2006 SUBARU OUTBACK Owners Manual

2-10 Keys and doors
„ Sounding a panic alarm
A “PANIC” button is located on the back of
the transmitter.
To activate the alarm, press the “PANIC”
button once.
The horn will sound and the turn signal
lights will flash.
To deactivate the panic alarm, press any
button on the remote transmitter. Unless a
button on the remote is pressed, the alarm
will be deactivated after approximately 30
seconds.
„ Selecting audible signal op-
erationUsing an electronic chirp, the system will
give you an audible signal when the doors
lock and unlock. If desired, you may turn the audible signal off.
Do the following to deactivate the audible
signal. You can also use the same steps
to restore the function.
1. Sit in the driver’s seat and shut all
doors and the rear gate.
2. Hold down the UNLOCK side of the
power door locking switch.
3. While holding down the “UNLOCK”
side of the power door locking switch, pull
the key out and re-insert it into the ignition
switch at least 6 times within 10 seconds
after Step 2.
4. Open and close the driver’s door once
within 10 seconds after Step 3.
5. The turn signal lights flash 3 times to in-
dicate completion of the setting.
You may have the above settings done by
your SUBARU dealer.
„ Replacing the battery
When the transmitter battery begins to get
weak, transmitter range will begin to de-
crease. Replace the battery as soon as
possible. To replace the battery:
1. Open the transmitter case using a flat-
head screwdriver.
2. Remove the old battery from the hold-
er.200714
Do not let dust, oil or water get on or
in the transmitter when replacing
the battery. 200902
200716

Keys and doors
2-11
– CONTINUED –1) Negative (–) side facing up
3. Replace with a new battery (Type
CR2025 or equivalent) making sure to in-
stall the new battery with the negative (–)
side facing up.
4. Refit the removed half of the transmit-
ter case.
After the battery is replaced, the trans-
mitter must be synchronized with the
keyless entry system’s control unit.
Press either the “ ” or “ ” button
six times to synchronize the unit.
„ Replacing lost transmittersIf you lose a transmitter or want to pur-
chase additional transmitters (up to four
can be programmed), you should re-pro- gram all of your transmitters for security
reasons. It is recommended that you have
your dealer program all of your transmit-
ters into your system.
T Programming the transmitters
The keyless entry system is equipped with
a special code learning feature that allows
you to program new transmitter codes into
the system or to delete old ones. The sys-
tem can learn up to four unique transmitter
codes. The four transmitter codes may be
the same or different.
Programming transmitter codes into
system:
Bag containing transmitter Transmitter circuit board
To register a new transmitter with the key-
less entry system, it is necessary to pro-
gram the transmitter’s code (identification
number) into the syst em. A label showing
the code is affixed to the bag containing
the transmitter, and another is affixed to
the circuit board inside the transmitter. If
there is no bag, open the transmitter case
and make a note of the eight-digit number.
Program the number into the system in
accordance with the following procedure:
1. Firmly close the doors and the rear
gate (Station wagon) or trunk lid (Sedan).
2. Open the driver’s door, sit on the driv-
er’s seat, and close the door.
3. Perform the following steps within 45
seconds.1 200717
200718 200719

2-12 Keys and doors
1) Open and close the driver’s door
once.
1) LOCK
2) ON
2) Insert the key into the ignition switch, then turn it from the “LOCK” position to
the “ON” position 10 times within 15
seconds.
NOTE y When you complete step 2), an elec-
tronic tone will sound once.
y If you do not perform steps 1) and 2)
within 45 seconds, an error will occur.
An electronic tone will not sound. In
this event, perform the whole proce-
dure again beginning with part 1.
4. Open and close the door once within
15 seconds.
NOTE y When part 4 of the procedure is com-
pleted, an electronic tone will sound
for 30 seconds.
y If you do not perform the operations
in part 4 within 15 seconds, an error
will occur and the electronic tone will
not sound. In this event, perform the
registration steps again beginning with
part 3 of the procedure. 5. Before the electronic tone stops sound-
ing, press the power door lock knob to the
“LOCK” side the same number of times as
the leftmost digit of the transmitter code.
For example, press the lock knob eight
times if the leftmost digit of the code is 8.
NOTE y The electronic tone will stop sound-
ing when you start entering the num-
ber.
y If you do not start entering the num-
ber using the lock knob before the
electronic tone stops sounding, an er-
ror will occur. In this event, perform the
registration steps again beginning with
part 3 of the procedure.
y If the interval between one push of
the knob and the next exceeds five sec-200840
2
1
200721LOCK
200841

