2005 INFINITI FX35 turn signal

REAR WINDOW DEFOGGER GW-95
C
D E
F
G H
J
K L
M A
B
GW
Revision: 2005 July 2005 FX
CONSULT-II Function (BCM)AIS004R7
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
1. Turn ignition switch “OFF”.
2. Connect “CONSULT-II” and CONSULT-II CONVERTER to data link connector.
3. Turn ignition switch “ON”.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “BCM”. If “BCM” is not indicated, go to GI-39
, “CONSULT-II Date Link
Connector (DLC) Circuit”
6. Touch “REAR DEFOGGER”.
BCM diagnostic test item Check item diagnostic test mode Content REAR DEFOGGER Data monitor Displays the input data of BCM in real time.
Active test Gives a drive signal to a load to check the operation.
PBIB1503E
BCIA0029E
BCIA0030E
LIIA0153E

GW-100
REAR WINDOW DEFOGGER
Revision: 2005 July 2005 FX
3. CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M3 terminal 9 and ground.
OK or NG
OK >> Replace A/C and AV switch.
NG >> Replace BCM.
Rear Window Defogger Power Supply Circuit CheckAIS004RB
1. CHECK FUSE

Check 10A fuse [No.12, located in the fuse block (J/B)]

Check 20A fuse (No.75, located in the IPDM E/R)

Check 20A fuse (No.80, located in the IPDM E/R)
NOTE:
Refer to GW-86, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse, refer to
PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Remove rear window defogger relay.
3. Turn ignition switch ON.
4. Check voltage between rear window defogger relay connector E13 terminals 1, 3, 6 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness. 9 (L/W) – Ground : Approx. 5
PIIA6208E
1 (OR) – Ground : Battery voltage
3 (W) – Ground : Battery voltage
6 (R) – Ground : Battery voltage
PIIA4233E

GW-102
REAR WINDOW DEFOGGER
Revision: 2005 July 2005 FX
6. CHECK REAR WINDOW DEFOGGER RELAY OUTPUT SIGNAL
1. Connect IPDM E/R connector and rear window defogger relay.
2. Turn ignition switch ON.
3. Check voltage between IPDM E/R connector E9 terminal 52 and ground.
OK or NG
OK >> Check condition of harness and connector.
NG >> Replace IPDM E/R.
Rear Window Defogger Circuit CheckAIS004RC
1. CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect rear window defogger connector.
3. Turn ignition switch ON.
4. Check voltage between rear window defogger connector and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear window defogger connector D114 terminal 2 and ground.
OK or NG
OK >> Check filament. Refer to GW-108, "Filament Check"

If filament is OK, check condition of harness and con-
nector.

If filament is NG, repair filament.
NG >> Repair or replace harness. 52 (G) – Ground : Battery voltage
PIIA6210E
Connector
Terminal (Wire color)
Condition Voltage (V)
(Approx.)
(+) (–)
D104 1(W) Ground Rear window defogger
switch ON. Battery voltage
Rear window defogger
switch OFF. 0
PIIA9347E
2 (B)
− Ground : Continuity should exist.
PIIA9348E

GW-106
REAR WINDOW DEFOGGER
Revision: 2005 July 2005 FX
Passenger Side Door Mirror Defogger Circuit Check AIS004RF
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door mirror (passenger side) connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror (passenger side) connector and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace harness.
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between door mirror (passenger side) connec- tor D32 terminal 2 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR MIRROR DEFOGGER
1. Connector door mirror connector.
2. Check continuity between each door mirror connector D32 (pas- senger side) terminals 1 and 2.
OK or NG
OK >> Check condition of harness and connector.
NG >> Replace door mirror (passenger side).
Rear Window Defogger Signal CheckAIS004RG
1. CHECK REAR WINDOW DEFOGGER SWITCH LAMP
A/C and AV switch self-diagnosis is performed. Refer to AV- 3 7 , "
A/C and AV Switch Self-Diagnosis Function"
Does rear window defogger switch light?
YES >> GO TO 2.
NO >> Replace A/C and AV switch.
Connector Terminal (Wire color)
Condition Voltage (V)
(Approx.)
(+) (–)
D32 1 (L) Ground Rear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF 0
PIIA6216E
2 (B) – Ground : Continuity should exist.
PIIA6214E
1 (L) – 2 (B) : Continuity should exist.
PIIA6215E

