4

1

A

2

3

B

NU761_2_G5-FRA.qxd 4/11/05 11:09 Page 5.22
5.22
BATTERY: troubleshooting (continued)
Starting the vehicle using the
battery from another vehicle
Proceed as follows when starting
your vehicle from another vehicle’s
battery:
Obtain suitable jump leads (with a
large cross section) from a
RENAULT Dealer or, if you already
have jump leads, ensure that they
are in perfect condition.
The two batteries must have an
identical voltage: 12 volts. The
battery supplying the current should
have a capacity (amp-hours, Ah)
which is at least the same as that of
the discharged battery.
Ensure that there is no risk of
contact between the two vehicles
(risk of short circuiting when the
positive terminals are connected)
and that the discharged battery is
properly connected. Switch off your
vehicle ignition.
Start the engine of the vehicle
supplying the current and run it at
an intermediate engine speed. Check that there is no contact
between cables
Aand Band that
cable A(+) is not touching any metal
parts on the vehicle supplying the
current.
Start the engine as you would
normally. As soon as it is running,
disconnect cables A and B in the
inverse order (4-3-2-1).
Secure the positive cable (+) Ato the
(+) terminal 1 of the discharged
battery, then to the (+) terminal2 of
the battery supplying the current.
Attach negative cable (–) B to (–)
terminal 3 of the battery supplying
the current and then to (–) terminal4
of the discharged battery.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.22 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
5

