SPLICE
NUMBERLOCATION FIG.
S126 Center Rear of Engine Compartment N/S
S128 Right Rear of Engine 3, 22
S129 Top Front of Transmission 3, 23
S130 Top Front of Transmission 3, 8, 9, 12, 14, 16, 17,
21, 22, 24
S131 Left Rear of Engine Compartment 22
S132 Left Rear of Engine Compartment 21, 22, 24
S133 Left Rear of Engine 11, 22
S134 Left Rear of Engine Compartment 15
S135 Headlamp and Dash, Left Side 26
S136 Left Front Fender 21, 29
S137 Left Rear of Engine Compartment 21
S138 Left Rear of Engine 3, 11
S139 Right Front of Transmission 14, 16, 17, 24
S141 Right Rear of Engine 3
S142 Left Side of Engine 22
S143 Left Side of Engine Compartment 21
S144 Top Front of Transmission 3, 14, 16, 17, 23, 24
S145 Left Front Fender 26
S146 Left Front Fender 26
S147 Right Rear of Engine 7
S148 Top Front of Transmission 3, 14, 16, 17, 22, 23,
24
S149 Left Rear of Engine 3, 4, 14
S150 Top Center of Engine 3, 5, 8
S153 Rear Engine Compartment 22
S154 Left Top Engine 5, 22
S155 Left Rear Engine Compartment near T/O for Fuel Control Actuator N/S
S156 Left Rear Engine Compartment 23
S157 Near T/O for Camshaft Position Sensor N/S
S158 Near T/O for C114 10
S159 Near T/O for Engine Control Module N/S
S160 Top Left Engine 10
S170 Left Engine 10
S171 Top Left Engine 10
S172 In T/O for Fuel Control Actuator N/S
S173 Near T/O for Engine Control Module N/S
S174 Near T/O for C114 N/S
S175 Near T/O for Engine Control Module N/S
S176 Left Side Engine Near T/O for Fuel Control Actuator N/S
S181 Top of Transmission 12
S182 Top of Transmission 12
8W - 91 - 10 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
SPLICE
NUMBERLOCATION FIG.
S183 Top of Transmission 12
S184 Top of Transmission 12
S191 Near Integrated Power Module 29
S197 Left Rear Engine Compartment 23
S201 Left Side of Instrument Panel 37
S204 Left Side of Instrument Panel 37
S205 Left Side of Instrument Panel 39
S206 At Steering Column N/S
S207 At Steering Column N/S
S208 Center of Instrument Panel 37, 38
S209 Center of Instrument Panel 37
S210 Center of Instrument Panel 39
S212 Left Side of Instrument Panel 33, 39
S213 Center of Instrument Panel in T/O for Instrument Cluster
ConnectorsN/S
S214 Left Side of Instrument Panel 33, 39
S216 Center of Instrument Panel 37
S217 Left Side of Instrument Panel 37, 40
S218 Left Side of Instrument Panel 39
S219 Center of Instrument Panel N/S
S220 Center of Instrument Panel N/S
S221 Center of Instrument Panel 37, 38
S222 Center of Instrument Panel 37
S224 Right Side of HVAC N/S
S225 Center of Instrument Panel 37
S226 Right Side of HVAC N/S
S230 Right Instrument Panel 37
S231 Left Instrument Panel 39
S301 Center of Headliner N/S
S302 Center of Headliner N/S
S304 Center of Headliner N/S
S305 Center of Body 44, 45
S306 Left Side of Frame N/S
S307 Center of Headliner N/S
S308 Left Rear Chassis 48, 49
S309 Center Rear of Chassis 49
S310 Center of Body 44, 45
S311 Left Front of Body 41, 44, 45
S312 Right Door N/S
S313 Left Front Door 42
S314 Left Rear Frame Rail N/S
S315 Left Front Body 41, 44, 45
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 11
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
