2005 MERCEDES-BENZ CL-Class Comand Manual

95 Telephone*
Telephone operation
Entering the unlock code
Use the number keys 1 through 0
to enter the four-digit unlock code.
Asterisks instead of digits will appear in
the input line.

Press the
OK
soft key.
If entered code is correct and the mobi-
le phone is registered in a network, the
mobile phone is ready for use.GSM mobile phone
Entering the PIN code

Enter the PIN code for the mobile pho-
ne. Refer to the mobile phone opera-
tor’s manual on how to do this.
If no SIM card is in the mobile phone,
the message
Check
SIM
Card
ap-
pears.

Insert a SIM card. Refer to the mo-
bile phone operator’s manual.
Entry incorrect:
You will hear a warning sound.

You need to re-enter your PIN code.
Entering codes
iYour unlock code prevents unauthori-
zed persons from using your mobile
phone. Be sure to memorize this code, a
four digit number, carefully.
If you enter an incorrect code, the sys-
tem returns to the menu for entering the
unlock code.iYou must always enter the unlock code
when you switch on the telephone the
first time (if mobile phone is in locked
mode). Warning
G
When in the enter unlock code screen, the
emergency number 911 (default input) will
be dialed if you press “1” longer than 2 se-
conds. The 911 emergency call system is a
public service. Using it without due cause is
a criminal offense.
!If the PIN is entered incorrectly three
times in a row, the SIM card will be
blocked. The message
SIM Card
Blocked
is displayed briefly. After that
the message
PIN Blocked
Please
Enter PUK on Cell Phone is
displayed.

96 Telephone*Telephone operationEntering the PUK
If you enter your PIN incorrectly three
times in a row, you need to enter the PUK
number.
The PUK can only be entered at the mobile
phone. Refer to the mobile phone
operator’s manual.When the COMAND is switched on, you
can switch to telephone operation from
any other system (e.g. radio):

Press a.
The Telephone menu will appear.The telephone is ready for operation
Message
Ready
and the reception
strength Ö are shown on the status bar.
Other messages

Roaming The mobile phone is using a non home
type system

no Serv.The mobile phone is not logged into a
network
Fault messages:
Telephone Not Inserted
Plug the mobile phone into the mobile
phone cradle*. Refer to the separate
mobile phone operator’s manual.
Telephone UnavailableYour vehicle may not have a mobile phone
cradle* installed and/or the telephone
control unit may not be coded properly.
Contact an authorized Mercedes-Benz
Center.
iThe PUK number is provided by your
mobile phone service provider.
Switching to telephone operation

97 Telephone*
Telephone operation
You can use the following functions in the
telephone menu:
Entering a telephone number
(page 98)

Use the redial function (
page 99)

Displaying the dialed numbers list
(page 100)

Displaying the received calls list
(page 101)

Use speed-dialing (
page 102)

Use quick-dialing (
page 102)

Displaying the phone book
(page 104)

Adjusting balance/fader settings
(page 29)The system detects an incoming call, the
phone rings.
Incoming calls are indicated in a window in
any system (e.g. radio).
The window shows:

the caller’s number if it is transmitted
or

the caller’s name if her or his name and
number are saved in the phone book.Accepting a call

Press k.
or

Press E.
The window disappears and the display
will change to the call menu
(page 102). An active audio source
will be muted. You talk over the hands-
free set.
Muting the ringing tone

Press K.
or

Press H to highlight
Reject
and
than press E.
The window disappears. The last active
audio source is audible.
Incoming call

98 Telephone*Telephone operationSetting the volume for hands-free ope-
ration
Raising the volume
Turn the rotary control on the e but-
ton to the right.
Lowering the volume

Turn the rotary control on the e but-
ton to the left.
For more information, see chapter “At
a glance” (
page 27).Sound settings
You can change the sound settings (only
Bal/Fad) during a conversation.
For more information, see chapter “At a
glance” (
page 29).
Additional control functions are explained
at “Active Call” (
page 102).
Ending a call

Press K.
You can use the following functions to
make a phone call:

Dialing a telephone number
(page 98)

Redial (
page 99)

Selecting an entry from the dialed
numbers list (
page 100)

Selecting an entry from the received
calls list (
page 101)

Use speed-dialing (
page 102)

Use quick-dialing (
page 102)

Selecting a phone book entry and
dialing the number (
page 105)
Dialing a telephone number
Entering a telephone number

Open the Telephone menu
(page 96).
iThis function is possible during an
active call, otherwise volume of audio
source, e.g. radio is changed.
After ending the call, the system stores
the current volume setting. If current
volume setting exceeds the default set-
ting, then the system will use the de-
fault level for next incoming/outgoing
call.
iNo ring or DTMF tones will be heard
when a mobile phone set to silent mode
is inserted into the cradle. For ringtone
settings, refer to the separate opera-
ting instructions for the mobile phone.Outgoing calls
iYou can also make a phone call from
the address book (
page 176) and
using the Voice control system*. Refer
to separate Voice control system*
operating instructions.

