2004 DAEWOO LACETTI sensor

5A2 – 4IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Drain Plug1713–
Control Cable Adjusting Nut8–71
Shift Control Lever Assembly Mounting Bolts8–71
Manual Valve Lever Shaft Nut12–106
Transmission Range (TR) Switch Bolts5.4–48
Input Speed Sensor Retaining Bolt5.4–48
Output Speed Sensor Retaining Bolt7.4–65
TCM Retaining Bolts5–44
Fluid Cooler Inlet Pipe Fitting Nut3526–
Fluid Cooler Inlet Pipe Bolt9–80
Inlet Pipe Union Bolt3526–
Fluid Cooler Rear Outlet Pipe Fitting Nut3526–
Fluid Cooler Rear Outlet Pipe Clip Bolt9–80
Front Outlet Pipe Union Bolt3526–
Lower Transaxle–to–Engine Retaining Bolts (a)7354–
Lower Transaxle–to–Engine Retaining Bolts (b)3123–
Lower Transaxle–to–Engine Retaining Bolts (c)2115–
Upper Transaxle–to–Engine Mounting Bolts7354–
Upper Transaxle Mounting Bracket Bolts6044–
Rear Mounting Bracket Bolts6044–
Damping Block Connection Nut and Bolt8059–
Torque Converter Bolts4543–
Screw Plugs7.4–65
Transaxle Apply Clamp Bolt5.4–48
Oil Reservoir Lock Plate Bolts5.4–48
Transaxle Case Plate Bolt9.8–87
Transaxle Housing Bolts2922–
Manual Detent Spring Bolt9.8–87
Parking Lock Pawl Bracket Bolts7.4–65
Planetary Ring Gear Nut (Standard)9.8–87
Planetary Ring Gear Nut (Maximum)2922–
Transaxle Rear Cover Bolts2518–
Oil Pump Bolts2518–
Valve Body Bolts11–97
Oil Strainer Bolts9.8–87
Oil Pan Bolts7–62
Unions2518–
Stator Shaft Bolts2518–
Shift Solenoid Valve Bolts11–97
Differential Case–to–Differential Ring Gear Bolt10275–

5A2 – 18IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
AUTOMATIC TRANSAXLE COMPONENTS
1. Breather Hose
2. Clip
3. Breather Plug
4. O–ring
5. Input Speed Sensor
6. Oil Cooler Outlet Union
7. O–ring8. Oil Cooler Inlet Union
9. O–ring
10. Screw Plug
11. O–ring
12. Washer
13. Drain Plug

5A2 – 26IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
X–1 : TCM Vehicle Side Wiring Connector
A1GroundB1R
A2Pressure Control Solenoid GroundB3Clock
A4Pressure Control SolenoidB4Hold
A5Lock–Up SolenoidB6Input Speed Sensor
A6Ignition (+)B7D
A7CAN (Low)B8N
A11Transmission Fluid Temperature SensorB16Input Speed Sensor Ground
A12Transmission Fluid Temperature Sensor
GroundB18L
A14Timing SolenoidB192
A15Shift Solenoid No.2B20P
A16Shift Solenoid No.1B22Stop Lamp Switch
A17CAN (High)B23DLC
A23GroundB25Output Speed Sensor
A24B+––
X–2 : Transmission Range (TR) Switch Connector
1P
2R
3Ground
42
5N
6ST(–)
7D
81
9ST(+)
X–4 : Output Speed Sensor Connector
1Ignition
2Ground
3Output Speed Sensor
X–3 : Transaxle Wiring Connector
1Transmission Fluid Temperature Sensor
2Timing Solenoid
3Pressure Control Solenoid
4Lock–Up Solenoid
5Shift Solenoid No.1
6Transmission Fluid Temperature Sensor
Ground
8Pressure Control Solenoid Ground
10Shift Solenoid No.2
X–5 : Input Speed Sensor
1Input Speed Sensor Ground
2Input Speed Sensor

5A2 – 30IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Manual Shifting Test
Manual shifting test is to determine whether failure symp-
tom is within electrical failure or mechanical failure.
1. Disconnect wire harness of shift solenoid, check
the range and gear positions correspond with below
table when driving by manual shifting.
Range
Gear
D3rd gear
RReverse
Notice : Make sure to disconnect only wire harness of shift
solenoid.
UNIT INSPECTION
Drive Plate Deflection
S Inspect drive plate deflection if within standard
value.
Standard Value
within 0.2mm (0.008 in)
Action :
Standard value is not within the specified value, replace
drive plate.
When ”abnormal wear” or ”stick” on torque converter
sleeve or oil pump is found, replace torque converter and
A/T.
Notice :
S When assembling torque converter and drive plate.
Be sure to use correct bolt with correct length. The
bolt pushes up torque converter front cover, and it
damages lock–up clutch lining. As a result, it cause
major failure ”No move”.
S Do not tighten the bolts by using impact wrench.
Cooler Pipe Bending and Choke
S Inspect it whether there is abnormal pipe bending in
the cooler pipe, pipe deformation and small cross–
section area of pipe line.
Action : Replace failure parts.S Apply compressed air of 2kg/cm
2 from cooler pipe
inlet side, inspect whether there is not cooler pipe
choke by confirming air flow smooth.
Action : Remove foreign particles and clean inside of pipe
line.
Normal
Vehicle Speed Sensor
1. Remove the connector of vehicle speed sensor,
connect 12V power supply and voltmeter to the ter-
minal.(Do not mistake polarity)
2. Check voltage change from approx. 0V to 12V with
vehicle speed sensor driven gear rotated.
Notice : The voltage change should be 4 times for 1 revo-
lution of the vehicle speed sensor driven gear.
Action : If the result of inspection is bad, replace the ve-
hicle speed sensor.

