2005 NISSAN X-TRAIL Power Steering System

EC-986
[YD (WITH EURO-OBD)]
ENGINE CONTROL SYSTEM

System ChartEBS0116V
*1: The input signal is sent to the ECM through CAN communication line.
*2: The output signal is sent from the ECM through CAN communication line.
Fuel Injection Control SystemEBS0116W
SYSTEM DESCRIPTION
Three types of fuel injection control are provided to accommodate engine operating conditions; normal control,
idle control and start control. The ECM determines the appropriate fuel injection control. Under each control,
the amount of fuel injected is adjusted to improve engine performance.
Pulse signals are sent to fuel injectors according to the input signals to adjust the amount of fuel injected to
preset value.
START CONTROL
Input/Output Signal Chart
When the ECM receives a start signal from the ignition switch, the
ECM adapts the fuel injection system for the start control. The
amount of fuel injected at engine starting is a preset program value
in the ECM. The program is determined by the engine speed, engine
coolant temperature and fuel rail pressure.
For better startability under cool engine conditions, the lower the
coolant temperature becomes, the greater the amount of fuel
injected. The ECM ends the start control when the engine speed
reaches the specific value, and shifts the control to the normal or idle
control.
Input (Sensor) ECM Function Output (Actuator)

Accelerator pedal position sensor

Fuel rail pressure sensor

Fuel pump temperature sensor

Engine coolant temperature sensor

Mass air flow sensor

Intake air temperature sensor

Crankshaft position sensor

Camshaft position sensor

Turbocharger boost sensor

Vehicle speed sensor*1

ESP/TCS/ABS control unit*1

Ignition switch

Stop lamp switch

Air conditioner switch*1

Park/neutral position switch

Battery voltage

Fuel level switch

Power steering pressure switch Fuel injection control Fuel injector and Fuel pump
Fuel injection timing control Fuel injector and Fuel pump
Fuel cut control Fuel injector and Fuel pump
Glow control system
Glow relay and glow indicator lamp*
2
On board diagnostic system
Malfunction indicator (MI)*2
EGR volume control EGR volume control valve
Cooling fan control Cooling fan relay
Turbocharger boost controlTurbocharger boost control solenoid
valve
Fuel transport pump control Fuel transport pump relay
Air conditioning cut control Air conditioner relay
Sensor Input Signal to ECM ECM Function Actuator
Engine coolant temperature sensor Engine coolant temperature
Fuel injection
control (start
control)Fuel injector
Fuel pump Crankshaft position sensor Engine speed
Camshaft position sensor Piston position
Ignition switch Start signal
Fuel rail pressure sensor Fuel rail pressure
SEF648S

TROUBLE DIAGNOSIS
EC-1011
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Priority Detected items (DTC)
1

U1000 CAN communication line

P0016 Crankshaft position - camshaft position correlation

P0101 P0102 P0103 Mass air flow sensor

P0112 P0113 Intake air temperature sensor

P0117 P0118 Engine coolant temperature sensor

P0122 P0123 P0222 P0223 P2135 Accelerator pedal position sensor

P0182 P0183 Fuel pump temperature sensor

P0192 P0193 Fuel rail pressure sensor

P0237 P0238 Turbocharger boost sensor

P0335 P0336 Crankshaft position sensor

P0340 P0341 Camshaft position sensor

P0563 Battery voltage

P0605 P0606 ECM

P0642 P0643 P0652 P0653 Sensor power supply

P1260 - P1267 Fuel injector adjustment resistor

P1610 - P1617 NATS

P2228 P2229 Barometric pressure sensor
2

P0045 Turbocharger boost control solenoid valve

P0089 P0628 P0629 P1272 - P1275 Fuel pump

P0200 - P0204 P1268 - P1271 P2146 - P2149 Fuel injector

P0380 Glow relay

P0404 EGR volume control valve

P0686 ECM relay

P1212 TCS communication line
3

P0088 P0093 Fuel system

P0217 Engine over temperature (OVERHEAT)

