2006 PORSCHE CAYENNE TURBO PORSCHE CAYNNE TURBO 2006 1.G Owners Manual

Controls, Safety, Instruments
121
Factory settingsMAIN MENU > SETTINGS > FACTORY SETTINGS
All settings made (Clock, Comfort, Lights, Units,
Language) can be reset to the factory settings.Resetting
fSelect RESET with the rocker switch.
fPress RESET switch.
Note
This will delete all personal settings selected up to
this point.

122
Controls, Safety, Instruments
Warning Lights and Warning MessagesIf a warning message appears, always refer to the corresponding chapters in this Owner's Manual.
Warning messages are issued only if all measurement preconditions are met.
Therefore, check all fluid levels regularly – in particular, always check the engine oil level after refuelling.
Instrument
panelMulti-purpose
displayText display Meaning/measures
Steering faulty Steering lock engaged.
Have the fault remedied at an authorized Porsche dealer.
Ignition lock faulty Do not continue driving.
Have the fault remedied at an authorized Porsche dealer.
System fault – Workshop Have the fault remedied at an authorized Porsche dealer.
Key not recognised in vehicle Make sure that you have the remote control with you.
Turn ignition key to left for
2 secondsEngage the steering lock.
Key: replace battery Replace the remote-control battery.
Move the steering wheel Turn the steering wheel so that the steering wheel lock can
engage/disengage.
Key not found Make sure that you have the remote control with you.
Switch selector lever to position “P”.The vehicle could roll away. The ignition key can be withdrawn
only in selector lever position P.
Apply the brake Apply the brake when starting.
Move selector lever to position
“P” or “N”The vehicle can be started only in position P or N.
Immobiliser active Have the fault remedied at an authorized Porsche dealer.

Controls, Safety, Instruments
123
Check left cornering light Check bulb.
Check right cornering light Check bulb.
Check low beam Check bulb.
Check trailer lights Check bulb.
Check direction indicatorsCheck turn signal bulb.
Check brake lights Check bulb.
Check high beam Check bulb.
Check number plate light Check bulb.
Check fog lights Check bulb.
Check reversing lights Check bulb.
Check tail lights Check bulb.
Check front side lights Check bulb.
Check headlight beam adjustment Have the fault remedied at an authorized Porsche dealer.
Daytime driving lights off Daytime driving lights switch off when the engine is shut off.
Switch on lights if necessary.
Airbag faulty Have the fault remedied at an authorized Porsche dealer.
Passenger airbag switched onAdvanced Airbag - displays when the passenger's airbag
switches on or displays for approx. 10 seconds with the passen-
ger's airbag switched on after switching on the ignition
Instrument
panelMulti-purpose
displayText display Meaning/measures

124
Controls, Safety, Instruments
Passenger's airbag deactivated Advanced Airbag - displays when the passenger's airbag deacti-
vates or displays for approx. 10 seconds with the passenger's
airbag deactivated after switching on the ignition
Checking passenger's seat settings Weight sensing is impaired on the passenger's seat (Advanced
Airbag).
Correct the seating position, set the backrest upright, do not
support weight on the armrests, or lift on the handles.
Safety belt Fasten safety belt.
Warning – Flat tire – Check tires Stop in a suitable place and check the tires. Change wheel if
necessary.
Check spare wheel – Required pressure:
50 psi/3,4 barAppears about every 6 months.
Check if the pressure of the mounted spare wheel matches the
required pressure, as it is not monitored electronically.
Tire pressure too low – Add air System detects a pressure loss of at least 2,9 psi/0,2 bar.
Correct tire pressure at the next opportunity.
Collapsible spare wheel/sealing set
max. 50 mph (80 km/h)Observe maximum permitted speed.
Collapsible spare wheel/51 psi/3,5 bar
max. 50 mph (80 km/h)Information on driving with a collapsible spare wheel.
Observe maximum speed of max 50 mph or 80 km/h and
required pressure of 51 psi or 3,5 bar.
System not activeIndication when spare wheel or collapsible spare wheel is used
or tire pressure monitoring is faulty.
Consult a qualified specialist workshop.
Select new set of wheels in the Tire pressure menu after chang-
ing the wheels.
System not active – Brief disturbance External interference of excessive temperature at the wheel
transmitters. System will reactivate itself.
Instrument
panelMulti-purpose
displayText display Meaning/measures

