2006 TOYOTA RAV4 2gr

PP–18PREPARATION – 2GR-FE EMISSION CONTROL
PP
EQUIPMENT
Ohmmeter -
Pressure gauge -
To r q u e w r e n c h -
Va c u u m g a u g e -

PREPARATION – 2GR-FE EMISSION CONTROLPP–19
PP
SSM
Toyota Genuine Adhesive 1324, Three Bond 1324 or Equivalent -

PREPARATION – 2GR-FE COOLINGPP–23
PP
EQUIPMENT
Ohmmeter -
Radiator cap tester -
Thermometer -
Torque wrench -
Side calipers -
Heater -

PP–24PREPARATION – 2GR-FE COOLING
PP
COOLANT
Item Capacity Classification
STD (A/T) 8.9 liters (9.4 US qts, 7.8 Imp. qts) Use only "TOYOTA Super Long Life Coolant"
or similar high quality ethylene glycol based
non-silicate, non-amine, non-nitrite, non-
borate, coolant with long-life hybrid organic
acid technology (coolant with long-life hybrid
organic acid technology consists of a
combination of low phosphates and organic
acids). TWG (A/T) 9.3 liters (9.8 US qts, 8.2 Imp. qts)

PREPARATION – 2GR-FE COOLINGPP–25
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent -

PREPARATION – 2GR-FE LUBRICATIONPP–25
PP
EQUIPMENT
Container -
Deep socket wrench (24 mm) -
Hose Oil filter
Oil pressure gauge -
Socket wrench (27 mm) -
Straightedge -
Torque wrench -
Wooden block -

PP–26PREPARATION – 2GR-FE LUBRICATION
PP
LUBRICANT
Item Capacity Classification
Oil grade - ILSAC multigrade engine oil is
recommended. SAE 5W-30 is the
best choice for good fuel
economy and good starting in
cold weather.
Drain and refill With oil filter change 6.1 liters ( 6.4 US qts, 5.4 Imp.
qts)-
Without oil filter change 5.7 liters ( 6.0 US qts, 5.0 Imp.
qts)-
Dry fill 6.5 liters ( 6.9 US qts, 5.7 Imp.
qts)-

PREPARATION – 2GR-FE LUBRICATIONPP–27
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent -
Toyota Genuine Seal Packing Block, Three Bond 1207B or Equivalent -
Toyota Genuine Seal Packing 1282B, Three Bond 1282B or
Equivalent-
