2006 TOYOTA HIGHLANDER HYBRID Owners Manual

’06 HIGHLANDER HB_U (L/O 0503)
157
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
MessageStatusAction
(m)Transmission is out of the “P” position
when starting the hybrid system.Shift the transmission to the “P” position when starting
the hybrid system.
(n)Fuel door is left open.Close the fuel door.

’06 HIGHLANDER HB_U (L/O 0503)
158
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
(a)

These messages are to remind the driv-
er if any of the doors are open.
If any of the doors are open with the
ignition on, any one of the messages ap-
pears and the open door warning light
comes on. The message specifies the
door that is open. When the vehicle speed
exceeds 5 km/h (3 mph), the master
warning light flashes and a warning tone
sounds.
If any one of the messages appears,
stop the vehicle and close the door se-
curely. (b)
This message is to remind the driver
that the parking brake is not released.
When the vehicle speed exceeds 5 km/h
(3 mph), the message appears, the master
warning light flashes and a warning tone
sounds.
If the message appears, stop the ve-
hicle and release the parking brake.
(c)
(U.S.A. only)
This message is to remind the driver to
change the engine oil. The message is
a prior notice.
If the driving range after the previous oil
change reaches 7200 km (4500 miles), the
message appears for 15 seconds with the
master warning light and warning tone
when the ignition is on. If the message appears, we recommend
that you change the engine oil at the
earliest opportunity depending on the
driving and road conditions.
The system must be reset after the en-
gine oil change. See following “Resetting
the system” of (d) “MAINT REQD” for the
procedure to reset the system.
(d)
(U.S.A. only)
This message is to remind the driver to
change the engine oil.
If the driving range after the previous oil
change reaches to 8000 km (5000 miles),
the message appears with the master
warning light and warning tone when the
ignition is on. The message stays on with
the ignition on.
If the message appears, change the en-
gine oil as soon as possible.
The system must be reset after the en-
gine oil change. See “Resetting the sys-
tem” below for the procedure to reset the
system.

’06 HIGHLANDER HB_U (L/O 0503)
159
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Resetting the system
The system must be reset after the en-
gine oil replacement. Reset the system
by the following procedure.
1. Turn the ignition key to the “LOCK” position with the odometer reading
shown.
For details, see “—Odometer and two trip
meters” on page 154 in this Section. 2. Turn the ignition key to the “ON” posi- tion while holding down the trip meter
reset knob. A message “MAINT REQD
RESET MODE” will appear on the dis-
play.
3. Hold down the knob at least 5 sec- onds. A message “COMPLETE” will ap-
pear and a beep will sound.
(e)
This message is to remind the driver
that the washer fluid level is low.
If the washer fluid level is low, the mes-
sage appears with the master warning
light and warning tone when the ignition
is on. If the message appears, fill the washer
tank as soon as possible. For instruc-
tions, see “Adding washer fluid” on
page 403 in Section 73.
(f)
This message is to warn the driver that
the vehicle stability control (VSC) func-
tion of the vehicle dynamics integrated
management (VDIM) is malfunctioning.
If a malfunction is detected, the message
appears with the master warning light and
warning tone when the ignition is on.
If the message appears, the functions
of VDIM listed below may not work pro-
perly. Have the vehicle checked by a
Toyota dealer as soon as possible.
Traction control function
Vehicle stability control function
(g)
This message is to warn the driver that
the engine oil pressure is too low.
If the engine oil pressure is too low, the
message appears with the master warning
light and warning tone when the ignition
is on.
If the message appears, turn the hybrid
system off as soon as possible and
contact a Toyota dealer.
(h)
This message is to warn the driver that
the hybrid system is almost overheat-
ing.
If the coolant temperature is too high, the
message appears with the master warning
light and warning tone when the ignition
is on.

