2004 INFINITI QX56 display

GW-86
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
CONSULT-II Function (BCM)EIS002VU
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “BCM”.
If “BCM” is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E

REAR WINDOW DEFOGGER
GW-87
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
6. Touch “REAR DEFOGGER”.
7. Select diagnosis mode,“DATA MONITOR” and “ACTIVE TEST”.
DATA MONITOR
Display Item List
ACTIVE TEST
Display Item List
Trouble Diagnoses Symptom ChartEIS002VV

Make sure other systems using the signal of the following systems operate normally.
LIIA0153E
BCIA0031E
Monitor item “Operation” Content
REAR DEF SW “ON/OFF”Displays “Press (ON)/others (OFF)” status determined with the rear window defogger
switch.
IGN ON SW “ON/OFF” Displays “IGN (ON)/OFF” status determined with the ignition switch signal.
Test item Content
REAR WINDOW DEFOGGER Gives a drive signal to the rear window defogger to activate it.
Symptom Diagnoses / Service procedure Refer to page
Rear window defogger and door mirror defoggers do not
operate.1. BCM power supply and ground circuit checkGW-89
2. IPDM E/R auto active test checkPG-23
3. Rear window defogger switch circuit checkGW-90
4. Rear window defogger power supply circuit checkGW-91
5. Replace IPDM E/ RPG-29
Rear window defogger does not operate but both of door
mirror defoggers operate.1. Rear window defogger power supply circuit checkGW-912. Rear window defogger circuit checkGW-92
3. Filament checkGW-96
4. Replace IPDM E/RPG-29
Both door mirror defoggers do not operate but rear win-
dow defogger operates.1. Door mirror defogger power supply circuit checkGW-92
2. Replace IPDM E/RPG-29
Driver side door mirror defogger does not operate. 1. Driver side door mirror defogger circuit checkGW-94

GW-88
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
Passenger side door mirror defogger does not operate. 1. Passenger side door mirror defogger circuit checkGW-95
Rear window defogger switch does not light, and rear win-
dow defogger is not displayed on the display.
But rear window defogger operates. 1. Rear window defogger signal checkGW-96
Symptom Diagnoses / Service procedure Refer to page

GW-96
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
3. CHECK DOOR MIRROR DEFOGGER
Check continuity between door mirror RH terminals 10 and 11.
OK or NG
OK >> Repair or replace harness.
NG >> Replace door mirror RH.
Rear Window Defogger Signal CheckEIS002W6
1. CHECK AV COMMUNICATION LINE
AV communication line check is executed. Refer to AT C - 3 2 , "
CAN Communication System Description" .
OK or NG
OK >> GO TO 2.
NG >> Replace display control unit.
2. CHECK CAN COMMUNICATION LINE
CAN communication line check is executed. Refer to LAN-5, "
CAN COMMUNICATION" .
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> In addition, it is necessary to check CAN communication line. Refer to LAN-5, "
CAN COMMUNI-
CATION" .
Filament CheckEIS002W7
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe.Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.10 - 11 : Continuity should exist.
LIIA2305E
Is rear window defogger displayed on the display?
SEL122R
SEL263