IDX-7
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
Pressure switch 6 ...............................
AT-164, AT-181
Pressure test (A/T) ............................................ AT-54
Propeller shaft ........................................... PR-4, PR-7
Propeller shaft on vehicle service .............. PR-4, PR-7
Propeller shaft vibration ............................. PR-4, PR-7
PS/SEN - Wiring diagram ................ EC-398, EC-1130
R
R/VIEW - Wiring diagram ................................. DI-117
Radiator(VK45DE) ............................................. CO-41
Radiator(VQ35DE) ............................................ CO-14
Rear axle ........................................................... RAX-5
Rear bumper ........................................................ EI-17
Rear combination lamp removal and installation ..........
LT-149
Rear door ............................................ BL-153, GW-80
Rear seat ......................................................... SE-106
Rear suspension ............................................... RSU-5
Rear view monitor ............................................. DI-114
Rear washer .................................................... WW-38
Rear window defogger ...................................... GW-86
Rear wiper ....................................................... WW-38
Refrigerant connection precaution ..................... ATC-8
Refrigerant discharging evacuating charging ATC-138
Refrigerant general precaution .......................... ATC-7
Refrigerant lines ............................................ ATC-138
Refrigerant pressure sensor ........... EC-674, EC-1364,
ATC-90
, ATC-156
Refrigeration cycle ........................................... ATC-21
Removal and installation (A/T) ........... AT-270, AT-273
Removal and installation (Transfer) .................... TF-44
Revolution sensor (A/T) ...................... AT-118, AT-263
Rocker cover(VK45DE) ................................... EM-197
Rocker cover(VQ35DE) ..................................... EM-51
Room lamp - See Interior lamp ......................... LT-159
ROOM/L - Wiring diagram ................................ LT-167
RP/SEN - Wiring diagram ................ EC-675, EC-1365
S
Seal - See Exterior .............................................. EI-27
SEAT - Wiring diagram ...................................... SE-93
Seat belt inspection ............................................. SB-6
Seat belt, front ..................................................... SB-3
Seat, rear ......................................................... SE-106
Self-diagnosis (Transfer) .................................... TF-22
SEN/PW - Wiring diagram ............... EC-484, EC-1230
SHIFT - Wiring diagram ................................... AT-237
Shift change signal ........................................ EC-1290
Shift lock system .............................................. AT-236
Shift schedule .................................................. AT-351
Shock absorber (rear) ....................................... RSU-9
Side air bag (satellite) sensor .......................... SRS-43
Side curtain air bag .......................................... SRS-40
Side trim .............................................................. EI-36
SMJ (super multiple junction) ............................ PG-78
SNOW MODE SW ......................................... EC-1388
SNOWSW - Wiring diagram .......................... EC-1389
Spark plug replacement .................................... MA-27
Spark plug replacement(VQ35DE) ................... MA-20
Spark plug(VK45DE) ...................................... EM-190
Spark plug(VQ35DE) ........................................ EM-43
Specification value ............................. EC-153, EC-844
Speedometer ........................................................ DI-5
Spiral cable ..................................................... SRS-37
Spot lamp .......................................................... LT-187
SROOF - Wiring diagram ..................... BL-172, RF-14
SRS - See Supplemental Restraint System ..... SRS-5
SRS - Wiring diagram ..................................... SRS-11
SRS Trouble diagnoses .................................... SRS-7
Stabilizer bar (rear) ......................................... RSU-16
Stall test (A/T) .................................................... AT-52
Standardized relay ............................................. PG-80
START - Wiring diagram .................................... SC-11
Starter ................................................................ SC-10
Starting system .................................................. SC-10
Steering gear and linkage inspection ................ MA-36
Steering linkage ................................................. PS-19
Steering wheel and column ................... PS-10, PS-12
Steering wheel turning force .............................. PS-10
Step lamp .......................................................... LT-126
Stop lamp .......................................................... LT-118
Stop lamp switch .............................. EC-614, EC-1297
STOP/L - Wiring diagram .................................. LT-120
Sun roof, electric ................................................ RF-10
Sunload sensor ............................. ATC-110, ATC-119
Sunroof .................................................. RF-10, RF-25
Supplemental Restraint System ....................... SRS-5
Supplemental restraint system - Wiring diagram ..........
SRS-11
Suspension ....................................................... MA-37
Symbols and abbreviations ...................... GI-10, GI-23
T
Tachometer ........................................................... DI-5
TCM circuit diagram ........................................... AT-51
TCM inspection table ......................................... AT-89
Thermostat(VK45DE) ....................................... CO-53
Thermostat(VQ35DE) ....................................... CO-26
Three way catalyst function (Bank 1) EC-316, EC-1050
Three way catalyst function (Bank 2) EC-316, EC-1050
Three way catalyst precautions ............................ GI-6
Three way catalyst(VK45DE) .......................... EM-182
Three way catalyst(VQ35DE) ........................... EM-26
Throttle control motor ....................... EC-437, EC-1161
Throttle control motor relay .............. EC-432, EC-1156
Throttle position sensor (TPS) .......... EC-213, EC-278,
EC-479
, EC-481, EC-633, EC-920, EC-1015, EC-1225,
EC-1227
, EC-1316
Throttle valve closed position learning ............. EC-786
Tie-rod ............................................................... PS-19
Timing chain(VK45DE) ................................... EM-200
Timing chain(VQ35DE) ..................................... EM-64
Tire rotation ............................................. WT-6, MA-35
Top tether strap child restraint ........................... SB-10
Torque converter installation AT-271, AT-272, AT-276