P0234 Turbocharger system

P0401 EGR function

P0501 P0502 P0503 ASCD vehicle speed sensor

P0504 ASCD brake switch

P0580 P0581 ASCD steering switch

P1211 TCS control unit

TROUBLE DIAGNOSIS
EC-1035
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


Freeze frame data
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
X: Applicable
*: This item includes 1st/2nd trip DTCs.
INSPECTION PROCEDURE
1. Turn ignition switch OFF.
2. Connect CONSULT-II to data link connector, which is located
under the driver side dash panel.
3. Turn ignition switch ON.
ItemDIAGNOSTIC TEST MODE
SELF-DIAG RESULTS
DATA MON-
ITORACTIVE
TEST
DTC*FREEZE
FRAME
DATA
ENGINE CONTROL COMPONENT PARTS
INPUTCrankshaft position sensor×××
Camshaft position sensor×
Engine coolant temperature sensor××××
Vehicle speed sensor×××
Fuel pump temperature sensor××
Accelerator pedal position sensor 1××
Accelerator pedal position sensor 2××
Fuel rail pressure sensor××
Mass air flow sensor×××
Intake air temperature sensor××
Turbocharger boost sensor×××
Battery voltage××
Park/neutral position (PNP) switch×
Power steering pressure switch×
Stop lamp switch×
Barometric pressure sensor (built-into ECM)××
Fuel injector adjustment resistor×
ASCD steering switch××
ASCD brake switch××
ASCD clutch switch××
OUTPUTFuel pump×××
Fuel injector×××
Glow relay×××
Cooling fan relay×××
EGR volume control valve×××
PBIB0376E

EC-1362
[YD (WITHOUT EURO-OBD)]
ENGINE CONTROL SYSTEM

System ChartEBS011WZ
*1: The input signal is sent to the ECM through CAN communication line.
*2: The output signal is sent from the ECM through CAN communication line.
Fuel Injection Control SystemEBS011X0
SYSTEM DESCRIPTION
Three types of fuel injection control are provided to accommodate engine operating conditions; normal control,
idle control and start control. The ECM determines the appropriate fuel injection control. Under each control,
the amount of fuel injected is adjusted to improve engine performance.
Pulse signals are sent to fuel injectors according to the input signals to adjust the amount of fuel injected to
preset value.
START CONTROL
Input/Output Signal Chart
When the ECM receives a start signal from the ignition switch, the
ECM adapts the fuel injection system for the start control. The
amount of fuel injected at engine starting is a preset program value
in the ECM. The program is determined by the engine speed, engine
coolant temperature and fuel rail pressure.
For better startability under cool engine conditions, the lower the
coolant temperature becomes, the greater the amount of fuel
injected. The ECM ends the start control when the engine speed
reaches the specific value, and shifts the control to the normal or idle
control.
Input (Sensor) ECM Function Output (Actuator)

Accelerator pedal position sensor

Fuel rail pressure sensor

Fuel pump temperature sensor

Engine coolant temperature sensor

Mass air flow sensor

Intake air temperature sensor

Crankshaft position sensor

Camshaft position sensor

Turbocharger boost sensor

Vehicle speed sensor*1

ESP/TCS/ABS control unit*1

Ignition switch

Stop lamp switch

Air conditioner switch*1

Park/neutral position switch

Battery voltage

Fuel level switch

Power steering pressure switch Fuel injection control Fuel injector and Fuel pump
Fuel injection timing control Fuel injector and Fuel pump
Fuel cut control Fuel injector and Fuel pump
Glow control system
Glow relay and glow indicator lamp*
2
On board diagnostic system
Malfunction indicator (MI)*2
EGR volume control EGR volume control valve
Cooling fan control Cooling fan relay
Turbocharger boost controlTurbocharger boost control solenoid
valve
Fuel transport pump control Fuel transport pump relay
Air conditioning cut control Air conditioner relay
Sensor Input Signal to ECM ECM Function Actuator
Engine coolant temperature sensor Engine coolant temperature
Fuel injection
control (start
control)Fuel injector
Fuel pump Crankshaft position sensor Engine speed
Camshaft position sensor Piston position
Ignition switch Start signal
Fuel rail pressure sensor Fuel rail pressure
SEF648S

EC-1382
[YD (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS

Basic InspectionEBS011XF
Precaution:
Perform Basic Inspection without electrical or mechanical loads applied;

Headlamp switch is OFF.

