ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)14 −129
AVENSIS Supplement (RM1045E)
166. INSTALL V −RIBBED BELT TENSIONER ASSY
Torque: 31 N
m (316 kgf
cm, 23 ft
lbf)
167. INSTALL GENERATOR BRACKET NO.1 Torque: 37 N
m (377 kgf
cm, 27 ft
lbf)
168. INSTALL GENERATOR ASSY (See Pub. No. RM1018E on page 19 −29)
169. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −138)
SST 09960 −10010 (09962 −01000, 09963 −01000)
170. INSTALL TIMING BELT (See page 14 −138)
171. CHECK VALVE TIMING (See page 14 −138)
172. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)
173. INSTALL TIMING BELT GUIDE (See page 14 −138)
174. INSTALL TIMING BELT NO.1 COVER (See page 14 −138)
175. INSTALL TIMING BELT NO.2 COVER (See page 14 −138)
176. INSTALL IDLER PULLEY SUB −ASSY
Torque: 40 N
m (408 kgf
cm, 30 ft
lbf)
177. INSTALL CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021
178. INSTALL GLOW PLUG ASSY (See Pub. No. RM1018E on page 19 −33)
179. INSTALL ENGINE MOUNTING BRACKET RR
Torque: 64 N
m (653 kgf
cm, 47 ft
lbf)
180. INSTALL ENGINE MOUNTING BRACKET FR Torque: 64 N
m (653 kgf
cm, 47 ft
lbf)
181. INSTALL DRIVE SHAFT BEARING BRACKET Torque: 64 N
m (653 kgf
cm, 47 ft
lbf)
182. INSTALL REAR END PLATE Torque: 8.4 N
m (86 kgf
cm, 74 in.
lbf)
183. INSTALL FLYWHEEL SUB −ASSY
(a) Using SST, hold the crankshaft. SST 09213 −54015 (09213 −70020), 09330 −00021
(b) Clean the bolts and their bolt holes.
(c) Apply adhesive to the 2 or 3 threads of the bolt end. Adhesive: Part No. 08833 −00070, THREE BOND 1324
or equivalent

A87967
Upward90_
Clamp
Bolt
Turbocharger Side:
Air Hose No. 2 Side:
Front 90
_ Clamp Bolt
20.4_
14
−134
−
ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD −FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
(b) Tighten the 2 hose clamps as shown in the illustration. Torque: 6.0 N
m (61 kgf
cm, 53 in.
lbf)
(c) Install the air tube No. 1 with the 3 bolts and nut. Torque: 25 N
m (255 kgf
cm, 18 ft
lbf)
208. INSTALL DIFFERENTIAL PRESSURE SENSOR ASSY Torque: 5.5 N
m (56 kgf
cm, 49 in.
lbf)
209. INSTALL RADIATOR ASSY (W/ AIR CONDITIONING) (See Pub. No. RM1018E on page 16 −51)
210. INSTALL ENGINE ROOM RELAY BLOCK NO.3
Torque: 5.3 N
m (54 kgf
cm, 47 in.
lbf)
211. INSTALL FUEL FILTER ASSY (See Pub. No. RM1018E on page 11 −82)
212. INSTALL AIR CLEANER ASSY Torque: 7.0 N
m (71 kgf
cm, 62 in.
lbf)
213. INSTALL BATTERY Torque:
5.0 N
m (51 kgf
cm, 44 in.
lbf) for bolt
3.0 to 4.0 N
m (31 to 41 kgf
cm, 27 to 35 in.
lbf) for nut
5.4 N
m (55 kgf
cm, 48 in.
lbf) for terminal
214. INSTALL ENGINE COVER SUB −ASSY NO.1
Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
215. BLEED CLUTCH PIPE LINE (See Pub. No. RM1018E on page 42 −12)
216. INSTALL FRONT WHEELS
Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
217. ADD MANUAL TRANSAXLE OIL (See Pub. No. RM1018E on page 41 −5)
218. ADD ENGINE OIL (See Pub. No. RM1018E on page 17 −30)
219. ADD ENGINE COOLANT (See page 16 −19)
220. CHECK CLUTCH FLUID LEAKAGE
221. CHECK FLUID LEVEL IN RESERVOIR
222. CHECK BRAKE FLUID LEAKAGE
223. CHECK FOR ENGINE OIL LEAKS
224. CHECK FOR FUEL LEAKS (See page 11 −46)
225. CHECK FOR ENGINE COOLANT LEAKS (See page 16 −15)
226. CHECK FOR EXHAUST GAS LEAKS
227. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See Pub. No. RM1018E on page 26 −6)

