2005 NISSAN X-TRAIL check

DI-60
WARNING CHIME

Symptom ChartEKS002XQ
Power Supply and Ground Circuit InspectionEKS002YF
1. CHECK FUSES
Check for blown time control unit fuses.
OK or NG
OK >> GO TO 2.
NG >> Be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-79, "
FUSE
BLOCK - JUNCTION BOX (J/B)" .
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between time control unit connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect time control unit connection.
3. Check continuity between time control unit harness connector
M30 terminal 16 (B/R) and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.
Symptom Diagnosis/Service procedure
Light warning chime does not activate.Perform the following inspections.
1.DI-60, "
Power Supply and Ground Circuit Inspection"
2.DI-61, "Front Door Switch (Driver Side) Inspection"
3.DI-62, "Lighting Switch Input Signal Inspection"
Replace time control unit, found normal function in the above inspections.
Key reminder warning chime does not activate. Perform key reminder system trouble diagnosis.
Refer to BL-54, "
SYMPTOM CHART" .
Seat belt warning chime does not activate.Perform seat belt warning system trouble diagnosis.
Refer to SB-16, "
Trouble Diagnosis Chart by Symptom" .
Unit Power source Fuse No.
Time control unitBattery 28 (10A)
Ignition switch (ON) 5 (10A)
Terminals Ignition switch position
(+)
(–) OFF ON
Connector Terminal (Wire color)
M30 1 (L) Ground Battery voltage Battery voltage
M31 17 (G) Ground 0 V Battery voltage
SKIA9645E
Continuity should exist.
PKIC0614E

WARNING CHIME
DI-61
C
D
E
F
G
H
I
J
L
MA
B
DI

Front Door Switch (Driver Side) InspectionEKS002YH
1. CHECK DOOR SWITCH (DRIVER SIDE) INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between time control unit harness connector M31
terminal 30 (SB) and ground.
OK or NG
OK >> Front door switch (driver side) is OK.
NG >> GO TO 2.
2. CHECK FRONT DOOR SWITCH (DRIVER SIDE)
1. Disconnect front door switch (driver side) connector.
2. Check continuity between front door switch (driver side) connec-
tor B16 terminals 2 and 3.
OK or NG
OK >> GO TO 3.
NG >> Replace front door switch (driver side).
3. CHECK FRONT DOOR SWITCH (DRIVER SIDE) CIRCUIT
1. Disconnect time control unit connector.
2. Check continuity between time control unit harness connector
M31 terminal 30 (SB) and front door switch (driver side) harness
connector B16 terminal 2 (R).
3. Check continuity between time control unit harness connector
M31 terminal 30 (SB) and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK FRONT DOOR SWITCH (DRIVER SIDE) GROUND CIRCUIT
Check continuity between front door switch (driver side) harness
connector B16 terminal 3 (B) and ground.
OK or NG
OK >> Replace time control unit.
NG >> Repair harness or connector.When driver side door is opened : Approx. 0 V
When driver side door is closed : Approx. 12 V
SKIA1001E
When door switch is
released: Continuity should exist.
When door switch is
pushed: Continuity should not exist.
SKIA4498E
Continuity should exist.
Continuity should not exist.
SKIA9647E
Continuity should exist.
SKIA4418E

DI-62
WARNING CHIME

Lighting Switch Input Signal Inspection EKS002XU
1. CHECK LIGHTING SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between time control unit harness connector M31
terminal 19 (R/L) and ground.
OK or NG
OK >> Lighting switch is OK.
NG >>

GO TO 2 (without daytime light control unit).

GO TO 3 (with daytime light control unit).
2. CHECK LIGHTING SWITCH CIRCUIT (WITHOUT DAYTIME LIGHT SYSTEM)
1. Disconnect time control unit connector and combination switch connector.
2. Check continuity between time control unit harness connector
M31 terminal 19 (R/L) and combination switch harness connec-
tor E110 terminal 12 (R/L).
3. Check continuity between time control unit harness connector
M31 terminal 19 (R/L) and ground.
OK or NG
OK >> Check combination switch. Refer to LT- 1 2 0 , "COMBINA-
TION SWITCH" .
NG >> Repair harness or connector.
3. CHECK LIGHTING SWITCH CIRCUIT (WITH DAYTIME LIGHT SYSTEM)
1. Disconnect time control unit connector and daytime light control unit connector.
2. Check continuity between time control unit harness connector
M31 terminal 19 (R/L) and daytime light control unit harness
connector E115 terminal 11 (R/L).
3. Check continuity between time control unit harness connector
M31 terminal 19 (R/L) and ground.
OK or NG
OK >> Check daytime light control unit. Refer to LT- 5 0 , "Trou-
ble Diagnoses" in HEADLAMP (WITH DAYTIME) -
XENON TYPE - or LT- 6 0 , "
Trouble Diagnoses" in HEADLAMP (WITH DAYTIME) - CONVEN-
TIONAL TYPE -.
NG >> Repair harness or connector.Lighting switch (1st or 2nd position) : Approx. 12 V
Lighting switch (OFF) : Approx. 0 V
SKIA0996E
Continuity should exist.
Continuity should not exist.
SKIA9653E
Continuity should exist.
Continuity should not exist.
SKIA9654E