99 Telephone*
Telephone operation

Use the number keys 1 - 0 to enter
the telephone number.
Deleting the last or several digits:
Press the
Delete
soft key once or
several times.
Deleting all digits:

Press K.
or

Press and hold
Delete
soft key for
more than 2 seconds.
Begin dialing

When you have entered the telephone
number, press k to confirm your
input.
or

In the Telephone menu, press the
Send

soft key.
or

Press E.Dialing will begin. If a name is associa-
ted with the phone number saved in the
phone book, the name appears on the
screen. In the status bar, the off-hook
symbol will appear.
COMAND will mute an active audio
source. If the person called answers
the call, the call is active. You talk over
the hands-free set.
Ending a call

Press K.
or

Press the
End
soft key.Subsequent dialing
Transmitting other dial tones:

During a call you can press the number
keys 1 through 0, # and *.
Redial

In the Telephone menu, press k or
E twice.
The telephone dials the number that
was dialed last.iIf the system is downloading the phone
book at that time (e.g. after inserting
the mobile phone) these tones may be
transmitted with delay.iIf you press k or E just once, the
dialed numbers list is displayed
(page 100).

100 Telephone*Telephone operationSelecting an entry from the dialed
numbers list
The COMAND automatically generates a
list of the last 10 numbers dialed. The list
is sorted chronologically with the most
recently dialed number at the top of the
list.
Displaying the list
In the Telephone menu (
page 96),
press the
Redial
soft key.
or

In the Telephone menu (
page 96),
press the
Calls
soft key.

Press H to display the dialed num-
bers list.
The most recently dialed number is
highlighted.The status bar shows:

the caller’s name if her or his name and
number are stored in the phone book

the message
Unknown
Name
if no entry
is available
You can select the following functions:

Changing the list display

Selecting an entry and begin dialing

Ending a call (
page 99)Changing the list display

Press the
123
soft key.
The display changes to names.
or

Press the
ABC
soft key.
The display changes to numbers.
Selecting an entry and begin dialing

Use g or G to select the desired
entry.

Press k.
or

Press E.
The telephone dials the number.
iDuplicate entries will be shown only
once. This means the list may contain
less than 10 entries.

101 Telephone*
Telephone operation
Selecting an entry from the received
calls list
The COMAND automatically generates a
list of the last 10 calls received. The list is
sorted chronologically with the most
recently received call at the top of the list.
Displaying the list
In the Telephone menu (
page 96),
press the
Calls
soft key.
The list is displayed and the most
recently received number is
highlighted. The status bar shows:

the caller’s name if her or his name and
number are stored in the phone book

the message
Unknown
Name
if no entry
is available

the telephone numberYou can select the following functions:

Changing list display (
page 100)

Selecting an entry and begin dialing
(page 100)

Ending a call (
page 99)
Missed calls
If there are one or more missed calls avai-
lable on the mobile phone, a correspon-
ding message will appear.

Press the
Back
soft key to return to the
Telephone menu.
or

Press a.
or

Press E.
iDuplicate entries will be shown only
once. This means the list may contain
less than 10 entries.

102 Telephone*Telephone operationSpeed-dialing
For all memory locations
At the mobile phone you can save
telephone numbers in the speed-dialing
memory and use them. Refer to the mobile
phone operator’s manual.
You can also use speed-dialing at the
COMAND (only mobile phone memory
locations 1-999).
You can enter up to 3 digits.
Open the Telephone menu
(page 96).
Memory locations with up to two digits:

Use the number keys 1 to 9 to
enter the memory location number.
Memory locations with three digits:

Use the number keys 1 to 9 to
enter the memory location number
followed by the # key.

Press k.
or

Press E.
The telephone dials the saved number.
Ending a call (
page 99)
Quick-dialing
Quick-dialing can be used on memory loca-
tions 1-9.

Open the Telephone menu
(page 96).

Press one of the number keys 1 - 9
longer than 2 seconds.
The telephone dials the saved number.
Ending a call (
page 99)If the person called or you answer a call,
the call is active. The call indication is
displayed.
Call menuYou talk over the hands-free set. You can
setting the volume for the hands-free
operation (
page 97).
The status bar indicates the call time.
Active call
