2005 JEEP WRANGLER Owners Manual

Cavity Fuse/Color Description
13 40 Amp Green Accessories
14 Open
15 50 Amp Red IOD
16 Open
17 20 Amp Yellow Power
18 20 Amp Yellow Horn
19 20 Amp Yellow Fog Lights
20 15 Amp Lt. Blue Radio
21 10 Amp Red A/C Clutch
22 25 Amp Natural Ignition Switch
23 20 Amp Yellow Fuel
24 20 Amp Yellow Off Road
25 Open
26 10 Amp Red Accessories
27 20 Amp Yellow MFSW
28 10 Amp Red Clutch OverrideCavity Fuse/Color Description
29 Relay ASD
30 Relay A/C Clutch
31 Relay Transmission
32 Relay Starter
33 Relay ABS
34 Open
35 Relay Fog Lamp
36 Relay Horn
37 Relay Fuel Pump
38 Relay HBL (Rear Window De-
froster)
39 Relay Front Differential Locker
(Rubicon) or High Speed
Fan (2.4L Engines)
40 Relay Rear Differential Locker
(Rubicon) or Low Speed
Fan (2.4L Engines)
MAINTAINING YOUR VEHICLE 289
7

VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove Cartridge fuse #15 in the Power Distribution
Center labeled Ignition-Off Draw (IOD).
•Store the removed IOD fuse in the Power Distribution
Center location #11 labeled “IOD Storage.”
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS — IF EQUIPPED
Interior Lights Bulb Type
Auto. Trans. Indicator Light................. 658
Courtesy Lights, Under Dash (1).............. 906
Heater Control Lights (2)................... 194
Rocker Switch Indicator Light
(Rear Window Defogger, and Rear Wash/Wipe).... **
Soundbar Dome Light..................... 912
** Bulbs only available from authorized dealer.
Instrument Cluster Bulb Type
Telltale (High Beam)....................... 74
Illumination............................ 103
Exterior Lights Bulb Type
Backup Lights (2)........................1156
Center High Mounted Stop Light (1).... 921orW16W
290 MAINTAINING YOUR VEHICLE

Fog Lights.............................. H3
Front Park/Turn Lights (2).................3157
Front Side Marker Lights (2).......... 168orW3W
Headlights (2)...................... H6024BL
Stop/Tail/Turn Lights (2)..................1157
Underhood Light......................... 561
License Light...........................1157
NOTE:Numbers refer to commercial bulb types that
can be purchased from your local authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
BULB REPLACEMENT
Head Light
1. Remove headlight bezel screws as shown.2. Remove the headlight bezel.
3. Remove the screws for the headlight retaining ring,
then remove ring.
MAINTAINING YOUR VEHICLE 291
7

4. Remove and replace the lamp.
Front Park/Turn Signal
1. Reach under the front fender and locate the front
park/turn signal socket.2. Turn the socket assembly counter–clockwise 1/3 turn
and remove it from the housing. Pull the bulb straight
from the socket to replace.
Front Side Marker
1. Reach under the front fender and locate the front side
marker socket.
2. Turn the socket assembly counter–clockwise 1/3 turn
and remove it from the housing. Pull the bulb straight
from the socket to replace.
Front Fog Light
1. Remove the three screws that attach the lamp bezel to
the lamp housing.
2. Separate the reflector from the light housing.
292 MAINTAINING YOUR VEHICLE

3. Squeeze the bulb/element spring retainer from the
reflector.
4. Disconnect the electrical connector.CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 293
7

Rear Tail, Stop, Turn Signal, and Back-Up Lights
1. Remove the screws attaching the lens to the tailight
housing.
2. Separate the lens from the housing.
3. Push the bulb in, turn it counter-clockwise 1/3 turn,
then remove it from the housing, and replace.
Center High Mounted Stop Light (CHMSL)
The stop lamp is mounted on a bracket that extends
upward from the tailgate. Remove the two screws hold-
ing the lens in place. Take the lens off and pull the bulb
from the socket.
294 MAINTAINING YOUR VEHICLE

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)19 Gallons 71.9 Liters
Engine Oil with Filter
2.4 Liter Engine (SAE 5W-30, API Certified Engine Oil) 5 Qts 4.7 Liters
4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) 6 Qts 5.7 Liters
Cooling System *
2.4 Liter Engine (MoparAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)9 Qts 8.5 Liters
4.0 Liter Engine (MoparAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)10.5 Qts 9.9 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 295
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology)
Engine Oil API Certified SAE 5W-30 Engine Oil is recommended for the 2.4L engine. API
Certified SAE 10W-30 Engine Oil is recommended for the 4.0L engine. Meets
the requirements of DaimlerChrysler Material Standard MS-6395.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine compart-
ment.
Oil Filter (2.4L Engine) MoparOil Filter (P/N 4105409)
Oil Filter (4.0L Engine) MoparOil Filter (P/N 05281090)
Fuel Selection 87 Octane
296 MAINTAINING YOUR VEHICLE
