2006 LEXUS LX470 Owners Manual

PICTORIAL INDEX
xvii
INSTRUMENT CLUSTER (Vehicles sold in Canada)
px504g

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xviiiPage
1
Roll sensing of curtain shield
airbags off indicator light 45, 146
. . . . . . . . . . . . . . . . .
2 Voltmeter 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
3 Fuel gauge 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Odometer and trip meter 51
. . . . . . . . . . . . . . . . . . . . .
5 “PWR” mode indicator light 261
. . . . . . . . . . . . . . . . .
6 Driver’s seat belt reminder light 55
. . . . . . . . . . . . . . .
7 Turn signal indicator light 32
. . . . . . . . . . . . . . . . . . . .
8 Headlight high beam indicator light 32
. . . . . . . . . . .
9 Tail light indicator light 30
. . . . . . . . . . . . . . . . . . . . . . .
10 Open door warning light 58
. . . . . . . . . . . . . . . . . . . . . .
11 Cruise control indicator light 276
. . . . . . . . . . . . . . . .
12 Automatic transmission second start
indicator light 266 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Tachometer 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14 Engine coolant temperature gauge 48
. . . . . . . . . . . .
15 Engine oil pressure gauge 49
. . . . . . . . . . . . . . . . . . . .
16 Lexus night view system warning light 275 . . . . . . .
17 Brake system warning light 54
. . . . . . . . . . . . . . . . . . .
18 Discharge warning light 61
. . . . . . . . . . . . . . . . . . . . . .
19 Automatic transmission fluid temperature
warning light 59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page
20 SRS warning light
56
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
21 Variable gear ratio steering system
warning light 294 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Unengaged “Park” warning light 59
. . . . . . . . . . . . . .
23 Active height control indicator lights 284
. . . . . . . . .
24 Low washer fluid warning light 61
. . . . . . . . . . . . . . . .
25 Vehicle stability control system
OFF indicator light 291 . . . . . . . . . . . . . . . . . . . . . . . . . .
26 Vehicle stability control system and active traction
control system warning light 289, 291 . . . . . . . . . . . . .
27 Slip indicator light 290
. . . . . . . . . . . . . . . . . . . . . . . . . .
28 Center differential lock indicator light 266
. . . . . . . .
29 Active traction control system indicator light 288 .
30 Automatic transmission indicator lights 259. . . . . .
31 Odo/Trip knob 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32 Tire pressure warning light 59
. . . . . . . . . . . . . . . . . . .
33 Malfunction indicator lamp 57
. . . . . . . . . . . . . . . . . . .
34 Antilock brake system warning light 58
. . . . . . . . . .
35 Instrument panel light control dial 66
. . . . . . . . . . . . .
36 Low fuel level warning light 61
. . . . . . . . . . . . . . . . . . .
37 Fuel filler door indicator 93
. . . . . . . . . . . . . . . . . . . . . .

00X003i
PICTORIAL INDEX
xix
SEAT AND STEERING WHEELPage
1 Tilt and telescopic steering
adjustment switch 192
. . . . . . . . . . . . .
2 Seat position, seat cushion angle
and height control switch 105, 106 . .
3 Seatback angle control
switch 105
. . . . . . . . . . . . . . . . . . . . . . . .
4 Lumbar support control
switch 106
. . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each section.

px603a
PICTORIAL INDEX
xx
EXTERIOR VIEWPage
1 Rear window defogger 37
. . . . . . . . . .
2 Back door 23
. . . . . . . . . . . . . . . . . . . . .
3 Fuel filler door 93
. . . . . . . . . . . . . . . . .
4 Moon roof 95
. . . . . . . . . . . . . . . . . . . . .
5 Windshield wiper
and washer 33, 458
. . . . . . . . . . . . . . . .
6 Outside rear view mirror 193 . . . . . . .
7 Side door 19
. . . . . . . . . . . . . . . . . . . . . .
8 Tire and wheel 424
. . . . . . . . . . . . . . . .
9 Headlights 30, 458
. . . . . . . . . . . . . . . . .
10 Hood 92
. . . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each section.

PICTORIAL INDEX
xxi

lxu
GAS STATION INFORMATION
Fuel selection:
Select Octane Rating 87 (Research Octane Number 91) or
higher. For improved vehicle performance, the use of
premium unleaded gasoline with an Octane Rating of 91
(Research Octane Number 96) or higher is recommended.
 Fuel tank capacity:
96 L (25.4 gal., 21.1 lmp.gal.)
 Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil.
Recommended oil viscosity − SAE 5W−30 if normal
temperatures are below 38 C (100F)
Oil capacity: L (qt., lmp.qt.)
Drain and refill with filter 6.8 (7.2, 6.0)
without filter 6.4 (6.8, 5.6)
See page 410 for detailed information.
Engine coolant:
Capacity: L (qt., lmp.qt.) 15.4 (16.3, 13.6)
Coolant type − “Toyota Super Long Life Coolant” or similar
high quality ethylene glycol based non −silicate, non −amine,
non−nitrite, and non −borate coolant with long −life hybrid
organic acid technology (Coolant with long −life hybrid
organic acid technology is a combination of low phosphates
and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page 413.
 Automatic transmission:
Fluid type − “Toyota Genuine ATF Type WS”
 Tire information:
See page 424 through 443 for detailed information.
 Tire inflation pressure:
Tire size: P275/60R18 111H
cold tires
kPa (kgf/cm
2 or bar, psi)
Normal driving Trailer towing
Front tires 200 (2.0, 29) 220 (2.2, 32) . . . . . .
Rear tires 220 (2.2, 32) 240 (2.4, 35) . . . . . .

BASIC OPERATION
1
QUICK REFERENCE
Driver’s seat2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Steering wheel 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Automatic transmission 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Headlight and turn signal switch 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper switch 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .

QUICK REFERENCE
2
1. DRIVER’S SEAT
00X005c
Seat adjustmentSeat
position
Seat
cushion angle
Seat cushion height
Head restraint height
Seatback
angle
Lumbar support
Head restraint angle
2. STEERING WHEEL
TILT STEERING COLUMN
00X016f
To tilt the steering column up or down to the desired
angle, push the control switch in the required direction
and release the button when the steering column
reaches the desired angle.
TELESCOPIC STEERING COLUMN
00X015f
To move the steering column to the desired position,
push the control switch away from you or pull it toward
you until the steering column reaches the desired
position.
