Page 4509 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual PERIODIC MAINTENANCE
MA-13
C
D
E
F
G
H
I
J
K
MA
B
MA

CHASSIS AND BODY MAINTENANCE (QR20DE AND QR25DE PETROL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace

Page 4510 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual MA-14
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Repla

MA-14
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, D = Check filter and drain water
NOTE:
Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.
(1) If valve noise increases, check valve clearance.
(2) Never use CG-4 oil.
(3) Oil filter element assembly and O-ring seal are replacement parts.
(4) First replace at 100,000 Km (60,000 miles), then every 60,000Km (36,000 miles). After first replacement, perform "I"
(checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(5) If engine power decreases, black exhaust smoke is emitted or engine noise increases, perform this maintenance item.
CHASSIS AND BODY MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence page
Perform at number of kilometers (miles) basis only.km x 1,000
(Miles x
1,000)20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Engine compartment and under vehicle
Intake & exhaust valve clearanceSee
NOTE (1)EM-185
Drive belts I I I I I IMA-29
Engine oil (Use recommended oil.)See
NOTE (2)RRRRRRMA-35
Engine oil filter (Use Eco filter or equivalent)See
NOTE (3)RRRRRRMA-36
Engine anti-freeze coolant (Use Genuine NISSAN
Anti-freeze Coolant (L250) or equivalent)See
NOTE (4)IRMA-30
Cooling system IIIIIIMA-32
Fuel linesIIMA-34
Air cleaner filter RRMA-35
Fuel filterDDRDDRMA-34
Fuel injectorSee
NOTE (5)EM-167
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page
Perform at number of kilometers (miles) basis only.km x 1,000
(Miles x
1,000)20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Underhood and under vehicle
Headlamp aiming I I ILT- 3 5
Brake & clutch, systems and fluid (For level & leaks) IIIIIIMA-44,
MA-39
Brake fluidRRMA-44
Brake booster vacuum hoses, connections & check
valveIIBR-25
Power steering fluid & lines (For level & leaks) IIIIIIMA-45
Manual transaxle gear oil (For leaks) I I IMA-39
Transfer gear oil (For level & leaks)IIIIIIMA-41
Differential gear oil (For level & leaks or replace)IIIIIIMA-43

Page 4513 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual RECOMMENDED FLUIDS AND LUBRICANTSMA-17
C
DE
F
G H
I
J
K
M A
B
MA

RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsELS000C8
*1: For further details, see “SAE Viscosity Number”.
*2:

RECOMMENDED FLUIDS AND LUBRICANTSMA-17
C
DE
F
G H
I
J
K
M A
B
MA

RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsELS000C8
*1: For further details, see “SAE Viscosity Number”.
*2: Never use API CG-4.
*3: Use Genuine NISSAN Anti-freeze Coolant (L250) or equivalent in its quality, in order to avoid possible aluminum corrosion w ithin the
engine cooling system caused by the use of non-genuine engine coolant.
Note that any repairs for the incidents within the engine cooling system while using non-genuine engine coolant may not be
covered by the warranty even if such incidents occurred during the warranty period.
*4: Contact a NISSAN dealership for more information regarding suitable fluids, including recommended brand(s) of DEXRON
TM III/
MERCONTM Automatic Transmission Fluid.
*5: Never mix different types of fluids (DOT 3 and DOT 4). Capacity (Approximate)
Recommended Fluids/Lubricants
Liter Imp measure
Engine oil
Drain and refill With oil filter
change
QR20DE,
QR25DE
4.1 3-5/8 qt
Gasoline engine
API SG, SH, SJ or SL *1
ILSAC grade GF-I, GF-II or GF-III *1
ACEA A2
Diesel engine
API CF-4*1, *2
ACEA B1, B3, B4, B5 *1, *2
YD22DDTi 5.2 4-5/8 qt
Without oil filter
change QR20DE,
QR25DE
3.7 3-1/4 qt
YD22DDTi 4.9 4-3/8 qt
Dry engine (engine overhaul) QR20DE,
QR25DE
4.7 4-1/8 qt
YD22DDTi 6.3 5-1/2 qt
Cooling system (with reservoir) QR20DE,
QR25DE
7.1 6-1/4 qt
Genuine NISSAN Anti-freeze Coolant (L250)
or equivalent in its quality*3
YD22DDTi 9.5 8-3/8 qt
Reservoir tank QR20DE,
QR25DE
0.7 5/8 qt
YD22DDTi 0.7 5/8 qt
Manual transaxle gear oil
2.2 3-7/8 pt
Genuine NISSAN gear oil or API GL-4, Vis-
cosity SAE 75W-85
Transfer gear oil 0.31 1/2 pt
API GL-5, Viscosity SAE 80W-90
Differential gear oil 0.55 1 pt
API GL-5, Viscosity SAE 80W-90
Automatic transaxle fluid 8.5 7-1/2 qt Genuine NISSAN ATF or equivalent*4
Power steering fluid — — DEXRON
TM III type ATF or equivalent
Brake and clutch fluid — —
DOT 3 or DOT 4 (US FMVSS No. 116)*5
Multi-purpose grease — — NLGI No. 2 (Lithium soap base)