IDX-8
ALPHABETICAL INDEX
Torque convertor clutch solenoid valve AT-125, AT-127
TPS1 - Wiring diagram .................... EC-280, EC-1017
TPS2 - Wiring diagram ...................... EC-215, EC-922
TPS3 - Wiring diagram .................... EC-635, EC-1318
Transfer control unit inspection table ................. TF-20
Transverse link (front) ...................................... FSU-14
TRNSCV - Wiring diagram ............................... BL-235
Trouble diagnoses .............................................. GI-11
Turbine revolution sensor ................................ AT-141
TURN - Wiring diagram ...................................... LT-96
Turn signal lamp ................................................. LT-91
Tyre pressure monitoring system - trouble diagnoses ..
WT-10
Tyre pressure monitoring system - wiring diagram .......
WT-11
U
Unified meter and A/C amp. ............................... DI-28
V
Vacuum hose (brake system) ............................ BR-18
Vacuum hose drawing (Engine control) ........... EC-120
Valve clearance(VK45DE) .............................. EM-219
Valve clearance(VQ35DE) ................................ EM-93
Valve guide ..................................................... EM-107
Valve guide(VK45DE) ..................................... EM-236
Valve lifter ......................................................... EM-88
Valve seat(VK45DE) ....................................... EM-238
Valve seat(VQ35DE) ...................................... EM-109
Valve spring(VK45DE) .................................... EM-239
Valve spring(VQ35DE) ................................... EM-110
Vanity mirror lamp ............................................. LT-151
Variable induction air control system (VIAS) EC-1292,
EC-1331
VDC -Wiring diagram ...................................... BRC-17
Vehicle security (theft warning) system ........... BL-186
Vehicle speed sensor (VSS) ........... EC-391, EC-1123,
EC-1288
VEHSEC - Wiring diagram ............................... BL-193
VENT/V - Wiring diagram EC-345, EC-570, EC-1078,
EC-1243
VIAS - Wiring diagram ................................... EC-1333
VIAS/V - Wiring diagram ................................ EC-1293
VIN registration .................................... EC-96, EC-786
W
WARN - Wiring diagram ..................................... DI-43
Warning chime .................................................... DI-58
Warning lamps .................................................... DI-42
Washer, front ..................................................... WW-4
Washer, rear .................................................... WW-38
Water control valve(VK45DE) ........................... CO-53
Water pump(VK45DE) ...................................... CO-51
Water pump(VQ35DE) ...................................... CO-22
Water temperature gauge ..................................... DI-5
Wheel alignment (front) ..................................... FSU-6
Wheel alignment (rear) ..................................... RSU-5
Wheel balance ....................................... WT-5, MA-33
Wheel bearing (front) .......................... FAX-4, FAX-10
Wheel bearing (rear) ......................................... RAX-5
Wheel hub (front) ................................ FAX-4, FAX-10
Wheel hub (rear) ............................................... RAX-5
Wheel sensor (VDC) ....................................... BRC-57
WINDOW - Wiring diagram .............................. GW-24
Window, door ...................................... GW-76, GW-80
Windshield ....................................................... GW-11
WIP/R - Wiring diagram ................................... WW-40
WIPER - Wiring diagram .................................. WW-11
Wiper, front ........................................................ WW-4
Wiper, rear ....................................................... WW-38
Wiring Diagram (Cell code) list ......................... PG-67
Wiring diagrams .................................................. GI-15
WT-T/WARN - Wiring diagram .......................... WT-11

INSTRUMENT PANEL ASSEMBLY IP-11
C
D E
F
G H
J
K L
M A
B
IP
Revision: 2005 July 2005 FX
Removal and InstallationAIS003CJ
WORK STEP
When removing instrument panel and pad, combination meter, display unit and audio unit, center console take
steps in the order shown by the numbers below.
CAUTION:

Disconnect both battery cables in advance.

