Practical Tips, Minor Repairs
337
10.Pull off vent hose D on the battery.
11.Unscrew screw E of the battery fastening
plate.
Remove battery fastening plate.12.Unscrew screw F of the bracket.
Remove bracket.
Danger!
Danger of caustic burns, explosion and risk
of injury. Contact with battery acid will burn
your eyes and skin.
fLift battery out of the battery box using the
folding handles.Try not to tip the battery.
13.Lift battery out of the battery box using the
folding handles. Try not to tip the battery.Installing the battery
1. Danger of caustic burns!
Place battery in the battery box without tipping
it if possible.
2. Push battery forwards and toward the center
of the vehicle until it is under the stops G.
f f f

338
Practical Tips, Minor Repairs fAlways tighten all screws to the
prescribed torque.
3. Fasten the battery fastening plate with screw
E. Tightening torque 15 ftlb. (20 Nm).
4. Fasten the bracket with screw F. Tightening
torque 6.5 ftlb. (9 Nm).
5.Important: Do not forget to connect vent
hose D to the battery.
Make sure that both ends of the vent hose are
properly connected.
Danger!
Danger of explosion and injury and risk of
short circuit and damage to the alternator
and electronic control units.
fConnect the positive cable first, and then the negative cable.
6. Connect the positive cable.
7. Connect the negative cable.
8. Put on the battery-box cover carefully.
Ensure that the ventilation duct is properly in-
serted.
9. Engage the 4 clamps C on the battery-box lid
and close them with a screwdriver.10.With the seat tilted back, use the fore-and-aft
adjustment to move the seat back.
Tilt the seat forward.
11.Clean threaded holes on the seat mounting.
12.Use only new bolts B (the bolts are micro-en-
capsulated).
Insert bolts B and screw them in a few turns by
hand.
Tighten bolts.
Tightening torque 37 ftlb. (50 Nm).
13.Clip in front seat trim.
14.Move seat to normal position.

Practical Tips, Minor Repairs
339
Removing and installing auxiliary battery
Danger!
Danger of explosion and injury and risk of
short circuit and damage to the alternator
and electronic control units.
fHave the battery removed and installed only by
a qualified professional.
fDo not disconnect battery while the engine is
running.
fDisconnect and connect the battery only with
the greatest care. Danger of short circuit and explosion.
Note
The general information contained in the chapter
on the battery applies to the battery under the driv-
er’s seat and the battery in the luggage compart-
ment.
fPlease observe the chapter “CHARGE STATE”
on Page 332.The auxiliary battery is located in the luggage
compartment under the cargo area floor.
Any subwoofers or collapsible spare wheels that
may be in the vehicle must be removed before the
battery is removed.
Removing the collapsible spare wheel
1. Take out rotary knob A and put it on bolt B.
2. Unscrew the bolt and take out the collapsible
spare wheel.
Installing the collapsible spare wheel
1. Insert collapsible spare wheel.
2. Screw in bolt B.
3. Place rotary knob A on bolt B and tighten it.
f f f

340
Practical Tips, Minor Repairs Removing subwoofer
1. Withdraw the ignition key.
Remove the Porsche Entry & Drive control unit
from the ignition lock in vehicles that contain
this feature.
Please observe the chapter “REMOVING THE
CONTROL UNIT FROM THE IGNITION LOCK” on
Page 70.
2. Remove any existing tire sealant C.3. Undo the two fastening nuts D.
4. Unscrew screw E.
5. Disconnect plug connection F.6. Remove subwoofer housing.
Installing subwoofer
1. Insert subwoofer housing.
2. Connect plug connection F.
3. Tighten the two fastening nuts D.
4. Tighten screw E.
5. Place any existing tire sealant C in recess.