’06 HIGHLANDER HB_U (L/O 0503)
160
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
If the message appears, stop the ve-
hicle as soon as possible and check
the engine compartment. For detailed
instructions, see “If your vehicle over-
heats” on page 343.
Your vehicle may overheat during severe
operating conditions, such as:
Driving up a long hill on a hot day.
Reducing speed or stopping after high
speed driving.
NOTICE
Do not remove the thermostat in
the cooling system as this may
cause the hybrid system to over-
heat. The thermostat is designed to
control the flow of coolant to keep
the temperature of the engine with-
in the specified operating range.
 Continued driving with the message
displayed could result in the over-
heating of the hybrid system.
(i)
This message is to warn the driver that
the hybrid system is malfunctioning.
If a malfunction of the hybrid system is
detected, the message appears with the
master warning light and warning tone
when the ignition is on.
If the message appears, stop the ve-
hicle as soon as possible and contact
a Toyota dealer.
(j)

(All wheel drive models only)
This message is to warn the driver that
the all wheel drive system is malfunc-
tioning.
If a malfunction of all wheel drive system
is detected, the message appears with the
master warning light and warning tone
when the ignition is on.
If the message appears, have the ve-
hicle checked by a Toyota dealer as
soon as possible. (k)
This message is to remind the driver
that the moonroof is open.
If the moonroof is open with the ignition
off, the message appears with the master
warning light and warning tone when the
driver opens the door.
If the message appears, close the
moonroof.
(l)
This message is to warn the driver that
the transmission is not in the “P” posi-
tion when leaving the vehicle.
If the transmission is not in the “P” posi-
tion with the ignition on, the message ap-
pears with the master warning light and
warning tone when the driver ’s door is
opened.
If the message appears, put the trans-
mission in the “P” position.

’06 HIGHLANDER HB_U (L/O 0503)
161
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
(m)
This message is to remind the driver
that the transmission is not in the “P”
position when starting the vehicle.
If the transmission is not in the “P” posi-
tion, the message appears with the master
warning light and warning tone when you
turn the ignition to “START”.
If the message appears, put the trans-
mission in the “P” position and turn
the ignition to “START” again. For the
hybrid system starting procedure, see
“How to start the hybrid system” on
page 326 in Section 3.
(n)
This message is to remind the driver
that the fuel filler door is open.
The message appears with the master
warning light and warning tone in the fol-
lowing cases.
1. When you start the vehicle with the fuel door left open after refueling.
2. When you leave the fuel door open for more than 30 minutes during refueling. In case 1, stop the vehicle and close
the fuel lid. In case 2, the internal valve
in the fuel tank is closed. You must
remove the fuel nozzle, tighten the fuel
tank cap and close the fuel door. If
refueling is not completed you must
start refueling from the beginning.
CAUTION
Do not continue to refuel in case 2.
Fuel may spray out of the fuel open-
ing if you refuel the vehicle.

’06 HIGHLANDER HB_U (L/O 0503)
162
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)

’06 HIGHLANDER HB_U (L/O 0503)
163
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Ignition switch, Transmission and Parking brake
Ignition switch 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Transmission 165
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Vehicle dynamics integrated management 167
. . . . . . . . . . . . . . . . . . . . .
Parking brake 172
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Cruise control 172
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
SECTION 1 7

’06 HIGHLANDER HB_U (L/O 0503)
164
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
“START”—Starting position of hybrid
system (“READY” indicator on). The key
will return to the “ON” position when
released.
For starting tips, see page 325 in Section
3.
“ON”—Hybrid system on and all acces-
sories on.
This is the normal driving position.
“ACC”—Accessories such as the radio
are operational, but the hybrid system
is off.
If you leave the key in the “ACC” or
“LOCK” position and open the driver’s
door, a buzzer will remind you to remove
the key. “LOCK”—Hybrid system is off and the
steering wheel is locked. The key can
be removed at this position only.
You must push in the key to turn it from
“ACC” to the “LOCK” position. The selec-
tor lever must be in the “P” position be-
fore pushing in the key.
Vehicles with engine immobilizer sys-
tem—Once you remove the key, the en-
gine immobilizer system is automatically
set. (See “Engine immobilizer system” on
page 25 in Section 1
−2.)
When starting the hybrid system, the key
may seem stuck at the “LOCK” position.
To free it, first be sure the key is pushed
all the way in, and then rock the steering
wheel slightly while turning the key.
Approximately five hours after the hybrid
system is turned off, you may hear sound
coming from underneath the luggage
compartment for several minutes. This is
normal operation and does not indicate a
malfunction. (See “Leak detection pump”
on page x.)
It is not a malfunction if the needles on
all meters and gauges move slightly when
the ignition key is turned to the “ACC”,
“ON” or “START” position.
NOTICE
Do not leave the key in the “ON”
position if the hybrid system is off.
The auxiliary battery will discharge.
Ignition switch
