A66060
E12
ECM Connector
E1
LUSL
A92422
Signal Waveform
10 msec./Dvision
10
−20
−
ENGINE CONTROL SYSTEM ECD SYSTEM (1CD−FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
(4) When turning the accelerator pedal position sensor lever t o t he f ull − open posit ion, check t hat t he
t hr ot t le v alve opening per cent age ( THRO TTLE
POS) of DATA LIST shows the standard value.
Standard throttle valve opening percentage:
60 % or higher
If the operation is not as specified, check the accelerator pedal
position sensor (see page 10 −22), wiring and ECM.
(c) If you have no hand −held tester:
(1) Inspect the throttle position sensor using a oscillo- scope.
(2) During idling, check the waveform between the spe- cified terminals of the E12 ECM connectors.
Standard:
Tester ConnectionSpecified Condition
LUSL (E12 −4) − E1 (E12 −7)Correct waveform is as shown on the left
If the operation is not as specified, check the accelerator pedal
position sensor (see page 10 −22), wiring and ECM.
(d) Inspect the air assist system.
(1) Start the engine, then check that the check engine warning light does not light up.
(2) Allow the engine to warm up to the normal operating
temperature.
(3) Turn the A/C compressor ON to OFF, then check the
idle speed (see page 14 −87).
Idle speed (transmission in neutral): 800 á50 rpm
If the result is not as specified, check the wiring and ECM.
NOTICE:
Perform the inspection under condition without electrical
load.
(e) After taking the above steps (b) to (c), perform the driving test.
(f) Check that there is no sense of incongruity.

A61190
90_ 90
_
90_90
_ 90
_
90_
Paint Mark
Front
A85427
TDC Mark
Dot Mark
90 _
A85942
New O −ring
14 −172−
ENGINE MECHANICAL CYLINDER HEAD GASKET (1CD −FTV)(From
September, 2003)
AVENSIS Supplement (RM1045E)
(d) Mark the front of the cylinder head bolt with paint.
(e) Retighten the cylinder head bolts by 90 _ in the same se-
quence as step (c).
(f) Retighten the cylinder head bolts by an additional 90 _ in
the same sequence as step (c).
(g) Retighten the cylinder head bolts by one more additional
90_ in the same sequence as step (c).
(h) Check that each painted mark is now at the intake man-
ifold side.
82. SET NO. 1 CYLINDER TO TDC/COMPRESSION
(a) Using the crankshaft pulley bolt, turn the crankshaft to set the dot mark of the crankshaft timing gear at the position
of 90_ BTDC.
NOTICE:
If the timing belt is disengaged, the crankshaft timing gear
placed at wrong angle can cause contact of the piston head
with the valve head.
83. INSTALL CAMSHAFT (See page 14 −151)
84. INSTALL NO.2 CAMSHAFT (See page 14 −151)
85. REMOVE CAMSHAFT OIL SEAL (See page 14 −151)
86. INSTALL CAMSHAFT OIL SEAL (See page 14 −151)
SST 09223 −46011
87. INSTALL CAMSHAFT OIL SEAL RETAINER (See page 14 −151)
88. I NSTALL EXHAUST F UEL ADDI TI O N I NJECTO R ASSY
(a) Install a new gasket to the cylinder head.
(b) Install a new O −ring to the injector.
(c) Apply a light coat of engine oil to the O −ring on the injec-
tor.
(d) Install the addition injector and nozzle holder clamp.
(e) Using a Torx socket wrench (T40), install the Torx screw. Torque: 12 N
m (117 kgf
cm, 8.5 ft
lbf)
NOTICE:
Be careful that the tools do not interfere with the resin part
when installing.
89. INSTALL CAMSHAFT TIMING PULLEY (See page 14 −151)
SST 09960 −10010 (09962 −01000, 09963 −01000)
90. INSTALL CAMSHAFT POSITION SENSOR (See page 14 −108)
91. INSTALL INJECTOR ASSY (See page 11 −46)
92. INSTALL NOZZLE LEAKAGE PIPE ASSY (See page 14 −151)
SST 09992 −00242

