2004 VOLVO XC90 Owners Manual

2004 VOLVO XC90
A/C - ON/OFF
Press the switch to turn the air conditioning on or off. The "ON" or "OF\
F" LED will light up to indicate if the system is
switched on or off. Other functions will still be regulated automaticall\
y (if the AUTO switch is on).
l The air conditioning functions only at temperatures above 32° F (0°\
C).
l While the Defroster function is selected, the air conditioning is tempor\
arily activated to dehumidify the air, even if you
have manually switched the air conditioning off. This will only function\
if the blower is not switched off.
Recirculation
Press this switch to engage the recirculation function (air in the pass\
enger compartment recirculates - no fresh air enters the
compartment). The LED in the switch will light up to indicate that the \
function is engaged.
l Use this function if the outside air is contaminated with exhaust gases,\
smoke, etc or to heat/cool the vehicle quickly.
l Recirculation should not be used for more than 15 minutes. If your windows begin to fog or mist, make sure that the
recirculation function is switched off.
l Selecting Defroster automatically switches recirculation off.
l Timer mode activation: (Vehicles equipped with the Interior Air Quality System have no timer m\
ode) Press and hold
the recirculation button for at least 3 seconds to activate a recirculat\
ion timer mode. The amber LED in the recirculation
button will flash 5 times to show that the timer mode is being activated\
. In timer mode, each time the recirculation button is
pressed, the climate control system will recirculate the air in the pass\
enger compartment for 5-12 minutes, depending on the
outside air temperature, and then revert back to fresh air.
l Timer mode deactivation: Press and hold the recirculation button for 3 s\
econds. The amber LED in the recirculation
button will illuminate steadily for 5 seconds to show a return to "norma\
l" mode.
pg. 51 Climate control

l In normal mode, when the recirculation button is pressed, the climate co\
ntrol system will recirculate the air in the
passenger compartment until the recirculation button is pressed again.
l Timer mode memory: If the vehicle is turned off while timer mode is acti\
ve, timer mode will still be active when the
vehicle is restarted.
Interior Air Quality sensor (option)
Some vehicles are equipped with a multifilter and Air Quality sensor. Th\
e filter separates gases and particles, thereby
reducing the amounts of odors and contaminants entering the vehicle. The\
Air Quality sensor detects increased levels of
contaminants in the outside air. When the Air Quality sensor detects con\
taminated outside air, the air intake closes and the
air inside the passenger compartment is recirculated, i.e. no outside ai\
r enters the vehicle. The filter also cleans recirculated
passenger compartment air. When the ECC system is in the AUTO mode, the \
green LED will be on
.
file:///K|/ownersdocs/2004/2004_XC90/04xc90_03.htm (6 of 7)12/30/2006 \
4:35:16 PM

2004 VOLVO XC90
Operation
Press
to operate the Air Quality sensor (normal setting).
Or:
Select one of the following three functions by pressing
1, 2 or 3 times.
1. The AUT LED lights. The Air Quality sensor is now activated.
2. No LED lights. Recirculation is not activated unless needed to cool t\
he passenger compartment in a warm climate.
3. The MAN LED lights. Recirculation is now activated.
Keep in mind the following:
l Make it a rule to have the Air Quality sensor activated at all times.
l Recirculation is limited in cold climates to avoid fogging.
l If window fogging occurs, you should deactivate the Air Quality sensor. \
l If fogging occurs, use the defroster functions for the windshield, side \
windows and rear window. See page 49.
l The filter should be changed at the intervals recommended in the mainten\
ance schedule. However, if the vehicle is used
in a severely contaminated environment, it may be necessary to change th\
e filter more frequently.
pg. 52 Climate control
This page intentionally left blank



Contents | Top of Page
file:///K|/ownersdocs/2004/2004_XC90/04xc90_03.htm (7 of 7)12/30/2006 \
4:35:16 PM

2004 VOLVO XC90
2 0 0 4
VOLVO XC90
Interior

pg. 53 Interior
Front seats54
Rear seats58
Interior lighting61
Floor mats62
Storage compartments63
Securing cargo67
pg. 54 Interior
Front seats
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (1 of 11)12/30/200\
6 4:35:19 PM

2004 VOLVO XC90
Manual height adjustment - front seat
The front edges of passenger seat cushions can be adjusted to seven diff\
erent settings and the rear edges
to nine different settings.
Lever (A) - adjusting the front edge of the seat.
Lever (B) - adjusting the rear edge of the seat.
Manual front-rear adjustment
The seat can be moved forward or rearward by pulling up on the front-rea\
r adjustment bar. Check that
the seat is securely locked into position after adjusting.
WARNING!
Do not adjust the seat while driving. The seat should be adjusted so tha\
t the brake pedal can be
depressed fully. In addition, position the seat as far rearward as comfo\
rt and control allow.
pg. 55 Interior
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (2 of 11)12/30/200\
6 4:35:19 PM

