2005 JEEP WRANGLER Owners Manual

10. Tuck the bottom retainer of the quarter window into
the bottom retainer, beginning from the rear and working
to the front of the vehicle. Repeat this step for the other
side.11. To assist in getting the zipper started, lay the retainer
bar inside the vehicle on the wheel wells and uninstall
half of the left sail panel from the bodyside retainer
beginning at the tailgate to expose zipper ends.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

12. Zip in the rear window beginning from the left using
both zipper ends. Run the upper zipper around the
window leaving the lower zipper at the start.13. Tuck the retainer bar into the tailgate clips.
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

14. Tuck the lower retainers of the rear window under
the tailgate clips. Reinstall the left corner if it was
untucked to get the rear window zipper started.15. Tuck the drip rail retainers into the door frame slot
above the door on both sides.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107
3

16. Close the header latches and return the sun visor to
it’s secured position.SOFT TOP — UNLIMITED MODELS
CAUTION!
•The soft top is not designed to carry any addi-
tional loads such as roof racks, spare tires, build-
ing, hunting, or camping supplies, and/or lug-
gage, etc. Also, it was not designed as a structural
member of the vehicle, and thus cannot properly
carry any additional loads other than environmen-
tal (rain, snow, etc.).
If the temperature is below 72°F (24°C) and/or the top
has been folded down for a period of time, the top will
appear to have shrunk when you raise it, making it
difficult to put up. This is caused by a natural contraction
of the vinyl coating on the fabric top.
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Place the vehicle in a warm area. Pull steadily on the top
fabric. The vinyl will stretch back to its original size and
the top can then be snapped into place.If temperature is
41°F (5°C) or below, do not attempt to put the top down
or roll the rear or side curtains.CAUTION!
•Do not run a fabric top through an automatic car
wash. Window scratches and wax build up may
result.
•Do not lower the top when the temperature is
below 41°F (5°C). Damage to the top may result.
•Do not lower the top when the windows are dirty.
Grit may scratch the window.
•Do not move your vehicle until the top has been
either fully attached to the windshield frame, or
fully lowered.
•Do not lower the top with the windows installed.
Window and top damage may occur.
•Refer to “Appearance Care for Fabric Top Mod-
els” in Section 7 of this manual. It contains
important information on cleaning and caring for
your vehicle’s fabric top.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109
3

WARNING!
•Do not drive vehicle with rear window curtain up
unless side curtains are also open. Dangerous
exhaust gases which can kill could enter the
vehicle.
•The fabric upper doors and fabric top are de-
signed only for protection against the elements.
Do not rely on them to contain occupants within
the vehicle or to protect against injury during an
accident. Remember, always wear seat belts.
Folding Down The Soft Top
NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
NOTE:Make sure the plastic sleeves are slid rearward
to keep the Sunrider feature locked.
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

1. Grasp the fabric of the top above the door frame. Pull
down and out on the fabric to untuck the drip rail
retainers from the door frame slot. Start at the back of the
rear drip rail retainer and work forward towards the
windshield. Repeat this on the other side.
2. Unclip and move the sun visors to the side.3. Release the header latches and hooks from the wind-
shield slots.
4. Open the tailgate, partially unzip the rear window on
each side, and untuck the lower window retainers from
the tailgate clips on both sides of the tailgate opening.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

5. Grip and rotate the retainer bar up towards you to
release it from the upper portion of the tailgate clips. The
retainer bar runs along the bottom of the rear window.
6. Remove the rear window entirely. This is done by
unzipping the window, bringing both the right zipper
and the left zipper tabs all the way to the end of the
zipper track at the bottom left corner. Both zipper tabswill remain on the zipper track attached to the top. Pull
up on the window to disengage zipper end. Stow win-
dow carefully to avoid scratching.
7. Undo the Velcrothat runs along the top and rear
edge of the side window. Beginning from the rear and
moving forward, partially unzip the side window and
untuck the bottom retainer.
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