Controls, Safety, Instruments
125
System not active –
Too many wheel transmittersTire pressure monitoring detects more than 4 wheel transmit-
ters (winter wheels in the luggage compartment, for example).
Tire pressure monitoring will reactivate itself after the additional
wheel transmitters have been removed.
No monitoring – System learning After the tire type and size are selected in the tire pressure
menu, the system re-learns the tires.
Wheel change? Check settings Display after a wheel change without changed settings in the tire
pressure menu. Select tire type and size.
When vehicle stops: Hit selection Displayed after a flat tire if the system was not informed about
the work performed.
Make a selection on the multi-purpose display when the vehicle
is stationary.
Monitoring off Tire pressure monitoring was intentionally deactivated.
Tire pressure monitoring can be switched on or off on the
multi-purpose display.
Engine temperature too high Switch engine off and let it cool.
Check coolant level. Add coolant if necessary.
Check coolant level Switch engine off and let it cool.
Check coolant level. Add coolant if necessary.
Battery/generator warning Stop in a suitable place and switch engine off. Do not continue
driving.
Have the fault remedied at an authorized Porsche dealer.
Starting engine The battery discharges if the engine is not running and loads are
switched on.
Start the vehicle or switch the loads off.
Electrics – Loads – Switch-off Vehicle electrical system is overloaded. Certain loads (e.g.
heated rear window, seat heating) will be switched off.
Please refuel
Topping up washer fluid
Instrument
panelMulti-purpose
displayText display Meaning/measures

126
Controls, Safety, Instruments
Oil level monitoring – Failure – Workshop Have the fault remedied at an authorized Porsche dealer.
Checking the oil level
Oil pressure too low Immediately stop in a suitable place and switch engine off.
Do not continue driving.
Check engine oil level. Add oil if necessary.
Do not continue driving if the warning light comes on even when
the oil level is correct. Have the fault remedied at an authorized
Porsche dealer.
Service in 1864 mls (3000 km)Service indicator
Bring the vehicle in for service no later than after the distance
shown has been covered. However, it is the intervals in the
„Maintenance” booklet that are decisive.
Service nowService indicator
Have your vehicle serviced at an authorized Porsche dealer.
Brake pads – Workshop Have the brake pads replaced at an authorized Porsche dealer
without delay.
Warning – Brake circuit division Stop immediately in a suitable place. Do not continue driving.
Have the fault remedied at an authorized Porsche dealer.
ABS failure – WorkshopDrive carefully. Have the fault remedied at an authorized
Porsche dealer.
PSM failure – WorkshopDrive carefully. Have the fault remedied at an authorized
Porsche dealer.
Warning – Brake fluid level Stop immediately in a suitable place. Do not continue driving.
Have the fault remedied at an authorized Porsche dealer.
Parking brake Parking brake not released.
PSM onPorsche Stability Management was switched on.
Instrument
panelMulti-purpose
displayText display Meaning/measures

Controls, Safety, Instruments
127
PSM offPorsche Stability Management was switched off.
PHC failure The Hillholder and the Porsche Down-Hill Assistant are not avail-
able.
Brake booster faulty Greater braking pedal force necessary. Drive carefully to the
nearest authorized Porsche dealer.
Sport shock absorber Current setting of Porsche Active Suspension Management.
Normal shock absorber Current setting of Porsche Active Suspension Management.
Comfort shock absorber Current setting of Porsche Active Suspension Management.
Warning – Air suspension Stop in a suitable place. Do not continue driving.
Have the fault remedied at an authorized Porsche dealer.
Air suspension faulty – Workshop Drive carefully to the nearest authorized Porsche dealer.
Spare wheel fillingCollapsible spare wheel being filled with level-control
compressor.
Do not drive off!
Control off Level control has been switched off (to jack up the vehicle).
Not permissible The prerequisites for setting the desired level have not been
met.
Pressure accumulator charging Level control temporarily unavailable.
Warning - off-road anti-roll bar The anti-roll bar cannot be engaged; the system is faulty. Drive
carefully to the nearest workshop. Have the fault remediesd at
an authorized Porsche dealer as soon as possible.
Off-road anti-roll bar faulty The anti-roll bar cannot be disengaged. Have the fault reme-
diesd at an authorized Porsche dealer.
Instrument
panelMulti-purpose
displayText display Meaning/measures

128
Controls, Safety, Instruments
Off-road anti-roll bar disengaged,
max. 30 mph (50 km/h)The anti-roll bars cannot be disengaged. Have the fault reme-
diesd at an authorized Porsche dealer.
Not permissible The prerequisites for disengaging the anti-roll bars have not
been met.
Only possible with reduction Disengagement of the anti-roll bars is only possible with
Low Range engaged.
All-wheel drive system faulty Have the fault remedied at an authorized Porsche dealer.
Shifting not possible,
Speed too highWhen changing between Low Range and High Range, the limit
speed (off-road shifting) must not be exceeded.
Possible only in neutral with brake
appliedThe vehicle must be stationary, the footbrake must be applied
and the selector lever must be in position N when changing
between Low Range and High Range.
Warning – Parking lock!
Operate footbrake.Do not continue driving. Apply the parking brake.
Have the fault remedied at an authorized Porsche dealer.
Spare wheel not locked.
Lock spare wheel bracket properly.
Driver’s door open
All unlocked doors and lids are displayed when the vehicle
exceeds 2 mph (3 km/h).
Passenger’s door open
All unlocked doors and lids are displayed when the vehicle
exceeds 2 mph (3 km/h).
Rear left door open
All unlocked doors and lids are displayed when the vehicle
exceeds 2 mph (3 km/h).
Rear right door open
All unlocked doors and lids are displayed when the vehicle
exceeds 2 mph (3 km/h).
Instrument
panelMulti-purpose
displayText display Meaning/measures
