2006 TOYOTA LAND CRUISER Owners Manual

167
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio system
Reference168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Audio system operating hints 181
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seat audio system 186
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Audio remote controls (steering switches) 187
. . . . . . . . . . . . . . . . . . . . .
For vehicle equipped with Navigation system, please refer to the
separate “Navigation System Owner’s Manual”.
SECTION 1 8

168
Reference
17c509c
AM·FM radio/cassette player/compact
disc changer controller/compact disc
player with changer (with XM satellite
radio* controller)
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details. This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-
tem.
Your audio system works when the ignition
key is in the “ACC” or “ON” position.
TURNING THE SYSTEM ON AND OFF
Push “PWR·VOL” to turn the audio system
on and off.
Push “AM·SAT”, “FM”, “TAPE” or “DISC”
to turn on that function without pushing
“PWR·VOL”.
You can turn on each player by inserting
a cassette tape or compact disc.
You can turn off each player by ejecting
the cassette tape or compact disc. If the
audio system was previously off, then the
entire audio system will be turned off
when you eject the cassette tape or com-
pact disc. If the another function was pre-
viously playing, it will come on again.
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details. SWITCHING BETWEEN FUNCTIONS
Push “AM·SAT”, “FM”, “TAPE” or “DISC”
if the system is already on but you want
to switch from one function to another.
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details.
LISTENING TO THE XM SATELLITE RA-
DIO BROADCAST*
To listen to a satellite radio broadcast in
your vehicle, an additional genuine Toyota
satellite receiver and antenna (or equiva-
lents) must be purchased and installed. A
subscription to the XM satellite radio ser-
vice is also necessary.
How to subscribe to an XM satellite
radio
An XM satellite radio is a tuner designed
exclusively to receive broadcasts provided
under a separate subscription. Availability
is limited to the 48 contiguous states.
Using your audio system—
—some basics

169
How to subscribe:
You must enter into a separate service
agreement with the XM radio in order to
receive satellite broadcast programming in
the vehicle. Additional activation and ser-
vice subscription fees apply that are not
included in the purchase price of the ve-
hicle and optional digital satellite tuner.
For complete information on subscription
rates and terms, or to subscribe to the
XM radio, visit XM on the web at
www.xmradio.com
or call an XM’s Listener
Care at (800) 852 −9696. The XM radio is
solely responsible for the quality, availabil-
ity and content of the satellite radio ser-
vices provided, which are subject to the
terms and conditions of the XM radio cus-
tomer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by tun-
ing to “channel 000” on the radio. For
details, see “Displaying the radio ID” be-
low.
All fees and programming are the respon-
sibility of the XM satellite radio and are
subject to change. Satellite tuner technology notice:
Toyota’s satellite radio tuners are awarded
Type Approval Certificates from XM Satel-
lite Radio Inc. on “March 10, 2003” and
“April 15, 2003” as proof of compatibility
with the services offered by the XM satel-
lite radio.
Displaying the radio ID
Each XM tuner is identified with a unique
radio ID. You will need the radio ID when
activating XM service or when reporting a
problem.
If you select the “CH 000” using the
“AUDIO
−TUNE” knob, the ID code of 8
alphanumeric characters appears. If you
select another channel, display of the ID
code is canceled. The channel (000) alter-
nates the display between the radio ID
and the specific radio ID code.
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details. TONE AND BALANCE
For details about your system’s tone and
balance controls, see the description of
your own system.
Tone
How good an audio program sounds to
you is largely determined by the mix of
the treble, midrange, and bass levels. In
fact, different kinds of music and vocal
programs usually sound better with differ-
ent mixes of treble, midrange, and bass.
Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to
a stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another.

170
YOUR RADIO ANTENNA
Lowering the antenna
The antenna automatically extends when
the radio is on, and retracts when the
radio mode is off. However, even if you
turn off the radio when the radio on the
rear seat audio system is on, the antenna
does not retract. To lower a power anten-
na, push the “” (down) switch. Also, the
antenna automatically goes down when the
radio mode is switched off to turn on the
cassette tape player or compact disc play-
er, turning off the audio system by push-
ing “PWR·VOL” or turning the ignition key
to “LOCK” position.NOTICE
 Retract the antenna when entering
or passing through low structures,
such as a garage or an automatic
car wash. Failure to do so may
damage the antenna.
 The antenna mast has to be ex-
tended higher than 100 mm (3.94
in.) length when the audio is on.
Extend the antenna mast when the
radio signal is weak.
 Putting a window tint (especially,
conductive or meta llic type) on the
righthand rear quarter window may
affect the reception of radio or mo-
bile telephone. For the installation
of the window tint, consult with
your Toyota dealer.
Down Up
Adjusting the power antenna
To adjust the antenna height, push the
switch at either side, this may also be
performed during antenna extension. The
maximum extension length is 850 mm
(33.5 in.).
Every time you turn the radio on, the
antenna will extend to its previous posi-
tion.
Clean the antenna mast periodically with
a clean dry cloth.

