Page 1153 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual PASSENGER POWER SEAT RECLINER MOTOR (MIDLINE/PREMIUM) - BLACK 2 WAY CAV CIRCUIT FUNCTION A P42 16BR/WT PASSENGER SEAT RECLINER DOWN DRIVER B P44 16GY/LB PASSENGER SEAT RECLINER UP DRIVER PASSENGER POW

Page 1154 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual PASSENGER SIDE IMPACT SENSOR - BLACK 4 WAY CAV CIRCUIT FUNCTION 1- - 2- - 3 R134 20LB/BR PASSENGER SIDE IMPACT SENSOR GROUND 4 R132 20LG/VT PASSENGER SIDE IMPACT SENSOR SIGNAL POWER AMPLIFIER C1 (PREM

Page 1155 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual POWER CONNECTOR - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 F85 16VT/WT FUSED B(+) 2 Z234 16BK GROUND POWERTRAIN CONTROL MODULE C1 (GAS) - BLACK 32 WAY CAV CIRCUIT FUNCTION 1 K93 14TN/OR COIL DRIVER NO. 3 2

Page 1156 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual POWERTRAIN CONTROL MODULE C2 (GAS) - WHITE 32 WAY CAV CIRCUIT FUNCTION 1 T54 18VT (4.0L) TRANSMISSION TEMPERATURE SENSOR SIGNAL 2 K26 18VT (4.7L) FUEL INJECTOR NO. 7 DRIVER 3- - 4 K11 18WT/DB FUEL INJ

Page 1157 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual POWERTRAIN CONTROL MODULE C3 (GAS) - GRAY 32 WAY CAV CIRCUIT FUNCTION 1 C13 18DB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL 2- - 3 K51 18DB/YL AUTO SHUT DOWN RELAY CONTROL 4 V36 18TN/RD SPEED CONTROL VACU

Page 1158 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual RADIATOR FAN RELAY - BLACK 4 WAY CAV CIRCUIT FUNCTION 1 Z1 20BK GROUND 2 C24 20DB/PK RADIATOR FAN RELAY CONTROL 3 C23 12DG RADIATOR FAN RELAY OUTPUT 4 A16 12GY FUSED B(+) RADIO C1 - GRAY 22 WAY CAV CI

Page 1159 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual RAIN SENSOR (AUTOWIPE) - BLACK 6 WAY CAV CIRCUIT FUNCTION 1- - 2 D25 20BK/PK PCI BUS 3- - 4 Z155 20BK/OR GROUND 5 Q30 20BK/LB ACCESSORY DELAY RELAY OUTPUT 6- - REAR POWER OUTLET - BLACK 3 WAY CAV CIRC

Page 1160 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual RED BRAKE WARNING INDICATOR SWITCH - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 Z231 18BK GROUND 2 G9 18GY/BK RED BRAKE WARNING INDICATOR DRIVER REMOTE KEYLESS MODULE (JAPAN) - BLUE 6 WAY CAV CIRCUIT FUNCTION