141NE−01
A93837
To
Turbocharger
Air Hose No. 2
A93406
SST
14 −90−
ENGINE MECHANICAL VALVE CLEARANCE (1CD−FTV)(From September,
2003)
AVENSIS Supplement (RM1045E)
VALVE CLEARANCE (1CD −FTV)(From September, 2003)
ADJUSTMENT
NOTICE:
S Before removing the injection pipes, clean them up with a soft brush and compressed air.
S After removing the injection pipes, cover the supply pump, common rail and injector mounting
area of the cylinder head cover with vinyl tape to prevent dust from being introduced.
S After removing the cylinder head cover, protect the injector inlet with a vinyl or plastic bag to
prevent foreign objects from being introduced.
HINT:
Inspect and adjust the valve clearance after the engine becomes cold.
1. REMOVE RADIATOR SUPPORT OPENING COVER
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER LH
4. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
5. REMOVE ENGINE UNDER COVER RH
6. REMOVE ENGINE COVER SUB −ASSY NO.1
(a) Remove the 5 nuts, then remove the engine cover.
7. REMOVE BATTERY
8. REMOVE AIR TUBE NO.1
(a) Disconnect the vacuum hoses and connectors.
(b) Loosen the 2 hose clamps.
(c) Remove the 3 bolts and nut, then detach the air tube No.1.
9. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
10. REMOVE FUEL PIPE NO.3 (See page 14 −108)
SST 09023 −12700
11. REMOVE INJECTION PIPE SUB −ASSY NO.1
(a) Remove the 2 upper injection pipe clamps from the intake
manifold.
(b) Using SST, remove the injection pipe from the common
rail side.
SST 09023 −12700
(c) Using SST, remove the injection pipe from the injector
side.
SST 09023 −12700
(d) After removing the fuel pipe, in order to prevent dust or foreign objects from being introduced, cover the common
rail with vinyl tape and protect the injector inlet with a vinyl
or plastic bag.

A93405
2to7mm
(0.0787 to
0.2756 in.)0to2mm
(0 to
0.0787 in.)
5to13mm
(0.1969 to
0.5118 in.)
Turbocharger Side:
Air Hose No. 2 Side:
A87967
Upward
90_
Clamp
Bolt
Turbocharger Side:
Air Hose No. 2 Side:
Front 90
_ Clamp Bolt
20.4_
−
ENGINE MECHANICAL VALVE CLEARANCE (1CD−FTV)(From September,
2003)14 −95
AVENSIS Supplement (RM1045E)
31. INSTALL AIR TUBE NO.1
(a) Install a new air hose No. 2 and new 2 hose clamps as
shown in the illustration.
(b) Tighten the 2 hose clamps as shown in the illustration. Torque: 6.0 N
m (61 kgf
cm, 53 in.
lbf)
(c) Install the air tube No. 1 with the 3 bolts and nut. Torque: 25 N
m (255 kgf
cm, 18 ft
lbf)
32. INSTALL BATTERY (See page 14 −108)
33. INSTALL ENGINE COVER SUB −ASSY NO.1
Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
34. INSTALL FRONT WHEEL RH
Torque: 103 N
m (1,050 kgf
cm, 76 ft
lbf)
35. CHECK FOR FUEL LEAKS (See page 11 −46)