On vehicles equipped with daytime light systems, set lighting switch to the 1st position to light
only small lamps.

Air conditioner switch is OFF.

Rear defogger switch is OFF.

Steering wheel is in the straight-ahead position, etc.
Priority Detected items (DTC)
1

U1000 CAN communication line

P0016 Crankshaft position - camshaft position correlation

P0102 P0103 Mass air flow sensor

P0112 P0113 Intake air temperature sensor

P0117 P0118 Engine coolant temperature sensor

P0122 P0123 P0222 P0223 P2135 Accelerator pedal position sensor

P0182 P0183 Fuel pump temperature sensor

P0192 P0193 Fuel rail pressure sensor

P0237 P0238 Turbocharger boost sensor

P0335 P0336 Crankshaft position sensor

P0340 P0341 Camshaft position sensor

P0563 Battery voltage

P0605 P0606 ECM

P0642 P0643 P0652 P0653 Sensor power supply

P1260 - P1267 Fuel injector adjustment resistor

P1610 - P1617 NATS

P2228 P2229 Barometric pressure sensor
2

P0089 P0628 P0629 P1272 - P1275 Fuel pump

P0200 - P0204 P1268 - P1271 P2146 - P2149 Fuel injector

P0686 ECM relay

P1212 TCS communication line
3

P0088 P0093 Fuel system

P0217 Engine over temperature (OVERHEAT)

P0234 Turbocharger system

P0501 P0502 P0503 ASCD vehicle speed sensor

P0504 ASCD brake switch

P0580 P0581 ASCD steering switch

P1211 TCS control unit

TROUBLE DIAGNOSIS
EC-1407
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
X: Applicable
SELF-DIAGNOSTIC MODE
Self Diagnostic Item
Regarding items detected in “SELF-DIAG RESULTS” mode, refer to EC-1351, "INDEX FOR DTC" .
Freeze Frame Data
ItemDIAGNOSTIC TEST MODE
SELF-DIAG RESULTS
DATA MON-
ITORACTIVE
TEST
DTCFREEZE
FRAME
DATA
ENGINE CONTROL COMPONENT PARTS
INPUTCrankshaft position sensor×××
Camshaft position sensor×
Engine coolant temperature sensor××××
Vehicle speed sensor×××
Fuel pump temperature sensor××
Accelerator pedal position sensor 1××
Accelerator pedal position sensor 2××
Fuel rail pressure sensor××
Mass air flow sensor××
Intake air temperature sensor×
Turbocharger boost sensor×××
Battery voltage××
Park/neutral position (PNP) switch×
Power steering pressure switch×
Stop lamp switch×
Barometric pressure sensor (built-into ECM)××
Fuel injector adjustment resistor×
ASCD steering switch××
ASCD brake switch××
ASCD clutch switch××
OUTPUTFuel pump×××
Fuel injector×××
Glow relay××
Cooling fan relay×××
EGR volume control valve××
Freeze frame data item Description
DIAG TROUBLE CODE
[PXXXX]

The engine control component part/control system has a trouble code, it is displayed as “PXXXX”.
(Refer to EC-1351, "
INDEX FOR DTC" .)
CAL/LD VALUE [%]

The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP [°C] or
[°F]

The engine coolant temperature at the moment a malfunction is detected is displayed.
ENGINE SPEED [rpm]

The engine speed at the moment a malfunction is detected is displayed.
VEHICL SPEED [km/h] or
[mph]

The vehicle speed at the moment a malfunction is detected is displayed.
INT MANI PRES [kPa]

The intake manifold pressure at the moment a malfunction is detected is displayed.

TROUBLE DIAGNOSIS
TF-29
C
E
F
G
H
I
J
K
L
MA
B
TF

Trouble Diagnosis Chart for SymptomsEDS001VJ
If 4WD warning lamp turns ON, perform self-diagnosis. Refer to TF-32, "SELF-DIAG RESULT MODE" .
NOTE:

Light tight-corner braking symptom may occur depending on driving conditions in AUTO mode. This is not malfunction.

