Symptom Diagnostic procedure Also check for
23-162
Audio System
Symptom Troubleshooting Index
Poor AM or FM radio reception or
interference (with navigation)
Symptom Troubleshooting (see page 23-
196) AM/FM antenna lead and/or
sublead short or open in the
wire
Poor AM or FM radio reception or
interference (without navigation) Symptom Troubleshooting (see page 23-
199) AM/FM antenna lead and/or
sublead short or open in the
wire
Audio unit power switch will not
turn on (No information display
and no sound) (with navigation) Symptom Troubleshooting (see page 23-
202)
Audio unit power switch will not
turn on (No information display
and no sound) (without
navigation) Symptom Troubleshooting (see page 23-
203)
Audio unit power switch will not
turn off (with navigation) Symptom Troubleshooting (see page 23-
205)
Audio unit power switch will not
turn off (without navigation) Symptom Troubleshooting (see page 23-
206)
No sound is heard from the
speaker(s) (display is normal)
(with navigation) Symptom Troubleshooting (see page 23-
206)
No sound is heard from the
speaker(s) (display is normal)
(without navigation) Symptom Troubleshooting (see page 23-
215)
Auxiliary i nput sound is low or
cannot be heard Symptom Troubleshooting (see page 23-
217)
Audio system sound is weak or
distorted (display is normal) Symptom Troubleshooting (see page 23-
220)
Radio preset memory is lost Symptom Troubleshooting (see page 23-221) Internal error
Volume does not change Symptom Troubleshooting (see page 23- 221)
Volume does not increase with
speed (with navigation) Symptom Troubleshooting (see page 23-
222)
Volume does not increase with
speed (without navigation) Symptom Troubleshooting (see page 23-
223)
Volume is too high or too low
when driving at freeway speeds Symptom Troubleshooting (see page 23-
224)
Radio tuner does not change
stations Symptom Troubleshooting (see page 23-
224)
08/08/21 14:08:45 61SNR030_230_0165
ProCarManuals.com
DYNOMITE -2009-

SymptomDiagnostic procedure Also check for
23-163
Navigation unit button
illumination does not work (with
navigation)Symptom Troubleshooting (see page 23-
225)
Audio unit button illumination
does not work (without
navigation) Symptom Troubleshooting (see page 23-
226)
Display does not dim or brighten
with dimmer (without navigation) Symptom Troubleshooting (see page 23-
227)
Audio disc does not load Symptom Troubleshooting (see page 23- 228)
Audio disc does not eject Symptom Troubleshooting (see page 23-228)
Audio disc does not play Symptom Troubleshooting (see page 23- 229)
Audio disc skips Symptom Troubleshooting (see page 23- 229)
Audio remote switch does not
work properly (with navigation) Symptom Troubleshooting (see page 23-
230)
Audio remote switch does not
work properly (without
navigation) Symptom Troubleshooting (see page 23-
232)
Audio disc cannot be inserted
and/or ejected (with navigation) Symptom Troubleshooting (see page 23-
233)
Display can be opened and/or
closed even when an audio disc is
being inserted or ejected Replace the navigation unit (see page
23-355)
PC card will not play/card icon on
audio screen cannot be selected
(with navigation) Symptom Troubleshooting (see page 23-
234)
USB input sound is low or cannot
be heard (with navigation) Symptom Troubleshooting (see page 23-
235) Requirement of the USB
devices (see Owner’s Manual)
USB input sound is low or cannot
be heard (without navigation) Symptom Troubleshooting (see page 23-
236) Requirement of the USB
devices (see Owner’s Manual)
USB device does not function
(with navigation) Symptom Troubleshooting (see page 23-
238) Requirement of the USB
devices (see Owner’s Manual)
USB device does not function
(without navigation) Symptom Troubleshooting (see page 23-
241) Requirement of the USB
devices (see Owner’s Manual)
Error code: XM NO SIGNAL or XM
ANTENNA is displayed (with
navigation) Symptom Troubleshooting (see page 23-
245)
XM radio display is blank and no
station information is displayed
(with navigation) Symptom Troubleshooting (see page 23-
245)
XM radio preset memory is lost
(with navigation) Symptom Troubleshooting (see page 23-
248)
Poor or no sound with XM radio
(Audio unit does display XM
channels) (with navigation) Symptom Troubleshooting (see page 23-
249)
08/08/21 14:08:45 61SNR030_230_0166
ProCarManuals.com
DYNOMITE -2009-