F45361F46832
C80802
F46213
To Master
Cylinder Rear
To
Master
Cylinder
Front
To Rear Wheel
RH
To Front Wheel LH
To Front Wheel RH
To Rear Wheel
LH
C80806
32−6
−
BRAKE BRAKE BOOSTER ASSY (RHD) (2AZ −FSE)
AVENSIS Supplement (RM1045E)
(b) Using SST, connect the 3 brake tubes to the ways. SST 09023 −00100
Torque: 15N
m( 155 kgf
cm, 11 ft
lbf)
(c) Using SST and a spanner, connect the brake tube to the flexible hose of front brake RH.
SST 09023 −00100
Torque: 15N
m( 155 kgf
cm, 11 ft
lbf)
(d) Using SST, connect the 6 brake tubes to the brake actua- tor, as shown in the illustration.
SST 09023 −00100
Torque: 15N
m( 155 kgf
cm, 11 ft
lbf)
(e) Install the brake tube clamps with the 2 bolts. Torque: 6.0 N
m(6 1 kgf
cm, 53 in.
lbf)
1 6. INSTALL BRAKE MASTER CYLINDER SUB −ASSY
SST 09023 −00100
1 7. INSTALL ENGINE ASSEMBLY WITH TRANSAXLE (SEE PAGE 14− 23)
1 8. INSTALL IGNITION COIL ASSY (SEE PAGE 14− 79)
1 9. INSTALL CYLINDER HEAD COVER SUB −ASSY (SEE PAGE 14− 79)

141NN−01
A61184
A85928
−
ENGINE MECHANICAL CRANKSHAFT SEAL (1CD−FTV)(From September,
2003)14 −177
AVENSIS Supplement (RM1045E)
CRANKSHAFT SEAL (1CD −FTV)(From September, 2003)
REPLACEMENT
1. DRAIN ENGINE OIL
(a) Install a new gasket and the drain plug after draining engine oil.
Torque: 34 N
m (350 kgf
cm, 25 ft
lbf)
2. REMOVE FRONT WHEEL RH
3. REMOVE ENGINE UNDER COVER SUB −ASSY NO.1
4. REMOVE ENGINE UNDER COVER RH
5. REMOVE RADIATOR SUPPORT OPENING COVER
6. REMOVE ENGINE ROOM COVER SIDE
7. REMOVE ENGINE COVER NO.1 (See page 14 −90)
8. REMOVE INJECTOR DRIVER (See page 14 −108)
9. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See Pub. No. RM1018E on page 14 −269)
10. REMOVE GENERATOR V BELT (See Pub. No. RM1018E on page 14 −269)
11. SEPARATE POWER STEERING IDLE PULLEY BRACKET (See page 14 −138)
12. DISCONNECT ENGINE WIRE (See page 14 −138)
13. DISCONNECT VACUUM HOSE (See page 14 −108)
14. REM O VE ENG I NE M O UNTI NG I NSULATO R SUB−ASSY RH
(a) Place a wooden block on a jack underneath the engine.
(b) Remove the 3 bolts and 3 nuts, then detach the engine mounting insulator sub −assembly.
15. REMOVE CRANKSHAFT PULLEY (See page 14 −138)
SST 09213 −54015 (09213 −70020), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05031)
16. REMOVE IDLER PULLEY SUB −ASSY (See page 14 −138)
17. REMOVE TIMING BELT NO.2 COVER (See page 14 −138)
18. REMOVE TIMING BELT NO.1 COVER (See page 14 −138)
19. REMOVE TIMING BELT GUIDE
20. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING BRACKET (See page 14 −138)

