2004 MERCEDES-BENZ E55AMG Owner's Manual

89 Controls in detail
Locking and unlocking
Factory setting
Global unlocking
Press buttonŒ.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The vehicle will lock again automatically
within approximately 40 seconds of un-
locking if:


neither door nor trunk is opened


the SmartKey is not inserted in the
starter switch


the central locking switch is not acti-
vated
Global locking

Press button‹.
All turn signal lamps flash three times.
The locking knobs in the doors move
down.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about five seconds
until battery check lamp5 flashes
twice.
The SmartKey will then function as fol-
lows:
Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.
Global unlocking

Press buttonΠtwice.
Global locking

Press button‹.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a looked door from the inside, which
could result in an accident or serious injury.!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of
electromagnetic radiation.iYou can also open and close the power
windows (
page 197) and
sliding / pop-up roof* (
page 201) or
panorama sliding / pop-up roof*
(
page 208) using the SmartKey.

90 Controls in detailLocking and unlockingRestoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about six seconds
until battery check lamp5 flashes
twice.
Unlocking and opening the trunk lid
You can unlock and open the trunk sepa-
rately.
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.

Press buttonŠ until trunk unlocks
and begins to open.The trunk can also be opened from its in-
side in an emergency, see “Trunk lid emer-
gency release” (
page 104).
!If you can no longer lock or unlock the
vehicle with the SmartKey, then the
batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the Smart-
Key (
page 91) and replace them if
necessary (
page 355).


Use the mechanical key to unlock
the doors (
page 353).


Have the vehicle batteries and their
connections checked.


Use the mechanical key to lock the
doors (
page 353) and the trunk
lid (if applicable) (
page 105).
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Center.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk lid opening/closing
system*: to stop the opening proce-
dure, press buttonŠ. The trunk lid
stops moving.
iIf the trunk lid does not open, it is still
locked separately (
page 105).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (page 99). The
turn signals will flash three times to
confirm locking.

91 Controls in detail
Locking and unlocking
Checking the batteries
Press button‹ orŒ.
Battery check lamp5 comes on brief-
ly to indicate that the SmartKey batter-
ies are in order.Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:

Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Specially equipped vehicles come with two
SmartKeys with KEYLESS-GO, each with
remote controls and a removable mechan-
ical key. The locking tabs for the mechani-
cal key portion of the two SmartKeys are a
different color to help distinguish each
SmartKey unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you grasp a door
handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks

the doors


the trunk lid


the fuel filler flap
!If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 355).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.

92 Controls in detailLocking and unlockingSmartKey 1‹ Lock button
2Š Unlock button for the trunk lid
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 73)
For more information on using the
SmartKey buttons, see “SmartKey”
(
page 88).Important notes on using KEYLESS-GO


You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 88).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the remote control).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause serious personal
injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.iYou can also open and close the power
windows (
page 197) and
sliding / pop-up roof* (
page 201) or
panorama sliding / pop-up roof*
(
page 208) using the SmartKey.

93 Controls in detail
Locking and unlocking


To lock or unlock the vehicle, the
SmartKey must be located outside the
vehicle within approximately 3 ft (1 m)
of a door or the trunk.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All the doors must be closed.


The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.


If you have started the engine with the
KEYLESS-GO start / stop button, you
can only turn it off again with this but-
ton, even if you have put the SmartKey
in the starter switch in the meantime.


This does not apply if, after starting, the
selector lever is still in positionP and
then the SmartKey is inserted in the
starter switch. The SmartKey will then
have priority over the KEYLESS-GO
function and the vehicle’s electrical
system will operate according to the
position of the SmartKey in the starter
switch, even stopping the engine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle and can no longer be recognized by
the system, the vehicle cannot be
locked or the engine started via the
KEYLESS-GO system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the SmartKey),
the message
Key not recognized!
will
appear in the multifunction display.
Find the SmartKey or change its
present location immediately (e.g.
place it on the front passenger seat or
insert it in shirt pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, the message
Key
recognized in vehicle!
will appear in
the multifunction display.

94 Controls in detailLocking and unlockingFactory setting
Global unlocking
Grasp the door handle.
The vehicle will lock again automatically
within approximately 40 seconds if neither
door nor trunk is opened.
Global locking

Press lock button at door handle
(page 54) or trunk lid (
page 96).
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with KEY-
LESS-GO so when you grasp the driver’s
door handle only the driver’s door and the
fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about five seconds
until battery check lamp5 flashes
twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.
Global unlocking

Press buttonΠtwice.
Global locking

Press button‹.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about six seconds
until battery check lamp5 flashes
twice.
!If you can no longer lock or unlock the
vehicle with the SmartKey, then the
batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the Smart-
Key (
page 91) and replace them if
necessary (
page 355).


Use the mechanical key to unlock
the doors (
page 353).


Have the vehicle batteries and their
connections checked.


Use the mechanical key to lock the
doors (
page 353) and the trunk
lid (if applicable) (
page 105).
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Center.

95 Controls in detail
Locking and unlocking
Unlocking and opening the trunk lid
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
The handle is located in the rear license
plate recess.
You can unlock and open the trunk lid sep-
arately.
Pull on the handle
or

Press and hold buttonŠ until the
trunk lid unlocks and opens.The trunk can also be opened from the in-
side in an emergency, see “Trunk lid emer-
gency release” (
page 104).
!If you can no longer lock or unlock the
vehicle with the SmartKey with KEY-
LESS-GO, then the batteries in the
SmartKey are discharged, the Smart-
Key with KEYLESS-GO is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the Smart-
Key with KEYLESS-GO (
page 91)
and replace them if necessary
(
page 355).


Use the mechanical key to unlock
the doors (
page 353).


Have the vehicle battery checked
by an authorized Mercedes-Benz
Center.


Use the mechanical key to lock the
doors (
page 353) and the trunk
lid (if applicable) (
page 105).
If the SmartKey with KEYLESS-GO is
malfunctioning, contact an authorized
Mercedes-Benz Center.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk lid opening/closing
system*: to stop the opening proce-
dure, press buttonŠ on the Smart-
Key. The trunk lid stops moving.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 105).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed. The turn signals will
flash three times to confirm locking.

96 Controls in detailLocking and unlockingLocking the vehicle
1Lock button at trunk
Press the lock button1.
or

Press the lock button at the outside
door handle (
page 54).
or

Vehicles with trunk lid opening/closing
system*, press the KEYLESS-GO
locking/closing switch in the trunk
(page 103).
The vehicle locks. The turn signals
flashes three times to confirm locking.Checking the batteries

Press button‹ orŒ.
Battery check lamp5 comes on brief-
ly to indicate that the SmartKey batter-
ies are in order.Loss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with KEY-
LESS-GO, you should do the following:

Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.

Report the loss immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
!If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 355).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.