A85428
Seal Width
2to4mm
(0.08 to 0.16 in.)Seal Packing
A62592
SST
A85760
90_
14
−156
−
ENGINE MECHANICAL CAMSHAFT (1CD−FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
(b) Apply seal packing to the oil seal retainer as shown in the illustration.
Seal packing: Part No. 08826 −00080 or equivalent
(1) Install a nozzle of which opening is cut to 2 to 4 mm
(0.08 to 0.16 in.).
(2) The parts must be set within 3 minutes and must be
assembled within 15 minutes after applying seal
packing.
(3) Immediately remove the nozzle from the tube, then reinstall the cap.
(c) Install the oil seal retainer with the 4 bolts. Tighten the 4 bolts uniformly in several steps.
Torque: 9.8 N
m (100 kgf
cm, 7.2 ft
lbf)
52. INSTALL CAMSHAFT TIMING PULLEY
(a) Install the pulley set key to the groove of the camshaft.
(b) Align the keyway of the timing pulley with the key located on the camshaft, then slide the pulley into place.
(c) Using SST, install the pulley bolt. SST 09960 −10010 (09962 −01000, 09963 −01000)
Torque: 88 N
m (899 kgf
cm, 65 ft
lbf)
53. INSTALL CAMSHAFT POSITION SENSOR (See page 14 −108)
54. INSTALL INJECTOR ASSY 55. INSTALL NOZZLE LEAKAGE PIPE ASSY
(a) Remove the bolt which is tightened at the center of thecamshaft bearing cap No. 4.
(b) Install the nozzle leakage pipe and 4 new gaskets.
NOTICE:
When installing the gaskets, pay attention to the mounting
orientation. Install the gasket so that the joint of the gasket
comes within the ranges shown in the illustration.
(c) Apply a light coat of engine oil to the 4 hollow screws and bolt.
(d) Tighten the 4 hollow screws and bolt by hand.
(e) Tighten the 4 hollow screws and bolt. Torque:
16 N
m (163 kgf
cm, 12 ft
lbf) for hollow screw
20 N
m (204 kgf
cm, 15 ft
lbf) for flange bolt
NOTICE:
In any case, when the torque exceeds the upper limit, re-
place the leakage pipe hollow screw and gaskets with new
ones.
(f) Check that there are no leaks from the nozzle leakage pipe connection.

A86430
New GasketHollow
Screw
SST
A09663
:Seal Packing
−
ENGINE MECHANICAL CAMSHAFT (1CD−FTV)(From September, 2003)
14 −157
AVENSIS Supplement (RM1045E)
(1) Apply a light coat of soapy water (any fluid to detect
fuel leakage) to the nozzle leakage pipe connec-
tion.
(2) Using SST (a turbocharger pressure gauge), attach SST to the fuel return side of the nozzle leakage
pipe, then maintain 100 kPa (1.0 kgf/cm
2 , 14.5 psi)
of pressure for 60 seconds to check that there are
no bubbles from the pipe connection.
SST 09992 −00242
(3) After checking fuel leaks, wipe off soapy water from the pipe connection.
56. INSTALL CYLINDER HEAD COVER SUB −ASSY
(a) Remove any old packing (FIPG) material.
(b) Apply seal packing to the cylinder head as illustrated. Seal packing: Part No. 08826 −00080 or equivalent
(c) Install the gasket to the cylinder head cover.
(d) Install the cylinder head cover with the 10 bolts. Torque: 13 N
m (135 kgf
cm, 9.7 ft
lbf)
57. INSTALL NOZZLE HOLDER SEAL
(a) Install 4 new nozzle holder seals.
58. INSTALL NOZZLE LEAKAGE PIPE NO.2 (See page 14 −108)
59. INSTALL VACUUM PUMP ASSY (See page 14 −108)
60. INSTALL INJECTION PIPE SUB −ASSY NO.1
NOTICE:
When assembling the pipes, perform the operation with the
engine cold at room temperature.
(a) Install the 2 lower injection pipe clamps to the intake man-
ifold.
(b) Remove the vinyl or plastic bag from the injector and the
vinyl tape from the common rail.
(c) Temporarily install the injection pipe.

A77437
Cylinder Head
Cylinder Block
Seal Packing
Cylinder
Head Gasket
2.5 to 3 mm
1.25 to 1.5 mm
A7741012
3 4
109 85
67
A00976A77411
90_
Engine
Front
Paint Mark
A83497
14−82
− ENGINE MECHANICALCYLINDER HEAD GASKET (2AZ−FSE)
AVENSIS Supplement (RM1045E)
63. INSTALL CYLINDER HEAD SUB−ASSY
HINT:
The cylinder head set bolts are tightened in the 2 successive
steps.
(a) Apply a continuous bead (Diameter 2.5 to 3 mm (0.098 to
0.118 in.)) of seal packing as shown in the illustration.
Seal packing: Part No. 08826−00080 or equivalent
NOTICE:
SRemove any oil from contact surface.
SInstall the cylinder head within 3 minutes after apply-
ing seal packing.
SAfter installing the cylinder head, cylinder head bolts
must be tightened within 15 minutes.
SDo not start the engine within 2 hours of installation.
(b) Apply a light coat of engine oil on the threads of the cylin-
der head bolts.
(c) Install bolts and plate washers to the cylinder head.
NOTICE:
Do not drop the washers into the cylinder head.
(d) Using several steps, install and tighten the 10 cylinder
head bolts and plate washers with a 10 mm bi−hexagon
wrench uniformly in the sequence shown in the illustra-
tion.
Torque: 79 N
m (806 kgf
cm, 58 ft
lbf)
(e) Mark the front side of the cylinder head set bolts with
paint.
(f) Retighten the cylinder head set bolts by 90_in the same
sequence as a step (d).
(g) Check that each paint mark is now at a 90_angle to the
front.
(h) Install the camshaft housing plug as shown in the illustra-
tion.