141UL–01
A93669
A60622
14–32–
ENGINE MECHANICAL CYLINDER HEAD GASKET (1ZZ–FE/3ZZ–FE)(From
February, 2004)
AVENSIS REPAIR MANUAL SUPPLEMENT
(RM1098E)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See Pub. No. RM1018E on page 11–1)
2. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14–9)
3. REMOVE ENGINE ROOM COVER SIDE (See page 14–9)
4. REMOVE FRONT WHEEL RH
5. REMOVE ENGINE UNDER COVER SUB–ASSY NO.1 (See page 14–9)
6. REMOVE ENGINE UNDER COVER RH (See page 14–9)
7. DRAIN ENGINE COOLANT (See page 16–5)
8. REMOVE CYLINDER HEAD COVER NO.2
(a) Remove the 2 nuts and 2 clips, then detach cylinder headcover No.2.
9. REMOVE AIR CLEANER HOSE NO.1
(a) Disconnect the VSV connector.
(b) Disconnect fuel vapor feed No. 1 hose from the VSV.
(c) Disconnect the fuel vapor feed hose from the VSV.
(d) Disconnect the ventilation hose from air cleaner hose No. 1.
(e) Loosen the 2 air cleaner hose clamp bolts, then remove the air cleaner h\
ose.
10. DISCONNECT WATER BY–PASS HOSE
(a) Disconnect the water by–pass hose from the throttle body.
11. DISCONNECT WATER BY–PASS HOSE NO.2
(a) Disconnect water by–pass hose No. 2 from the throttle body.
12. REMOVE EFI FUEL PIPE CLAMP (See Pub. No. RM1018E on page 11–11)
13. DISCONNECT FUEL TUBE SUB–ASSY (See Pub. No. RM1018E on page 11–11)
14. DISCONNECT UNION TO CONNECTOR TUBE HOSE
(a) Disconnect the union to connector tube hose from the hose to hose tube.
15. DISCONNECT RADIATOR HOSE INLET
(a) Disconnect the radiator hose inlet from the cylinder head.
16. DISCONNECT HEATER INLET WATER HOSE
(a) Disconnect the heater inlet water hose from the cylinder head. 17. REMOVE FAN AND GENERATOR V BELT
(a) Turn the V–ribbed belt tensioner clockwise slowly andloosen it. Remove the fan and generator V belt, then put
back the V–ribbed belt tensioner carefully.

A76719
A62838SST
A62838SST
A76713
– ENGINE MECHANICALPARTIAL ENGINE ASSY (1ZZ–FE/3ZZ–FE)(From
February, 2004)14–15
AVENSIS REPAIR MANUAL SUPPLEMENT
(RM1098E)
(b) Remove the through bolt, then detach the engine mount-
ing insulator RR from the suspension crossmember.
(c) Separate the engine and the transaxle assembly from the
suspension crossmember and engine mounting member.
60. REMOVE STARTER ASSY (See Pub. No. RM1018E on page 19–3)
61. REMOVE MANUAL TRANSAXLE ASSY (M/T TRANSAXLE)
(See Pub. No. RM1018E on page 41–15)
62. REMOVE AUTOMATIC TRANSAXLE ASSY (A/T TRANSAXLE)
(See Pub. No. RM1018E on page 40–11)
63. REMOVE CLUTCH COVER ASSY (M/T TRANSAXLE) (See Pub. No. RM1018E on page 42–26)
64. REMOVE CLUTCH DISC ASSY (M/T TRANSAXLE) (See Pub. No. RM1018E on page 42–26)
65. REMOVE FLYWHEEL SUB–ASSY (M/T TRANSAXLE)
(a) Hold the crankshaft with SST, then remove the 8 bolts and
flywheel.
SST 09960–10010 (09962–01000, 09963–01000)
66. REMOVE DRIVE PLATE & RING GEAR SUB–ASSY
(A/T TRANSAXLE)
(a) Hold the crankshaft with SST, then remove the 8 bolts and
drive plate & ring gear.
SST 09960–10010 (09962–01000, 09963–01000)
67. REMOVE IGNITION COIL ASSY
(a) Disconnect the 4 ignition coil connectors.
(b) Remove the 2 nuts which are used to secure the engine
wire.