Practical Tips, Minor Repairs
341
Removing battery
1. Withdraw the ignition key.
Remove the Porsche Entry & Drive control unit
from the ignition lock in vehicles that contain
this feature.
Please observe the chapter “REMOVING THE
CONTROL UNIT FROM THE IGNITION LOCK” on
Page 70.
2. Undo the 4 fastening nuts of the battery box.3. Open the 4 clamps of the battery-box cover.
4. Remove the battery-box cover.
Danger!
Danger of explosion and injury and risk of
short circuit and damage to the alternator
and electronic control units.
fDisconnect the negative cable first, and then the positive cable.
5. Disconnect the negative cable.
6. Disconnect the positive cable.7. Pull off vent hose G on the battery.
8. Undo fastening nut H of battery fastening
plate.
9. Remove battery fastening plate.
10.Lift battery out of the battery box using the
folding handles.

342
Practical Tips, Minor Repairs Installing the battery
1. Place battery in the battery box.
2.Important: Do not forget to connect vent
hose G to the battery.
Make sure that both ends of the vent hose are
properly connected.
Danger!
Danger of explosion and injury and risk of
short circuit and damage to the alternator
and electronic control units.
fConnect the positive cable first, and then the negative cable.3. Connect the positive cable.
4. Connect the negative cable.
5. Tighten battery fastening plate with fastening
nut H.
6. Put on the battery-box cover carefully.
7. Engage the 4 clamps on the battery-box cover
and close them.
8. Tighten the 4 fastening nuts of the battery box.

Practical Tips, Minor Repairs
343
Emergency Starting with Jumper
CablesIf the battery is discharged, e.g. in winter or after
the car has been parked for a long time, the bat-
tery of another car can be used for starting with
the help of jumper cables.
Make sure the voltage of both batteries is the
same.
The capacity (Ampere hours, Ah) of the booster
battery must not be substantially less than that of
the discharged battery.The discharged battery
must be correctly connected to the vehicle's elec-
trical system.
fPlease observe the chapter “BATTERY” on
Page 332.
Note
Do not try to start the car by pushing or towing.
Damage to the catalytic converters and other
components of the car may result.
Danger!
Risk of damage and serious personal injury
due to short circuit.
fUse only jumper cables of adequate diameter
cross-section and fitted with completely insu-
lated alligator clips.
fFollow all warnings and instructions of the
jumper cable manufacturer.
fWhen connecting jumper cables, make sure
that they cannot get caught in any moving
parts in the engine compartment.
The jumper cables must be long enough so
that neither vehicles nor cables touch another.
fThe vehicles must not be in contact, otherwise
current might flow as soon as the positive ter-
minals are connected.
fThe cable clamps must not be allowed to con-
tact each other when one end of the jumper ca-
bles are connected to a battery.
fCarefully ensure that tools or conductive jewel-
ery (rings, chains, watch straps) do not come
into contact with the positive jumper cable or
the positive battery post.
fImproper hook-up of jumper cables can ruin
the alternator.
Danger of caustic burns.
fDo not lean over the battery.Danger of gas explosion.
fImproper use of booster battery to start a ve-
hicle may cause an explosion, resulting in se-
vere personal injuries.
fKeep sources of ignition away from the bat-
tery, e.g. open flame, burning cigarettes or
sparking due to cable contact or welding work.
fA discharged battery can freeze even at
14°F (−10°C). Before connecting jumper ca-
bles, a frozen battery must be thawed out.

344
Practical Tips, Minor Repairs
Connecting jumper cablesAlways observe the sequence below:
1. Remove cover A.
2. Open the cap of the positive terminal for jump
starting(+).
3. Attach the positive lead first to the positive
terminal for jump starting (+), then to the posi-
tive terminal of the donor battery.
4. Connect the negative lead first to the negative
terminal of the donor battery, then to the
grounding point for jump starting (–).
+ = Positive terminal for jump starting
– = Grounding point for jump starting5. Run the engine of the donor car at a higher
speed.
6. Start the engine.
An attempted start using jumper cables should
not last more than 15 seconds. Then allow a
waiting period of at least one minute.
7. Disconnect the negative jumper cable from the
ground point for jump starting (–) first, then
from the negative terminal of the donor bat-
tery.8. Disconnect the positive jumper cable from the
positive terminal of the donor battery first,
then from the positive terminal for jump start-
ing (+).
9. Close the cap of the positive terminal for jump
starting (+).