Keys and doors
2-13
– CONTINUED –onds, an error will occur. In this event,
perform the procedure again beginning
with part 4. If an error occurs six times,
perform the procedure again starting
with part 3.
6. When you have finished entering the
number, pull the lock knob to the “UN-
LOCK” side within five seconds.
NOTE y An electronic tone will sound.
y If you pull the lock knob to the “UN-
LOCK” side when more than five sec-
onds have passed, an error will occur.
In this event, perform the procedure
again beginning with part 4. If an error
occurs six times, perform the proce-
dure again starting with part 3. 7. Perform parts 5 and 6 of the procedure
for each of the remaining digits of the
transmitter code beginning with the sec-
ond digit (counting from the left) and fin-
ishing with the eighth digit.
NOTE y When you finish entering the eighth
digit, an electronic tone will sound for
30 seconds.
y If the interval between one push of
the knob and the next exceeds five sec-
onds, an error will occur. In this event,
perform the procedure again beginning
with part 4. If an error occurs six times,
perform the procedure again starting
with part 3.
8. Before the electronic tone stops sound-
ing, use the power door lock knob to again
enter the transmitter code beginning with
the leftmost digit.
NOTE If you do not start entering the number
using the lock knob before the elec-
tronic tone stops sounding, an error
will occur. In this event, perform the
procedure again beginning with part 3.
9. When you have finished entering the
code a second time, an electronic tone will
sound for one second to indicate comple-
tion of registration, provided the code en- tered the second time is identical to that
entered the first time.
NOTE If the code entered the second time is
not identical to th e code entered the
first time, an error will occur. In this
event, perform the procedure again be-
ginning with part 5. If an error occurs
five times, perform the procedure
again starting with part 3.
10.If you wish to program another trans-
mitter code into the system (up to four
transmitter codes can be programmed
into the system), perform the procedure
beginning with part 4. When you have fin-
ished programming all of the necessary
transmitter codes into the system, remove
the key from the ignition switch.
11.Test every registered transmitter to
confirm correct operation.
T Deleting old transmitter codes
The control unit of the keyless entry sys-
tem has four memory locations to store
transmitter codes, giving it the ability to
operate with up to four transmitters. When
you lose a transmitter, the lost transmit-
ter’s code remains in the memory. For se-
curity reasons, lost transmitter codes
should be deleted from the memory.
To delete old transmitter codes, program
LOCK
200842

