2006 HONDA CR-V Owners Manual

If you take your vehicle f or a state
emissions test shortly af ter the
battery has been disconnected or
gone dead, it may not pass the test.
This is because of certain ‘‘readiness
codes’’ that must be set in the on-
board diagnostics f or the emissions
systems. These codes are erased
when the battery is disconnected,
and set again only after several days
of driving under a variety of
conditions.
If the testing f acility determines that
the readiness codes are not set, you
will be requested to return at a later
date to complete the test. If you must
get the vehicle retested within the
next two or three days, you can
condition the vehicle f or retesting by
doing the f ollowing.Make sure the gas tank is nearly,
but not completely f ull (around
3/4). Make sure the vehicle has been
parked with the engine of f f or 8
hours or more.
Make sure the ambient
temperature is between 20° and
95°F.
Without touching the accelerator
pedal, start the engine, and let it
idle f or 20 seconds.
Select a nearby lightly traveled
major highway where you can
maintain a speed of 50 to 60 mph
(80to97km/h)foratleast20
minutes. Drive on the highway in
D (A/T) or 5th (M/T). Do not usethecruisecontrol.Whentraffic
allows, drive f or 90 seconds
without moving the accelerator
pedal. (Vehicle speed may vary
slightly; this is okay.) If you cannot
do this f or a continuous 90
seconds because of traf f ic
conditions, drive f or at least 30
seconds, then repeat it two more
times (for a total of 90 seconds).
Then drive in city/suburban
traffic for at least 10 minutes.
When traf f ic conditions allow, let
the vehicle coast f or several
seconds without using the
accelerator pedal or the brake
pedal.
If the testing facility determines the
readiness codes are still not set, see
your dealer.
Keep the vehicle in Park
(automatic transmission) or
neutral (manual transmission).
Increase the engine speed to 2,000
rpm,andholditthereuntilthe
temperature gauge rises to at least
1/4of thescale(about3minutes).
T esting of Readiness Codes
State Emissions T esting
254

Customer Service................................
Inf ormation .256
....................
Warranty Coverages .257
Reporting Saf ety Def ects ..........................
(U.S. Vehicles) .258
.....................
Authorized Manuals .259
Warranty and Customer Relations
Warrant y and Cust omer Relat ions
255

Honda dealership personnel are
trained prof essionals. They should
be able to answer all your questions.
If you encounter a problem that your
dealership does not solve to your
satisf action, please discuss it with
the dealership’s management. The
service manager or general manager
can help. Almost all problems are
solved in this way.
U.S. Owners:Canadian Owners:
In Puerto Rico and the U.S. Virgin
Islands:
When you call or write, please give
us this inf ormation:
If you are dissatisf ied with the
decision made by the dealership’s
management, contact your Honda
Customer Service Office. Vehicle Identif ication Number
(see page )
Name and address of the dealer
who services your vehicle
Date of purchase
Mileage on your vehicle
Your name, address, and tele-
phone number
A detailed description of the
problem
Name of the dealer who sold the
vehicle to you244
Customer Service Inf ormation
256
CUSTOMER RELATIONS
RELATIONS AVEC LA CLIENTÈLE
Honda Canada Inc.
715 Milner Avenue
Toronto, ON
M1B 2K8
Tel: 1-888-9-HONDA-9
Fax: Toll-free 1-877-939-0909 Toronto (416) 287-4776
American Honda Motor Co., Inc.
Automobile Customer Service
Mail Stop 500-2N-7A
1919 Torrance Boulevard
Torrance, California 90501-2746
Tel: (800) 999-1009 Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7098