(#'



)
Overview
Speed-sensitive volume compensation (SVC)
23-164Audio System
System Description
The audio unit acts as the processor for all audio functions. Select audio functions from the audio unit, the audio
remote (on the steering wheel), or by using the navigation voice control system. The audio display provides the
current audio status. For vehicles with navigation, additional audio information is available by touching the audio
button on the navigation audio screen (See the owner’s manual and the navigation system manual for more details.).
The XM receiver passes its signal to the audio unit. In addition, it communicates with the audio unit via the GA-Net bus.
Any open connections in the GA-Net bus circuit causes audio and navigation functions to appear inoperative.
For vehicles with navigation, pressing the open/close switch on the navigation display panel allows access to the CD
slot and PC card.
A security signal is daisy-chained between the audio and vehicle components for integration into the vehicle’s security
system.
Some audio systems are equipped with speed-sensitive volume compensation (SVC). The navigation or audio unit
receives the vehicle speed pulse (VSP) from the ECM/PCM. The system processes the speed input and increases the
navigation or audio system volume level as the vehicle speed increases to compensate for the various interior noises
that occur at higher speeds. When the vehicle slows down, the volume returns to its normal level. The SVC has four
settings: SVC OFF, LOW, MID and HIGH that can be adjusted using the navigation or audio unit. The SVC comes from
the factory with the MID setting as the default.
To change the audio unit SVC setting, press the tune folder sound knob repeatedly until the SVC is displayed, rotate
the knob to adjust the SVC to the desired setting (SVC OFF, LOW, MID, or HIGH).
To change the navigation unit SVC setting, press the AUDIO button, and then select the SOUND icon on the navigation
display. Press the navigation display to select the desired setting (OFF, LOW, MID, HI).
08/08/21 14:08:46 61SNR030_230_0167
ProCarManuals.com
DYNOMITE -2009-

Î
Contents Audio output
Left front CH Right front CH Right rear CH Left rear CH Subwoofer CH
USB Adapter
GA-Net Bus Configuration
23-165
Navigation unit
or audio unit
Accessory
(CD changer etc.)
XM Receiver
USB Adapter
(With navigation)
The navigation system allows voice control of the audio, XM, PC card, and CD player. Voice control commands are
communicated on the GA-Net (audio unit). When using the navigation TALK/BACK button, the audio is muted on all
speakers and you get navigation sound on the front channels. When using the navigation or route guidance (RG), the
front speakers give the navigation sound and the rear speakers continue to play. For more information, see the
navigation section. The outline of the interruption function is shown in this table.
Navigation TALK/BACK Buttons Navigation voice
output Navigation voice
output Muted Muted Muted
Route guidance Navigation voice outputNavigation voice
output Audio Audio Audio
The audio unit can play digital music from portable audio players, USB drive, etc. When the device is plugged into the
USB adapter. The audio unit uses the GA-NET to allow you to control the device from the audio unit when searching
and playing the files. Not all players and player functions work with the USB adapter. Please see the owner’s manual
for more information.
The GA-Net bus passes audio and navigation commands throughout the navigation and audio components.
These commands include navigation touch screen and hard button signals, audio/XM selections by voice, and XM
station and music title names. Because the entire bus is daisy chained between components (see diagram), any open
or short in the GA-Net bus harness will cause any or all of these functions to become inoperative. Naturally the
addition of any audio accessory must maintain the continuity of the GA-Net bus by installing the Y cable included with
the accessory kit.
(cont’d)
08/08/21 14:08:46 61SNR030_230_0168
ProCarManuals.com
DYNOMITE -2009-

