2006 MERCEDES-BENZ SLK55AMG Owner's Manual

216 Controls in detailAudio systemSelecting a station
The following options are available:

Selecting a station using the selected
category (
page 217).


Tuning via station presets
(page 216).


Tuning via scan search (
page 217).


Tuning via manual channel input
(page 216).


Tuning via the program category list
(page 216).
Tuning via station presets
Ten satellite radio station presets are
available.
You can access the presets via number
keys.Accessing via number keys

Enter number of preset you wish to
select, e.g. 1.
The radio plays the station stored
under this number and the PTY function
changes to the category corresponding
to the station.
Tuning via manual channel input
Example: tuning in channel 16

Press *.
Input line appears in the main radio
menu.

Use number keys to enter desired
channel within 8 seconds,
e.g.16.
The system tunes to channel 16.
The station you have selected begins to
play.
Tuning via the program category list
The category list contains all currently
receivable categories of programs. It is
arranged alphabetically.iYou can only enter available channel
numbers.

217 Controls in detail
Audio system


Selecting a category
Press
PTY
soft key.
The current PTY category of the
station is displayed.

Press
<<<
or
>>>
soft key.
This switches between the
individual categories.
When changing the category, the
channel selected last in the new
category becomes audible.The system will automatically switch to
a station of the selected category if the
currently selected station is not of the
selected category. Otherwise, the
currently selected station remains
tuned.


Tuning a station within the selected
category
The channels identified for the
currently selected category are
arranged numerically. Only one entry is
visible at a time.
PressGorHbutton briefly.
The next station within the category
is started.
or

Press and hold
GorHbutton for approx.
3 seconds until desired station has
been reached.Tuning via scan search
Scan search is characterized as follows:


Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current cat-
egory.


Scan search can be terminated
manually.

Press
SC soft key.
The search starts.
SC appears in the
display.

Press
SC soft key again.
The search stops.

218 Controls in detailAudio systemObtaining additional text information
Additional text information (artist, title)
related to the current channel can be
displayed.
Press
INF
soft key.
The title being played is displayed.

Press
INF
soft key again.
The name of the artist performing the
title being played is displayed.Storing stations

Tune in desired station.

Press and hold desired station
button1 to R until a brief signal
tone is heard.
The frequency is stored on the selected
station button.
The radio saves the current station at
the memory preset selected. The
memory preset selected appears in the
status line, e.g. S3.Calling up the ESN information menu

Press
INF
soft key.

Press
ESN
soft key.
The twelve-digit electronic serial
number (ESN) of the SAT tuner*
installed in your vehicle is displayed.

Press
RET
soft key to exit the menu.
iIf a button is not pressed within
4 seconds, the radio will return to the
standard display.
iThere are ten presets available.
An existing entry is overwritten in the
memory list when a new entry is given.

219 Controls in detail
Audio system
CD mode
Safety precautions
General notes
The system may not be able to play audio
CDs with copy protection.
Playing copied CDs may cause
malfunctions during playback.Warning!
G
The single CD player and the CD changer*
are Class 1 laser products. There is a danger
of invisible laser radiation if the housing is
opened or damaged.
Do not open the housing. The single CD
player and the CD changer* do not contain
any parts that can be serviced by the user.
For safety reasons, have any service work
which may be necessary performed only by
qualified personnel.
Warning!
G
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and
operate the audio system only if permitted
by road, weather and traffic conditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car covers a
distance of 44 feet (approximately 14 m)
every second.iThe audio system plays both CD-Rs and
CD-RWs with audio data.
!If you affix stickers to the CDs, they can
become warped due to the heat that
develops in the CD drive or
CD changer.
In certain situations, the CDs can then
no longer be ejected and cause
damage to the drive. Such damage is
not covered by the Mercedes-Benz
Limited Warranty.!Your CD drive or CD changer has been
designed to play CDs which
correspond to the EN 60908 standard.
You can therefore only use CDs with a
maximum thickness of 1.3 mm.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they cannot be ejected and
will damage the drive.

220 Controls in detailAudio systemDo not use CDs with an 8 cm diameter, not
even with a CD adapter. Attempting to play
CDs with an 8 cm diameter or playing such
CDs with an adapter may cause damage to
the CD drive. Such damage is not covered
by the Mercedes-Benz Limited Warranty.
Should excessively high or low tempera-
tures occur while in CD changer mode*, CD TEMP
will appear in the display, and the
CD will be muted until the temperature has
reached an acceptable level for the system
to continue operation.
The single CD player and the CD changer*
play audio CDs.Tips on handling CDs


Handle CDs carefully to prevent
interference during playback.


Avoid scratches, fingerprints and dust
on the CDs.


Do not write on CDs or apply any labels
or other material to them.


Clean CDs from time to time with a
commercially available cleaning cloth.
Never wipe the CD in a circular motion;
instead, wipe it in a straight line start-
ing in the center and moving outward.
Do not use solvents, anti-static sprays,
etc. for cleaning.