2-14 Keys and doors
four transmitter codes into the system. If
you have only one current transmitter,
program it four times. If you have two cur-
rent transmitters, pr ogram each one twice.
If you have three current transmitters, pro-
gram two of them once and the third one
twice. This process will leave only current
transmitter codes in the system’s memory.
NOTE Make sure no one else is operating
their keyless entry system within range
of your vehicle when programming
transmitters. If someone else were to
operate their remote transmitter while
you are programming your transmit-
ters, it is possible that their transmitter
code will be programmed into your
system, allowing them unauthorized
access to your vehicle. Alarm system The alarm system helps to protect your
vehicle and valuables from theft. The horn
sounds and the turn signal lights flash if
someone attempts to break into your vehi-
cle.
The system can be armed and disarmed
with the remote transmitter.
The system does no t operate when the
key is inserted into the ignition switch.
Your vehicle’s alarm system has been set
for activation at the time of shipment from
the factory. You can set the system for de-
activation yourself or have it done by your
SUBARU dealer.
„ System alarm operation The alarm system will give the following
alarms when triggered:
y The vehicle’s horn will sound and the
turn signal lights will flash for 30 seconds.
y If any door (or the rear gate/trunk lid) re-
mains open after the 30-second period,
the horn will continue to sound for a maxi-
mum of 3 minutes. If the door (or the rear
gate/trunk lid) is closed while the horn is
sounding, the horn will stop sounding with
a delay of up to 30 seconds.
The alarm is triggered by: y Opening a door, the rear gate or trunk
lid
y Physical impact to the vehicle, such as
forced entry (only vehicles with shock sen-
sors (dealer option))
„ Activating and deactivating
the alarm system To change the setting of your vehicle’s
alarm system for activation or deactiva-
tion, do the following.
1. Disarm the alarm system (see “Disarm-
ing the system” in this section).
2. Sit in the driver’s seat and shut all
doors (and the rear gate if your vehicle is
a Station wagon).
3. Turn the ignition switch to the “ON” po-
sition.
4. Hold down the UNLOCK side of the
driver’s power door locking switch, open
the driver’s door within the following 1 sec-
ond, and wait 10 seconds without releas-
ing the switch. The setting will then be
changed as follows:
If the system was pr eviously activated:
The odometer/trip meter screen displays
“AL oF” and the horn sounds twice, indi-
cating that the system is now deactivated.
If the system was prev iously deactivated:
The odometer/trip meter screen displays

Keys and doors
2-15
– CONTINUED –“AL on” and the horn sounds once, indi-
cating that the system is now activated.
NOTE You may have the above setting
change done by your SUBARU dealer.
„ If you have accidentally trig-
gered the alarm systemT To stop the alarm
Do any of the following operations:
y Insert the key in the door lock of the
driver’s door and turn it to the unlock posi-
tion.
y Press any button on the remote trans-
mitter.
y Turn the ignition switch to the “ON” po-
sition.
„ Arming the systemT To arm the system using remote
transmitter
1. Close all windows and the moonroof (if
so equipped).
2. Remove the key from the ignition
switch.
3. Open the doors and get out of the vehi-
cle.
4. Make sure that the engine hood (and
the trunk lid on the Sedan) are locked. 5. Close all doors (and the rear gate on
the Station wagon).
: Press to Arm the system.
: Press to Disarm the system.
6. Briefly press the “ ” button (for less than two seconds). All doors (and the rear
gate on the Station wagon) will lock, an
electronic chirp will sound once, the turn
signal lights will flash once, and the indica-
tor lights will start flashing rapidly. After
rapid flashing for 30 seconds (standby
time), the indicator lights will then flash
slowly (twice approximately every two
seconds), indicating that the system has
been armed for surveillance.
If any of the doors, (re ar gate or trunk lid)
is not fully closed, an electronic chirp
sounds five times, the turn signal lights
flash five times to alert you that the doors
(or the rear gate) are not properly closed.
When you close the door, the system will
automatically arm and doors will automat-
ically lock.
T To arm the system using power
door locking switches
1. Close all windows.
2. Remove the key from the ignition
switch.
3. Open the doors and get out of the vehi-
cle.
4. Make sure that the engine hood is
locked.
5. Close the doors (and the rear gate on
the station wagon) but leave only the driv-
er’s door or the front passenger’s door
open. 200918
200835