WW-1
WIPER, WASHER & HORN
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION WW
A
B
WW

WIPER, WASHER & HORN
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
FRONT WIPER AND WASHER SYSTEM .................. 4
System Description .................................................. 4
WIPER OPERATION ............................................ 4
WASHER OPERATION ......................................... 5
Wiring Diagram — WIPER — .................................. 6
Wiring Diagram — WIPER —/LHD models .............. 7
Terminal and Reference Values for Combination
Switch ....................................................................... 8
Removal and Installation of Front Wiper Arms,
Adjustment for Wiper Arms Stop Location ............... 8
Removal and Installation of Front Wiper Drive
Assembly .................................................................. 9
REMOVAL ............................................................. 9
INSTALLATION ................................................... 10
Front Washer Nozzle Adjustment ............................ 11
Washer Tube Layout ............................................... 11
Removal and Installation of Front Washer Nozzle ... 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 12
Inspection for Front Washer Nozzle ....................... 12
CHECK VALVE ................................................... 12
Removal and Installation of Wiper and Washer
Switch ..................................................................... 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 12
Removal and Installation of Washer Tank .............. 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 13
Removal and Installation of Washer Motor ............ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 13
REAR WIPER AND WASHER SYSTEM .................. 14
Wiring Diagram — WIP/R — .................................. 14
Terminal and Reference Values for Combination
Switch ..................................................................... 16Removal and Installation of Rear Wiper Arms ........ 16
WIPER ARMS ..................................................... 16
Removal and Installation of Rear Wiper Motor ....... 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 17
Rear Washer Nozzle Adjustment ........................... 18
Removal and Installation of Rear Washer Nozzle ... 18
REMOVAL ........................................................... 18
INSTALLATION ................................................... 18
Inspection for Rear Washer Nozzle ........................ 18
CHECK VALVE .................................................... 18
Removal and Installation of Wiper and Washer
Switch ..................................................................... 19
Removal and Installation of Washer Tank .............. 19
Removal and Installation of Washer Motor ............. 19
Washer Tube Layout .............................................. 19
HEADLAMP WASHER ............................................. 20
System Description ................................................. 20
Wiring Diagram —HLC— ....................................... 21
Wiring Diagram —HLC—/RHD models .................. 23
Removal and Installation of Headlamp Washer Noz-
zle ........................................................................... 25
REMOVAL ........................................................... 25
INSTALLATION ................................................... 25
Inspection for Headlamp Washer Nozzle ............... 25
CHECK VALVE .................................................... 25
Removal and Installation of Washer Tank .............. 25
Removal and Installation of Washer Motor ............. 25
Washer Tube Layout .............................................. 26
HORN ........................................................................ 27
Wiring Diagram — HORN — .................................. 27
Removal and Installation ........................................ 28
REMOVAL ........................................................... 28
INSTALLATION ................................................... 28
CIGARETTE LIGHTER ............................................. 29
Wiring Diagram — CIGAR — ................................. 29
Removal and Installation ........................................ 30
REMOVAL ........................................................... 30
INSTALLATION ................................................... 30
POWER SOCKET ..................................................... 31

WW-10
FRONT WIPER AND WASHER SYSTEM

4. Remove 4 screws and remove front wiper drive assembly from
the vehicle.
5. Disconnect front wiper motor connector.
6. Remove wiper link from wiper frame.
7. Remove motor arm from wiper motor.
8. Remove front wiper motor from wiper frame.
INSTALLATION
1. Connect front wiper motor to connector. Turn the front wiper
switch ON to operate front wiper motor, then turn the front wiper
switch OFF (auto stop).
2. Disconnect wiper motor connector.
3. Install front wiper motor to the wiper frame.
4. Install front wiper drive assembly to the vehicle.
5. Install wiper link to the wiper motor arm.
6. Connect front wiper motor connector. Turn the front wiper switch
ON to operate the front wiper motor, then turn wiper switch OFF
(auto stop)
7. Rotate motor arm to the upper limit position.
8. Install front wiper drive assembly to the vehicle.
9. Turn the front wiper switch ON to operate the Wiper motor, then
turn front wiper switch OFF (auto stop)
10. Install cowl top cover. Refer to EI-20, "
COWL TOP" .
11. Install wiper arm to the vehicle.
CAUTION:

Never drop the wiper motor or cause it to contact other parts.