AISIN AUTOMATIC TRANSAXLE 5A2 – 31
DAEWOO V–121 BL4
Input Speed Sensor
S Inspect resistance of each input speed senor be-
tween terminals.
Notice :
S Make sure to inspect resistance again at 20°C
(68°F) when resistance differ from standards ex-
cept 20°C (68°F).
S It might become infinity ohm when inspect resist-
ance at higher temperature.
Action : If the result of inspection is bad, replace ISS.
Transmission Range (TR) Switch
S Remove TR switch connector and inspect continuty
each range according to the conection chart.
Action : If the result of inspection is bad, replace the TR
switch.
Transmission Fluid Temperature Sensor
S Inspect the resistance between the terminals of
TFT sensor at 10°C (50°F) and 110°C (230°F).
Standard Value
10°C (50°F)11 0°C (230°F)
5.80~7.09 kΩ0.23~0.263 kΩ
Action : If the result of inspection is bad, replace the TFT
sensor.

5A2 – 36IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE DIAGNOSIS
DIAGNOSTIC TROUBLE CODE CHART
DTCDESCRIPTIONTYPEIlluminate
MILBlink
Hold
Lamp
P0562System Voltage LowBYe sNo
P0563System Voltage HighBYe sNo
P0601Internal Control Module Memory Checksum ErrorAYe sNo
P0604Internal Transmission Control Module (TCM) Random Access
Memory (RAM) ErrorBYe sNo
P0705Transmission Range (TR) Switch Circuit MalfunctionBYe sNo
P0712Transmission Fluid Temperature Sensor Circuit Low InputAYe sNo
P0713Transmission Fluid Temperature Sensor Circuit High InputAYe sNo
P0717Input Shaft Speed (ISS) Sensor Circuit No SignalAYe sNo
P0722Output Shaft Speed (OSS) sensor Circuit No SignalAYe sNo
P0727Engine Speed Input Circuit No SignalAYe sNo
P0741Torque Converter Clutch (TCC) Circuit Stuck OffBYe sNo
P0742Torque Converter Clutch (TCC) Circuit Stuck OnBYe sNo
P0743Torque Converter Clutch (TCC) ElectricalBYe sNo
P0748Pressure Control Solenoid (PCS) ElectricalAYe sNo
P0751Shift Solenoid 1 (SS1) Stuck OffBYe sNo
P0753Shift Solenoid 1 (SS1) ElectricalAYe sNo
P0756Shift Solenoid 2 (SS2) Stuck OffBYe sNo
P0758Shift Solenoid 2 (SS2) ElectricalAYe sNo
P0785Timing Solenoid (ST) ElectricalAYe sNo
P1781Engine Torque Signal ErrorAYe sNo
P1791Throttle Position Signal ErrorAYe sNo
P1792Engine Coolant Temperature (ECT) Signal ErrorDNoNo
U2105CAN ErrorAYe sNo
* Description of Type
S Type A : TCM will request the illumination of MIL and store DTC when TCM detects a failure on the first ignition
cycle.
S Type B : TCM will request the illumination of MIL and store DTC when TCM detects failures on two consecutive
ignition cycle.
S Type D : TCM will not request the illumination of MIL or hold lamp, but will store DTC when TCM detects a failure
on the first ignition cycle.

5A2 – 50IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0712
TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
CIRCUIT LOW INPUT
Conditions for Setting the DTC
S TCM detects that A/D value of Transmission Fluid
Temperature sensor (TFT) signal is less than 10 for
5 minutes continuously after 1 time of this detec-
tion. (A/D VALUE 10: 24mV)
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S TCM judges the temperature of the transmission
fluid is 200°C (392°F).
S No lockup control
S No 4th gear
S No self–learning control
S No timing solenoid control N–DConditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects the temperature of the transmission
fluid is between 0°C (32°) and 150°C (302°F) for
10 seconds continuously.
Cause of Failure
S Wiring harness or connector between Transmission
Fluid Temperature (TFT) sensor and TCM
S TFT sensor
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 51
DAEWOO V–121 BL4
DTC P0712 Transmission Fluid Temperature (TFT) Sensor Circuit
Low Input
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0712 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
31. Turn the ignition OFF.
2. Inspect the resistance between the vehicle har-
ness and Transmission Fluid Temperature
(TFT) sensor. Refer to ”Unit Inspection” in this
section.
3. Disconnect the TCM connector (X–1) and in-
spect the resistance between the terminal A11
and A12.
Is the measurement within the specified value?10°C (50°F):
5.80–7.09 kW
11 0°C (230°F):
0.231–0.263
kWGo to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of between the vehicle har-
ness and TFT sensor.
2. Disconnect the connector (X–3) of T/M wire
and inspect the resistance between TFT sen-
sor connector terminal 1 and 6.
Is the measurement within the specified value?10°C (50°F):
5.80–7.09 kW
11 0°C (230°F):
0.231–0.263
kWGo to Step 7Go to Step 8