Page 4548 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual IDX-2
ALPHABETICAL INDEX
Numerics
4WD - Wiring diagram ....................................... TF-23
4WD control unit inspection table ...................... TF-30
A
A/C air flow ................

IDX-2
ALPHABETICAL INDEX
Numerics
4WD - Wiring diagram ....................................... TF-23
4WD control unit inspection table ...................... TF-30
A
A/C air flow ......................................... ATC-32
, MTC-5
A/C component layout ..................................... ATC-23
A/C compressor clutch removal and installation ...........
ATC-146
A/C compressor precaution ............................. ATC-10
A/C compressor special service tool ................ ATC-14
A/C diagnostic work flow (auto A/C) ................ ATC-34
A/C HFC134a (R134a) system precaution ........ ATC-4
A/C HFC134a (R134a) system service procedure .......
ATC-141
A/C HFC134a (R134a) system service tools ... ATC-15
A/C HFC134a system service equipment precaution ...
ATC-10
A/C lubricant (R134a) ...................................... ATC-24
A/C operational check ......................... ATC-65, MTC-7
A/C performance test diagnoses ..................... ATC-98
A/C reray .......................................................... ATC-94
A/C self-diagnoses (auto A/C) ......................... ATC-57
A/C system description (auto A/C) ................... ATC-27
A/C trouble diagnoses (auto A/C) ....... ATC-34, MTC-3
A/C, A - Wiring diagram ................................... ATC-39
A/T fluid checking .................................. AT-16, MA-40
A/T fluid replacement ............................. AT-17, MA-41
A/T fluid temperature sensor ........................... AT-111
A/T IND - Wiring diagram .................................... DI-53
A/T indicator ........................................................ DI-53
A/T shift lock system ........................................ AT-398
A/T shift lock system - Wiring diagram ............ AT-399
A/T trouble diagnoses .......................... AT-57, AT-251
A/T Wiring diagram AT - 1ST ........................... AT-127
A/T Wiring diagram AT - 2ND .......................... AT-132
A/T Wiring diagram AT - 3RD .......................... AT-137
A/T Wiring diagram AT - 4TH .......................... AT-143
A/T Wiring diagram AT - BA/FTS ..................... AT-376
A/T Wiring diagram AT - CAN .............. AT-98, AT-330
A/T Wiring diagram AT - ENG SS ...... AT-121, AT-383
A/T Wiring diagram AT - FTS .......................... AT-108
A/T Wiring diagram AT - LPSV .......... AT-156, AT-389
A/T Wiring diagram AT - MAIN ........................ AT-395
A/T Wiring diagram AT - OVRCSV .... AT-180, AT-364
A/T Wiring diagram AT - PNP/SW ................... AT-102
A/T Wiring diagram AT - SSV/A ......... AT-163, AT-352
A/T Wiring diagram AT - SSV/B ......... AT-169, AT-358
A/T Wiring diagram AT - TCV ............ AT-150, AT-370
A/T Wiring diagram AT - TPS ............ AT-175, AT-347
A/T Wiring diagram AT - VSS A/T ..... AT-114, AT-334
A/T Wiring diagram AT - VSSMTR .... AT-194, AT-341
Accelerator control system ............................... ACC-2