190V6−01
Z11580A80938A82936
Type A:
Type B:
BlueWhite
Red Green DarkClear or
light yellow
B00543
B00540
19−6
− STARTING & CHARGINGCHARGING SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
ON−VEHICLE INSPECTION
1. INSPECT BATTERY (EXCEPT MAINTENANCE−FREE
BATTERY)
(a) Check the battery electrolyte level.
(1) Check the electrolyte quantity of each cell.
If the electrolyte quantity is below the recommended amount,
add distilled water.
(b) Check the indicator as shown in the illustration.
HINT:
Indicator colorConditionType AType BCondition
GreenBlueOK
DarkWhiteCharging necessary
Clear or light yellowRedReplace
2. INSPECT BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Visually check the battery terminals.
(1) Check that the battery terminals are not loosened or corroded.
(b) Visually check the fusible link and fuses.
(1) Check that there is continuity of the fusible links, high−current fuses and regular fuses.
3. INSPECT V−RIBBED BELT
(a) Visually check the belt for excessive wear, frayed cords
etc.
SIf any defects are found, replace the v−ribbed belt.
SCracks on the rib side of the belt are considered ac-
ceptable.
If the belt has chunks missing from the ribs, it should
be replaced.
(b) Check that the belt fits properly in the ribbed grooves.
Confirm that the belt has not slipped out of the groove on the
bottom of the pulley by hand.
4. VISUALLY CHECK GENERATOR WIRING
(a) Check that the wiring is in good condition.
5. LISTEN FOR ABNORMAL NOISES FROM GENERATOR
(a) Check that no abnormal noise is heard from the generator while the engine is running.
6. INSPECT CHARGE WARNING LIGHT CIRCUIT

A88419
Disconnect Wire
from Terminal B
Generator Voltmeter
BatteryAmmeter
− STARTING & CHARGINGCHARGING SYSTEM (2AZ−FSE)
19−7
AVENSIS Supplement (RM1045E)
(a) Turn the ignition switch ON. Check that the charge warning light comes on.
(b) Start the engine, then check that the light goes off.
HINT:
If the light does not operate as specified, troubleshoot the charge warning light circuit.
7. INSPECT CHARGING CIRCUIT WITHOUT LOAD
(a) If a tester is not available, connect a voltmeter to the
charging circuit as follows:
(1) Disconnect the wire from terminal B of the genera-
tor, then connect it to the negative (−) lead of the
ammeter.
(2) Connect the positive (+) lead of the ammeter to ter-
minal B of the generator.
(3) Connect the positive (+) lead of the voltmeter to ter-
minal B of the generator.
(4) Ground the negative (−) lead of the voltmeter.
(b) Check the charging circuit.
(1) Keep the engine speed at 2,000 rpm, then check
the reading on the ammeter and voltmeter.
Standard amperage: 10 A or less
Standard voltage: 12.9 to 14.9 V
8. INSPECT CHARGING CIRCUIT WITH LOAD
(a) With the engine running at 2,000 rpm, turn the high beam headlights ON and turn the heater blower
switch to the ”HI” position.
(b) Check the reading on the ammeter.
Standard amperage: 30 A or more
SIf the ammeter reading is less than the standard amperage, repair the generator.
SIf the battery is fully charged, the indication will sometimes be less than the standard amperage.

Front Mark
A52515
A36644
Mark
1, 2 or 3Mark
1, 2 or 3
A13840
A13469
− ENGINE MECHANICALCYLINDER BLOCK ASSY (2AZ−FSE)
14−57
2AZ−FSE ENGINE REPAIR MANUAL (RM1083E)
(g) Check that the front mark of the connecting rod cap is fac-
ing in the correct direction.
(h) Apply a light coat of engine oil on the threads and under
the heads of the connecting rod cap bolts.
(i) Install the connecting cap (see step 37).
NOTICE:
Do not turn the crankshaft.
(j) Remove the 2 bolts and connecting rod cap.
(k) Measure the Plastigage at its widest point.
Standard oil clearance:
0.024 to 0.048 mm (0.0009 to 0.0019 in.)
Maximum oil clearance: 0.08 mm (0.0031 in.)
If the crank pin or bearing is damaged, replace the bearings. If
necessary, replace the crankshaft.
HINT:
If replacing a bearing, replace it with one that has the same
number as the connecting rod. There are 3 sizes of standard
bearings: 1, 2 and 3.
Standard bearing center wall thickness:
Mark 11.485 to 1.488 mm (0.0585 to 0.0586 in.)
Mark 21.489 to 1.491 mm (0.0586 to 0.0587 in.)
Mark 31.492 to 1.494 mm (0.0587 to 0.0588 in.)
(l) Completely remove the Plastigage.
3. REMOVE PISTON SUB−ASSY W/CONNECTING ROD
(a) Using a ridge reamer, remove all the carbon from the top
of the cylinder.
(b) Push the piston, connecting rod assembly and upper
bearing through the top of the cylinder block.
HINT:
SKeep the bearing, connecting rod and cap together.
SArrange the piston and connecting rod assemblies in the
correct order.
4. REMOVE CONNECTING ROD BEARING