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Brake lines and cables inspection ..................... MA-27
Brake master cylinder ....................................... BR-15
Brake switch .................................................... EC-551
BRK/SW - Wiring diagram ............................... EC-552
Bulb specifications ........................................... LT-170
Bumper, front ...................................................... EI-13
Bumper, rear ....................................................... EI-15
C
Cabin air filter .................................................... MA-20
Camshaft ........................................................... EM-43
Camshaft inspection .......................................... EM-47
Camshaft position sensor (PHASE) ................ EC-261
CAN - Wiring diagram EC-136, LAN-18, LAN-52, LAN-
92, LAN-128
CAN (Controller Area Network) .. WT-9, BRC-10, LAN-
16, LAN-50, LAN-90, LAN-126
CAN communication . EC-31, EC-135, AT-103, WT-9,
BRC-10
, LAN-16, LAN-50, LAN-90, LAN-126
Canister-See EVAP canister ........................... EC-636
Center case (Transfer) ..................................... TF-113
CHARGE - Wiring diagram ............................... SC-18
Charging system ............................................... SC-17
Chassis and body maintenance ........................ MA-20
Chassis and body maintenanceSchedule 1 ........ MA-7
Chassis and body maintenanceSchedule 2 ........ MA-9
CHIME - Wiring diagram ..................................... DI-46
Circuit breaker ................................................... PG-67
Clock ................................................................... DI-70
CLOCK - Wiring diagram .................................... DI-70
Closed loop control ........................................... EC-27
Closed loop control (Bank 1) ........................... EC-407
Closed loop control (Bank 2) ........................... EC-407
Clutch drum (Transfer) ..................................... TF-116
Clutch force release limit adjustment ................. TF-42
Clutch pressure switch (Transfer) ...................... TF-95
Coil spring (front) ............................................. FSU-10
Collision diagnosis .......................................... SRS-60
Combination lamp, front, removal and installation . LT-
33
Combination lamp, rear, removal and installation .. LT-
122
Combination meter ................................................ DI-5
Combination switch ............................................ LT-97
COMBSW - Wiring diagram ............................... LT-97
COMM - Wiring diagram ................................... AV-87
COMPAS - Wiring diagram ................................. DI-27
Compass ............................................................. DI-26
Component Location (auto A/C) ...................... ATC-37
Compressor clutch removal and installation . ATC-167
Compressor mounting ................................... ATC-166
Compressor precaution ................................... ATC-11
Compressor special service tool ..................... ATC-14
Condenser ..................................................... ATC-173
Connecting rod .................................................. EM-91
Connecting rod bearing clearance .................... EM-91
Connecting rod bushing clearance .................... EM-91
Console box - See Instrument panel ................... IP-10
Console box lamp ............................................. LT-152
CONSULT for all-mode 4WD ............................. TF-31
CONSULT for VDC ......................................... BRC-28
CONSULT-II for engine ................................... EC-103
Control units (terminal arrangement) ................. PG-71
Control valve (A/T) ............................................. AT-37
Control valve (Transfer) .................................... TF-119
Controller Area Network (CAN) . WT-9, BRC-10, LAN-
16, LAN-50, LAN-90, LAN-126
Converter housing installation ............ AT-257, AT-260
COOL/F - Wiring diagram ................................ EC-413
Coolant mixture ratio ......................................... MA-11
Coolant replacement ......................................... MA-12
Cooling circuit (engine) ........................................ CO-6
Cooling fan ........................................................ CO-13
Cooling fan control ........................................... EC-410
Cooling fan motor ............................................ EC-419
Cooling unit (A/C evaporator) ....... ATC-144, ATC-175
Corrosion protection ......................................... BL-167
Crankcase ventilation system - See Positive crankcase
ventilation ........................................................ EC-645
Crankshaft ......................................................... EM-74
Crankshaft position sensor (POS) ................... EC-255
Crash zone sensor .......................................... SRS-55
Cylinder block .................................................... EM-73
Cylinder block boring ......................................... EM-94
D
D/LOCK - Wiring diagram ................................... BL-20
Data link connector .......................................... EC-105
Daytime light system .......................................... LT-34
Daytime running light - See Daytime light system .. LT-
34
DEF - Wiring diagram ....................................... GW-82
Diagnosis sensor unit ...................................... SRS-58
Diagnostic trouble code (DTC) .......................... EC-53
Diagnostic trouble code (DTC) for OBD system .. EC-8
Diagnostic trouble code (DTC) inspection priority chart
EC-76
Differential carrier assembly ............................ RFD-11
Differential carrier disassembly ....................... RFD-13
Differential gear oil replacement ........................ MA-25
Dimensions ......................................................... GI-49
Direct clutch solenoid valve ................ AT-157, AT-160
Display and amp.assembly .............................. ATC-60
Display Control Unit ......................................... AV-158
Dome light - See Interior lamp .......................... LT-129
Door glass .......................................... GW-69, GW-72
Door lock .......................................................... BL-132
Door mirror lamp ............................................... LT-129
Door trim .............................................................. EI-31
Door, front ........................................... BL-129, GW-69
Door, rear ........................................... BL-129, GW-72
Drive belt ........................................................... EM-12
Drive chain (Transfer) ....................................... TF-115
Drive pinion diff. inspection .............................. RFD-12
Drive pinion height ........................................... RFD-17
Drive shaft (rear) ................................................ RAX-7