2004 VOLVO XC90
Folding the backrests in the front seat
The front passenger seat backrest can be folded to a horizontal position\
to make room for a long load.
Fold the backrest as follows:
l Move the seat as far back as possible.
l Adjust the backrest to the upright position.
l Lift the catches on the rear of the backrest.
l Without releasing the catches, push the backrest forward.
l Move the seat as far forward as possible.
WARNING!
Cover sharp edges on the load to help prevent injury to occupants. Secur\
e the load to help prevent
shifting during sudden stops.
pg. 56 Interior
Front seats (contd)
Power seat
Operation
Passenger seat: The seat can only be adjusted if the ignition key is in position I, II \
or if the engine is
running.
Driver's seat: The seat can be adjusted if the ignition key is in position I, II or if\
the engine is running.
It can also be adjusted in the following circumstances:
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (3 of 11)12/30/200\
6 4:35:19 PM

2004 VOLVO XC90
1. Within 40 seconds of the ignition key being turned to position 0 or r\
emoved from the ignition switch.
2. After you have unlocked the driver's door with the key or remote cont\
rol, the driver's seat can be
adjusted during a 10 minute period if the door remains open. If the door is closed, the seat can be
adjusted for 40 seconds. The ignition key can be in position 0 or not yet inserted in the ignition switch.
Remote keyless entry system and driver's seat
The remote control transmitter also controls the electrically operated d\
river's seat in the following way:
l Adjust the seat to your preferences.
l When you leave your vehicle, lock it using the remote control.

Power seat control panel
The next time you unlock the driver's door with the same remote control \
(the one you used to lock the
doors with) and open the driver's door, the driver's seat will automati\
cally move to the position in which
you left it.
The seat will move to this position even if someone else has adjusted it\
since you last unlocked the
vehicle with the same remote control.
NOTE: This feature will work in the same way with all of the remote control tr\
ansmitters (up to 3) that
you use with your vehicle. This feature will not function if you lock yo\
ur vehicle with the key.
Seat adjustment
Adjust the power seat(s) with the two switches at the side of the seat\
as follows:
A - Front edge of seat (raise/lower)
B - Forward - rearward
C - Rear edge of seat (raise/lower)
D - Backrest tilt
NOTE: The power seats have an overload protector that activates if a seat is b\
locked by any object. If
this occurs, switch off the ignition (key in position 0) and wait abou\
t 20 seconds before operating the
seat again.
Please refer to the following page for information on programming the me\
mory function in the
driver's seat.
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (4 of 11)12/30/200\
6 4:35:19 PM

2004 VOLVO XC90
Emergency stop
If the seat accidentally begins to move, press one of the buttons to sto\
p the seat.
pg. 57 Interior
WARNING!
- Because the driver's seat can be adjusted with the ignition off, child\
ren should never be left
unattended in the vehicle.
- Movement of the seat can be STOPPED at any time by pressing any button\
on the power seat
control panel.
- Do not adjust the seat while driving.
- The seat should be adjusted so that the brake pedal can be depressed f\
ully. In addition, position the
seat as far rearward as comfort and control allow.
- The seat rails on the floor must not be obstructed in any way when the\
seat is in motion.
Programming the memory
Please note that only the driver's seat is equipped with the memory func\
tion.
Three seat positions can be programmed. To program a seat position:
1. Adjust the seat to the desired position.
2. Hold down the MEM button.
3. While holding down the MEM button, press button 1 to program the curr\
ent position of the seat.
Buttons 2 and 3 can be programmed in the same way.
To move the seat to a programmed position, press and hold down button 1,\
2 or 3 until the seat moves to
the preset position and stops.
As a safety precaution, the seat will stop automatically if the button i\
s released before the seat has
reached the programmed position.
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (5 of 11)12/30/200\
6 4:35:19 PM

2004 VOLVO XC90
pg. 58 Interior
Rear seats
Entering the optional third row of seats
Tilting the outboard backrests in the second row of the seats:
Pull up the handle (1), hold it up, and tilt the backrest forward to m\
ove the seat.
Return the backrest to the upright position to slide the seat back to it\
s original position.
Forward/rearward seat adjustment
Lift the adjustment bar (2) to move the seat forward or rearward.
Removing the center console (seven-seat models only)
In order to make it possible to move the center seat in the second row o\
f seats as far forward as possible
(seven-seat models only), the rear section of the center console can b\
e removed.
l Pull the handle (see illustration above) and lift out the console.
l To return the console to its original position, slide it back into posit\
ion until it clicks into place.
file:///K|/ownersdocs/2004/2004_XC90/04xc90_04a.htm (6 of 11)12/30/200\