6

NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.27
5.27
WINDSCREEN WIPER BLADES (continued)
Regularly clean your rear screen.
Rear screen wiper blade 5
- Lift the wiper arm 6;
- move blade 5until some resistance
is met.
- remove the blade by pulling it. To refit
To refit the wiper blade, proceed in
reverse order to removal. Make sure
that the blade is correctly locked in
position.
 In frosty weather, makesure that the wiper
blades are not stuck by
ice (to avoid the risk of
the wiper motor overheating).
 Check the condition of the wiper blades.
Replace the wiper blades as
soon as they begin to lose
efficiency: approximately once
a year.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.27 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.28
5.28
TOWING: breakdown
Press the Start/Stop button twice in
succession once towing is finished
(risk of running down the battery).
Furthermore, it is essential to
respect the towing regulations
defined in the legislation of the
country concerned and, if your
vehicle is the towing vehicle, do not
exceed the towing weight of your
vehicle. Contact your RENAULT
Dealer.Towing procedure
Before any towing, check that the
steering column is not locked.
If it is not locked, insert the
RENAULT card into the reader and
press the start/stop button for five
seconds without pressing on the
pedals. The steering column
unlocks, the vehicle accessory
functions are supplied with power
and you can use the lights (stop
lights, directional indicator lights,
etc.): the vehicle must have its lights
on at night.
Do not remove the RENAULT card
from the reader at any point when
the vehicle is being towed.
Towing a vehicle with
automatic transmission: special
information
Engine switched off: The gearbox is
no longer lubricated. It is preferable
to tow this type of vehicle on a
trailer or tow it with the front
wheels off the ground.
Under exceptional circumstances ,
you may tow the vehicle with all
four wheels on the ground, only
going forward, with the gear lever in
the N position, and for a distance
not exceeding 30 miles (50 km).
If the lever is stuck at P,
even though you are
depressing the brake
pedal, the lever can be
released manually.
To do this, unclip the upper
section of the cover at the base of
the lever.
Press simultaneously on the mark
on the gaiter and the unlocking
button on the lever.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.28 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.32
OPERATING FAULTS (continued)
When the starter is activated CAUSES REMEDIAL ACTION
 There is no response, the indicator lights fail to light up and the starter
does not turn. Battery lead disconnected or terminals
oxidised.
Check battery terminals: scrape and
clean if oxidised and re-tighten.
Discharged battery. Connect another battery to the faulty battery.
Battery unserviceable. Replace battery. Do not push the vehicle if the steering
column is locked.
 Warning light bulbs go dim and starter turns very slowly. Battery terminals not tight, battery
terminals oxidised. Check battery terminals: scrape and
clean if oxidised and re-tighten.
Discharged battery. Connect another battery to the faulty battery.
5.32
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.32 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.34
5.34
OPERATING FAULTS (continued)
On the open road CAUSES REMEDIAL ACTION
 Abnormal white smoke from the exhaust. Mechanical fault: damaged cylinder
head gasket. Stop the engine.
Contact a RENAULT Dealer.
 Vibrations. Tyres not inflated to correct pressures,
incorrectly balanced or damaged.Check tyre pressures. If this is not the
problem, have them checked by a
RENAULT Dealer.
 Coolant boiling in the expansion
bottle. Mechanical fault: cylinder head gasket
blown, faulty coolant pump. Stop the engine.
Contact a RENAULT Dealer.
Engine cooling fan not working. Check appropriate fuse, otherwise contact a RENAULT Dealer.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.34 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.35
5.35
OPERATING FAULTS (continued)
On the open road CAUSES REMEDIAL ACTION
Coolant circuit fault. Contact a RENAULT Dealer.
 Smoke under the bonnet. Short circuit. Stop, switch off the ignition,
disconnect the battery.
- is slow to go out or remains litwhen accelerating. Low oil pressure. Stop: contact a RENAULT Dealer.
- at idle speed, Low oil pressure. Consult the nearest RENAULT Dealer.
 The oil pressure warning light
comes on:
- while turning or braking, The level is too low. Add engine oil (refer to the engine oil -
Top-up/Filling information in
section 4).
Faulty spark plugs, incorrect electrode
gaps.Contact a RENAULT Dealer.
 Unstable idle speed or the engine stalls. Poor compression (spark plugs,
ignition, air leak). Contact a RENAULT Dealer.
Fuel supply fault. Check the fuel level.
 Loss of engine power. Clogged air filter. Replace the cartridge.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.35 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.36
5.36
OPERATING FAULTS (continued)
On the open road CAUSES REMEDIAL ACTION
- weak or dead battery. Recharge or replace the battery.
 Steering wheel hard to turn: - assistance overheating, Leave to cool.
 The engine overheats. The coolant
temperature warning light comes on
(or the indicator needle is in the red
area). Coolant pump: belt stretched or
broken.
Engine cooling fan not working.
Stop the vehicle and switch off the
engine. Contact a RENAULT Dealer.
Coolant leaks. Check the condition of hoses and clips.
Check the expansion bottle: it should
contain coolant. If it does not, top it up
(once it has cooled). Take care not to
scald yourself. This action is only
temporary: contact your RENAULT
Dealer as soon as possible.
Radiator: never fill a hot radiator with cold coolant if a considerable quantity h\
as been lost. After any operation
on the vehicle which has involved even partial draining of the cooling s\
ystem, it must be refilled with a new
mixture prepared in the correct proportions. Reminder: only products app\
roved by RENAULT’s Technical
Department may be used for this purpose.
NU761_2_G5-ENG.qxp 1/5/2006 5:30 PM Page 5.36 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G5-FRA.qxd 4/11/05 11:10 Page 5.38
5.38
OPERATING FAULTS (continued)
Electrical equipment CAUSES REMEDIAL ACTION
- faulty earth connection. See above. - disconnected wire or incorrectly- positioned connector, Check and reconnect the wire or the
connector.
 The headlights One only:
no longer operate. - bulb blown. Replace bulb.
 Traces of condensation in the lights. This is not a fault. The presence of
traces of condensation in lights is a
natural phenomenon linked to
variations in temperature.
These traces soon disappear when the
lights are switched on.
Both: - if the circuit is fused. Check and replace if necessary.
 The headlights do not switch off. Faulty electrical controls. Contact your RENAULT Dealer.
