2006 SUBARU OUTBACK Owners Manual

2-2 Keys and doors Keys and doors
Keys
1) Master key
2) Submaster key
3) Valet key
4) Key number plate
5) Security ID plate
Three types of keys are provided for your
vehicle.
Master key, submaste r key and valet key.
The master key and submaster key fit all
locks on your vehicle.
y Ignition switch
y Driver’s door
y Glove box
y Trunk lid release lever
The valet key fits only the ignition switch and door locks. You can keep the trunk
and glove box locked when you leave your
vehicle and valet key at a parking facility.
„ Key number
1) Key number plate
2) Security ID plate
The key number is stamped on the key number plate attached to the key set.
Write down the key number and keep it in
another safe place, not in the vehicle. This
number is needed to make a replacement
key if you lose your key or lock it inside the
vehicle.
For information on making replacement
keys for vehicles with the immobilizer sys-
tem, refer to the “Immobilizer” section in
this chapter.4 5321
200700
Do not attach a large key holder or
key case to either key. If it bangs
against your knees while you are
driving, it could turn the ignition
switch from the ON position to the
ACC or OFF position, thereby stop-
ping the engine.
12 200701

Keys and doors
2-3
– CONTINUED –Immobilizer The immobilizer system is designed to
prevent an unauthorized person from
starting the engine. Only keys registered
with your vehicle’s immobilizer system
can be used to operate your vehicle. Even
if an unregistered key fits into the ignition
switch and can be turned to the “START”
position, the engine will automatically stop
after several seconds.
Each immobilizer key contains a tran-
sponder in which the key’s ID code is
stored. When a key is inserted into the ig-
nition switch and turned to the “ON” posi-
tion, the transponder transmits the key’s
ID code to the imm obilizer system’s re-
ceiver. If the transmitt ed ID code matches
the ID code registered in the immobilizer
system, the system allo ws the engine to
be started. Since the ID code is transmit-
ted and acted upon almost instantly, the
immobilizer system does not impede nor-
mal starting of the engine.
If the engine fails to start, pull out the key
once before trying again. (Refer to the “Ig-
nition switch” section [chapter 3].)
This device complies with Part 15 of
the FCC Rules and with RSS-210 of In-
dustry Canada. Operation is subject to
the following two co nditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including in-
terference that may cause undesired
operation.
Changes or modifications not express-
ly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
NOTE To protect your veh icle from theft,
please pay close attention to the fol-
lowing security precautions:
y Never leave your vehicle unattended
with its keys inside.
y Before leaving your vehicle, close all
windows and lock the doors and rear
gate (Stati on wagon).
y Do not leave spare keys or any
record of your key number in the vehi-
cle. „ Security ID plate
1) Key number plate
2) Security ID plate
The security ID is stamped on the security
ID plate attached to the key set. Write
down the security ID and keep it in another
safe place, not in the vehicle. This number
is needed to make a replacement key if
you lose your key or lock it inside the vehi-
cle.
This number is also needed for replace-
ment or repair of the engine control unit,
integrated unit, and combination meter.y Do not place the key under direct
sunlight or anywhere it may be-
come hot.
y Do not get the key wet. If the key
gets wet, wipe it dry with a cloth
immediately. 12 200701

2-4 Keys and doors
„ Security indicator light
The security indicator light deters potential
thieves by indicating that the vehicle is
equipped with an immobilizer system. It
begins flashing approximately 60 seconds
after the ignition switch is turned from the
“ON” position to the “ACC” or “LOCK” po-
sition or immediately after the key is pulled
out.
If the security indicator light does not
flash, the immobilizer system may be
faulty. If this occurs, contact your
SUBARU dealer as soon as possible.
In case an unauthorized key is used (e.g.
an imitation key), the security indicator
light comes on. NOTE Even if the security indicator light
flashes irregularly or its fuse blows
(the light does not flash if its fuse is
blown), the immobilizer system will
function normally.
„ Key replacement Your key number plate and security ID
plate will be required if you ever need a re-
placement key made. Any new key must
be registered for use with your vehicle’s
immobilizer system before it can be used.
Up to four keys can be registered for use
with one vehicle.
For security, all the keys registered with
your vehicle’s immobilizer system will
have their ID codes erased and re-regis-
tered when a new key is made. Therefore,
all of your vehicle’s keys must be present-
ed when a new key is registered. Any key
that is not re-registered when a new key is
made cannot be used after the other keys
are re-registered. For information on re-
placement keys and on the registration of
keys with your imm obilizer system, con-
tact your SUBARU dealer. Door locks „ Locking and unlocking from
the outside
To lock the driver’s door from the outside
with the key, turn the key toward the rear.
To unlock the door, turn the key toward
the front.
Lift the outside door handle to open an un-
locked door.200835
200836

