2006 PORSCHE CAYENNE TURBO PORSCHE CAYNNE TURBO 2006 1.G Owners Manual

Practical Tips, Minor Repairs
361
2. Screw in towing hook B as far as the stop (left-
hand thread) and tighten hand-tight.
Pulling vehicle onto flat bed1. Position wooden ramps at the base of the flat
bed to reduce the angle of the pull.
2. Reel in the hoist cable and check the underside
of the vehicle for any interference.
Tying down vehicle on flat bed1. Carefully feed towing straps through the open-
ing in the rear wheels.
Make sure metal parts of straps do not dam-
age rim. Make sure the strap is flat over the
rim bead.
Make sure brake backing plate is not dam-
aged.
2. Secure straps to rear of flat bed.
3. Reel in hoist cable only far enough to tension
tie-down straps.
f f f

362
Practical Tips, Minor Repairs 4. Carefully feed towing straps through the open-
ing in the front wheels.
Make sure metal parts of straps do not dam-
age rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not dam-
aged.
5. Secure straps to front of flat bed.
6. Release tension on hoist cable, but do not dis-
connect. Use hoist cable as a safety cable.
Recovering the vehicleDepending on the vehicle equipment, the spare-
wheel well contains one or two towing lugs.
fWhen recovering the vehicle, always use two
towing lugs if possible.
Screw in the towing lugs only at the front or
rear.
Never screw them in so that one towing lug is
at the front and one is at the back.

Vehicle Identification, Technical Data
363 Vehicle Identification, Technical Data
Vehicle Identification................................... 364
Engine Data ............................................... 366
Transmission ............................................. 367
Tires, Rims, Tracks .................................... 368
Tire Pressures, Cold................................... 370
Capacities ................................................. 371
Weights ..................................................... 372
Driving Performance................................... 373
Dimensions ................................................ 374
Ground Clearance ...................................... 375

364
Vehicle Identification, Technical Data
Vehicle IdentificationWhen ordering spare parts or making inquiries,
please always quote the vehicle identification
number.Data bankThe data bank is located in the passenger com-
partment below the steering wheel. It contains all
important data about your car.This label contains the following information:
1. Vehicle Identification No.
2. Type/Type description
3. Engine code/Transmission code
4. Paint No./Interior
5. Optional equipment
A duplicate of this label is in your Maintenance
Booklet.
Note
The data bank cannot be reordered when lost or
damaged.
Vehicle identification numberIn accordance with Federal Safety Regulations,
the vehicle identification number of your car is lo-
cated at the bottom left of the windshield frame
and can be seen from the outside and in the lug-
gage compartment on the right in front of the tool
box.

Vehicle Identification, Technical Data
365
Safety compliance stickerThe safety compliance sticker is your assurance
that your new Porsche complies with all applicable
Federal Motor Vehicle Safety Standards which
w e re i n e f f e c t a t t h e t ime the vehicle was manufac-
tured.
The sticker also shows the month and year of pro-
duction and the vehicle identification number of
your car (perforations) as well as the Gross Vehi-
cle Weight Rating and the Gross Axle Weight Rat-
ing.
Tire pressure plateThe tire pressure plate is fitted to the driver's
door.

366
Vehicle Identification, Technical Data
Engine Data
Cayenne Turbo Increased performance
Cayenne Turbo
Ty p e
Four-cycle spark-ignition engine
Number of cylinders 8Bore
3.66 in. (93 mm)
Stroke 3.27 in. (83 mm)Displacement
275 cu. in. (4511 cm
3)
Net-horsepower, SAE J 1349 450 HP (331 kw) 500 HP (368 kW )at engine speed
6000 rpm
5500 - 6000 rpm
Net. torque, SAE J 1349 460 ftlb. (620 NM) 518 ftlb. (700 Nm )
at engine speed
2250 - 4750 rpm
Maximum permitted engine speed 6500 rpm

Vehicle Identification, Technical Data
367
TransmissionTransmission ratio1st gear
4.15 : 1
2nd gear 2.37 : 1
3rd gear
1.56 : 1
4th gear 1.16 : 1
5th gear
0.86 : 1
6th gear 0.69 : 1
Reduction gear
2.70 : 1
Reverse gear 3.39 : 1
Final drive ratio
3.70 : 1

368
Vehicle Identification, Technical Data
Tires, Rims, Tracks
Tires Wheel Rim offset Track
front/rear front/rear front rear
Summer tires
255/55 R 18 109 Y XL
2, 4)

8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
275/45 R 19 108 Y XL 9 J x 19 60 mm 64.6 in. (1641 mm) 65.2 in. (1656 mm)
275/40 R 20 106 Y XL
9 J x 20
60 mm
64.6 in. (1641 mm)
65.2 in. (1656 mm)
275/40 R 20 106 Y XL 9 J x 19/10 J x 20 60mm / 55 mm 64.6 in. (1641 mm) 65.6 in. (1666 mm)
Winter tires
235/60 R 18 107 H XL
1, 4)

8 J x 18
57 mm
64.8 in. (1647 mm)
64.8 in. (1662 mm)
255/55 R18 109 V XL
2, 4)
8 J x 18 57 mm 64.8 in. (1647 mm) 65.4 in. (1662 mm)
255/50 R19 107 V XL
3)
9 J x 19
60 mm
64.6 in. (1641 mm)
65.2 in. (1656 mm)
All-Season
255/55 R 18 109 V XL
2, 4)

8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
All-Terrain
235/60 R 18 107 T XL
1, 4)

8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
The load capacity coefficient (e.g. “106”) and maximum speed code letter (e.g. “T”) for permitted top speed are
minimum requirements.
When fitting new tires or changing tires: Please observe the chapter “TIRES/WHEELS” on Page 285.
Tire and rim sizes
Extensive tests are performed before specific tires and wheels are approved by Porsche. Your Porsche dealer
has information about approved tires and wheels and is happy to assist you.
If aftermarket tires and/or wheels are installed which are not approved by Porsche, the vehicle’s roadability and
handling characteristics might be impaired. Since Porsche has no data on such combinations, Porsche cannot
stand behind the safety or durability of these aftermarket combinations.
Please observe the chapter “SNOW CHAINS” on Page 296.
Collapsible spare wheel195/75 18 6.5 J x 18