171
CAUTION
Before extending the antenna, confirm
that no one is close enough to get
injured.
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed
tape should be to the right.
NOTICE
Do not oil any part of the player and
do not insert anything other than cas-
sette tapes into the slot, or the tape
player may be damaged.
YOUR COMPACT DISC PLAYER
When you insert a disc, gently push it in
with the label side up.
The discs set in the player are played
continuously, starting with disc number 1.
The disc number of the disc currently be-
ing played, the track number and the time
from the beginning of the program appear
on the display.
When play of one disc ends, the first
track of the following disc starts. When
play of the final disc ends, play of the
first disc starts again.
The player will skip any empty disc num-
ber.
NOTICE
Do not stack up two discs for in-
sertion, or it will cause damage the
compact disc player. Insert only one
compact disc into slot at a time.
 Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything other than com-
pact discs into the slot.
The player is intended for use with 12 cm
(4.7 in.) discs only.

172
—Controls and features
Details of specific buttons, controls, and
features are described in the alphabetical
list that follows.
17c517d

173
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station (see “AUDIO−TUNE”
knob or “SEEK TRACK” button). Push and
hold down the button until you hear a
beep—this will set the station to the but-
ton. The button number will appear on the
display.
To tune in to a preset station: Push the
button for the station you want. The but-
ton number and station frequency will ap-
pear on the display.
These systems can store one AM and two
FM stations for each button (The display
will show “AM”, “FM1” or “FM2” when you
push “AM·SAT” or “FM” button).
XM satellite radio*—
These buttons are used to preset and
tune in radio channels.
To preset a channel to a button: Tune in
the desired channel. (See “AUDIO −TUNE”
or “SEEK TRACK”.) Push and hold down
the button until you hear a beep—this will
set the channel to the button. The preset
button number will appear on the display. To recall a preset channel: Push the but-
ton for the channel you want. The preset
button number and channel number will
appear on the display.
This radio can store three XM channels
for each button. (The display will show
“SAT1”, “SAT2” or “SAT3” when you push
“AM·SAT” button
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details.
(Eject button)
Cassette tape
Push the cassette tape eject button to
eject a cassette.
Compact disc
To eject one compact disc only: Push and
release the compact disc eject button. If
you hold the button too long (if the audio
system is on at this time, you hear a
beep.), the mechanism will change to the
mode for ejecting all the discs loaded in
the changer. You can also eject any spe-
cific one of the discs loaded in the player
as follows: 1. Push either side of the “ DISC ”
button until the number of the disc you
want to eject is displayed. 2. Push and release the compact disc
eject button.
To eject all the discs loaded in the player:
Push and hold the compact disc eject but-
ton (until you hear a beep when the audio
system is on). The last compact disc
played before pushing the button will be
ejected first. If a disc is left in the slot
for a long time, the function to eject all
the discs will be automatically cancelled.
(Program)
Push “
” to select the other side of a
cassette tape. The display indicates which
side is currently selected (“
” indicates
top side, “
” indicates bottom side).
Auto −reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.

174
(Reverse/Fast forward buttons)
Cassette Player
Push the fast forward button to fast for-
ward a cassette tape. “FF” will appear on
the display. Push the reverse button to
rewind a tape. “REW” will appear on the
display.
To stop the tape while it is fast forward-
ing, push the fast forward button or
“TAPE”; to stop the tape while it is re-
winding, push the reverse button or
“TAPE”.
If a tape side rewinds completely, the cas-
sette player will stop and then play that
same side. If a tape fast forwards com-
pletely, the cassette player will play the
other side of the tape, using the auto −re-
verse feature.
Compact Disc Player
If you want to fast forward or reverse
through a compact disc track, push and
hold in the fast forward or reverse button.
When you release the button, the compact
disc player will resume playing. AM button
Push “AM·SAT” to turn on the radio and
select the AM band. “AM” will appear on
the display.
If the audio system is off, you can turn
on the radio by pushing “AM”. Also, push
“AM” to switch from cassette or compact
disc operation to radio operation.
AUDIOTUNE Knob
This knob is used to adjust the tone and
balance or to tune the station manually on
the radio mode.
Tone and sound balance adjustment func-
tion—
Each time you push the “AUDIO
−TUNE”
knob, the display changes as in the fol-
lowing. To adjust the tone and balance or
turn on or off the automatic sound leveliz-
er, turn the knob.
BAS: Adjusts low −pitched tones.
MID: Adjusts mid −pitched tones.
TRE: Adjusts high −pitched tones.
BAL: Adjusts the sound balance between
the right and left speakers.
FAD: Adjusts the sound balance between
the front and rear speakers. Manual tuning function—
Turn the knob. The radio will step up or
down to another frequency.
XM satellite radio*—
Turn the knob. The radio will step up or
down the channel.
*: Use of satellite radio requires XM tuner
and service. Contact your Toyota dealer
for details.
DISC (Compact Disc) button
Push “DISC” to switch from radio or cas-
sette operation to compact disc operation.
If the audio system is off, you can turn
on the compact disc player by pushing
“DISC”. In both cases, a disc must alrea-
dy be loaded in the player.
When the audio is set into compact disc
operation, the display shows the track or,
track and disc number currently being
played.
If the player or another unit equipped with
the player malfunctions, your audio system
will display one of the four following error
messages.
