2004 DAEWOO LACETTI sensor

5A2 – 52IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
61. Replace the master TCM.
2. Perform the reproducing test under user condi-
tion after confirming no DTC.
Is DTC displayed?–Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section).Replace the
TCM.
71. Estimate the failure of the vehicle wiring har-
ness or between connectors.
2. Inspect continuity and short circuit for the ve-
hicle wiring harness and inspect the connection
condition between connectors (C–3). Refer to
”Wiring Harness and Connector Inspection” in
this section.
Is the condition OK?–Repair the tem-
porary connec-
tion failure of
connectorReplace the ve-
hicle harness
or adjustment
between con-
nectors
81. Estimate the failure of T/M wire or between
connectors of TFT sensor.
2. Inspect fluid temperature. Refer to ”Unit In-
spection” in this section.
Is the problem found?–Replace TFT
sensorGo to Step 9
91. Estimate the failure of T/M wire.
Inspect continuity and short circuit for the T/M wire
and inspect the connection condition between con-
nectors (C–3). Refer to ”Wiring Harness and Con-
nector Inspection” in this section.
Is the condition OK?–Repair the tem-
porary connec-
tion failure of
connectorReplace the
T/M wire or ad-
justment be-
tween connec-
tors

AISIN AUTOMATIC TRANSAXLE 5A2 – 53
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0713
TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
CIRCUIT HIGH INPUT
Conditions for Setting the DTC
S TCM detects that A/D value of Transmission Fluid
Temperature sensor (TFT) signal is less than 15
and the minimum A/D value is more than 943,
when it is past 15 minutes after ignition ON.(A/D
value 943 : 4.7 v)
S After 1 time of above detection.
S Gear selector position is except P and N.
S Engine revolution is 400 rpm or greater.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S TCM judges the temperature of the transmission
fluid is 200°C (392°F).
S No lockup control
S No 4th gear
S No self–learning controlS No timing solenoid control N–D
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects the temperature of the transmission
fluid is between 0°C (32°F) and 150°C (302°F) for
10 seconds continuously.
Cause of Failure
S Wiring harness or connector between Transmission
Fluid Temperature (TFT) sensor and TCM
S TFT sensor
S TCM

5A2 – 54IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0713 Transmission Fluid Temperature (TFT) Sensor Circuit
High Input
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0713 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
31. Turn the ignition OFF.
2. Inspect the resistance between the vehicle har-
ness and Transmission Fluid Temperature
(TFT) sensor. Refer to ”Unit Inspection” in this
section.
3. Disconnect the TCM connector (X–1) and in-
spect the resistance between the terminal A11
and A12.
Is the measurement within the specified value?10°C (50°F):
5.80–7.09 kW
11 0°C (230°F):
0.231–0.263
kWGo to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of between the vehicle har-
ness and TFT sensor.
2. Disconnect the connector (X–3) of T/M wire
and inspect the resistance between TFT sen-
sor connector terminal 1 and 6.
Is the measurement within the specified value?10°C (50°F):
5.80–7.09 kW
11 0°C (230°F):
0.231–0.263
kWGo to Step 7Go to Step 8

AISIN AUTOMATIC TRANSAXLE 5A2 – 55
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
61. Replace the master TCM.
2. Perform the reproducing test under user condi-
tion after confirming no DTC.
Is DTC displayed?–Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section).Replace the
TCM.
71. Estimate the failure of the vehicle wiring har-
ness or between connectors.
2. Inspect continuity and short circuit for the ve-
hicle wiring harness and inspect the connection
condition between connectors (C–3). Refer to
”Wiring Harness and Connector Inspection” in
this section.
Is the condition OK?–Repair the tem-
porary connec-
tion failure of
connectorReplace the ve-
hicle harness
or adjustment
between con-
nectors
81. Estimate the failure of T/M wire or between
connectors of TFT sensor.
2. Inspect fluid temperature. Refer to ”Unit In-
spection” in this section.
Is the problem found?–Replace TFT
sensorGo to Step 9
91. Estimate the failure of T/M wire.
Inspect continuity and short circuit for the T/M wire
and inspect the connection condition between con-
nectors (C–3). Refer to ”Wiring Harness and Con-
nector Inspection” in this section.
Is the condition OK?–Repair the tem-
porary connec-
tion failure of
connectorReplace the
T/M wire or ad-
justment be-
tween connec-
tors