INSTRUMENT PANEL ASSEMBLY
IP-11
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: August 20072004 QX56
1. Remove instrument lower cover LH. Refer to IP-13, "Instrument Lower Cover LH" .
2. Remove glove box assembly.
3. Remove center console lower covers.
4. Remove shift knob and A/T finisher. Refer to IP-13, "
A/T Finisher" .

Disconnect harness from bottom of A/T finisher.
5. Remove shifter assembly. Refer to AT-233, "
Control Device Removal and Installation" .

Disconnect harness and shifter cable.
6. Remove center console and disconnect harness.
7. Remove cluster lid C and disconnect harnesses.
8. Remove cluster lid D and disconnect harness.
9. Remove display assembly and the audio unit. Refer to AV-45, "
Removal and Installation for Audio Unit"
and AV- 1 5 8 , "Removal and Installation of Display Unit" .
10. Remove power point assemblies.
11. Remove front passenger air bag status light.
12. Remove hazard switch.
13. Remove clock.
14. Remove combination meter cover.
15. Remove cluster lid A and disconnect harness.
16. Remove combination meter and disconnect harness.
17. Remove lower knee protector LH.
18. Remove the upper and lower steering column covers.

Disconnect harness from ADP steering switch.
19. Remove defrost grille and disconnect optical sensor harness.
20. Remove side ventilator assembly LH.
21. Remove side ventilator assembly RH.
22. Remove instrument panel.

Remove passenger air bag nuts and remove air bag. Refer to SRS-50, "FRONT PASSENGER AIR
BAG MODULE" .

Disconnect GPS antenna.

Disconnect harnesses to instrument panel speakers LH and RH and remove speakers.

Disconnect all remaining harnesses.
Installation is in the reverse order of removal.
1. Steering member brackets 2. Bracket assembly LH 3. Steering member assembly
4. Combination meter cover 5. Defrost grille 6. Instrument panel speaker LH
7. Instrument panel 8. Bin mat 9. Side ventilator assembly LH
10. Instrument lower cover LH 11. Lower knee protector LH 12. Steering column cover upper
13. Steering column cover lower 14. Center console lower cover LH 15. Combination meter
16. Audio unit bracket LH 17. Driver instrument stay 18. Audio unit
19. Passenger instrument stay 20. Display assembly 21. Switch assembly
22. Cluster lid A 23. Cluster lid D ventilator LH 24. Front passenger air bag status light
25. Power point assemblies 26. Clock 27. Cluster lid C
28. Front air control 29. Audio control 30. Hazard switch
31. Cluster lid D ventilator RH 32. Cluster lid D 33. Glove box door
34. Glove box assembly 35. Glove box housing 36. Glove box striker
37. Rubber bumpers 38. Glove box damper 39. Audio unit bracket RH
40. Center console lower cover RH 41. Fuse block cover 42. Side ventilator assembly RH
43. Instrument panel bracket 44. Instrument panel speaker RH 45. Bracket assembly RH
46. Key cylinder escutcheon 47. Instrument lower cover RH

INSTRUMENT PANEL ASSEMBLY
IP-13
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: August 20072004 QX56
Instrument Lower Cover LH
Remove screws using power tool, and remove instrument lower
cover LH.

Pull to disconnect clips.

Disconnect harnesses from back of instrument lower cover LH.
Installation is in the reverse order of removal.
Combination Meter
1. Remove instrument lower cover LH. Refer to IP-13, "Instrument Lower Cover LH" .
2. Remove the combination meter cover.
3. Remove cluster lid A.
4. Remove screws using power tool and remove the combination
meter assembly.