Accelerator pedal position (APP) sensor ........ EC-409,
EC-416
, EC-432, EC-815, EC-822, EC-838, EC-1099,
EC-1138
, EC-1285, EC-1455, EC-1493, EC-1624
Accelerator pedal released position learning .... EC-46, EC-559
Air bag .............................................................. SRS-3
Air bag disposal .............................................. SRS-42
Air bleeding (hydraulic clutch) .............................. CL-8
Air bleeding for brake system .............................. BR-9
Air cleaner and air duct(QR20DE-QR25DE) ..... EM-16
Air cleaner and air duct(YD22DDTi) ............... EM-142
Air cleaner filter replacement(QR20DE-QR25DE) ........
MA-24
Air cleaner filter replacement(YD22DDTi) ......... MA-35
Air cleaner filter(QR20DE-QR25DE) ................. EM-16
Air cleaner filter(YD22DDTi) ........................... EM-142
Air conditioner cut control .... EC-38, EC-551, EC-988,
EC-1364
Air flow meter - See Mass air flow sensor ....... EC-151,
EC-644
Air mix door control linkage adjustment ......... ATC-78,
ATC-135
, MTC-10, MTC-32
Air mix. door motor ......................... ATC-76, ATC-135
Air spoiler, rear ................................................... EI-30
Alternator ........................................................... SC-13
Ambient sensor ............. ATC-109, ATC-111, ATC-121
Angular tightening application(QR20DE-QR25DE) ......
EM-5
Angular tightening application(YD22DDTi) ..... EM-130
Antenna - See Power antenna ........................... AV-37
APP2PW - Wiring diagram ........... EC-1241, EC-1580
APPS - Wiring diagram . EC-1101, EC-1457, EC-1626
APPS1 - Wiring diagram ................... EC-411, EC-817
APPS2 - Wiring diagram .. EC-418, EC-824, EC-1140,
EC-1495
APPS3 - Wiring diagram ... EC-434, EC-840, EC-1287
ASC/BS - Wiring diagram ............. EC-1208, EC-1547
ASC/SW - Wiring diagram EC-379, EC-782, EC-1220,
EC-1559
ASCBOF - Wiring diagram ................ EC-507, EC-947
ASCD ................................................ EC-529, EC-969
ASCD brake switch EC-387, EC-506, EC-790, EC-946
ASCD indicator lamp ........................ EC-514, EC-954
ASCD steering switch ....................... EC-377, EC-780
ASCIND - Wiring diagram EC-515, EC-955, EC-1342,
EC-1693
Ashtray illumination .......................................... LT-121
Audio .................................................................... AV-4
Auto air conditioner - Wiring diagram ............. ATC-39
Automatic amplifier ........................... ATC-55, ATC-67
Automatic transmission fluid replacement ....... MA-40,
MA-42
Axle ................................................................... MA-46
B
Back door ........................................................... BL-99
Back door window ............................................ GW-15
Back window .................................................... GW-15
BACK/L - Wiring diagram ................................. LT-100
Back-up lamp ...................................... LT-100, LT-118
Back-up lamp switch (M/T) ............................... MT-15
Barometric pressure (BARO) sensor ............ EC-1303,