Replace the CD in its case after use.


Protect CDs from heat and direct
sunlight.MP3
The CD changer* can play audio CDs as
well as CDs with MP3 files.
Information on MP3 data carriers
iCD media, CD burning software and
CD writers are available in great vari-
ety. Due to this variety, it cannot be
guaranteed that the CD changer will be
able to play every user-written CD.
The burning process can lead to data
errors and aging of the medium may re-
sult in data loss. Therefore, the
CD changer may be restricted in its
a bi li ty to p la y MP3 da ta c a rri ers ; it m a y
play them with reduced sound quality,
or it ma y not b e a bl e t o pla y them a t a ll .
Problems may be encountered during
playback of user-written CDs with a
storage capacity of more than 700 MB.
These CDs do not meet valid standards
as of this printing.

221 Controls in detail
Audio system
Compatible MP3 data carriers
The CD changer can read the following
data carriers in MP3 mode:

CD-DA


CD-R


CD-RW
Compatible file systems and compres-
sion methods
Use Romeo or Joliet. Depending on file for-
mat used, up to 128 characters are possi-
ble.
The following compression methods are
compatible:


MP3


WMA


WAVCompatible bit and sampling rates
Fixed and variable bit rates of up to
320 kBit/s are possible.
The following table lists possible sampling
rates:Information on copyright
The music tracks that you create for use in
MP3 mode or that you play in MP3 mode
are subject to copyright laws under appli-
cable international and national regula-
tions.
In many countries, the reproduction of
copyrighted materials is not permitted,
even if only for personal use, without the
express prior consent of the copyright
holder.
Please check the current copyright laws
for your country and comply with them.
These restrictions do not apply, for exam-
ple, to your own compositions and record-
ings, or for recordings for which
authorization has been obtained from the
copyright holder.
MPEG1
Audio Layer3
44.1 KHz, 48 KHz,
32 KHZ
MPEG2
Audio Layer3
22.5 KHz, 24 KHz,
16 KHz
MPEG2.5
Audio Layer3
11.025 KHz,
12 KHz, 8 KHz
WMA
32 KHz, 44.1 KHz,
48 KHz
iOnly use MP3 tracks with a bit rate of
128 kBit/s or higher and with the spec-
ified sampling rates.
The use of rates other than those spec-
ified may lead to noticeably inferior
sound quality.

222 Controls in detailAudio systemMP3 playback
You can play an MP3 CD on the
CD changer* as you would any standard
audio CD. All of the functions described for
the CD changer also apply for the playback
of MP3 CDs. Keep in mind that the single
CD player in the audio system unit is not
able to read MP3 CDs.
The first 99 tracks on the CD, including
tracks in subdirectories, are recognized
and played. Any additional tracks will not
be played.Operating the single CD player in the
audio system unit
Loading a CD
The single CD player in the audio system
unit has capacity for one CD. The CD slot
for loading the drive is located underneath
the soft keys.

Make sure the system is switched on.

Insert CD into CD slot. The label side of
the CD must face upwards.
The system automatically pulls the CD
into the CD slot. The audio CD begins
to play.Ejecting a CD

Make sure the system is switched on.

Press gbutton.
The system ejects the CD.
Remove CD0

will appear in the display.

Remove CD from slot.
With the CD removed,
NO CD
will appear
in the display.
iDue to the branched data structure,
playback of the first track may be de-
layed slightly.
!If a CD is already loaded, it must be
ejected before inserting a new CD.
Inserting a second CD in the slot with
another CD still loaded will cause dam-
age to the CD drive not covered by the
Mercedes-Benz Limited Warranty.
iIf a CD has been inserted incorrectly or
cannot be read,
WRONG CD0
will appear
in the display.
iIf you do not take the CD out of the CD
slot within approx. 15 seconds, the
system automatically pulls the CD back
in and plays it.
If a CD is pulled back in, press
gbutton, the CD will then be
ejected.

223 Controls in detail
Audio system
Operational readiness of CD changer*
If a CD changer has been installed in the
vehicle, it can be operated from the front
control panel of the audio system.
The CD changer is located in the glove box.
1CD loading slot
2Magazine slot button
A magazine is integrated into the CD
changer as a fixed element. It holds a max-
imum of six CDs.
The CD changer features six magazine slot
buttons2 for controlling the loading pro-
cedure.A light-emitting diode in the buttons shows
the status of the corresponding magazine
slot.
CD loading slot1 is above buttons2
and is used to load CDs.Loading the CD magazine
Loading single CDs

Open the glove box.
1CD loading slot
2Magazine slot button
LEDsno LED is lit
Magazine slot is
empty.
green LED flashes
CD can be loaded.
red LED is lit
Magazine slot is in
use.
red LED flashes
CD is being ejected.
iIf a CD has been inserted incorrectly or
cannot be read,
WRONG CD0
will appear
in the display.
Loading one or more CDs interrupts the
CD playback.
