2005 TOYOTA AVENSIS Circuit

: ON : According to Flex Lock−up: OFF
NormalSolenoid
ValveSL1
SL2
SL3
S4
Gear Position 2nd 3rd 4th 5th1st
SL1
SL2
SL3
S4 Solenoid
Valve
Gear Position2nd 3rd 2nd 4th 2nd 5th 2nd 1st 2nd
SL1Malfunction
(During driving at1st
or 2nd)
SL1
SL2
SL3
S4 Solenoid
Valve
Gear Position3rd 4th 5th 4th 1st 4th
SL1Malfunction
(During driving at 3rd)
2nd 4th4th
SL1
SL2
SL3
S4 Solenoid
Valve
Gear Position3rd 4th 5th 4th 1st 4th
SL1Malfunction
(During driving at 4th
or 5th)
2nd 4th4th
SL1
SL2
SL3
S4 Solenoid
Valve
Gear Position3rd 4th 5th 4th 1st 4th
SL2 Malfunction
2nd 4th4th
Solenoid
ValveSL1
SL2
SL3
S4
Gear Position 2nd 3rd 4th1st
5th 4th
SL3 Malfunction
Solenoid
ValveSL1
SL2
SL3
S4
Gear Position 2nd 3rd 4th1st
5th 4th
SL1
SL2
SL3
S4 Solenoid
Valve
Gear Position3rd 4th 5th 4th 1st 4th
SL1, SL2, SL3, and S4
Malfunction
2nd 4th
4th
S4 Malfunction
: Condition in the normal operation is shown on the left of ” ”.
Condition in the fail−safe mode is shown on the right of ” ”.
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−561
AVENSIS Supplement (RM1045E)
(d) Shift solenoid valve SL1, SL2, SL3 and S4:
Fail safe function:
If either of the shift solenoid valve circuits develops an open or short, the ECM turns the other shift solenoid
”ON” and ”OFF” in order to shift into the gear positions shown in the table below.
Manual shifting as shown in the following table must be done (In case of a short circuit, the ECM stops send-
ing the current to the short circuit solenoid).
Even if starting the engine in the fail−safe mode, the gear position remain in the same position.

05−556−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)
AVENSIS Supplement (RM 1045E)
5. CHECK CHK ENG (MIL)
(a) The CHK ENG (MIL) comes on when the ignition switch
is turned to ON position and the engine is not running.
HINT:
If the CHK ENG (MIL) is not illuminated, troubleshoot the CHK
ENG (MIL) circuit (see page 05 −25 1).
( 1 ) When the engine is started, the CHK ENG (MIL)
should go off. If the lamp remains on, it means that
the diagnosis system has detected a malfunction or
abnormality in the system.