Heavy tight-corner braking symptom occurs when vehicle is driven in the following conditions: LOCK mode, steering
wheel is turned fully to either sides, and accelerator pedal was depressed.Symptom Condition Check item Reference page
4WD indicator lamp and LOCK indicator
lamp do not turn ON for approx. 1 second
when the ignition switch is turned to ON.
(4WD indicator lamp and LOCK indicator
lamp check)Ignition switch: ONCAN communication line
TF-46
Power supply and ground for 4WD con-
trol unit
Unified meter control unit
4WD warning lamp does not turn ON when
the ignition switch is turned to ON.
(4WD warning lamp check)Ignition switch: ONCAN communication line
TF-47
Unified meter control unit
4WD warning lamp does not turn OFF sev-
eral seconds after engine started.Engine runningCAN communication line
TF-48
Power supply and ground for 4WD con-
trol unit
Unified meter control unit
4WD solenoid
4WD actuator relay (integrated in 4WD
control unit)
Wheel sensor
4WD mode cannot be switched after engine
is started.Engine running4WD mode switch
TF-49
CAN communication line
Unified meter control unit
Heavy tight-corner braking symptom occurs
when the vehicle is driven in AUTO mode
and the steering wheel is turned fully to
either side after the engine is started. (See
NOTE.)

While driving

AUTO mode

Steering wheel is
turned fully to either
sidesCAN communication line
TF-50
4WD mode switch
Accelerator pedal position signal
4WD solenoid
Mechanical malfunction of electric con-
trolled coupling (clutch sticking etc.)
Vehicle does not enter 4WD mode even
though 4WD warning lamp turned to OFF.Vehicle speed: 10 km/h
(6 MPH) or less4WD solenoid
TF-51
Mechanical malfunction of electric con-
trolled coupling (Mechanical engage-
ment of clutch is not possible.)
Vehicle speed: 10 km/h
(6 MPH) or moreOperating condition of parking brake
4WD solenoid
Mechanical malfunction of electric con-
trolled coupling (Mechanical engage-
ment of clutch is not possible.)
While driving, 4WD warning lamp flashes
rapidly. (When flashing in approx. 1 minute
and then turning OFF.)
Rapid flashing: 2 times/second

While driving

AUTO mode and
LOCK modeProtection function is activated due to
heavy load to electric controlled cou-
pling. (4WD system is not malfunction-
ing.)TF-52
While driving, 4WD warning lamp flashes
slowly. (When continuing to flash until turn-
ing ignition switch OFF)
Slow flashing: 1 time/2 seconds
While driving

Vehicle speed: 20 km/h
(12 MPH) or moreTire size is different between front and
rear of vehicle.TF-53

