EM-248
[YD22DDTi]
CYLINDER BLOCK

CONNECTING ROD BEND AND TORSION

Use connecting rod aligner to check bend and torsion.

If it exceeds the limit, replace connecting rod assembly.
CONNECTING ROD BIG END INNER DIAMETER

Install connecting rod caps without connecting rod bearings and
tighten connecting rod nuts to the specified torque. Refer to EM-
235, "ASSEMBLY" .

Using inside micrometer, measure connecting rod big end inner
diameter.

If out of the standard, replace connecting rod.
CONNECTING ROD BUSHING OIL CLEARANCE
Connecting Rod Bushing Inner Diameter
Use inside micrometer to measure bushing inner diameter.Bend limit : 0.12 mm (0.0047 in)/100 mm (3.94 in)
Torsion limit : 0.12 mm (0.0047 in)/100 mm (3.94 in)
PBIC2077E
Standard : 55.000 - 55.013 mm (2.1654 - 2.1659 in)
PBIC1641E
Standard : 28.026 - 28.038 mm (1.1034 - 1.1039 in)
PBIC0120E

CYLINDER BLOCK
EM-249
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM

Piston Pin Outer Diameter
Use micrometer to measure piston pin outer diameter.
Calculation of Connecting Rod Bushing Clearance
(Connecting rod bushing clearance) = (Connecting rod bushing inner diameter) − (Piston pin outer diameter)

If it exceeds the limit, replace connecting rod and/or piston and piston pin assembly. Refer to EM-242,
"HOW TO SELECT CONNECTING ROD BEARING" and/or EM-242, "HOW TO SELECT PISTON" .
CYLINDER BLOCK TOP SURFACE DISTORTION

Using scraper, remove gasket installed onto cylinder block sur-
face. Remove contamination such as engine oil, scale, and car-
bon.
CAUTION:
Keep broken pieces of gasket clear of engine oil and engine
coolant passages.

Use straightedge and feeler gauge to check block upper surface
for six distortion.

If it exceeds the limit, replace cylinder block.
MAIN BEARING HOUSING INNER DIAMETER

Without installing main bearings, install main bearing caps, and
tighten bolts to the specified torque. Refer to EM-235, "
ASSEM-
BLY" .

Measure the inner diameter of main bearing housing with a bore
gauge.

If the measurement is out of the standard, replace cylinder block
and main bearing caps.
NOTE:
These components cannot be replaced as a single unit, because
they were processed together.Standard : 27.995 - 28.000 mm (1.1022 - 1.1024 in)
PBIC0117E
Standard : 0.026 - 0.044 mm (0.0010 - 0.0017 in)
Limit : 0.057 mm (0.0022 in)
Limit : 0.1 mm (0.004 in)
SEM501G
Standard : 66.654 - 66.681 mm (2.6242 - 2.6252 in)
PBIC1643E

CYLINDER BLOCK
EM-253
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM

MAIN BEARING OIL CLEARANCE
Method by Measurement

Install main bearings to cylinder block and bearing cap, and
tighten the bolts to the specified torque. Refer to EM-235,
"ASSEMBLY" . Then, measure the inner diameter of main bear-
ings.
(Bearing clearance) = (Bearing inner diameter) − (Crankshaft
main journal diameter)

If out of the standard, check main bearing housing inner diame-
ter and crankshaft main journal diameter, and select appropriate
main bearing to adjust clearance to specifications. Refer to EM-
244, "HOW TO SELECT MAIN BEARING" .
Method of Using Plastigage

Remove contamination such as engine oil and dust completely
from crankshaft main journal and each bearing surface.

Cut plastigage slightly shorter than bearing width. Place it in
crankshaft turning direction, avoiding oil holes.

Install main bearings and bearing cap and tighten to the speci-
fied torque. Refer to EM-235, "
ASSEMBLY" for the tightening
procedure.
CAUTION:
Do not rotate crankshaft.

Remove main bearings and bearing caps, and measure plasti-
gage width using scale on plastigage bag.
NOTE:
If out of specification, take same action mentioned in “Method by Measurement”.
CRUSH HEIGHT OF MAIN BEARING

When bearing cap is removed after being tightened to the speci-
fied torque with main bearings installed, the tip end of bearing
must protrude. Refer to EM-235, "
ASSEMBLY" .

If out of the standard, replace main bearings.
CRUSH HEIGHT OF CONNECTING ROD BEARING

When connecting rod bearing cap is removed after being tight-
ened to the specified torque with connecting rod bearings
installed, the tip end of bearing must protrude. Refer to EM-235,
"ASSEMBLY" .

If out of the standard, replace connecting rod bearings.Standard : 0.039 - 0.066 mm (0.0015 - 0.0026 in)
PBIC1644E
EM142
Standard : There must be crush height.
SEM502G
Standard : There must be crush height.
PBIC1646E

EM-254
[YD22DDTi]
CYLINDER BLOCK

MAIN BEARING CAP BOLT DEFORMATION

Measure the outer diameter of threaded area, “d1” and “d2”, at
the points specified in the figure.

When the necked point is identified at a point other than where
specified, measure at the point as “d2”.

Calculate the difference between “d1” and “d2”.

If it exceeds the limit, replace main bearing cap bolt.
CONNECTING ROD BOLT DEFORMATION

Install nuts to connecting rod bolts. Make sure that the nut can
be screwed smoothly on bolt threads by hand to the last thread
on the bolt.

If the nut does not screw in smoothly, measure the outer diame-
ter of the bolt thread at the point specified in the figure.

If a necked point is identified, measure at that point.

If it exceeds the limit, replace connecting rod bolts and nuts.
OIL JET

Check nozzle for deformation and damage.

Blow compressed air from nozzle, and check for clogs.

If out of the standard, replace oil jet.
OIL JET RELIEF VALVE

Using clean plastic stick, press check valve in oil jet relief valve.
Make sure that valve moves smoothly with proper reaction
force.

If out of the standard, replace oil jet relief valve.Limit : 0.13 mm (0.0051 in)
JEM219G
Standard : 8.90 - 9.00 mm (0.3504 - 0.3543 in) dia.
Limit : 8.75 mm (0. 3445 in) dia.
JEM220G
Standard : No deformation and no damage.
JEM221G
Standard:
Valve moves smoothly with proper reaction force.
