2005 NISSAN X-TRAIL Power Steering System

PS-32
POWER STEERING OIL PUMP

Removal and Installation (YD22DDTi Engine Model)EGS000AI
1. Remove chain case cover.
2. Revolving crank pulley, set sprocket holder [SST].
3. Fix sprocket holder [SST] with chain cover fixing bolts.
4. Using suitable tool, remove sprocket fixing nut and washer.
CAUTION:
Do not remove Tool while power steering oil pump is
removed.
5. Remove power steering pump fixing bolts, then remove it.
6. Apply Gasket to the installation surface of the engine chain case
cover as shown in the figure before installing the chain case
cover to the engine.
7. Bleed air after installation. Refer to PS-6, "
Air Bleeding Hydrau-
lic System" .
SST884C
SST885C
SST886C
SST890C
