2006 LEXUS LX470 Owners Manual

INTRODUCTION
395
THEFT PREVENTION LABELS(U.S.A.ONLY)
17E002
Type A
61RY058
Type B Your new vehicle carries theft prevention labels which are
approximately 56 mm (2.20 in.) by 16 mm (0.63 in.) (Type
A) or 47 mm (1.85 in.) by 12 mm (0.47 in.) (Type B).
The purpose of these labels is to reduce the incidence of
vehicle thefts by facilitating the tracing and recovery of parts
from stolen vehicles. The label is designed so that once it is
applied to a surface, any attempt to remove it will result in
destroying the
integrity of the label. Transferring these labels
intact from one part to another will be impossible.
NOTICE
You should not attempt to remove the theft prevention
labels as it may violate certain state or federal laws.

61X004m
INTRODUCTION
396
ENGINE COMPARTMENT OVERVIEW
1 Engine oil filler cap
2 Engine oil level
dipstick
3 Brake fluid reservoir
4 Fuse box
5 Battery
6 Washer fluid tank
7 Condenser
8 Radiator
9 Engine coolant
reservoir
10 Power steering fluid
reservoir
11 Suspension fluid
reservoir

INTRODUCTION
397
DOITYOURSELF SERVICEPRECAUTIONS
If you perform maintenance yourself, be sure to follow the
correct procedure given in this Section.
You should be aware that improper or incomplete servicing
may result in operating problems.
Performing do −it−yourself maintenance during the warranty
period may affect your warranty coverage. Read the separate
Lexus Warranty statement for details and suggestions.
This Section gives instructions only for those items that are
relatively easy for an owner to perform. As explained in
Section 5, there are still a number of items that must be
performed by a qualified technician with special tools.
For information on tools and parts for do −it −yourself
maintenance, see “Parts and tools” on page 398.
Utmost care should be taken when working on your vehicle to
prevent accidental injury. Here are a few precautions that you
should be especially careful to observe:
CAUTION
 When the engine is running, keep hands, clothing,
and tools away from the moving fan and engine drive
belt. (Removing rings, watches, and ties is
advisable.)
 Right after driving, the engine compartment the
engine, radiator, exhaust manifold and power
steering fluid reservoir and spark plug boots, etc.
will be hot. So be careful not to touch them. Oil, other
fluids and spark plugs may also be hot.
 If the engine is hot, do not remove the radiator cap or
loosen the drain plugs to prevent burning yourself.
 Do not smoke, cause sparks or allow open flames
around fuel or the battery. Their fumes are
flammable.
 Do not get under your vehicle with just the body jack
supporting it. Always use automotive jack stands or
other solid supports.
 Use eye protection whenever you work on or under
your vehicle where you may be exposed to flying or
falling material, fluid spray, etc.
 Be extremely cautious when working on the battery.
It contains poisonous and corrosive sulfuric acid.

INTRODUCTION
398
NOTICE
Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally
causing a short circuit.
 Add only “T oyota Super Long Life Coolant” or similar
high quality ethylene glycol based nonsilicate,
nonamine, nonnitrite, and nonborate coolant with
longlife hybrid organic acid technology to fill the
radiator. “Toyota Super Long Life Coolant” is a
mixture of 50% coolant and 50% deionized water (for
the U.S.A.) or 55% coolant and 45% deionized water
(for Canada).
 If you spill some of the coolant, be sure to wash it off
with water to prevent it from damaging the parts or
paint.
 Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.
 Do not drive with the air cleaner removed, or
excessive engine wear could result. Also backfiring
could cause a fire in the engine compartment.
 Do not overfill automatic transmission fluid, transfer
oil and power steering fluid, or the transmission,
transfer and power steering could be damaged.
 Be careful not to scratch the glass surface with the
wiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do−it−yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil. For recommended
oil viscosity, see page 412.
Tools:
 Rag or paper towel
 Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):
“Toyota Super Long Life Coolant” or similar high quality
ethylene glycol based non −silicate, non −amine, non −nitrite,
and non −borate coolant with long life hybrid organic acid
technology.
“Toyota Super Long Life Coolant” is a mixture of 50% coolant
and 50% deionized water (for the U.S.A.) or 55% coolant
and 45% deionized water (for Canada).
Tools:
 Funnel (only for adding coolant)

INTRODUCTION
399
Checking brake fluid
Parts (if level is low):
FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):
Automatic transmission fluid DEXRON
II or III
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking suspension fluid AHC
Parts (if level is low):
Suspension fluid AHC
Tools:
 Rag or paper towel
 Funnel (only for adding fluid)
Checking battery condition
Tools:
Warm water
 Baking soda
 Grease
 Conventional wrench (for terminal clamp bolts)
Checking and replacing the blade type fuses
Parts (if replacement is necessary):
Fuse with same amperage rating as original
Checking the cartridge type fuses
Parts (if replacement is necessary):
Genuine Lexus fuse or equivalent with same amperage
rating as original
Adding washer fluid
Parts:
Water
 Washer fluid containing antifreeze (for winter use)
Tools:
 Funnel

INTRODUCTION
400

SECTION 6 – 2
401
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications402
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Fuel 405
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel pump shut off system 407
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 408
. . . . . . . . . . . . . . . . . . . . . . . .
Used engine oil 409
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Checking the engine oil level 410
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 413
. . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the radiator and condenser 414
. . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 415
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .

ENGINE
402
SPECIFICATIONS
– GENERALModel
4.7L V8 (2UZ− FE)
Type8 cylinder V type, 4 cycle, gasoline
Bore and stroke94.0 X 84.0 mm (3.70 X 3.30 in.)
Displacement4664 cm3 (284.6 cu.in.)
Valve clearance (engine cold)
Intake
Exhaust0.15 − 0.25 mm (0.006 − 0.010 in.)
0.25 − 0.35 mm (0.010 − 0.014 in.)
Drive belt tensionAutomatic adjustment
– FUEL
Fuel type
Unleaded gasoline only
Octane rating87 (Research octane number 91) or higher