Check the grease conditions of the motor arm and wiper link joint (at retainer). Apply grease if
necessary.
SKIA0016E
PKIA0475E
Motor arm mounting
nut : 17.7 N·m (1.8 kg-m, 13 ft-lb)
Wiper motor mount-
ing screw : 4.5 N·m (0.46 kg-m, 40 in-lb)
Front wiper drive
assembly mounting
bolt : 7.7 N·m (0.79 kg-m, 68 in-lb)
SKIA0092E
PKIA0476E

WW-12
FRONT WIPER AND WASHER SYSTEM

Removal and Installation of Front Washer Nozzle EKS0032U
REMOVAL
Push front washer nozzle pawl toward engine hood to pull out.
INSTALLATION
1. After connecting washer hose, press nozzle from cowl top cover surface.
2. Assemble nozzle and socket.
3. Adjust nozzle injection position.
Inspection for Front Washer Nozzle EKS0032V
CHECK VALVE
Blow air in the injection direction, and check that air flows only one
way. Make sure that the reverse direction (inhale) is not possible.
Removal and Installation of Wiper and Washer Switch EKS0032W
REMOVAL
1. Remove steering column cover. Refer to IP-10, "INSTRUMENT
PANEL ASSEMBLY" in “INSTRUMENT PANEL (IP)” section.
2. Remove wiper and washer switch connector.
3. Remove two screws then remove wiper and washer switch from
the spiral cable.
INSTALLATION
Installation is the reverse order of removal.
PKIA9740E
PKIA9741E
SKIA0018E

FRONT WIPER AND WASHER SYSTEM
WW-13
C
D
E
F
G
H
I
J
L
MA
B
WW

Removal and Installation of Washer Tank EKS0032X
REMOVAL
1. Remove washer tank inlet mounting screw and pull out washer
tank inlet.
2. Remove fender protector. Refer to EI-21, "
FENDER PROTEC-
TOR" .
3. Remove washer motor connector.
4. Remove washer tank mounting screw and pawl.
5. Remove washer hose, and remove the washer tank from the
vehicle.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
After installation, add water up to the upper level of the washer tank inlet, and check for water leaks.
Removal and Installation of Washer Motor EKS0032Y
REMOVAL
1. Remove fender protector. Refer to EI-21, "FENDER PROTECTOR"
2. Remove washer motor connector and hose.
3. Pull out washer motor in the direction of the arrow in the figure,
and remove the washer motor from the washer tank.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
When installing washer motor, there should be no packing twists, etc.
PKIA0484E
PKIA8885E
Washer tank mounting screw
: 4.5 N·m (0.46 kg-m, 40 in-lb)
PKIC0591E

REAR WIPER AND WASHER SYSTEM
WW-17
C
D
E
F
G
H
I
J
L
MA
B
WW

Removal and Installation of Rear Wiper MotorEKS00332
REMOVAL
1. Remove the back door finisher. Refer to EI-34, "BACK DOOR TRIM" .
2. Disconnect wiper motor connector.
3. Remove wiper arm from the vehicle.
4. Remove wiper motor form the vehicle.
5. Remove rubber from the vehicle.
INSTALLATION
1. Install rubber to the vehicle.
2. Install wiper motor to the vehicle.
3. Connect wiper motor to connector. Turn the rear wiper switch ON to operate wiper motor, then turn the
rear wiper switch OFF (auto stop).
4. Install wiper arm to the vehicle.
5. Install back door finisher. Refer to EI-34, "
BACK DOOR TRIM" .
CAUTION:

Never drop the wiper motor or cause it to contact other parts.

Check the grease conditions of the motor arm and wiper link joint (at retainer). Apply grease if
necessary.
1. Wiper motor 2. Rubber 3. Nut cover
4. Wiper arm 5. Wiper blade
PKIA7846E
SKIA0040E
Rear wiper motor mounting bolt
: 4.5 N·m (0.46 kg-m, 40 in-lb)
