2006 MERCEDES-BENZ SLK55AMG Owner's Manual

392 Practical hintsWhere will I find...?
In case of a flat tire, you may temporarily
use the spare wheel with collapsible tire
when observing the following restrictions:

Do not exceed a vehicle speed of
50 mph (80 km/h).


Drive to the nearest tire repair facility
to have the flat tire repaired or
replaced as appropriate.


Do not operate vehicle with more than
one spare wheel with collapsible tire
mounted.
For more information, see “Rims and tires”
(
page 439).
Spare wheel bolts
1Wheel bolt for light alloy rims
2Wheel bolt for spare wheel with
collapsible tire (located under plastic
cover on the outside of spare wheel
rim)
Warning!
G
The dimensions of the spare wheel with col-
lapsible tire are different from those of the
road wheels. As a result, the vehicle han-
dling characteristics change when driving
with a spare wheel with collapsible tire
mounted.
The spare wheel with collapsible tire should
only be used temporarily, and should be re-
placed with a regular road wheel as quickly
as possible.

393 Practical hints
Where will I find...?
!
Wheel bolts2 must be used when
mounting the spare wheel with
collapsible tire. The use of any wheel
bolts other than wheel bolts2 for the
spare wheel with collapsible tire will
physically damage the vehicle’s
brakes. Warning!
G
Make sure to use the original length wheel
bolts when remounting the original wheel
after it has been repaired.

394 Practical hintsUnlocking/locking in an emergencyUnlocking the vehicle
If you cannot unlock the vehicle with the
SmartKey, open the driver’s door and the
trunk using the mechanical key. Removing the mechanical key
1Mechanical key locking tab
2Mechanical key

Move locking tab1 direction of arrow.

Slide mechanical key2 out of the
housing.Unlocking the driver’s door
1Unlocking

Insert the mechanical key into the
driver’s door lock until it stops.

Turn the mechanical key counterclock-
wise to position1.
The driver’s door is unlocked.
iUnlocking and opening the driver’s
door and/or the trunk with the me-
chanical key will trigger the anti-theft
alarm system.
To cancel the alarm, do one of the
following:

Press buttonŒor‹on the
SmartKey.


Insert the SmartKey in the starter
switch.

395 Practical hints
Unlocking/locking in an emergency
Unlocking and opening the trunk
A minimum height clearance of
5.78 ft (1.76 m) is required to open the
trunk lid.
The trunk lid lock is located next to the
handle above the rear license plate recess.Trunk lid lock1Unlocking in an emergency

Fully insert the mechanical key into the
trunk lid lock.

Turn the mechanical key counterclock-
wise to position1 until it stops,
and simultaneously

pull the trunk lid handle and lift lid.

Turn the mechanical key back and re-
move it from the trunk lid lock.
Locking the vehicle
If you cannot lock the vehicle with the
SmartKey, do the following:
Close the passenger door and the trunk
lid.

Press the central locking switch in the
upper part of the center console
(page 102).

Check to see whether the locking knob
on the passenger door has moved
down.

If necessary, push it down manually.
The passenger door is locked.

Exit the vehicle and close the driver’s
door.
!Always make sure there is sufficient
overhead clearance.


396 Practical hintsUnlocking/locking in an emergency1Locking
Insert the mechanical key into the
driver’s door lock until it stops.

Turn the mechanical key clockwise to
position1.
The driver’s door is locked.Manually unlocking the gear selector
lever (automatic transmission*)
In case of power failure, the gear selector
lever can be manually unlocked, e.g. to tow
the vehicle.
1Gear selector lever cover
2Release

Insert flat, blunt object (e.g. screwdriv-
er) into the left edge of cover1 at the
position indicated by the arrows.

Loosen cover1 using this object.

Using your hands, pull cover1 out
and remove.

Push down and hold release2 in di-
rection of arrow.

Simultaneously move gear selector le-
ver out of positionP.
The gear selector lever is unlocked
now.iThe gear selector lever is locked again
as soon as you place it in positionP
again.


397 Practical hints
Opening/closing in an emergency
Opening/closing in an emergency
Raising retractable hardtop manuallyWarning!
G
If the retractable hardtop does not com-
pletely open or close, the roof hydraulics will
lose pressure and the retractable hardtop is
lowered

after approximately 7 minutes when the
ignition is switched on


after approximately 15 seconds when
the ignition is switched off
Shortly before the hardtop is lowered, a
warning will sound. In the multifunction dis-
play you will seeK and the message
Retractable roof being opened
.


Properly lock retractable hardtop before
continuing to drive (
page 252).
Warning!
G
Manually closing the retractable hardtop is a
complicated and technically demanding pro-
cedure and should only be performed by an
authorized Mercedes-Benz Center or quali-
fied technician. Attempting to manually
close the retractable hardtop may cause
damage to the retractable hardtop and/or
personal injury.
Warning!
G
To prevent possible accidents, drive the ve-
hicle only with the retractable hardtop either
completely closed and locked, or fully low-
ered into its storage compartment.

398 Practical hintsReplacing SmartKey batteriesIf the batteries in the SmartKey are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an autho-
rized Mercedes-Benz Center.Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen inserting the batteries, make
sure they are clean and free of lint.
When replacing batteries, always re-
place both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.

399 Practical hints
Replacing SmartKey batteries
SmartKey
Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove mechanical key1
(page 394).
1Mechanical key
2Slide
3Battery compartment

Insert mechanical key1 in direction
of arrow in side opening.

Using mechanical key1, push gray
slide2 to unlatch battery
compartment3.

Pull battery compartment3 out of the
housing in direction of arrow.

Remove the discharged batteries in di-
rection of arrow.
4Battery
5Contact spring

Using a lint-free cloth, insert new
batteries4 under contact spring5
with the positive terminal (+) facing up.

Return battery compartment2 into
the housing until it locks into place.

Slide mechanical key1 back into the
SmartKey.

Check the operation of the SmartKey.