056IN−05
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)05 −545
AVENSIS Supplement (RM 1045E)
PROBLEM SYMPTOMS TABLE
HINT:
If a normal code is displayed during the diagnostic trouble code check although the trouble still occurs, check
the electrical circuits for each symptom in the order given in the charts on the following pages and proceed
to the page given for troubleshooting.
The Matrix Chart is divided into 2 chapters.
1. Chapter 1: Electronic Circuit Matrix Chart
S Refer to the table below when the trouble cause is considered to be electrical.
S If the instruction ”Proceed to next circuit inspection shown on matrix chart” is given in the flow chart
of each circuit, proceed to the circuit with the next highest number in the table to continue the check.
S If the trouble still occurs even though there are no abnormalities in any of the other circuits, check and
replace the ECM.
HINT:
* 1 : When the circuit on which mark * 1 is attached is a malfunction, DTC could be output (see page 05 −564).
*2: LHD
SymptomSuspect AreaSee page
No down −shift
(A particular gear, from 1st to 4th gear, is not down −shifted)
1. Shift solenoid valve (SL 1) circuit*1
2. Shift solenoid valve (SL2) circuit*1
3. Shift solenoid valve (SL3) circuit*1
4. Shift solenoid valve (SR) circuit*1
5. ECM
05 −589
05 −60 1
05 −61 0
05 −598
0 1− 32
No down −shift (5th
4th)
1. Park/neutral position switch circuit *1
2. Shift solenoid valve (S4) circuit*1
3. ECM
05 −566
05 −595
0 1− 32
No up −shift
(A particular gear, from 1st to 4th gear, is not up −shifted)1. Shift solenoid valve (SL 1) circuit*1
2. Shift solenoid valve (SL2) circuit*1
3. ECM
05 −589
05 −60 1
0 1− 32
No up −shift (4th
5th)
1. Park/neutral position switch circuit *1
2. Shift solenoid valve (S4) circuit*1
3. ECM
05 −566
05 −595
0 1− 32
No lock −up
1. Shift solenoid valve (DSL) circuit*1
2. Stop light switch circuit*1
3. Engine coolant temp. sensor circuit*1
4. ECM
05 −582
05 −580
05 −31
0 1− 32
No lock −up off1. Shift solenoid valve (DSL) circuit*1
2. ECM
05 −582
0 1− 32
Shift point too high or too low
1. Throttle position sensor circuit*1
2. Shift solenoid valve (SLT) circuit*1
3. ECM
05 −31
05 −622
0 1− 32
Up −shift to 5th from 4th while engine is cold1. Engine coolant temp. sensor circuit*1
2. ECM
05 −31
0 1− 32
No gear change by shifting into ”+” or ” −” while the shift lever is in
the S position1 . Transmission control switch circuit
2. ECM05 −625
0 1− 32
Harsh engagement (N
D)1. Shift solenoid valve (SL 1) circuit*1
2. ECM
05 −589
0 1− 32
Harsh engagement (Lock −up)1. Shift solenoid valve (SL2) circuit*1
2. ECM
05 −60 1
0 1− 32
Harsh engagement (Any driving position)1. Shift solenoid valve (SLT) circuit*1
2. ECM
05 −622
0 1− 32
Poor acceleration1. Shift solenoid valve (SLT) circuit*1
2. ECM
05 −622
0 1− 32

05−546−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)
AVENSIS Supplement (RM 1045E)
No kick
−down
1. Kick− down switch circuit *2
2. ECM
05−634
0 1− 32
Engine stalls when starting off or stopping1. Shift solenoid valve (DSL) circuit*1
2. ECM
05 −582
0 1− 32
ECT SNOW (ECTS) does not operate
1. Shift solenoid valve (SLT) circuit*1
2. Pattern select (SNOW/ECTS) switch circuit
3. ECM
05 −622
05 −630
0 1− 32
Malfunction in shifting
1. Park/neutral position switch circuit *1
2. Transmission control switch circuit
3. ECM
05 −566
05 −625
0 1− 32

05JL7−01
G23405Transmission Wire
05 −540−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)
AVENSIS Supplement (RM 1045E)
MANUAL SHIFTING TEST
1. PERFORM MANUAL SHIFTING TEST
HINT:
S With this test, it can be determined whether the trouble oc-
curs in the electrical circuit or is a mechanical problem in
the transaxle.
S If any abnormalities are found in the following test, the
problem is in the transaxle itself.
(a) Disconnect the transmission wire connector.
(b) Drive with the transmission wire disconnected. Shifting the shift lever to the D position to check whether
the shifting condition changes the table below.
Shift PositionShifting Condition
DNo Shift (Not Change)
HINT:
When driving with the transmission wire disconnected, the gear
position will be as follows:
S When the shift lever is in the D position, the gear is held
in the 4th position.
S When the shift lever is in the R or the P position, the gear
is also in the R or the P position respectively.
(c) Connect the transmission wire connector.
(d) Clear the DTC (see page 05 −557).