ÎWith navigation
23-166Audio System
System Description (cont’d)
Reverse signal
GPS antenna
AM/FM antenna Speakers
Navigation unit
Navi DVD
Navigation/Audio Display Screen
CLOCK
(Set by GPS)Color
signal
XM antenna
(satellite &
terrestrial)
Auxiliary jack
assembly
Audio remote
switches
(steering wheel)
Illumination
Signal
(lighted buttons)
AM/FM
receiverCD Player
(CD, MP3, WMA)
Audio
processor
PC Card Slot (for playing audio
MP3, and WMA audio files) Navi
processor
(ECU)
GPS
receiver
Yaw rate sensor
(senses turning)
DVD player
(navi maps)
GA-net
Audio
Section
Navigaion
Section
Illumination
(Night/Day
display mode)
ECM/PCM
(vehicle speed pulses) Voice control switch
USB Adapter unit
XM Receiver HandsFreeLink
control unitMicrophone
HFL TALK/BACK
buttons
Navigation
TALK/BACK
buttons
Stereo Amplifier
(Type S model)
Climate
control unit
08/08/21 14:08:46 61SNR030_230_0169
ProCarManuals.com
DYNOMITE -2009-

Audio GlossaryItem Definition
23-168Audio System
System Description (cont’d)
GA-Net
The GA-Net allows the audio unit to communicate with all the audio and
navigation components in a vehicle. If there is an open in the GA-Net, or
components, components or the entire audio and navigation system may
appear inoperative.
GB (Gigabyte) A unit of memory or disk storage equal to billion bytes (1000 million bytes).
HDD Abbreviation for hard disc drive. They are sensitive to heat and it is not
recommended that they be used in the PC card slot for playing audio files.
Hertz (Hz) The unit of frequency equal to one cycle per second (cps). One kilohertz (kHz)
equals 1,000 cps; one megahertz (MHz) equals 1 million cps.
Integrated amplifier A component that combines a pre amp and a power amp into a single unit. A
receiver combines an integrated amp and a tuner into a single unit.
Jewel case The hard plastic case that contains a compact disc or DVD. Always use a jewel
case to prevent scratches on the underside of a CD or DVD.
LCD (Liquid Crystal Display) A type of digital display that changes reflectance or transmittance when an electrical field is applied to it.
Memory Circuitry or devices that hold information in electrical or magnetic form, such
as the AM/FM radio presets.
MB (Megabyte) One million bytes. Written as 1 MB. Megabytes are used as a measure of digital
storage space. For example, a CD can hold 650 MB.
Mic An abbreviation for microphone. For vehicles with navigation, the microphone
accepts navigation voice commands to control audio and navigation functions.
MP3 music files MP3 is an audio coding format. MP3 is a popular audio compression format on
the Internet and computers. CDs and PC Cards with these files can be played on
some vehicle’s audio system.
Mute When the navigation gives guidance, the front speakers are muted (no music).
When you use the voice control system, all of the speakers are muted.
Noise Unwanted random sounds like buzzing, hiss, pops, static, whine, etc.
PC card The slot used for playing MP3 and WMA music files. The PC Card is usually a
combination of a small flash card in a PCMCIA adaptor that slides into the slot.
The ATA, SD, and compact flash types of cards have been tested up to 1 GB.
PCMCIA A computer standard for the slot that the PC card slides into. Another term for
the PC card slot.
Processor The part of an audio device that performs tasks/calculations. In the audio unit
the processor handles muting to allow the navi to speak voice commands, and
the decoding/playback of the sound files etc.
Radio A head unit that combines a tuner, a preamplifier, and often a power-amplifier.
Route guidance (RG) Spoken voice used for turn-by-turn navigation from the audio speakers.
SCF (Cold Start Fix) screens These screens are displayed if the system requires a GPS initialization. The vehicle should be moved outside into an open area away from buildings/power
lines.
Stereo A recording of at least two channels where you can hear sound or music from
the left or right side.
SD (Secure Digital) card This compact type of memory card allows for fast data transfer and has built-in security functions. SD cards have a small write-protection switch on the side.
Shield A metallic foil or braided wire layer surr ounding conductors which are
designed to prevent electrostatic or electromagnetic interference (noise) from
external sources such as buzzing, or popping sounds heard on the speakers.
Speaker (Loudspeaker) A device that converts electrical energy into acoustical energy (sound).
Speed-sensitive volume
compensation (SVC) The SVC increases the audio volume to compensate for increased interior noise
when the vehicle drivers at freeway speeds.
Subwoofer A loudspeaker made to reproduce the lowest audio frequencies, about 25 Hz to
125 Hz.
08/08/21 14:08:47 61SNR030_230_0171
ProCarManuals.com
DYNOMITE -2009-