BRC-2 SENSOR ROTOR ...................................................... 48
Removal and Installation ........................................ 48
REMOVAL ........................................................... 48
INSTALLATION .................................................... 48
ABS ACTUATOR AND ELECTRIC UNIT (ASSEM-
BLY) ........................................................................... 49
Removal and Installation ........................................ 49
ESP/TCS/ABS
PRECAUTIONS ......................................................... 50
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................. 50
Precautions for Brake System ................................ 50
Precautions for Brake Control ................................ 50
PREPARATION ......................................................... 51
Special Service Tools ............................................. 51
ON-VEHICLE SERVICE ............................................ 52
Adjustment of Steering Angle Sensor Neutral Posi-
tion .......................................................................... 52
SYSTEM DESCRIPTION .......................................... 53
System Diagram ..................................................... 53
ESP Function .......................................................... 53
TCS Function .......................................................... 53
ABS Function .......................................................... 54
EBD Function ......................................................... 54
Fail-Safe Function .................................................. 54
ESP/ TCS SYSTEM ............................................ 54
ABS, EBD SYSTEM ............................................ 54
Hydraulic Circuit Diagram ....................................... 55
CAN COMMUNICATION ........................................... 56
System Description ................................................. 56
CAN Communication Unit ....................................... 56
TYPE 4/TYPE 5 ................................................... 56
TYPE 6 ................................................................ 57
TYPE 9 ................................................................ 58
TROUBLE DIAGNOSIS ............................................ 60
How to Proceed With Diagnosis ............................. 60
BASIC CONCEPT ............................................... 60
DIAGNOSIS FLOWCHART ................................. 61
ASKING COMPLAINTS ....................................... 62
EXAMPLE OF DIAGNOSIS SHEET .................... 62
Component Parts and Harness Connector Location ... 63
Schematic ............................................................... 64
Wiring Diagram —ESP/TCS/ABS— ..................... 65
LHD MODEL ........................................................ 65
RHD MODEL ....................................................... 71
Control Unit Input/Output Signal Standard .............. 77
REFERENCE VALUE FROM CONSULT-II ......... 77
CONSULT-II Functions ........................................... 79
CONSULT-II MAIN FUNCTION ........................... 79
CONSULT-II BASIC OPERATION PROCEDURE
... 79
SELF-DIAGNOSIS .............................................. 81
DATA MONITOR .................................................. 83
ACTIVE TEST ..................................................... 86
For Fast and Accurate Diagnosis ........................... 88PRECAUTIONS FOR DIAGNOSIS ..................... 88
Basic Inspection ...................................................... 89
BASIC INSPECTION 1 BRAKE FLUID AMOUNT,
LEAKS, AND BRAKE PADS INSPECTION ......... 89
BASIC INSPECTION 2 POWER SYSTEM TER-
MINAL LOOSENESS AND BATTERY INSPEC-
TION .................................................................... 89
BASIC INSPECTION 3 ABS WARNING LAMP,
ESP OFF INDICATOR LAMP, SLIP INDICATOR
LAMP AND BRAKE WARNING LAMP INSPEC-
TION .................................................................... 90
Inspection 1 Wheel Sensor System ........................ 91
INSPECTION PROCEDURE ............................... 91
Inspection 2 Engine System ................................... 93
Inspection 3 ESP/TCS/ABS Control Unit System ... 93
Inspection 4 Pressure Sensor and the Circuit
between Pressure Sensor and ESP/TCS/ABS Con-
trol Unit. ................................................................... 93
Inspection 5 Steering Angle Sensor and Circuit
between Steering Angle Sensor and ESP/TCS/ABS
Control Unit. ............................................................ 95
Inspection 6 Yaw Rate/Side G sensor and the Circuit
between Yaw Rate/Side G sensor and ESP/TCS/
ABS Control Unit. .................................................... 97
Inspection 7 Solenoid Valve, ESP Switch-over Sole-
noid Valve and Circuit ............................................. 98
Inspection 8 Actuator Motor, Motor Relay and Circuit
.101
Inspection 9 Actuator Relay and Circuit ................103
Inspection 10 Stop Lamp Switch and Circuit .........105
Inspection 11 ESP/TCS/ABS Control Unit Power
Supply Circuit ........................................................105
Inspection 12 When “EMERGENCY BRAKE” is
indicated in the Self-Diagnostic Results ................107
Inspection 13 When “ST ANG SEN SIGNAL” is Indi-
cated in the Self-Diagnostic Results .....................107
Inspection 14 Brake Fluid Level of Reservoir Tank,
Communication Circuit between ESP/TCS/ABS
Control Unit and Brake Fluid Level Warning Switch .108
Inspection 15 CAN Communication Circuit, ESP/
TCS/ABS Control Unit and Steering Angle Sensor .109
Component Check ................................................109
ESP OFF SWITCH ............................................109
ESP RELAY BOX ...............................................109
ESP ACTUATOR ...............................................110
Symptom 1: ABS Works Frequently .....................112
Symptom 2: Unexpected Pedal Reaction .............113
Symptom 3: Longer Stopping Distance .................113
Symptom 4: ABS Does Not Work .........................113
Symptom 5: Pedal Vibration and ABS Operation
Noise .....................................................................113
Symptom 6: ESP OFF Indicator Lamp Does Not Illu-
minate ...................................................................114
Symptom 7: SLIP Indicator Lamp Does Not Illumi-
nate .......................................................................114
Symptom 8: Vehicle Jerks During ESP/TCS/ABS
Control ..................................................................115
