2003 TOYOTA SIENNA Owners Manual

03 SIENNA_U (L/O 0207)
1252003 MY SIENNA (OM45410U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
Position 3 (“AUTO”)—Headlights and/or all
of the lights in position 1
They automatically turn on or off depend-
ing on the darkness of the surroundings.
Manually twist the knob to the position 2
to turn on the headlights if they are need-
ed immediately when entering a dark tun-
nel, parking structure, etc.The automatic light control sensor is on
the top of the driver’s side instrument
panel.
Do not place anything on the instrument
panel, and/or do not affix anything on the
windshield to block this sensor.
Headlights and turn signals
(with automatic light control
system)

03 SIENNA_U (L/O 0207)
1262003 MY SIENNA (OM45410U)
The lights automatically turn off when ei-
ther front doors or sliding doors are
opened with the ignition key in the “ACC”
or “LOCK” position. To turn them on
again, turn the key to the “ON” position
or actuate the headlight switch. If you are
going to park for over one week, make
sure the headlight switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the “OFF” position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.

03 SIENNA_U (L/O 0207)
1272003 MY SIENNA (OM45410U)
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
To adjust the brightness of the instru-
ment panel lights, turn the dial.
Emergency flashersInstrument panel light control

03 SIENNA_U (L/O 0207)
1282003 MY SIENNA (OM45410U)
To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
only when the headlights are on low
beam.Front (with moon roof)
Front (without moon roof)
Center
The personal lights operate separately
with each lens.
To turn on the light, push the lens on your
side. To turn the light off, push the lens
once again.
Front (without moon roof) and center—
The personal light switch has the following
positions:
“OFF”—Turns the light off.
“DOOR”—Turns the light on when either
front or sliding door is opened.
Front fog lightsPersonal lights

03 SIENNA_U (L/O 0207)
1292003 MY SIENNA (OM45410U)
ILLUMINATED ENTRY SYSTEM
Front (with moon roof)—
The light comes on when either front or
sliding doors are opened. After all the
doors are closed, the light remains on for
about 15 seconds and then goes out.
Front (without moon roof) and center—
With the switch in the “DOOR” position,
the light comes on when either front or
sliding door is opened. After all the doors
are closed, the light remains on for about
15 seconds and then goes out.
However, in the following cases, the light
goes out immediately:
All the doors are closed when the igni-
tion key is in “ACC” or “ON” position.
All the doors are locked when the light
is still on.
One door will be closed with the lock
knob pushed forward (front door) or
downward (sliding door) while the other
doors are locked.
When the driver’s door is unlocked with a
key, the light comes on for 15 seconds,
even if the doors are not opened. PERSONAL LIGHTS CUT OFF
OPERATION
When the ignition switch is “OFF” and any
personal lights in the vehicle stay lighting
on, the lights will cut off automatically
after 30 minutes.
You can cancel the cut off operation by:
Turning the key to the “ACC” position.
Opening or closing any of the doors.
Turning off all the “ON” lights.
All the lights are turned off when all the
doors are locked by the key or wireless
remote control transmitter.
The key must be in the “OFF” position.
Front
Center and rear
Interior light

03 SIENNA_U (L/O 0207)
1302003 MY SIENNA (OM45410U)
Front—
To turn on the front interior light, push
the switch.
The front interior light switch has the fol-
lowing positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
Vehicles without power door lock system—
“DOOR”—Turns the light on when either
front door is opened.
Vehicles with power door lock system—
“DOOR”—Turns the light on when either
front or sliding door is opened.
Center and rear—
To turn on the center or rear interior
light, slide the switch.
The center interior light switch has the
following positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when either
front or sliding door is opened.ILLUMINATED ENTRY SYSTEM
(with power door lock system)
Front and center—
With the switch in the “DOOR” position,
the light comes on when either front or
sliding doors are opened. After all the
doors are closed, the light remains on for
about 15 seconds and then goes out.
However, in the following cases, the light
goes out immediately:
All the doors are closed when the igni-
tion key is in “ACC” or “ON” position.
All the doors are locked when the light
is still on.
One door will be closed with the lock
knob pushed forward (front door) or
downward (sliding door) while the other
doors are locked.
When the driver’s door is unlocked with a
key, the light comes on for 15 seconds,
even if the doors are not opened. INTERIOR LIGHTS CUT OFF OPERATION
When the ignition switch is “OFF” and any
interior lights in the vehicle stay lighting
on, the lights will cut off automatically
after 30 minutes.
You can cancel the cut off operation by:
Turning the key to the “ACC” position.
Opening or closing any of the doors.
Turning off all the “ON” lights.
All the lights are turned off when all the
doors are locked by the key or wireless
remote control transmitter.
The key must be in the “OFF” position.

03 SIENNA_U (L/O 0207)
1312003 MY SIENNA (OM45410U)
For easy access to the ignition switch,
the ignition switch light comes on when
any of the doors are opened.
The light remains on for 15 seconds when
all the doors are closed.
Vehicles with power door lock system—
However, in the following cases, the light
goes out immediately:
All the doors are closed when the igni-
tion key is in “ACC” or “ON” position.
All the doors are locked when the light
is still on.
One door will be closed with the lock
knob pushed forward (front door) or
downward (sliding door) while the other
doors are locked.When the driver’s door is unlocked with a
key, the light comes on for 15 seconds,
even if the doors are not opened.
IGNITION SWITCH LIGHT CUT OFF
OPERATION
When the ignition switch is “OFF” and
ignition switch light in the vehicle stays
lighting on, the light will cut off automati-
cally after 30 minutes.
You can cancel the cut off operation by:
Turning the key to the “ACC” position.
Opening or closing any of the doors.
Turning off all the “ON” lights.
The light is turned off when all the doors
are locked by the key or wireless remote
control transmitter.
The key must be in the “OFF” position.To turn the luggage compartment light
on, open the back door and push the
switch downwards. To turn it off, push
the switch upwards or close the back
door.
Ignition switch light Luggage compartment light

03 SIENNA_U (L/O 0207)
1322003 MY SIENNA (OM45410U)
LUGGAGE COMPARTMENT LIGHT CUT
OFF OPERATION
When the ignition switch is “OFF” and
luggage compartment light in the vehicle
stays lighting on, the light will cut off au-
tomatically after 30 minutes.
You can cancel the cut off operation by:
Turning the key to the “ACC” position.
Opening or closing any of the doors.
Turning off all the “ON” lights.
The light is turned off when all the doors
are locked by the key or wireless remote
control transmitter.
The key must be in the “OFF” position.
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
With interval adjuster: The “INT TIME”
band lets you adjust the wiping time inter-
val when the wiper lever is in the intermit-
tent position (position 1). Twist the band
upward to increase the time between
sweeps, and downward to decrease it. To squirt washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 73.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Windshield wipers and washer