Page 4553 of 4555

NISSAN X-TRAIL 2005 Service Repair Manual IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
P
Park/Neutral position switch ............. EC-398
, EC-802,
EC-1322
, EC-1673
Park/neutral position switch (A/T) .................... AT-100

IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
P
Park/Neutral position switch ............. EC-398
, EC-802,
EC-1322
, EC-1673
Park/neutral position switch (A/T) .................... AT-100
Park/neutral position switch (M/T) ..................... MT-15
PCV (positive crankcase ventilation) . EC-527, EC-967
PGC/V - Wiring diagram .................................. EC-271
PHASE - Wiring diagram ................... EC-258, EC-703
Pilot bushing replacement - See Pilot
converter(QR20DE-QR25DE) ........................... EM-89
Piston assembly(QR20DE-QR25DE) .............. EM-111
Piston pin inspection(QR20DE-QR25DE) ....... EM-107
Piston pin inspection(YD22DDTi) .................... EM-242
Piston ring inspection(QR20DE-QR25DE) ...... EM-108
Piston ring inspection(YD22DDTi) ................... EM-247
Piston to bore clearance(QR20DE-QR25DE) . EM-111
Piston to bore clearance(YD22DDTi) .............. EM-250
PNP/SW - Wiring diagram EC-400, EC-804, EC-1323,
EC-1674
POS - Wiring diagram ........................ EC-251, EC-695
POWER - Wiring diagram .................................... PG-3
Power antenna .................................................. AV-37
Power door lock .................................................. BL-22
Power seat ......................................................... SE-10
Power socket ................................................... WW-31
Power steering fluid level ......................... PS-6, MA-45
Power steering gear .......................................... PS-16
Power steering oil pressure switch EC-1326, EC-1677
Power steering oil pump .................................... PS-27
Power steering pressure (PSP) sensor .......... EC-278,
EC-711
Power steering system bleeding .......................... PS-6
Power supply routing ........................................... PG-2
Power window .................................................. GW-40
Precations for Leak detection dye ................... ATC-12
Precautions (General) .......................................... GI-4
Pre-delivery inspection ........................................ MA-4
Pressure plate - See Clutch cover ..................... CL-16
PRGVLV - Wirng diagram ............................... EC-885
Propeller shaft ..................................................... PR-3
Propeller shaft on vehicle service ........................ PR-3
PS/SEN - Wiring diagram .................. EC-279, EC-712
PST/SW - Wiring diagram ............. EC-1327, EC-1678
Q
Quick-glow system ........................ EC-1305
, EC-1643
R
R/FOG - Wiring diagram ................................... LT-112
Radiator(QR20DE-QR25DE) ................ CO-12, CO-15
Radiator(YD22DDTi) ............................ CO-35, CO-39
Radio - See Audio ............................................... AV-4
Rear air spoiler .................................................... EI-30
Rear bumper ........................................................ EI-17
Rear disc brake ................................................. BR-32
Rear door ............................................................ BL-18
Rear fog lamp ................................................... LT-112
Rear panel finisher .............................................. EI-31
Rear seat ........................................................... SE-32
Rear seat belt ...................................................... SB-4
Rear side window ............................................. GW-13
Rear suspension ............................................... RSU-5
Rear washer .................................................... WW-14
Rear window defogger ...................................... GW-17
Rear wiper ....................................................... WW-14
Refrigerant connection precaution ..................... ATC-5
Refrigerant discharging evacuating charging ATC-141
Refrigerant general precaution .......................... ATC-5
Refrigerant lines ............................................. ATC-141
Refrigerant pressure sensor EC-474, EC-914, ATC-18,
ATC-94
, ATC-157
Refrigeration cycle ........................................... ATC-18
Release bearing (clutch) .................................... CL-14
Removal and installation (A/T) ......................... AT-413
Removal and installation (Transfer) ................... TF-57
Reverse idler shaft (M/T) ...................... MT-23, MT-41
Reverse lamp switch (M/T) - See Back-up lamp switch
(M/T) .................................................................. MT-15
Reverse main gear (M/T) ...................... MT-23, MT-41
Rocker cover(QR20DE-QR25DE) .................... EM-44
Rocker cover(YD22DDTi) ............................... EM-178
Room lamp ....................................................... LT-132
Room lamp - See Interior lamp ......................... LT-132
ROOM/L - Wiring diagram ................................ LT-132
RP/SEN - Wiring diagram .................. EC-475, EC-915
RRO2 - Wiring diagram ..................... EC-852, EC-868
S
S/LOCK - Wiring diagram ....................... BL-24
, BL-45
S/SIG - Wiring diagram .................. EC-1345, EC-1696
SCTC/V - Wiring diagram ............. EC-1232, EC-1265,
EC-1271
, EC-1276, EC-1281, EC-1571, EC-1604,
EC-1610
, EC-1615, EC-1620
SEAT - Wiring diagram ...................................... SE-11
Seat belt inspection .......................................... MA-47
Seat belt pre-tensioner disposal ..................... SRS-42
Seat belt, front ..................................................... SB-3
Seat belt, rear ...................................................... SB-4
Seat, front .......................................................... SE-24
Seat, rear ........................................................... SE-32
Self-diagnosis (Transfer) ................................... TF-32
SEN/PW - Wiring diagram ................. EC-373, EC-776
Sheft warning system ...................................... BL-104
SHIFT - Wiring diagram ................................... AT-399
Shift control components (M/T) ............. MT-25, MT-43
Shift fork (M/T) ...................................... MT-25, MT-43
Shift lever ........................................................... MT-16
Shift lock system .............................................. AT-398
Shift schedule .................................................. AT-530
Shift solenoid valve A (A/T) ............................. AT-128
Shift solenoid valve B (A/T) ............................. AT-128
Side air bag (satellite) sensor ......................... SRS-39
Side window - See Rear side window ............... GW-13
Spark plug replacement(QR20DE-QR25DE) ... MA-26

Page: < prev 1-10 ... 17-24 25-32 33-40 41-48 49-56

engine overheat tyre pressure open gas tank instrument cluster automatic transmission fluid reset