µ
µ
µ µ
µµ µ
µ
µ
Your new vehicle is covered by these
warranties:
provides prorated
coverage f or a replacement battery
purchased f rom your dealer.
covers your new vehicle, except f or
the battery, emissions control
systems, and accessories against
def ects in materials and
workmanship.
these two
warranties cover your vehicle’s
emissions control systems. Time,
mileage, and coverage are
conditional. Please read your
warranty booklet f or exact
inf ormation. a seat
belt that f ails to f unction properly is
covered f or the usef ul lif e of the
vehicle.
all exterior body panels are
covered f or rust-through f rom the
inside f or the specif ied time period
with no mileage limit. provides
coverageforaslongasthepur-
chaser of the muf f ler owns the
vehicle.
Honda accessories are covered
under this warranty. Time and
mileage limits depend on the type of
accessory and other factors. Please
read your warranty booklet f or
details. covers all Honda
replacement parts against defects in
materials and workmanship.
this warranty gives up
to 100 percent credit toward a
replacement battery. Restrictions and exclusions apply to
all these warranties. Please read the
2006 Honda Warranty Inf ormation
booklet that came with your vehicle
f or precise inf ormation on warranty
coverages. Your vehicle’s original
tires are covered by their
manuf acturer. Tire warranty
inf ormation is in a separate booklet.
Please ref er to the 2006 Warranty
Manual that came with your vehicle.
U.S. Owners
Canadian Owners
Replacement Bat t ery L imit edWarranty
New Vehicle L imit ed Warrant y
Emissions Cont rol Syst ems Def ect sWarrant y and EmissionsPerf ormance Warranty Seat Belt Limited Warranty
Rust Perf orat ion L imit ed Warrant y Replacement Muf f ler L if et ime Limited Warranty
Accessory Limited Warranty
Replacement Part s L imit edWarranty
Original Equipment Bat t ery L imit ed Warranty
Warranty Coverages
Warrant y and Cust omer Relat ions
257

If NHTSA receives similar com-
plaints, it may open an investigation,
and if it f inds that a saf ety def ect
exists in a group of vehicles, it may
order a recall and remedy campaign.
However, NHTSA cannot become
involved in individual problems
between you, your dealer, or
American Honda Motor Co., Inc.
If you believe that your vehicle has a
def ect which could cause a crash or
could cause injury or death, you
should immediately inf orm the
National Highway Traf f ic Saf ety
Administration (NHTSA) in addition
to notifying American Honda Motor
Co., Inc.
Reporting Saf ety Def ects (U.S. Vehicles)
258
To contact NHTSA, you may call the
VehicleSafetyHotlinetoll-freeat
1-888-327-4236 (TTY: 1-800-424-9153);
go to
http://www.saf ercar.gov; or
write to: Administrator, NHTSA, 400
Seventh Street, SW., Washington,
DC 20590.
You can also obtain other
inf ormation about motor vehicle
safety from http://www.safercar.gov.

ÎÎ
Î
µ
Î




$
#
Valid only f or sales within the United States. Canadian
owners should contact their authorized Honda dealer.
T he publications shown below can be purchased f rom Helm
Incorporated. You can order in any of three ways:
Detach and mail the order f orm on the right half of this page
Call Helm Inc. at 1-800-782-4356
Go online at
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.
(credit card orders only)
Authorized Manuals
Authorized Manuals
Purchasing Factory Authorized Manuals (U.S. only)
259
ORDER TOLL FREE: 1-800-782-4356
OR
(NOTE: For Credit Card Holder Orders Only)
MINIMUM CREDIT CARD PURCHASE $10.00
Publication
Form Number 61S9A04
61S9A03EL 61S9A30
31S9A640
31S9AM10 31S9AQ30 HON-R Form Description
2006 Honda CR-V
Service Manual
2006 Honda CR-V
Electrical Troubleshooting Manual 2002-06 Honda CR-VBody Repair Manual 2006 Honda CR-VOwner’s Manual
2006 Honda CR-V
Honda Service History 2006 Honda CR-V
Quick Start Guide
Order Form for Previous Years-
Indicate Year and Model Desired Price
Each
$75.00
$50.00
$44.00
$35.00
$12.00
$12.00
FREE
PUBLICATION NUMBER VEHICLE MODEL
Name Year Qty
Price
Each Total
Price
GRAND TOTAL HANDLING CHARGE Mich. Purchases
Add 6% Sales Tax TOTAL MATERIAL
$6.95Prices are subject to change without notice and without incurring obligation.
Monday-Friday 8:00 A.M. 6:00 P.M. EST
By completing this form you can order the materials desired. You can
pay by check or money order, or charge to your credit card. Mail to
Helm Incorporated at the address shown on the back of the order form.
Prices are subject to change without
notice and without incurring obligation.
Orders are mailed within 10 days. Please
allow adequate time for delivery.
www. helminc. com

