the wire harness side
connector.
If the result is not as specified, there may be a
malfunction in the wire harness.
(c) Reconnect the E5 amplifier connector.
(d) Measure the resistance and voltage of the
connector.
If the result is not as specified, there may be a
malfunction in the amplifier.
(e) Using an oscilloscope, check the waveform 1.
Waveform 1 (Reference):
B065593E16
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
AGND (E5-7) - Body
groundR - Body ground Ground Always Below 1
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
AGND (E5-7) - Body
groundR - Body ground Ground Always Below 1
VC5 (E5-1) - AGND (E5-7) B - R Power sourceNo key is in ignition key
cylinder Below 1 V
Key inserted 4.6 to 5.4 V
CODE (E5-4) - AGND (E5-
7)P - R Demodulated signal of key
code dataNo key is in ignition key
cylinderBelow 1 V
Key insertedPulse generation (see
waveform 1)
TXCT (E5-5) - AGND (E5-
7)G - R Key code output signalNo key is in ignition key
cylinderBelow 1 V
Key insertedPulse generation (see
waveform 2)
B069240E13
Item Content
Symbols (Terminal No.) CODE (E5-4) - AGND (E5-7)
Tool Setting 5 V/DIV., 20 msec./DIV.
Condition Key inserted

ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEMEI–15
EI
(f) Using an oscilloscope, check the waveform 2.
Waveform 2 (Reference):
2. CHECK TRANSPONDER KEY ECU
(a) Disconnect the E46 ECU connector.
(b) Measure the resistance and voltage of the wire
harness side connector.
If the result is not as specified, there may be a
malfunction on the wire harness side.
(c) Reconnect the E46 ECU connector.
(d) Measure the resistance and voltage of the
connector.
B069239E10
Item Content
Symbols (Terminal No.) TXCT (E5-5) - AGND (E5-7)
Tool Setting 5 V/DIV., 20 msec./DIV.
Condition Key inserted
B121962E04
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
GND (E46-16) - Body
groundW-B - Body ground Ground Always Below 1
+B (E46-1) - GND (E46-
16)R - W-B Battery Always 10 to 14 V
IG (E46-2) - GND (E46-
16)B - W-B Ignition switchIgnition switch OFF Below 1 V
Ignition switch ON 10 to 14 V
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
AGND (E46-5) - GND
(E46-16)R - W-B Amplifier ground circuit Always Below 1
EGND (E46-11) - GND
(E46-16)V - W-B ECM ground circuit Always Below 1
KSW (E46-3) - GND (E46-
16)L - W-B Unlock warning switchNo key is in ignition key
cylinder10 to 14 V
Key inserted Below 1 V
VC5 (E46-14) - AGND
(E46-5)B - R Power sourceNo key is in ignition key
cylinderBelow 1 V
Key inserted 4.6 to 5.4 V
TXCT (E46-4) - AGND
(E46-5)G - RTransponder key amplifier
communication signalNo key is in ignition key
cylinderBelow 1 V
Key insertedPulse generation (see
waveform 1)

EI–16ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEM
EI
If the result is not as specified, there may be a
malfunction in the ECU.
(e) Using an oscilloscope, check the waveform 1.
Waveform 1 (Reference):
(f) Using an oscilloscope, check the waveform 2.
Waveform 2 (Reference):
(g) Using an oscilloscope, check the waveform 3.
Waveform 3 (Reference):
CODE (E46-15) - AGND
(E46-5)P - RTransponder key amplifier
communication signalNo key is in ignition key
cylinderBelow 1 V
Key insertedPulse generation (see
waveform 2)
EFIO (E46-13) - EGND
(E46-11)P - V ECM output signalIgnition switch OFF Below 1 V
Ignition switch ONPulse generation (see
waveform 3)
EFII (E46-12) - EGND
(E46-11)LG - V ECM input signalIgnition switch OFF Below 1 V
Ignition switch OFFPulse generation (see
waveform 3)
IND (E46-8)- GND (E46-
16)Y - W-BSecurity indicator light
signalEngine immobiliser
system SET3 to 5 V
Engine immobiliser
system UNSETBelow 1 V
D (E46-9) - GND (E46-16) W - W-BDiagnosis tester
communicationIgnition switch ON Pulse generation Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
B069239E11
Item Content
Symbols (Terminal No.) TXCT (E46-4) - AGND (E46-5)
Tool Setting 5 V/DIV., 20 msec./DIV.
Condition Key inserted
B069240E14
Item Content
Symbols (Terminal No.) CODE (E46-15) - AGND (E46-5)
Tool Setting 5 V/DIV., 20 msec./DIV.
Condition Key inserted
B069241E07
Item Content
Symbols (Terminal No.) EFIO (E46-13) - EGND (E46-11)
Tool Setting 10 V/DIV., 500 msec./DIV.
Condition Ignition switch ON

ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEMEI–17
EI
(h) Using an oscilloscope, check the waveform 4.
Waveform 4 (Reference):
3. CHECK ECM
(a) Measure the resistance and voltage of the wire
harness side connector.
If the result is not as specified, there may be a
malfunction in the wire harness.
(b) Using an oscilloscope, check the waveform 1.
Waveform 1 (Reference):
B069242E09
Item Content
Symbols (Terminal No.) EFII (E46-12) - EGND (E46-11)
Tool Setting 10 V/DIV., 500 msec./DIV.
Condition Ignition switch ON
B116297E02
Symbols (Terminal No.) Wiring Color Terminal Description ConditionSpecified Condition
EOM (A9-9) - Body ground V - Body ground Ground Always Below 1
IMI (A9-11) - EOM (A9-9) P - VTransponder key ECU
input signalIgnition switch OFF Below 1 V
Ignition switch ONPulse generation (see
waveform 1)
IMO (A9-10) - EOM (A9-9) LG - VTransponder key ECU
output signalIgnition switch OFF Below 1 V
Ignition switch ONPulse generation (see
waveform 2)
B069241E08
Item Content
Symbols (Terminal No.) IMI (A9-11) - EOM (A9-9)
Tool Setting 10 V/DIV., 500 msec./DIV.
Condition Ignition switch ON

EI–18ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEM
EI
(c) Using an oscilloscope, check the waveform 2.
Waveform 2 (Reference):
B069242E10
Item Content
Symbols (Terminal No.) IMO (A9-10) - EOM (A9-9)
Tool Setting 10 V/DIV., 500 msec./DIV.
Condition Ignition switch ON

ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEMEI–19
EI
DIAGNOSIS SYSTEM
1. DESCRIPTION
(a) Engine immobiliser system data and Diagnostic
Trouble Codes (DTCs) can be read through the
vehicle's Data Link Connector 3 (DLC3). In some
cases, a malfunction may be occurring in the engine
immobiliser system even though the security
indicator light is not illuminated. When the system
seems to be malfunctioning, use the intelligent
tester to check for malfunctions and perform repairs.
2. CHECK DLC3
The vehicle's ECU uses the ISO 15765-4 communication
protocol. The terminal arrangement of the DLC3
complies with SAE J1962 and matches the ISO 15765-4
format.
NOTICE:
*: Before measuring the resistance, leave the vehicle
as is for at least 1 minute and do not operate the
ignition switch, other switches or doors.
If the result is not as specified, the DLC3 may have a
malfunction. Repair or replace the harness and
connector.
H100769E16
Symbols (Terminal No.) Terminal Description Condition Specified Condition
SIL (7) - SG (5) Bus "+" line During transmission Pulse generation
CG (4) - Body ground Chassis ground Always Below 1
SG (5) - Body ground Signal ground Always Below 1
BAT (16) - Body ground Battery positive Always 11 to 14 V
CANH (6) - CANL (14) HIGH-level CAN bus line Ignition switch off*54 to 69
CANH (6) - Battery positive HIGH-level CAN bus line Ignition switch off* 1 k or higher
CANH (6) - CG (4) HIGH-level CAN bus line Ignition switch off* 1 k
or higher
CANL (14) - Battery positive LOW-level CAN bus line Ignition switch off* 1 M
or higher
CANL (14) - CG (4) LOW-level CAN bus line Ignition switch off* 1 M
or higher

EI–20ENGINE IMMOBILISER – ENGINE IMMOBILISER SYSTEM
EI
HINT:
Connect the cable of the intelligent tester (with CAN
VIM) to the DLC3, turn the ignition switch ON and
attempt to use the intelligent tester. If the screen displays
UNABLE TO CONNECT TO VEHICLE, a problem exists
in the vehicle side or the tester side.
If the communication is normal when the tester is
connected to another vehicle, inspect the DLC3 on the
original vehicle.
If the communication is still not possible when the tester
is connected to another vehicle, the problem is probably
in the tester itself. Consult the Service Department listed
in the tester's instruction manual.
DTC CHECK / CLEAR
1. CHECK DTC
(a) Connect the intelligent tester (with CAN VIM) to the
DLC3.
(b) Turn the ignition switch ON and turn the intelligent
tester ON.
(c) Select the following menu items: DIAGNOSIS /
OBD/MOBD / IMMOBILISER / DTC INFO /
CURRENT CODES.
(d) Check DTCs and then write them down.
HINT:
Refer to the intelligent tester operator's manual for
further details.
(e) Confirm the details of the DTCs (see page EI-20).
2. CLEAR DTC
(a) Connect the intelligent tester (with CAN VIM) to the
DLC3.
(b) Turn the ignition switch ON (do not start the engine)
and turn the intelligent tester ON.
(c) Select the following menu items: DIAGNOSIS /
OBD/MOBD / IMMOBILISER / DTC INFO / CLEAR
CODES.
HINT:
Refer to the intelligent tester operator's manual for
further details.
(d) Erase DTCs by pressing the YES button on the
tester.
HINT:
Refer to the intelligent tester operator's manual for
further details.
B127989E02
