POWER WINDOW SYSTEM
GW-17
C
D
E
F
G
H
J
K
L
MA
B
GW

POWER WINDOW SYSTEMPFP:25401
Component Parts and Harness Connector LocationBIS000Z7
System DescriptionBIS000Z8
Power is supplied at all times

through 50A fusible link (letter M , located in the fuse and fusible link box), and

to BCM terminal 55.

through BCM terminal 54

to power window main switch terminal 19.

through 15A fuse [No. 17, located in the fuse block (J/B)].

to BCM terminal 42.
Ground is supplied at all times

to BCM terminal 52
PIIB0632E

GW-30
POWER WINDOW SYSTEM

Check BCM Power Supply and Ground Circuit BIS000ZF
1. CHECK FUSE

10A fuse [No.1, located in fuse block (J/B)]

15A fuse [No.17, located in fuse block (J/B)]

50A fusible link (letter M , located in the fuse and fusible link box)
NOTE:
Refer to GW-17, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse.
Refer toPG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between BCM connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Check BCM power supply circuit for open or short.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector M4 terminal 52 and
ground.
OK or NG
OK >> BCM power supply and ground circuit are OK.
NG >> Check BCM ground circuit for open.
Check Power Window Main Switch Power Supply and Ground Circuit BIS000ZG
1. CHECK POWER SUPPLY CIRCUIT
Check voltage between power window main switch connector and
ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
ConnectorTerminal (Wire color)
Condition of ignition
switchVoltage [V]
(Approx.)
(+) (-)
M338 (R)
GroundON
Battery voltage 42 (LG)
OFF
M4 55 (W/B)
PIIB1097E
52 (B) – Ground : Continuity should exist.
PIIB1099E
ConnectorTerminal (Wire color)
Condition of ignition
switchVoltage [V]
(Approx.)
(+) (-)
D6 10 (L/W)
GroundON
Battery voltage
D7 19 (R/Y) OFF
PIIB1144E

GW-54
REAR WINDOW DEFOGGER

REAR WINDOW DEFOGGERPFP:25350
Component Parts and Harness Connector LocationBIS000ZU
System DescriptionBIS000ZV
The rear window defogger is controlled by BCM and IPDM E/R.
The rear window defogger operates only for approximately 15 minutes.
Power is supplied at all times

through 20A fuse (No. 75, located in the IPDM E/R)

to rear window defogger relay terminal 3.

through 10A fuse (No. 32, located in the fuse and fusible link box)

to rear window defogger relay terminal 6.

through 50A fusible link (letter M , located in the fuse and fusible link box)

to BCM terminal 55.
PIIB2185E

GW-64
REAR WINDOW DEFOGGER

Check BCM Power Supply and Ground Circuit BIS00107
First perform the “SELF-DIAG RESULTS” in “BCM” with CONSULT-II, when perform the each trouble
diagnosis. Refer to BCS-14, "
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)" .
1. CHECK FUSE

10A fuse [No.1, located in fuse block (J/B)]

15A fuse [No.17, located in fuse block (J/B)]

50A fusible link (letter M, located in the fuse and fusible link box).
NOTE:
Refer to GW-54, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
Check voltage between BCM connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Check BCM power supply circuit for open or short.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector M4 terminal 52 and
ground.
OK or NG
OK >> Power supply and ground circuit are OK.
NG >> Check BCM ground circuit for open.
ConnectorTerminal
Condition of ignition
switchVoltage [V]
(Approx.)
(+) (-)
M338 (R)
GroundON
Battery voltage 42 (LG)
OFF
M4 55 (W/B)
PIIB1097E
52 (B) – Ground : Continuity should exist.
PIIB1099E

IDX-4