5A2 – 56IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0717
INPUT SHAFT SPEED (ISS) SENSOR CIRCUIT NO
SIGNAL
Conditions for Setting the DTC
S This DTC detects no signal of Input Shaft Speed
(ISS) sensor circuit for a long period of time. ( Rev-
olution : 0 rpm
10000 rpm).
S TCM detects no pulse of ISS sensor while TCM
detects 4 pulses of Output Speed Sensor. This
detection 1000 times continuously.
S D,2,L range selected
S Engine revolution is 400 rpm or greater.
S DTCs P0751, P0753, P0756, P0758, and P0705
are not set.
S Output revolution is 775 rpm or greater.
S 25 seconds later after Neutral to Drive shift.
S 10 seconds later after changing the gear.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S No lockup control
S No engine torque reduction controlS No engagement pressure control
S No 4th gear
S No self–learning control
S No timing solenoid control N–D
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects 250 pulses of ISS while failure detec-
tion is not achieved.
Cause of Failure
S Wiring harness or connector between Input Shaft
Speed (ISS) sensor and TCM
S ISS sensor
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 57
DAEWOO V–121 BL4
DTC P0717 Input Shaft Speed (ISS) Sensor Circuit No Signal
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector” in
this section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0717 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector” in
this section.)
31. Turn the ignition OFF.
2. Inspect the resistance between the vehicle har-
ness and Input Shaft Speed (ISS) sensor. Re-
fer to”Unit Inspection” in this section.
3. Disconnect the TCM connector (X–1) and in-
spect the resistance between the terminal B6
and B16.
Is the measurement within the specified value?20°C (68°F):
560–680 WGo to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of T/M wire or between the
connectors of ISS sensor.
2. Disconnect the ISS sensor connector (X–5)
and inspect the resistance between terminals 1
and 2.
Is the measurement within the specified value?20°C (68°F):
560–680WGo to Step 7Replace the
ISS sensor

AISIN AUTOMATIC TRANSAXLE 5A2 – 59
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0722
OUPUT SHAFT SPEED (OSS) SENSOR CIRCUIT NO
SIGNAL
Conditions for Setting the DTC
S This DTC detects no signal of Output Shaft Speed
(OSS) sensor circuit for a long period of time. (
Revolution : 0 rpm
10000 rpm).
S TCM detects no pulse of Output Shaft Speed
(OSS) sensor while TCM detects 178 pulses of In-
put Shaft Speed sensor. This detection 500 times
continuously.
S D,2,L range selected
S Input speed is 5 km/h (3 mph) or greater.
S DTCs P0751, P0753, P0756, P0758, P0717 and
P0705 are not set.
S 25 seconds later after Neutral to Drive shift.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S No lockup control
S No engine torque reduction control
S No engagement pressure controlS No 4th gear
S No self–learning control
S No prevent reverse gear control
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects 250 pulses of Output Shaft Speed
(OSS) sensor while failure detection is not
achieved.
Cause of Failure
S Wiring harness or connector between Output Shaft
Speed (OSS) sensor and TCM
S OSS sensor
S TCM

5A2 – 60IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0722 Output Shaft Speed (OSS) sensor Circuit No Signal
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0722 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
31. Turn the ignition OFF.
2. Inspect the voltage between vehicle harness
and the Output Shaft Speed (OSS) sensor.
3. Disconnect the connector (X–1) of the vehicle
harness.
4. Connect the voltmeter to monitor the voltage
between terminal B25 and ground.
5. Turn ignition ON and lift up the vehicle.
6. Check the voltage change from approximately
0 v to 12 v when the wheel is turned slowly.
Does the measurement change within the specified
value?0–12 vGo to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of T/M wire or between the
connectors of OSS sensor.
2. Inspect the OSS sensor. Refer to ”Unit Inspec-
tion” in this section
Is the condition of OSS sensor OK?–Go to Step 7Replace the
OSS sensor