2-16 Keys and doors
6. Push the front side (“LOCK” side) of
the power door locking switch to set the
door locks.
7. Close the door. An electronic chirp will
sound once, the turn signal lights will flash
once and the indicator lights will start
flashing rapidly. After rapid flashing for 30
seconds (standby time), the indicator
lights will then flash slowly (twice approxi-
mately every two seconds), indicating that
the system has been armed for surveil-
lance.
NOTE y The system can be armed even if the
engine hood, the windows and/or
moonroofs are opened. Always make
sure that they are fully closed before
arming the system. y The 30-second standby time can be
eliminated if you prefer. Have it per-
formed by your SUBARU dealer.
y If your vehicle is a Sedan and you un-
lock the trunk usin g the remote trans-
mitter’s “ ” button with the alarm
system armed, the system will be tem-
porarily placed in a standby state. The
system will go back to the surveillance
state upon locking the trunk.
y The system is in the standby mode
for a 30-second period after locking the
doors with the remo te transm itter. The
security indicator light will flash at
short intervals during this period.
y If any of the following actions is done
during the standby period, the system
will not switch to the surveillance state.
y Doors are unlocked using the re-
mote transmitter.
y Any door (including the rear gate
of a Station wagon or the trunk of a
Sedan) is opened.
y Ignition switch is turned to the
“ON” position.
„ Disarming the system Briefly press the “ ” button (for less
than two seconds) on the remote transmit-
ter. The driver’s door will unlock, an elec-
tronic chirp will sound twice, the turn sig-
nal lights will flash twice and the indicator light will go off.
To unlock all other doors and the rear gate
(Station wagon), briefly press the “ ”
button a second time within 5 seconds.
NOTE If the interval betw een the first and sec-
ond presses of the “ ” button (for
unlocking of all of the doors and the
rear gate) is extreme ly short, the sys-
tem may not respond.
Or the system can be disarmed by the
following method, too.
y Insert the key in the door lock of the
driver’s door and turn it to the unlock
position.
T Emergency disarming
If you cannot disarm the system using the
transmitter (i.e. the transmitter is lost, bro-
ken or the transmitter battery is too weak),
you can disarm the system without using
the transmitter.
The system can be disarmed if you turn
the ignition switch from the “LOCK” to the
“ON” position with a registered key.
Insert the key in the door lock of the driv-
er’s door and turn it to the unlock position.
„ Valet mode
When you choose the valet mode, the
alarm system does not operate. In valet200897
LOCK

Keys and doors
2-17
– CONTINUED –mode, the remote transmitter is used only
for locking and unlocking the doors and
rear gate (Station wagon) and panic acti-
vation.
To enter the valet mode, change the set-
ting of your vehicle’s alarm system for de-
activation mode. (Refer to “Activating and
deactivating the ala rm system” in this sec-
tion.) The security indicator light will con-
tinue to flash once every three seconds in-
dicating that the syst em is in the valet
mode.
To exit valet mode, change the setting of
your vehicle’s alarm system for activation
mode. (Refer to “Activating and deactivat-
ing the alarm system” in this section.)
„ Passive armingWhen passive arming mode has been
programmed by the dealer, arming of the
system is automatic ally accomplished
without using the remote transmitter. Note
that in this mode, DOORS MUST BE
MANUALLY LOCKED.
T To enter the passive mode
If you wish to program the passive arming
mode, have it done by your SUBARU
dealer. T Arming the system
1. Turn the ignition switch to the “ON” po-
sition.
1) LOCK
2) ON
2. Turn the ignition switch from “ON” to “LOCK” position and remove the key from
the ignition switch.
3. Open the doors and get out of the vehi-
cle.
4. Before closing the doors, lock all doors
with the inside door lock levers.
5. Close the doors. The system will auto-
matically arm after one minute.
In the passive mode, the system can also
be armed with the remote transmitter or
with the power door locking switches. If
the remote transmitter or power door lock-
ing switch is used to lock the vehicle, arm-
ing will take place immediately regardless
of whether or not the passive mode has
been selected.In passive mode, the system will au-
tomatically activate the alarm but
WILL NOT automatically lock the
doors. In order to lock the doors you
must either lock them as indicated
in step 4 below or with the key once
they have been closed. Failure to
lock the doors manually will result
in a higher security risk.
2
1
200721 200704
