These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury. Read these labels caref ully. If
a label comes of f or becomes hard to
read (except f or the U.S. dashboard
label which is removed by the
owner), contact your Acura dealer
f or a replacement.
U.S. modelsCanadian models U.S. models only
On models with side curtain airbags
Saf ety L abels
Driver and Passenger Saf ety54
HOOD DASHBOARD
RADIATOR CAP

U.S. modelsCanadian models On cars with side curtain airbags
U.S. models
Canadian models
U.S. models Canadian models
Saf ety L abels
Driver and Passenger Saf ety55
SUN VISOR
DOORJAMBS

56

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your Acura. All the essential controls
are within easy reach............................
Control Locations .58
...............................
Indicator Lights .59
.............................................
Gauges .65
...............................
Speedometer .65
.................................
Tachometer .65
.....................................
Odometer .65
Outside Temperature ...................................
Indicator .66
...................................
Trip Meter .66 ...................
Temperature Gauge . 66
..................................
Fuel Gauge .67
Maintenance Required ...................................
Indicator .67
Controls Near the Steering .......................................
Wheel .69
...................................
Headlights .70
Automatic Lighting Off .....................................
Feature .71
............
Daytime Running Lights . 72
....
Instrument Panel Brightness . 72
................................
Turn Signals .73
.....................
Windshield Wipers .73
..................
Windshield Washers . 75
..........................
Hazard Warning .75
.............
Rear Window Def ogger . 75
......
Steering Wheel Adjustment . 76
...............................
Keys and Locks .77
..............................................
Keys .77
....................
Immobilizer System . 79
............................
Ignition Switch .80
......................
Power Door Locks .81
...................
Remote Transmitter . 83
..............
Childproof Door Locks . 87
...........................................
Trunk .87
........
Emergency Trunk Opener . 88....................................
Glove Box .89
............................
Seat Adjustments .90
Driver’s Seat Full Power ............................
Adjustments .90
...........
Driver’s Lumbar Support . 91
Front Passenger’s Seat ............................
Adjustments .92
..........................
Head Restraints .93
.......................
Folding Rear Seat .94
......................
Rear Seat Armrest .95
....................................
Seat Heaters .96
..............................
Power Windows .97
.......................................
Moonroof .101
...........................................
Mirrors .102
..
Adjusting the Power Mirrors . 102
...............................
Parking Brake .104
.................
Console Compartment . 105
..........................................
Armrest .105
.........................
Beverage Holders .106
.........................
Center CD Pocket .107
.................................
Utility Pocket .107
........................................
Sun Visor .108
................................
Vanity Mirror .108
........................
Sunglasses Holder .109
............
Accessory Power Sockets . 109
...............................
Interior Lights .110
Instruments and Controls
Inst rument s and Cont rols57

Inst rument s and Cont rols
Control L ocations
58
MIRROR CONTROLS
DOOR LOCK SWITCH
POWER WINDOW
SWITCHESAUDIO SYSTEM
HEATING/COOLING
CONTROLS
TRUNK RELEASE HANDLE/
FUEL FILL DOOR RELEASE HAZARD WARNING
LIGHTS
HOOD RELEASE HANDLE DIGITAL CLOCK
(P.102)
(P.81)
(P.97)
(P.186) (P.115,
121)
(P.129,
148)
(P.
75)
(P.135,
153)
(P.87/ 184)

Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Indicator L ights
Inst rument s and Cont rols59
CRUISE CONTROL INDICATORHIGH BEAM INDICATOR
ANTI-LOCK BRAKE SYSTEM
INDICATOR
SECURITY SYSTEM INDICATOR IMMOBILIZER SYSTEM INDICATOR
CRUISE MAIN INDICATOR LOW OIL PRESSURE INDICATOR
DOOR AND TRUNK OPEN MONITOR
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATORLOW FUEL INDICATOR
VSA ACTIVATION
INDICATOR
SIDE AIRBAG CUTOFF INDICATOR
SUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR SEAT BELT
REMINDER
LIGHT
CHARGING SYSTEM
INDICATOR
MAINTENANCE REQUIRED
INDICATOR
MALFUNCTION INDICATOR LAMP PARKING BRAKE AND BRAKE
SYSTEM INDICATOR
LIGHTS ON INDICATOR
(P.62)
(P.64)
(P.64)
(P.63)(P.60) (P.61)
(P.61)
(P.60)
(P. 60)
(P.67)
(P.60)
(P.61)
(P.63)
(P.62)
(P.61)
(P.64)
(P.64)
(P.63)
(P.60)

The instrument panel has many
indicators to give you important
inf ormation about your car.
This indicator lights when you turn
the ignition switch ON (II). It is a
reminder to you and your passengers
to protect yourselves by f astening
the seat belts. A beeper also sounds
if you have not fastened your seat
belt.
If you do not f asten your seat belt,
the beeper will stop af ter a f ew
seconds but the light stays on until
you do. Both the light and the beeper
stay of f if you f asten your seat belt
bef ore turning on the ignition.The engine can be severely damaged
if this light f lashes or stays on when
the engine is running. For complete
inf ormation, see page .
If this light comes on when the
engine is running, the battery is not
being charged. For complete
inf ormation, see page .
See page .
This light has two f unctions:
This indicator comes on when you
turn the ignition switch ON (II). It
is a reminder to check the parking
brake. A beeper sounds if you try
to drive with the parking brake not
f ully released. Driving with the
parking brake not f ully released
can damage the brakes and tires.
If the indicator remains lit after
you have f ully released the
parking brake while the engine is
running, or if it comes on while
driving, it can indicate a problem
in the brake system. For complete
inf ormation, see page .
1.
2.
317
318
319
321
Indicator L ights
Inst rument s and Cont rols
Seat Belt Reminder L ightL ow Oil Pressure
Indicator
Charging System
Indicator
Malf unction Indicator
LampParking Brake and Brake
System Indicator
60
U.S. Canada

This indicator lights brief ly when
you turn the ignition switch to ON
(II). If it comes on at any other time,
it indicates a potential problem with
your f ront airbags. This light will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
automatic seat belt tensioners, or
side curtain airbags. For complete
inf ormation, see page .
This indicator lights brief ly when
you turn the ignition switch ON (II).
If it comes on at any other time, it
indicates that the passenger’s side
airbag has automatically shut off.
For complete inf ormation, see page. This light normally comes on f or a
f ew seconds when you turn the
ignition switch ON (II). If this light
comes on at any other time, there is
a problem in the ABS. If this happens,
take the car to your dealer to have it
checked. With the light on, your car
still has normal braking ability but no
anti-lock. For complete inf ormation,
see page .
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II).
If this light comes on and stays on at
any other time, or it does not come
on when you turn the ignition switch
ON (II), there is a problem with the
VSA system. Take the car to your
dealer to have it checked. Without
VSA, your car still has normal
driving ability, but will not have VSA
traction and stability enhancement.
See page f or more inf ormation
on the VSA system.
49
50 213
216
Indicator L ights
Inst rument s and Cont rols
Supplemental Restraint
System IndicatorAnti-lock Brake System (ABS)
Indicator
Side A irbag Cutof f
Indicator Vehicle Stability Assist
(VSA ) System Indicator
61
