2003 Lancia Ypsilon Owner handbook (in English)

126
G
Car maintenance should
be entrusted to a LANCIA
Dealership. For interven-
tions of routine maintenance and
small repairs you wish to carry out
yourself, make sure you always
have the proper equipment, gen-
uine LANCIA spare parts and the
necessary liquids; do not carry out
servicing operations if you have no
experience.
Pay attention when top-
ping up not to confuse the
different types of fluid:
they are all incompatible with
each other and could seriously
damage the car.
If the car is frequently
used with a trailer, main-
tenance should be carried
out more frequently.
The jack supplied with
the car is only to be used
when changing a wheel.
For other operations that require
the car to be lifted, special meth-
ods are to be used. It is therefore
recommended to have them per-
formed by a LANCIA Dealership.
Scarves, ties and loose
garments can get caught in
moving parts.
Never smoke while work-
ing on the engine compart-
ment: gas or inflammable
vapours could be present, causing
a risk of fire.
4C120-143 ING 11-03-2008 12:01 Pagina 126

127
G
CHECKING
FLUID LEVELS
fig. 1 - 1.2 versions
P4C00385
1.Engine oil - 2.Battery - 3.Brake
fluid - 4.Windscreen washer liquid -
5.Engine coolant - 6.Power-assisted
steering fluid.
1.Engine oil - 2.Battery - 3.Brake
fluid - 4.Windscreen washer liquid -
5.Engine coolant - 6.Power-assisted
steering fluid.
fig. 2 - 1.2 16Vversions
P4C00386
4C120-143 ING 11-03-2008 12:01 Pagina 127

128
G
ENGINE OIL (fig.s 1, 2)
Check the oil level a few minutes
(approx. 5) after the engine has
stopped with the car parked on level
ground.
The oil level must be between the
MINandMAXmarks on the dipstick.
The space between MINandMAX
corresponds to approximately one
litre of oil.If the oil level is near or even below
theMINmark, pour in oil through
the filler hole until it reaches the MAX
mark.
The oil level must never exceed the
MAXmark.
IMPORTANTIf following a regular
check the oil level is over the MAX
line, go to a LANCIA Dealershipto
have the correct level restored.
IMPORTANTAfter adding or
changing the oil, let the engine turn
over for a few seconds and wait a few
minutes after turning it off before you
check the level.ENGINE OIL CONSUMPTION
During the beginning of the car’s life
the engine is be tuned in. Engine oil
consumption can only be considered
stabilised after the first 5,000 - 6,000
km.
IMPORTANTOil consumption de-
pends on the driving style and the
conditions of use.
When the engine is hot,
operate very carefully in-
side the engine compart-
ment: danger of burns. Remember
that, when the engine is hot, the
electric fan could start operating:
danger of injuries.
Do not add oil with dif-
ferent specifications from
the oil already in the en-
gine.
Used engine oil and re-
placed oil filters contain
substances that can harm
the environment. We recommend
you have the car seen to at a LAN-
CIA Dealership for the oil and fil-
ter change. It is suitably equipped
for disposing of used oil and filters
in an environmentally-friendly
way that complies with the law.
4C120-143 ING 11-03-2008 12:01 Pagina 128

129
G
ENGINE COOLANT SYSTEM
(fig.s 1, 2)
IMPORTANTThe cooling system is
pressurised. If the plug must be re-
placed, replace it only with a genuine
spare part or system efficiency may be
impaired.
The coolant level must be checked
while the engine is cold and must be
between the MINandMAXmarks on
the reservoir.Do not take the cap of the
reservoir off when the en-
gine is very hot as you run
the risk of scalding yourself.
If there is not enough coolant, pour
a 50% mixture of distilled water and
FL Group PARAFLU
11liquid slowly
through the filler hole 5in the reser-
voir, until the level is near the MAX
mark.
A 50-50 mixture of PARAFLU
11
and distilled water gives freeze pro-
tection to –35 °C.WINDSCREEN/REAR WINDOW
WASHER LIQUID (fig.s 1, 2)
To add liquid, remove cap 4then
pour in the liquid until the reservoir
is completely full.
Use a mixture of water and DP1liq-
uid in these percentages:
30%DP1and 70% water in sum-
mer.
50%DP1and 50% water in winter.
If the temperature falls below –20°C,
useDP1undiluted.
IMPORTANTDo not travel with
the windscreen washer bottle empty:
using the windscreen washer is fun-
damental for improving visibility.
Some commercial addi-
tives for windscreen
washer fluids are flamma-
ble. The engine compartment con-
tains hot parts which could ignite
the fluid if it comes into contact
with them.
4C120-143 ING 11-03-2008 12:01 Pagina 129

