2003 SUBARU FORESTER Owners Manual

7-32
Starting and operating
3. Push the control lever downward in the “SET,
COAST” direction and release it. Then release the ac-
celerator pedal.
The vehicle will maintain the desired speed.
Vehicle speed can be temporarily increased while
driving with the cruise control activated. Simply de-
press the accelerator pedal to accelerate the vehicle.
When the accelerator pedal is released, the vehicle
will return to and maintain the previous cruising speed.
To temporarily cancel the cruise con- trol
There are four ways to cancel the cruise control tem- porarily:
Depress the brake pedal.
Pull the control lever in the “CANCEL” direction. (if
so equipped) Depress the clutch pedal (manual transmission ve-
hicles only). Shift the selector lever into the “N” position (auto-
matic transmission vehicles only).
To resume the cruise control after it has been tempo-
rarily canceled and with vehicle speed of about 20
mph (32 km/h) or more, push the control lever upward
in the “ACCEL, RESUME” direction to return to the
original cruising speed automatically. To turn off the cruise control
Therearetwowaystoturnoffthecruisecontrol: Pushthemainswitchagain.
Turn the ignition switch to the “ACC” or “LOCK” po-
sition (but only when the vehicle is completely
stopped). To change the cruising speed
To increase the speed (by control lever)
Push the control lever upward in the “ACCEL, RE-
SUME” direction and hold it until the vehicle reaches
A CC
RE S
CANC EL
S ET
C OAS
T
HS7018BA

7-33
Starting and operating
–CONTINUED –
the desired speed. Then, release the control lever.
The vehicle speed at that moment will be memorized
and treated as the new set speed.
When the difference between the actual vehicle speed
and the set speed is less than 4 mph (6.8 km/h), the
set speed can be increased 1 mph (1.6 km/h) each
time by pressing the control lever upward in the “AC-
CEL, RESUME” direction quickly within 0.5 second. To increase the speed (by accelerator pedal)
1. Depress the accelerator pedal to accelerate the ve-
hicle to the desired speed.
2. Push the control lever downward in the “SET,
COAST” direction once. Now the desired speed is set
and the vehicle will keep running at that speed without
depressing the accelerator pedal.
NOTE
If the difference between the actual vehicle speed
when the control lever is pushed downward and
the speed last time you set is less than 4 mph (6.8
km/h), the vehicle speed will be lowered by 1 mph
(1.6 km/h). This occurs because the cruise control
system unit regards this lever operation as that in-
tended to decrease the vehicle speed.
To decrease the speed (by control lever)
Push the control lever downward in the “SET, COAST”
direction and hold it until the vehicle reaches the de-
sired speed. Then, release the control lever. The vehi-
cle speed at that moment will be memorized and
treated as the new set speed.
When the difference between the actual vehicle speed
and the set speed is less than 4 mph (6.8 km/h), the
set speed can be lowered 1 mph (1.6 km/h) each time
by pressing the control lever downward in the “SET,
COAST” direction quickly within 0.5 second. To decrease the speed (by brake pedal)
1. Depress the brake pedal to release cruise control
temporarily.
2. When the speed decreases to the desired speed,
press the control lever downward in the “SET,
COAST” direction once. Now the desired speed is set
and the vehicle will keep running at that speed without
depressing the accerelator pedal.

7-34
Starting and operating
Self-leveling rear suspension (if
equipped)
The self-leveling suspension adjusts the vehicle body
position automatically to keep it level at all times irre-
spective of the number of occupants and the amount
of cargo.
The self-leveling system is incorporated in the rear
suspension shock absorber and operates only when
the vehicle is in motion.
Owing to the self-leveling suspension, the vehicle
body is adjusted to the proper position after several
drive trips, even if the rear of the vehicle is lowered by
loaded cargos or a coupled trailer.
If cargos are unloaded all at once, the vehicle height
may become higher than the normal level. This is be-
cause that the hydraulic pressure in the self-leveling
suspension was increased for leveling the body when
the cargos were loaded. In such a case, the vehicle
height will return to the origi
nal level after several driv-
ing trips.
NOTE
If the rear axle is loaded excessively, the vehicle
HS7019BA
HS7020BA

7-35
Starting and operating
–CONTINUED –
body may not be adjusted to the proper position.