Disconnect air bag system line in advance.

Never temper with air bag lid or force air bag lid to open, as this may adversely affect air bag per-
formance.

Be careful not to scratch pad and other parts.
1. Front defroster grille (RH) 2. Instrument panel and pad 3. Front defroster grille (LH)
4. Screw 5. Bolt 6. Combination meter assembly
7. Steering lock escutcheon 8. Side ventilation (LH) 9. Display unit and audio unit
10. Wiper and washer switch 11. Clip 12. Rubber
13. Lighting and turn signal switch 14. Combination meter bracket 15. Cluster lid C
16. Steering column upper cover 17. Steering column lower cover 18. Steering column front lower cover
19. Instrument side panel (LH) 20. Instrument clock finisher 21. A/T console finisher
22. Instrument driver lower panel 23. Console finisher (LH) 24. Center console
25. Console finisher (RH) 26. Instrument side panel (RH) 27. Instrument lower cover
28. Instrument passenger lower panel 29. Side ventilation (RH) 30. Front passenger air bag module mounting nut
Parts Reference
page Instrument
panel and pad Combination
meter Display unit and
audio unit Center console
(A) Front kicking plate (RH/LH) EI-38
[ 1 ] [ 1 ]
(B) Dash side finisher (RH/LH) EI-37
[ 2 ] [ 2 ]
(C) Front pillar garnish (RH/LH) EI-38
[ 3 ]
(D) A/T select lever knob AT- 2 3 3
[ 4 ] [ 1 ]
(E) Instrument clock finisher IP-12
[ 5 ] [ 2 ]
(F) A/T console finisher IP-12
[ 6 ] [ 3 ]
(G) Console finisher (RH/LH) IP-12
[ 7 ] [ 4 ]
(H) Center console IP-12
[ 8 ] [ 5 ]
(I) Instrument lower cover IP-13
[ 9 ]
(J) Instrument passenger lower panel IP-13
[10]
(K) Instrument driver lower panel IP-13
[11] [ 3 ]
(L) Steering column front lower cover IP-13
[12] [ 4 ]
(M) Steering column lower cover IP-13
[13] [ 5 ]
(N) Steering column upper cover IP-14
[14] [ 6 ]
(O) Wiper and washer switch IP-14
[15] [ 7 ]
(P) Lighting and turn signal switch IP-14
[16] [ 8 ]
(Q) Steering lock escutcheon IP-14
[17] [ 9 ]
(R) Combination meter assembly IP-14
[18] [10]
(S) Instrument side panel (RH/LH) IP-14
[19]
(T) Cluster lid C IP-15
[20] [ 1 ]
(U) Display unit and audio unit IP-15
[21] [ 2 ]
(V) Front defroster grille (RH/LH) IP-15
[22]
(W) Combination meter bracket IP-15
[23]
(X) Side ventilation (RH/LH) IP-16
[24]
(Y) Instrument panel and pad IP-16
[25]

IP-14
INSTRUMENT PANEL ASSEMBLY
Revision: 2005 July 2005 FX
(N) Steering Column Upper Cover
Remove the steering column upper cover.
(O) Wiper and Washer Switch
Remove wiper and washer switch. Refer to WW-36, "Removal and Installation of Front Wiper and Washer
Switch" .
(P) Lighting and Turn Signal Switch
Remove lighting and turn signal switch. Refer to LT- 11 0 , "LIGHTING AND TURN SIGNAL SWITCH" .
(Q) Steering Lock Escutcheon
Pull back to your side, and remove steering lock escutcheon.
(R) Combination Meter Assembly
1. Remove bolts with power tool, and then remove connector
bracket.
2. Remove bolts with power tool and then disconnect harness con- nector.
CAUTION:
To prevent it from damaged by interference with the combina-
tion meter assembly, protect the combination meter assembly
with cloths.
(S) Instrument Side Panel (RH/LH)
1. Remove screws with power tool.
2. Pull to the side, disconnect clip and pawls and remove instru- ment side panel (RH/LH).
PIIA5002E
PIIA5003E
PIIA5004E