130
G
POWER-ASSISTED STEERING
FLUID (fig.s 1, 2)
Check the fluid level is not below the
MINmark visible on the reservoir
with the engine cold.
If necessary, add fluid making sure
that it has the same specifications as
the fluid in the reservoir.BRAKE FLUID (fig.s 1, 2)
Check that the fluid level in the
reservoir is at maximum level.
Periodically check that the warning
light on the instrument panel is work-
ing properly by pressing on the reser-
voir cover with the key at MAR.
Warning light
xshould come on.
If you need to add fluid, only use the
type classified DOT4. You are advised
in particular to use TUTELA TOP 4
with which the braking system was
originally filled.
Symbolπon the con-
tainer indicates synthetic
type brake fluid distin-
guishing it from the mineral kind.
Using mineral type fluids damages
the special rubber braking system
gaskets beyond repair.
Make sure the power-as-
sisted steering fluid does
not come into contact with
hot parts of the engine as it catches
fire very easily.
Do not push on the power
steering limit switch for
more than 15 seconds with
the engine running. This causes
noise and could damage the sys-
tem.Oil consumption is ex-
tremely low. If further top-
ping up is required soon
after the initial top-up, have the
system checked over at a LANCIA
Dealership for leaks.
4C120-143 ING 11-03-2008 12:01 Pagina 130

131
G
Make sure the highly cor-
rosive brake fluid does not
drip onto the paintwork. If
it does, wash it off immediately
with water.
IMPORTANTBrake fluid is hygro-
scopic (meaning it absorbs humidity).
This is why the fluid should be
changed more frequently than shown
in the Service Schedule if the car is
mainly driven in areas with a high
percentage of humidity in the air.AIR CLEANER
REPLACEMENT
1.2 versions
Loosen the screws on the edge and
on the air cleaner cover A (fig. 3)and
remove the filtering element Bto be
replaced.1.2
16Vversions
Unscrew the three screws A (fig. 4),
remove cover Band remove the filter
elementCto be replaced.
The brake fluid is poiso-
nous and corrosive. If it
accidentally comes into
contact with the skin, wash with
neutral soap and water, then rinse
copiously. If swallowed, contact a
doctor immediately.
If you often drive on
dusty roads, the filter will
require changing more fre-
quently than indicated in the Ser-
vice Schedule.
Any cleaning operations
on the filter could damage
it, causing serious damage
to the engine.
fig. 3
P4C00421
fig. 4
P4C00413
4C120-143 ING 11-03-2008 12:01 Pagina 131

BATTERY
The Lancia Y’s battery is of the
“Limited Maintenance” type: under
normal conditions, it requires no top-
ping up with distilled water.
REPLACING THE BATTERY
If required, replace the battery with
a genuine spare part presenting the
same specifications. If a battery with
different specifications is fitted, the
frequencies shown in the Service
Schedule will no longer be valid. Re-
fer to the instructions provided by the
battery manufacturer.
132
G
POLLEN FILTER
Lift cover A (fig. 5), pull out the fil-
ter element Band replace it.
IMPORTANTFailure to replace the
filter can reduce the climate control
system’s efficiency considerably.
If the car is often used in dusty or
highly polluted areas, you should
change the pollen filtering element
more frequently, especially if you no-
tice that the amount of air entering
the passenger compartment is re-
duced.The pollen filter is only a stan-
dard fitting on cars equipped with
climate control system.
For cars without climate control,
provision has been made for fitting
the filter, which is available from
Lineaccessori LANCIA.
fig. 5
P4C00155
Batteries contain sub-
stances that are very
harmful for the environ-
ment. You are advised to have the
battery changed at a LANCIA
Dealership. It is properly equip-
ped for disposing of used batteries
in an environmentally-friendly
way that complies with the law.
4C120-143 ING 11-03-2008 12:01 Pagina 132

133
G
USEFUL ADVICE
FOR LENGTHENING
THE LIFE OF YOUR BATTERY
When you park the car, ensure the
doors, boot and bonnet are closed
properly. The ceiling and map-read-
ing lights must be off.
Do not leave accessories (e.g. radio,
hazard lights, etc.) switched on for a
long time when the engine is not run-
ning.
IMPORTANTIf the battery is left
with a charge of less than 50% for a
long time it will be damaged by sul-
phation, engine startup will deterio-
rate and it will be more subject to
freezing (this may occur at –10°C).
If the car is to be inactive for a long
period of time, refer to the “Storing
the car” paragraph in the “Driving
your car” section.
The liquid in the battery
is poisonous and corrosive.
Do not let it touch the skin
or eyes. Do not bring naked flames
or possible sources of sparks near
to the battery: fire and explosion
risk.
Incorrect fitting of elec-
trical and electronic ac-
cessories can seriously
damage the car.
IMPORTANTWhen removing/in-
stalling the battery, make sure the
battery is mechanically secured cor-
rectly.
Running the car with the
fluid level too low could
damage the battery beyond
repair, even breaking the casing
and allowing the acid contained in
it to leak out completely.
Always wear goggles to
protect the eyes when
working on or near the
battery.
If the car is to remain un-
used for a long period in
very cold weather, remove
the battery and keep it in a warm
place, otherwise it could freeze.
CHECKING THE BATTERY
FLUID LEVEL (electrolyte)
Check the electrolyte level and top
up, if required, at the frequency
shown in the Service Schedule in this
chapter. Have this operation carried
out at a LANCIA Dealership.