Keys and doors
2-5
– CONTINUED –Locking without the key
1) Rotate the lock lever rearward.
2) Close the door.
To lock the door fr om the outside without
the key, rotate the lock lever rearward and
then close the door. Locking without the key
1) Push the power door locking switch for-
ward.
2) Close the door.
To lock the door from the outside using the
power door locking switch, push the
switch forward (“LOCK” side) and then
close the door. In this case, all closed
doors and the rear gate (Station wagon)
are locked at the same time.
Always make sure that all doors and the
rear gate are locked before leaving your
vehicle.
NOTE Make sure that you do not leave the key
inside the vehicle before locking the
doors from the outs ide without the key. „ Locking and unlocking from
the inside2 1
200837
LOCK
2 1
200838
Keep all doors locked when you
drive, especially when small chil-
dren are in your vehicle.
Along with the proper use of seat-
belts and child restraints, locking
the doors reduces the chance of be-
ing thrown out of the vehicle in an
accident.
It also helps prevent passengers
from falling out if a door is acciden-
tally opened, and intruders from un-
expectedly opening doors and en-
tering your vehicle.
200384

2-6 Keys and doors
To lock the door from the inside, rotate the
lock lever rearward.
To unlock the door from the inside, rotate
the lock lever forward.
The red mark on the lock lever appears
when the door is unlocked.
Pull the inside door handle to open an un-
locked door.
Always make sure that all doors and the
rear gate (Station wagon) are closed and
locked before starting to drive.
„ Battery drainage prevention
functionWhen a door or the rear gate (Station
wagon) is not completely closed and the
dome light, ignition switch light, and door open warning light remain illuminated as a
result, the lights are automatically turned
off by the battery drainage prevention
function after 10 minutes of illumination to
prevent the battery from going dead. The
operational/non-operational setting of this
function can be changed by a SUBARU
dealer. Contact the nearest SUBARU
dealer if you would like to change the set-
ting.
NOTE y When leaving the vehicle, please
make sure that all doors and the rear
gate (Station wago n) are completely
closed.
y The battery drainage prevention
function does not operate while the key
is in the ignition switch. Power door locking switches
Driver’s switch
Front passenger’s switch200385LOCK
200386
200839

Keys and doors
2-7
– CONTINUED –All doors and the rear gate (Station wag-
on) can be locked and unlocked by the
power door locking switches located at the
driver’s side and the front passenger’s
side doors.
To lock all doors (including the rear gate of
a Station wagon), push the switch to the
front (“LOCK”) position.
To unlock all doors (including the rear
gate of a Station wagon), pull the switch to
the rear position.
When you close the doors after you set
the door locks, the doors remain locked.
NOTE Make sure that you do not leave the key
inside the vehicle before locking the
doors from the outside using the pow-
er door locking switches.
„ Key lock-in prevention func-
tionThis function prevents the doors from be-
ing locked with the key still in the ignition
switch.
T Behavior with key lock-in preven-
tion function operative
With the driver’s door open, the doors are
automatically kept unlocked even if the
door locking switch is pushed to the front (“LOCK”) position.
T Behavior with key lock-in preven-
tion function non-operative
y If the lock lever is turned to the rear
(“LOCK”) position with the driver’s door
open and the driver’s door is then closed
with the lock lever in that position, the driv-
er’s door is locked.
y If the spare key is used to lock the driv-
er’s door from the outside of the vehicle,
the door is locked.
This function’s operative/non-operative
setting can be changed by a SUBARU
dealer. Contact a SUBARU dealer for de-
tails.
NOTE When leaving the vehicle, make sure
you are holding the key before locking
the doors. Remote keyless entry sys-
tem
This device complies with Part 15 of
the FCC Rules and with RSS-210 of In-
dustry Canada. Operation is subject to
the following two co nditions: (1) This
device may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including in-
terference that may cause undesired
operation.
Changes or modifications not express-
ly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
Two transmitters are provided for your ve- y Do not expose the transmitter to
severe shocks, such as those ex-
perienced as a result of dropping
or throwing.
y Do not take the transmitter apart
except when replacing the bat-
tery.
y Do not get the tran smitter wet. If it
gets wet, wipe it dry with a cloth
immediately.