G23405Transmission Wire
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−539
AVENSIS Supplement (RM1045E)
(9) Disconnect the connector of the transmission wire.
HINT:
Disconnect the connector only when performing the D position
stall test.
(10) Start the engine.
(11) Firmly depress the brake pedal, shift to the D posi-
tion, depress the accelerator pedal all the way down
and check the line pressure while the stall test is
performed.
Specified line pressure:
ConditionD position
Stall test931to1,031kPa
(9.5 to10.5 kgf/cm2,135 to150 psi)
(12) Turn the ignition switch off.
(13) Remove the SST, install the test plug A.
(14) Remove the test plug B, install the SST and start en-
gine.
SST 09992−00095 (09992−00231, 09992−00271)
(15) Connect the transmission wire connector, depress
the brake pedal firmly, shift to the R position and
check that the line pressure while the engine is id-
ling and during the stall test.
Specified line pressure:
ConditionR position
Idling672 to 742 kPa
(6.9 to 7.6 kgf/cm2,97to108 psi)
Stall test1,768 to1,968 kPa
(18.0 to 20.1kgf/cm2, 256 to 285 psi)
(16) Remove the SST, install the test plug B.
(17) Clear the DTC.
Evaluation:
ProblemPossible cause
If the measured values at all position are higherSShift solenoid valve (SLT) defective
SRegulator valve defective
If the measured values at all position are lower
SShift solenoid valve (SLT) defective
SRegulator valve defective
SOil pump defective
SU/D (Underdrive) direct clutch defective
If pressure is low in the D position onlySD position circuit fluid leak
SForward clutch defective
If pressure is low in the R position only
SR position circuit fluid leak
SReverse clutch defective
S1st and reverse brake defective

190V6−01
Z11580A80938A82936
Type A:
Type B:
BlueWhite
Red Green DarkClear or
light yellow
B00543
B00540
19−6
− STARTING & CHARGINGCHARGING SYSTEM (2AZ−FSE)
AVENSIS Supplement (RM1045E)
ON−VEHICLE INSPECTION
1. INSPECT BATTERY (EXCEPT MAINTENANCE−FREE
BATTERY)
(a) Check the battery electrolyte level.
(1) Check the electrolyte quantity of each cell.
If the electrolyte quantity is below the recommended amount,
add distilled water.
(b) Check the indicator as shown in the illustration.
HINT:
Indicator colorConditionType AType BCondition
GreenBlueOK
DarkWhiteCharging necessary
Clear or light yellowRedReplace
2. INSPECT BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Visually check the battery terminals.
(1) Check that the battery terminals are not loosened or corroded.
(b) Visually check the fusible link and fuses.
(1) Check that there is continuity of the fusible links, high−current fuses and regular fuses.
3. INSPECT V−RIBBED BELT
(a) Visually check the belt for excessive wear, frayed cords
etc.
SIf any defects are found, replace the v−ribbed belt.
SCracks on the rib side of the belt are considered ac-
ceptable.
If the belt has chunks missing from the ribs, it should
be replaced.
(b) Check that the belt fits properly in the ribbed grooves.
Confirm that the belt has not slipped out of the groove on the
bottom of the pulley by hand.
4. VISUALLY CHECK GENERATOR WIRING
(a) Check that the wiring is in good condition.
5. LISTEN FOR ABNORMAL NOISES FROM GENERATOR
(a) Check that no abnormal noise is heard from the generator while the engine is running.
6. INSPECT CHARGE WARNING LIGHT CIRCUIT

A88419
Disconnect Wire
from Terminal B
Generator Voltmeter
BatteryAmmeter
− STARTING & CHARGINGCHARGING SYSTEM (2AZ−FSE)
19−7
AVENSIS Supplement (RM1045E)
(a) Turn the ignition switch ON. Check that the charge warning light comes on.
(b) Start the engine, then check that the light goes off.
HINT:
If the light does not operate as specified, troubleshoot the charge warning light circuit.
7. INSPECT CHARGING CIRCUIT WITHOUT LOAD
(a) If a tester is not available, connect a voltmeter to the
charging circuit as follows:
(1) Disconnect the wire from terminal B of the genera-
tor, then connect it to the negative (−) lead of the
ammeter.
(2) Connect the positive (+) lead of the ammeter to ter-
minal B of the generator.
(3) Connect the positive (+) lead of the voltmeter to ter-
minal B of the generator.
(4) Ground the negative (−) lead of the voltmeter.
(b) Check the charging circuit.
(1) Keep the engine speed at 2,000 rpm, then check
the reading on the ammeter and voltmeter.
Standard amperage: 10 A or less
Standard voltage: 12.9 to 14.9 V
8. INSPECT CHARGING CIRCUIT WITH LOAD
(a) With the engine running at 2,000 rpm, turn the high beam headlights ON and turn the heater blower
switch to the ”HI” position.
(b) Check the reading on the ammeter.
Standard amperage: 30 A or more
SIf the ammeter reading is less than the standard amperage, repair the generator.
SIf the battery is fully charged, the indication will sometimes be less than the standard amperage.
