2. Fold the door frames and store the knobs and door
frames outside of the vehicle. Repeat this step for the
other side.
WARNING!
•Use both hands to remove the door frames. The
door frames will fold and could cause injury if
both hands are not used.
•Never store the door frames in your vehicle. In an
event of an accident, a loose door frame many
cause personal injury. If removed, always store
the door frames outside of the vehicle.
Door Frame Installation
1. Set the door frame pin into the hole on top of the body
side, just behind the door opening.2. Insert the top front of the door frame into the opening
at the top corner of the door opening. Push the top rear of
the door frame to the side bar.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

3. Slide door frame forward until the pin holes in the top
line up with the holes in the side bar. Screw in the knobs
and tighten, beginning with the front knob. Repeat
procedures on the other side.FOLDING WINDSHIELD
The fold down windshield and removable side bars on
your vehicle are structural elements that can provide
some protection in some accidents. The windshield also
provides some protection against weather, road debris
and intrusion of small branches and other objects.
Do not drive your vehicle on-road with the windshield
down and the side bars removed as you lose the protec-
tion these structural elements can provide.
NOTE:Before lowering windshield, disconnect the elec-
trical connector for the inside Compass/Temperature
mirror (if equipped).
NOTE:The windshield wiper arm and blade assemblies
must be removed prior to lowering the windshield, this
can be done by sliding out the attachment clip and gently
rocking the arm until it loosens, the wiper arms must be
returned to their “Park” positions when the windshield is
returned to its upright position.
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

If required for certain off-road uses, the side bars can be
removed and the windshield folded down. However, the
protection afforded by these features is then lost. If you
remove the side bars and fold down the windshield,
drive slowly and cautiously. It is recommended that the
speed of the vehicle be limited to 10 mph (16 km/h), with
low range operation preferred, if you are driving off-road
with the windshield folded down.
Raise the windshield and reinstall the side bars as soon as
the task that required their removal is completed and
before you return to on-road driving. Both you and your
passenger should wear seat belts at all times, on-road and
off-road, regardless of whether the windshield is raised
or folded down.Outside rear view mirrors are mounted on the doors. If
you choose to remove the doors, see your authorized
dealer for a replacement cowl-mounted outside mirror.
Federal law requires outside mirrors on vehicles for
on-road use.
NOTE:If the doors are removed, the courtesy lights will
remain on. To turn these lights off, remove fuse #4 in the
fuse panel. Refer to “Fuse Panel” in Section 7 of this
manual.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
3

WARNING!
Carefully follow these warnings to help protect against
personal injury:
•Do not drive your vehicle on-road with the wind-
shield down.
•Do not drive your vehicle unless the windshield is
securely fastened, either up or down.
•Eye protection, such as goggles, should be worn at all
times when the windshield is down.
•Be sure that you carefully follow the instructions for
raising the windshield. Make sure that the folding
windshield, windshield wipers, side bars, and all
associated hardware and fasteners are correctly and
tightly assembled before driving your vehicle. Fail-
ure to follow these instructions may prevent your
vehicle from providing you and your passengers
protection in some accidents.
•If you remove the doors, store them outside the
vehicle. In the event of an accident, a loose door may
cause personal injury.
Lowering the Windshield and Removing Side
Bars
1. Lower the fabric top or remove the hard top following
the instructions in this manual.
2. Remove the sun visors, if desired. Store the sun visors.
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Remove the two Torxhead screws holding each side
bar to the windshield frame. Shift the side bar inboard to
clear windshield pillar molding when removing the side
bar.
NOTE:Store all of the mounting bolts in their original
threaded holes and tighten for safekeeping.4. Unzip the sport bar padding to expose the side bar
bolts. Remove the two front and rear Torxhead screws
for each bar. Remove the side bars and rezip sport bar
padding in place.
Do not loosen or remove the adjusting bolts on the side
of the side bars. These bolts are set at the factory to
properly fit the side bar to the vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

CAUTION!
Do not remove the head impact foam from the side
bars, as damage to the foam may result.
5. To safely store the side bars in your vehicle, use four of
the cinch straps, found in the glove box. Attach the straps
through the footman loops located in the floor behind the
folded rear seat on each side of the vehicle.
WARNING!
You or others could be injured if you carry the side
bars loose in your vehicle. Remove the bars from the
vehicle or securely store them as described or they
may cause personal injury if an accident occurs. See
your authorized dealer for replacement if the cinch
straps are not found in the glove box.
6. Remove the windshield wiper arms by first pulling
the wiper away from the windshield and out to the
“lock” position. Then, using a small flat tool such as a
screw driver, release the retaining clip from the top of the
wiper arm. Lift the wiper arms off and store in center
console or securely behind the rear seat.
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Remove the black round headed windshield Torx
head screw on each side of the base of the windshield.8. Lower the windshield gently until it contacts the
rubber hood bumpers.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

9. Secure the windshield by passing the remaining cinch
strap, found in the glove box, through the footman hoop
on the center of the hood and on the center of the
windshield frame. Tighten the strap to secure the wind-
shield in place.Raising The Windshield And Replacing Side Bars
To raise the windshield, install the windshield wipers,
and install the side bars use these same steps in reverse.
WARNING!
To help protect against personal injury, always in-
stall the side bars when raising the windshield on
your vehicle. If you do not raise the windshield and
install the side bars, you lose the protection these
structural elements provide in some accidents.
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
