2004 TOYOTA PRIUS Owners Manual

329
Precautions for useof hybrid vehicle
The vehicle has both high voltage
DC and AC systems as well as a
12volt system. DC and AC high
voltage are both very dangerous
and can cause death or serious inju-
ry, severe burns and electric shock.
In order to avoid personal in-
juries, do not touch the high
voltage cables (orange col-
ored) and their connectors.
Follow the caution labels at-
tached to the high voltage
parts.
Do not remove or replace the
high voltage parts such as
the inverter unit (located in
the engine compartment), hy-
brid vehicle battery (located
behind rear seat), etc.
Do not touch the service plug
located in the left side trim
of the luggage compartment
without hybrid system techni-
cal training. (See “Precau-
tions for use” on page 12 in
Section 12.) This component
is provided to disable the
high voltage system in case
of servicing at a Toyota deal-
er.
CAUTIONIf an accident occurs
Pull your vehicle off the road,
push the “P” position switch,
stop the hybrid system and if
the key is inserted into key
slot, remove it.
In order to avoid personal in-
juries, do not touch any high
voltage wirings and their con-
nectors, and high voltage
parts (inverter unit, hybrid ve-
hicle battery, etc.).
If some exposed electric
wires are protruding inside or
outside of your vehicle, an
electric shock may occur.
Never touch the electric
wires.
If fluid leaks or gets in some
parts of the vehicle, never
touch it because it may be
electrolyte (strong alkali) from
the hybrid vehicle battery. If
it gets into your skin or eyes,
wash off immediately with a
large amount of water, if pos-
sible, boric acid solution, and
get immediate medical atten-
tion in order to help avoid
serious injury.
If a vehicle fire occurs, extin-
guish it using a fire extin-
guisher for the exclusive use
on electric fires. Or, use a
large amount of water to pre-
vent flammable gas from be-
ing generated from the batter-
ies.

330
If your vehicle needs to be
towed, do it with the front
wheels raised. For details on
towing, see “If your vehicle
needs to be towed” on page
254 in Section 5.

331
CAUTION
High Voltage
Your vehicle is equipped with
cables connected to parts of
the vehicle subject to high volt-
age (about 500 V at maximum).
There are some other parts that
reach high temperatures while
you drive. Never touch battery
cables (wrapped in orangecol-
ored harnesses) or their con-
nectors since they are under
high voltage and dangerous.
Caution labels are applied to
these parts to identify them.
Carefully observe the instruc-
tions on these caution labels.
00p001

332

2
Publication No. OM47482U
Part No. 01999-47482
Printed in Japan 04−0407 −01
U 5Quick index
 If a service reminder indicator or warning buzzer comes on 117 . . .
 If your vehicle will not start 238 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 If your vehicle overheats 242 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
 If you have a flat tire 243 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
 If your vehicle needs to be towed 254 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Tips for driving during break-in period 202 . . . . . . . . . . . . . . . . . . . . . . . . . .
 How to start the hybrid system 230 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 General maintenance 269 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher.
See page 202 for detailed information.
Fuel tank capacity:
45 L (11.9 gal., 9.9 lmp. gal.)
See page 204 for detailed information.
Engine oil:
API grade SL “Energy −Conserving” or ILSAC multigrade engine oil
is recommended.
See page 283 for detailed information.
Tire information: See pages 289 through 296.
Tire inflation pressure: See page 313.