Î
Audio Unit Connector for Inputs and Outputs
With navigation (Navigation unit)
23-170Audio System
System Description (cont’d)
NAVIGATION UNIT
CONNECTOR G (3P)
NAVIGATION UNIT
CONNECTOR B (24P)
NAVIGATION UNIT
CONNECTOR A (24P)
NAVIGATION UNIT
CONNECTOR E (14P)
08/08/21 14:08:47 61SNR030_230_0173
ProCarManuals.com
DYNOMITE -2009-

µµ
´
µ
´
´
´ µ
´
µ
´
´ µ
µ
´
µ
´
´
µ
´
µ
´
´
Î
NAVIGATION UNIT CONNECTOR A (24P)
Type S model
Cavity Wire Color Connect to Except Type S model
Cavity Wire Color Connect to
23-171
A1 RED Dash lights brightness
controller (ILL )
A3 LT BLU Data link connector (DLC) (K-LINE)
A4 GRN Multiplex integrated control unit (MICU) (SCTY RADIO)
A5 BRN Audio remote switch (AUDIO REMOTE GND)
A6 PUR Stereo amplifier (RR SIG )
A7 LT GRN Stereo amplifier (RR SIG )
A10 WHT Stereo amplifier (RL SIG )
A11 BLK Stereo amplifier (RL SIG )
A12 BLK Body ground to G505 (GND)
A13 GRY No. 14 (7.5 A) fuse in the under- dash fuse/relay box (ILL )
A14 PUR No. 35 (7.5 A) fuse in the under- dash fuse/relay box
(ACC RADIO)
A15 BLU ECM/PCM (VSP)
A16 PNK Audio remote switch (AUDIO REMOTE SW)
A17 LT BLU Stereo amplifier (SWD B)
A18 PNK Stereo amplifier (FR SIG )
A19 BLU Stereo amplifier (FR SIG )
A22 RED Stereo amplifier (FL SIG )
A23 BLU Stereo amplifier (FL SIG )
A24 WHT No. 23 (10 A) fuse in the under- hood fuse/relay box
( B BACK UP) A1 RED Dash lights brightness
controller (ILL )
A3 LT BLU Data link connector (DLC) (K-LINE)
A4 GRN Multiplex integrated control unit (MICU) (SCTY RADIO)
A5 BRN Audio remote switch (AUDIO REMOTE GND)
A6 ORN Right rear speaker (RR R )
A7 BLU Right rear speaker (RR R )
A10 BRN Left rear speaker (RR L )
A11 YEL Left rear speaker (RR L )
A12 BLK Body ground to G505 (GND)
A13 GRY No. 14 (7.5 A) fuse in the under- dash fuse/relay box (ILL )
A14 PUR No. 35 (10 A) fuse in the under- dash fuse/relay box
(ACC RADIO)
A15 BLU ECM/PCM (VSP)
A16 PNK Audio remote switch (AUDIO REMOTE SW)
A18 BRN Front passenger’s door speaker, right tweeter (FR R )
A19 GRY Front passenger’s door speaker, right tweeter (FR R )
A22 PNK Driver’s door speaker, left tweeter (FR L )
A23 LT GRN Driver’s door speaker, left tweeter (FR L )
A24 WHT No. 23 (10 A) fuse in the under- hood fuse/relay box
( B BACK UP)
(cont’d)
Wire side of female terminals
08/08/21 14:08:47 61SNR030_230_0174
ProCarManuals.com
DYNOMITE -2009-