2-8 Keys and doors
hicle.
The keyless entry system has the follow-
ing functions.
y Locking and unlocking the doors (and
rear gate on the Station wagon) without a
key
y Locking and unlocking the doors (and
trunk lid on the Sedan) without key
y Unlocking the rear gate on the Station
wagon without key
y Unlocking the trunk lid on the Sedan
without key
y Sounding a panic alarm
y Arming and disarming the alarm sys-
tem. See the next section “Alarm system”
for detailed information.
The operable distance of the keyless entry
system is approximately 30 feet (10
meters). However, this distance will vary
depending on environmental conditions.
The system’s operable distance will be
shorter in areas near a facility or electronic
equipment emitting strong radio waves
such as a power plant, broadcast station,
TV tower, or remote controller of home
electronic appliances.
The keyless entry system does not oper-
ate when the key is inserted in the ignition
switch. : Trunk lid/rear gate unlock button
: Unlock/disarm button
: Lock/arm button
A: Panic button
1) Front
2) Back „ Locking the doors
Press the “ ” button to lock all doors
and rear gate (Station wagon). An elec-
tronic chirp will sound once and the turn
signal lights will flash once.
If any of the doors (o r the rear gate/trunk
lid) is not fully closed, an electronic chirp
will sound five times and the turn signal
lights will flash five times to alert you that
the doors (or the rear gate/trunk lid) are
not properly closed. When you close the
door, it will automatically lock and then an
electronic chirp will sound once and the
turn signal lights will flash once. 200898A12
200899

Keys and doors
2-9
– CONTINUED –„ Unlocking the doors
Press the “ ” button to unlock the driv-
er’s door. An electronic chirp will sound
twice and the turn signal lights will flash
twice. To unlock all doors and the rear
gate (Station wagon), briefly press the
“ ” button a second time within 5 sec-
onds.
NOTE If the interval between the first and sec-
ond presses of the “ ” button (for
unlocking of all of the doors and the
rear gate) is extremely short, the sys-
tem may not respond. „ Unlocking the trunk lid/rear
gate
T Sedan
The trunk lid un locks when the “ ”
button is pressed continuously for at least
2 seconds. An electr onic chirp will sound
twice and the turn signal lights will flash
twice.
T Station wagon
Pressing the “ ” button opens the
rear gate.
An electronic chirp will sound twice and
the turn signal lights will flash twice.
„ Illuminated entry
The interior (dome) light will illuminate
when the “ ” button is pressed. This light stays illuminated for approximately
30 seconds if any of the doors or the rear
gate (Station wagon) is not opened.
If the “ ” button is pressed before 30
seconds have elapsed, this light will go
out. The interior light must be set to the
middle position in order for this function
to operate.
A SUBARU dealer can change the illumi-
nation period setting of the interior light in
accordance with your preference. Contact
the nearest SUBARU dealer for details.
„ Vehicle finder function Use this function to find your vehicle
parked among many vehicles in a large
parking lot. Provided you are within 30
feet (10 meters) of the vehicle, pressing
the “ ” button three times in a five-sec-
ond period will cause your vehicle’s horn
to sound once and its turn signal lights to
flash three times.
NOTE If the interval between presses is too
short when you press the “ ” button
three times, the system may not re-
spond to the signal s from the remote
transmitter.200900
200901