µµ
µ
(


%
)
$
%

.
"

#
) This manual covers maintenance and recommended
procedures f or repair to engine and chassis components.
It is written f or the journeyman mechanic, but is simple
enough f or most mechanically-inclined owners to under-
stand.
This manual describes the procedures involved in the
replacement of damaged body parts. This manual complements the service manual by
providing in-depth troubleshooting inf ormation f or each
electrical circuit in your vehicle.
Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
260
NOTE: Dealers and companies, please provide dealer or company name,
and the name of the person to whose attention the shipment should be
sent. For purchases outside U.S.A. please write to the address shown
below for a quotation.
P.O. BOX 07280·DETROIT, MICHIGAN 48207·1-800-782-4356
Customer Name Attention
Apartment Number
State & Zip Code
City
Daytime Telephone Number
Check or money order enclosed payable to Helm Inc U.S. funds only.
Do not send cash
Master
Card VISA
Check here if your billing address is different
from the shipping address shown above.
Account Number Expiration: Mo. Yr.
CUSTOMER SIGNATURE DATE
Street Address No P.O. Box Number
()
These publications cannot be returned for credit without receiving advance authorization within 14
days of delivery. On returns, a restocking fee may be applied against the original order.

CONT INUED
BatteryCharging System ...........................
Indicator .56, 233
............................
Jump Starting .229
..............................
Maintenance .217
............................
Specif ications .247
..............................
Bef ore Driving .141
....................................
Belts,Seat .8,18
...........................
Beverage Holders .91
..................................
Booster Seats .47
Brakes ...........
Anti-lock System (ABS) . 168
.............
Break-in, New Linings . 142
....................
Bulb Replacement .205
...........................................
Fluid .201
.........................................
Parking .68
.................
System Indicator . 56,235 ..........................
System Design .167
........................
Wear Indicators .167
.............................
Braking System .167
.................
Break-in, New Vehicle . 142
..
Brightness Control, Instruments . 67
..................
Brights, Headlights . 66,67
...................................
Built-in Table .91
Bulb Replacement ..........................
Back-up Lights .205
..............................
Brake Lights .205
................
Front Parking Lights . 205
........
Front Side Marker Lights . 205
.................................
Headlights .203
.........
High-mount Brake Light . 207
.........
Rear Side Marker Lights . 205
............................
Specif ications .247
....................
Turn Signal Lights . 205
..............................
Bulbs, Halogen .203
............................
Capacities Chart .246
.............
Carbon Monoxide Hazard . 50
..............................................
Cargo .150
....................................
Accessories .148
ACCESSORY (Ignition Key .......................................
Position) .72
..............
Accessory Power Sockets . 95
....................
Additives, Engine Oil . 193
.......
Adjusting the Steering Wheel . 69
...........................
Advanced Airbags .25
...............................
Airbag (SRS) .9, 21
................
Air Conditioning System . 98
.........................................
Usage .100
.......................
Air Pressure, Tires .213
.......................
Alcohol in Gasoline .142
......................................
Antif reeze .196
Anti-lock Brakes (ABS) ...............................
Indicator .57, 168
...................................
Operation .168
..............
Anti-thef t, Audio System . 136
.
Anti-thef t Steering Column Lock . 72
................................
Audio System .103
...
Automatic Seat Belt Tensioners . 19
.............
Automatic Speed Control . 138
..............
Automatic Transmission . 161
..........................
Capacity, Fluid .246
...............
Checking Fluid Level . 199....................................
D3 Mode .163
.......................................
Shif ting .161
Shif t Lever Position ...............................
Indicators .161
................
Shif t Lever Positions . 162
....................
Shif t Lock Release . 165
Index
A
B
C
INDEX
I