8-1
8
Driving tips
New vehicle break-in driving – the first
1,000 miles (1,600 km) ................................. 8-2
Fuel economy hints ..................................... 8-2
Engine exhaust gas (Carbon monoxide) .. 8-3
Catalytic converter ...................................... 8-4
Periodic inspections ................................... 8-5
Driving in foreign countries ........................ 8-5
Driving tips for AWD vehicles .................... 8-6
Off road driving ........................................... 8-7
Winter driving .............................................. 8-9 Operation during cold weather ...................... 8-9
Driving on snowy and icy roads .................... 8-11
Corrosion protection ...................................... 8-12
Snow tires ........................................................ 8-12
Tire chains ....................................................... 8-13
Rocking the vehicle ........................................ 8-13
Loading your vehicle .................................. 8-14 Vehicle capacity weight .................................. 8-15
GVWR and GAWR (Gross Vehicle Weight
Rating and Gross Axle Weight Rating) ......... 8-16
Roof rail and crossbar (if equipped) ............. 8-17
Trailer hitch (if equipped) ........................... 8-22 Connecting a trailer ........................................ 8-22
When you do not tow a trailer ........................ 8-24
Trailer towing ............................................... 8-25 Warranties and maintenance ......................... 8-25
Maximum load limits ....................................... 8-25
Trailer hitches ................................................. 8-30
Connecting a trailer ........................................ 8-31 Trailer towing tips ........................................... 8-32

8-2
Driving tips
Driving tips
New vehicle break-in driving – the
first 1,000 miles (1,600 km)
The performance and long life of your vehicle are de-
pendent on how you handle and care for your vehicle
while it is new. Follow these instructions during the
first 1,000 miles (1,600 km):
Do not race the engine. And do not allow engine
speed to exceed 4,000 rpm except in an emergency. Do not drive at one constant engine or vehicle
speed for a long time, either fast or slow. Avoid starting suddenly and rapid acceleration, ex-
cept in an emergency. Avoid hard braking, except in an emergency.
The same break-in procedures should be applied to
an overhauled engine, newly mounted engine or when
brake pads or brake linings are replaced with new
ones.
Fuel economy hints
The following suggestions will help to save your fuel. Select the proper gear position for the speed and
road conditions. Avoid sudden acceleration or deceleration. Always
accelerate gently until you reach the desired speed.
Then try to maintain that speed for as long as possible. Do not pump the accelerator and avoid racing the
engine. Avoid unnecessary engine idling.
Keep the engine properly tuned.
Keep the tires inflated to the correct pressure shown
on the tire placard, which is located under the door
latch on the driver’s side. Low pressure will increase
tire wear and fuel consumption. Use the air conditioner only when necessary.
Keep the front and rear wheels in proper alignment.
Avoid carrying unnecessary cargo.

8-3
Driving tips
– CONTINUED –
Engine exhaust gas (Carbon monox-
ide)
Never inhale engine exhaust gas. Engine ex-
haust gas contains carbon monoxide, a color-
less and odorless gas which is dangerous, or
even lethal, if inhaled. Always properly maintain the engine exhaust
system to prevent engine exhaust gas from en-
tering the vehicle. Never run the engine in a closed space, such
as a garage, except for the brief time needed to
drive the vehicle in or out of it. Avoid remaining in a parked vehicle for a
lengthy time while the engine is running. If that
is unavoidable, then use the ventilation fan to
force fresh air into the vehicle. Always keep the front ventilator inlet grille
free from snow, leaves or other obstructions to
ensure that the ventilation system always
works properly. If at any time you suspect that exhaust fumes
are entering the vehicle, have the problem
checked and corrected as soon as possible. If
you must drive under these conditions, drive only with all windows fully open.
Keep the rear gate closed while driving to
prevent exhaust gas from entering the vehicle.
NOTE
Due to the expansion and contraction of the met-
als used in the manufacture of the exhaust sys-
tem, you may hear a crackling sound coming from
the exhaust system for a short time after the en-
gine has been shut off. This sound is normal.