Disconnect electrical connectors.
Installation is in the reverse order of removal.
A/T Finisher
1. Remove shift knob.
2. Remove console mask.
3. Pull up to release clips and remove A/T finisher.

Disconnect harnesses.
Installation is in the reverse order of removal.
Display Assembly and Audio Unit
1. Remove audio unit. Refer to AV- 4 5 , "Removal and Installation for Audio Unit" .
2. Remove display assembly. Refer to AV- 1 5 8 , "
Removal and Installation of Display Unit" .
LIIA1327E
LIIA1249E
LIIA1335E

LAN-1
LAN SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION LAN
A
B
LAN
Revision: August 20072004 QX56
CAN
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions When Using CONSULT-II ..................... 3
CHECK POINTS FOR USING CONSULT-II ......... 3
Precautions For Trouble Diagnosis .......................... 3
CAN SYSTEM ....................................................... 3
Precautions For Harness Repair .............................. 4
CAN SYSTEM ....................................................... 4
CAN COMMUNICATION ............................................ 5
System Description .................................................. 5
CAN Communication Unit ........................................ 5
TYPE1 ................................................................... 5
TYPE2 ................................................................... 8
TYPE 3 ................................................................ 10
TYPE 4 ................................................................ 13
CAN SYSTEM (TYPE 1) ........................................... 16
System Description ................................................ 16
Component Parts and Harness Connector Location ... 16
Schematic .............................................................. 17
Wiring Diagram - CAN - ......................................... 18
Work Flow .............................................................. 21
CHECK SHEET ................................................... 23
CHECK SHEET RESULTS (EXAMPLE) ............. 25
Circuit Check Between TCM and Driver Seat Con-
trol Unit ................................................................... 40
Circuit Check Between Driver Seat Control Unit and
Data Link Connector .............................................. 41
Circuit Check Between Data Link Connector and
IPDM E/R ............................................................... 42
ECM Circuit Check ................................................. 43
TCM Circuit Check ................................................. 43
Driver Seat Control Unit Circuit Check ................... 44
Combination Meter Circuit Check .......................... 44
Display Control Unit Circuit Check ......................... 45
BCM Circuit Check ................................................. 45
Data Link Connector Circuit Check ........................ 46
Steering Angle Sensor Circuit Check ..................... 46Front Air Control Circuit Check ............................... 47
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ..................................................................... 47
IPDM E/R Circuit Check ......................................... 48
CAN Communication Circuit Check ........................ 48
IPDM E/R Ignition Relay Circuit Check .................. 49
Component Inspection ............................................ 49
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION .................................................................... 49
CAN SYSTEM (TYPE 2) ........................................... 50
System Description ................................................. 50
Component Parts and Harness Connector Location ... 50
Schematic ............................................................... 51
Wiring Diagram - CAN - .......................................... 52
Work Flow ............................................................... 55
CHECK SHEET ................................................... 57
CHECK SHEET RESULTS (EXAMPLE) ............. 59
Circuit Check Between TCM and ICC Sensor ........ 78
Circuit Check Between ICC Sensor and ICC Unit ... 79
Circuit Check Between ICC Unit and Driver Seat
Control Unit ............................................................. 80
Circuit Check Between Driver Seat Control Unit and
Data Link Connector ............................................... 80
Circuit Check Between Data Link Connector and
IPDM E/R ................................................................ 81
ECM Circuit Check ................................................. 82
TCM Circuit Check ................................................. 82
ICC Sensor Circuit Check ....................................... 83
ICC Unit Circuit Check ............................................ 83
Driver Seat Control Unit Circuit Check ................... 84
Combination Meter Circuit Check ........................... 84
Display Control Unit Circuit Check ......................... 85
BCM Circuit Check ................................................. 85
Data Link Connector Circuit Check ........................ 86
Steering Angle Sensor Circuit Check ..................... 86
Front Air Control Circuit Check ............................... 87
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ..................................................................... 87
IPDM E/R Circuit Check ......................................... 88
CAN Communication Circuit Check ........................ 88
